Antenna Amplifier Inspection

  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000) .)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000) .)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000) .) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000) .)
  6. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000) .)
  7. Switch the ignition to ON.
  8. Turn the audio unit power to ON.
  9. Tune in the radio.
  10. Verify that voltage is B+ at the antenna amplifier terminal B. If the battery voltage cannot be verified, replace the center roof antenna. If the battery voltage can be verified, go to the feeder line inspection.

Scheme 3

Scheme 3: Feeder Line Inspection
Scheme 3: Feeder Line Inspection

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Remove the center roof antenna. (See «CENTER ROOF ANTENNA REMOVAL/INSTALLATION»(ref-520392-S23499665282013010300000).)
  2. Verify that there is no continuity between the center roof antenna terminals A and C using an ohmmeter. (Scheme 3): Identifying Center Roof Antenna Connector Terminals A And C (AM/FM Type) (Scheme 4): Identifying Center Roof Antenna Connector Terminals A And C (AM/FM/SIRIUS Type)
  3. Inspect for continuity between the center roof antenna terminals using an ohmmeter. If not as indicated in the table, replace the center roof antenna. (Scheme 5): Center Roof Antenna Terminals Continuity Chart (AM/FM Type) (Scheme 6): Center Roof Antenna Terminals Continuity Chart (AM/FM/SIRIUS Type)

Scheme 7

Scheme 7: GLASS ANTENNA INSPECTION
Scheme 7: GLASS ANTENNA INSPECTION

Scheme 8

Scheme 8
Scheme 8
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the antenna amplifier connector B. (See «ANTENNA AMPLIFIER REMOVAL/INSTALLATION»(ref-520392-S12000969702013010300000).)
  3. Inspect the glass antenna for damage visually.
  4. Inspect for continuity between the glass antenna terminals using an ohmmeter. (Scheme 7): Identifying Antenna Amplifier Connector B If not as specified, repair the glass antenna. (See «FILAMENT REPAIR»(ref-520370-S02096807682013010300000).) (Scheme 8): Antenna Amplifier Terminals Continuity Chart

Scheme 9

Scheme 9: ANTENNA AMPLIFIER REMOVAL/INSTALLATION
Scheme 9: ANTENNA AMPLIFIER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Remove the clips A and B. (Scheme 9): Antenna Amplifier, Connector, Clips And Bolt With Torque Specification
  7. Disconnect the connector A. (with SIRIUS satellite radio system)
  8. Disconnect the connector B. (See «CONNECTOR B REMOVAL NOTE»(ref-520392-S18768773402013010300000).)
  9. Remove the clip C.
  10. Remove the bolt.
  11. Remove the Antenna amplifier.
  12. Install in the reverse order of removal.

Scheme 10

Scheme 10: Connector B Removal Note
Scheme 10: Connector B Removal Note
  1. Remove the connector B in the direction of the arrow (2) shown in the figure while pressing the glass antenna terminal in the direction of the arrow (1). (Scheme 10): Pressing Glass Antenna Terminal

Scheme 11

Scheme 11: ANTENNA AMPLIFIER INSPECTION
Scheme 11: ANTENNA AMPLIFIER INSPECTION

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  7. Switch the ignition to ON.
  8. Turn the audio unit power to ON.
  9. Tune in the radio.
  10. Verify that voltage is B+ at the antenna amplifier terminal A. (Scheme 11): Identifying Antenna Amplifier Connector Terminals If the battery voltage cannot be verified, replace the antenna amplifier.
  11. Verify that the continuity between antenna amplifier terminals is as indicated in the table. (with SIRIUS satellite radio system) (Scheme 12): Identifying Antenna Amplifier Connector Terminals If not as indicated in the table, replace antenna amplifier. (Scheme 13): Antenna Amplifier Terminals Continuity Chart

Scheme 14

Scheme 14: SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION
Scheme 14: SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Grove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).)
  3. Remove in the order indicated in the table. (Scheme 14): SIRIUS Satellite Radio Unit, Connector And Nut With Torque Specifications
  4. Install in the reverse order of removal.

Scheme 15

Scheme 15: 4SD
Scheme 15: 4SD
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (LH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (LH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (LH) (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).)
  3. Disconnect the connector. (Scheme 15): Condenser, Connector And Bolt (4SD) With Torque Specifications
  4. Remove the bolt.
  5. Remove the condenser.
  6. Install in the reverse order of removal.

Scheme 16

Scheme 16: 5HB
Scheme 16: 5HB
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S18879345672013010300000).)
  3. Disconnect the connector. (Scheme 16): Condenser, Connector And Bolt (5HB) With Torque Specifications
  4. Remove the bolt.
  5. Remove the condenser.
  6. Install in the reverse order of removal.
