Entertainment System: Removal & Installation Mazda 3 BL рестайлинг

Entertainment Systems 49 illustrations ~2723 words

CAR-NAVIGATION UNIT REMOVAL/INSTALLATION

Note. Car-navigation unit is integrated with the multi information display.

  1. Refer to «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-520387-S06200430132013010300000) .

Scheme 17

Scheme 17: AUDIO AMPLIFIER REMOVAL/INSTALLATION
Scheme 17: AUDIO AMPLIFIER REMOVAL/INSTALLATION

Scheme 18

Scheme 18
Scheme 18
  1. Slide the passenger seat rearward.
  2. Remove the cover. (Scheme 17): Audio Amplifier, Cover, Clips And Bolt With Torque Specification
  3. Remove the bolt.
  4. Detach the clips and set the vehicle wiring harness aside.
  5. Slide the passenger seat forward.
  6. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  7. Remove the caps. (Scheme 18): Audio Amplifier Connector, Caps And Nuts With Torque Specification
  8. Remove the nuts.
  9. Disconnect the connector.
  10. Remove the audio amplifier.
  11. Install in the reverse order of removal.

Scheme 19

Scheme 19: FRONT DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 19: FRONT DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  4. Disconnect the connector. (Scheme 19): Front Door Speaker, Connector And Screws (Without Bose) (Scheme 20): Front Door Speaker, Connector And Screws (With Bose)
  5. Remove the screw.
  6. Remove the front door speaker in the direction of the arrow shown in the figure. (Scheme 21): Front Door Speaker (Without Bose) (Scheme 22): Front Door Speaker (With Bose)
  7. Install in the reverse order of removal.

Scheme 23

Scheme 23: FRONT DOOR SPEAKER INSPECTION
Scheme 23: FRONT DOOR SPEAKER INSPECTION

Scheme 24

Scheme 24
Scheme 24
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  4. Remove the front door speaker. (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S06651380612013010300000).)
  5. Verify the resistance between the front door speaker terminals. (Scheme 23): Front Door Speaker Connector Terminals If not within the specification, replace the front door speaker. (Scheme 24): Front Door Speaker Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 1.83-2.47 ohms

Scheme 25

Scheme 25: REAR DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 25: REAR DOOR SPEAKER REMOVAL/INSTALLATION

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  3. Disconnect the connector. (Scheme 25): Rear Door Speaker, Connector And Screws (Without Bose) (Scheme 26): Rear Door Speaker, Connector And Screws (With Bose)
  4. Remove the screw.
  5. Remove the rear door speaker in the direction of the arrow shown in the figure. Without Bose® (Scheme 27): Rear Door Speaker (Without Bose®) (Scheme 28): Removing Rear Door Speaker (With Bose®)
  6. Install in the reverse order of removal.

Scheme 29

Scheme 29: REAR DOOR SPEAKER INSPECTION
Scheme 29: REAR DOOR SPEAKER INSPECTION

Scheme 30

Scheme 30
Scheme 30
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  3. Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S15708751742013010300000).)
  4. Verify the resistance between the rear door speaker terminals. (Scheme 29): Rear Door Speaker Connector Terminals If not within the specification, replace the rear door speaker. (Scheme 30): Rear Door Speaker Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 2.89-3.91 ohms

Scheme 31

Scheme 31: REAR DOOR SPEAKER INSPECTION
Scheme 31: REAR DOOR SPEAKER INSPECTION

Scheme 32

Scheme 32
Scheme 32
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  3. Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S15708751742013010300000).)
  4. Verify the resistance between the rear door speaker terminals. (Scheme 31): Rear Door Speaker Connector Terminals If not within the specification, replace the rear door speaker. (Scheme 32): Rear Door Speaker Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 2.89-3.91 ohms

Scheme 33

Scheme 33: FRONT CENTER SPEAKER INSPECTION
Scheme 33: FRONT CENTER SPEAKER INSPECTION

Scheme 34

Scheme 34
Scheme 34
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-520387-S33083702672013010300000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-520454-S30556586742013010300000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-520454-S03838017672013010300000).) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S05052835622013010300000).) Front center speaker (See FRONT CENTER SPEAKER REMOVAL/INSTALLATION.)
  3. Verify the resistance between the front center speaker terminals. (Scheme 33): Front Center Speaker Connector Terminals If not within the specification, replace the front center speaker. (Scheme 34): Front Center Speaker Terminals Resistance Chart Resistance 3.24-3.96 ohms

Scheme 35

Scheme 35: REAR CENTER SPEAKER REMOVAL/INSTALLATION
Scheme 35: REAR CENTER SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-520454-S40285089582013010300000).)
  3. Remove the screw. (Scheme 35): Rear Center Speaker, Connector And Screws
  4. Disconnect the connector.
  5. Remove the rear center speaker.
  6. Install in the reverse order of removal.

Scheme 36

Scheme 36: REAR CENTER SPEAKER INSPECTION
Scheme 36: REAR CENTER SPEAKER INSPECTION

Scheme 37

Scheme 37
Scheme 37
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-520454-S40285089582013010300000).) Rear center speaker (See «REAR CENTER SPEAKER REMOVAL/INSTALLATION»(ref-520392-S15471707232013010300000).)
  3. Verify the resistance between the rear center speaker terminals. (Scheme 36): Rear Center Speaker Connector Terminals If not within the specification, replace the rear center speaker. (Scheme 37): Rear Center Speaker Terminals Resistance Chart Resistance 0.9-1.1 ohms

Scheme 38

Scheme 38: 4SD
Scheme 38: 4SD
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-520454-S40285089582013010300000).)
  3. Remove the screw. (Scheme 38): Rear Speaker, Connector And Screws
  4. Disconnect the connector.
  5. Remove the rear speaker.
  6. Install in the reverse order of removal.

Scheme 39

Scheme 39: 5HB
Scheme 39: 5HB
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S41103934472013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).)
  3. Remove the screw. (Scheme 39): Rear Speaker, C-Pillar Trim, Connector And Screw
  4. Disconnect the connector.
  5. Remove the rear speaker.
  6. Install in the reverse order of removal.

Scheme 40

Scheme 40: 4SD
Scheme 40: 4SD

Scheme 41

Scheme 41
Scheme 41
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-520454-S40285089582013010300000).) Rear speaker (See «REAR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S06371282002013010300000).)
  3. Verify the resistance between the rear speaker terminals. (Scheme 40): Rear Speaker Connector Terminals (4SD) If not within the specification, replace the rear speaker. (Scheme 41): Rear Speaker Terminals Resistance Chart (4SD) 3.24-3.96 ohms

Scheme 42

Scheme 42: 5HB
Scheme 42: 5HB

Scheme 43

Scheme 43
Scheme 43
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S41103934472013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Rear speaker (See «REAR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S06371282002013010300000).)
  3. Verify the resistance between the rear speaker terminals. (Scheme 42): Rear Speaker Connector Terminals (5HB) If not within the specification, replace the rear speaker. (Scheme 43): Rear Speaker Terminals Resistance Chart (5HB) Resistance 3.24-3.96 ohms

Scheme 44

Scheme 44: TWEETER REMOVAL/INSTALLATION
Scheme 44: TWEETER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  3. Remove the tweeter in the direction of the arrow shown in the figure. (Scheme 44): Removing Tweeter
  4. Install in the reverse order of removal.

Scheme 45

Scheme 45: TWEETER INSPECTION
Scheme 45: TWEETER INSPECTION

Scheme 46

Scheme 46
Scheme 46
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  3. Remove the tweeter. (See «TWEETER REMOVAL/INSTALLATION»(ref-520392-S09775659852013010300000).)
  4. Verify the resistance between tweeter terminals. (Scheme 45): Tweeter Connector Terminals If not within the specification, replace the tweeter. (Scheme 46): Tweeter Terminals Resistance Chart Resistance Without Bose ®: 3.4-4.6 ohms With Bose ®: 3.06-3.74 ohms

Scheme 47

Scheme 47: BASS-BOX REMOVAL/INSTALLATION
Scheme 47: BASS-BOX REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the connector. (Scheme 47): Bass-Box, Short-Cord, Connector And Bolt With Torque Specification
  3. Remove the short-cord.
  4. Remove the bolt.
  5. Remove the bass-box.
  6. Install in the reverse order of removal.

Scheme 48

Scheme 48: BASS-BOX INSPECTION
Scheme 48: BASS-BOX INSPECTION

Scheme 49

Scheme 49
Scheme 49
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the connector. (See «BASS-BOX REMOVAL/INSTALLATION»(ref-520392-S03340437942013010300000).)
  3. Verify the resistance between bass-box terminals. (Scheme 48): Identifying Bass-Box Connector Terminals If not within the specification, replace the bass-box. (Scheme 49): Bass-Box Terminals Resistance Chart Resistance 0.9-1.1 ohms

AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION

Note. AudioPilot ® 2 is a registered trademark of Bose ® Corporation.

Scheme 50

Scheme 50: AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION
Scheme 50: AudioPilot®2 MICROPHONE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the connector.
  3. Remove the nut. (Scheme 50): AudioPilot® 2 Microphone, Connector And Nut With Torque Specifications
  4. Remove the AudioPilot ® 2 microphone.
  5. Install in the reverse order of removal.

Scheme 51

Scheme 51: 4SD
Scheme 51: 4SD

Scheme 52

Scheme 52
Scheme 52
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Disconnect the connector. (Scheme 51): Ground Plate And Connector With Torque Specifications
  7. Remove the ground plate.
  8. Remove the center roof antenna in the direction of the arrow (2) shown in the figure while pressing the center roof antenna tabs in the direction of the arrow (1). (Scheme 52): Pressing Center Roof Antenna Tabs
  9. Install in the reverse order of removal.
  10. After installation, verify that the rubber of the center roof antenna is installed to the roof panel with no space between them.

Scheme 53

Scheme 53: 5HB
Scheme 53: 5HB

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S29808716532013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).)
  6. Disconnect the connector. (Scheme 53): Connector And Ground Plate (AM/FM Type) With Torque Specifications (Scheme 54): Connector And Ground Plate (AM/FM/SIRIUS Type) With Torque Specifications
  7. Remove the ground plate.
  8. Remove the antenna rod.
  9. Remove the center roof antenna in the direction of the arrow (2) shown in the figure while pressing the center roof antenna tabs in the direction of the arrow (1). (Scheme 55): Center Roof Antenna (AM/FM Type) (Scheme 56): Center Roof Antenna (AM/FM/SIRIUS Type)
  10. Install in the reverse order of removal.
  11. After installation, verify that the rubber of the center roof antenna is installed to the roof panel with no space between them.

Scheme 57

Scheme 57: 4SD
Scheme 57: 4SD

Scheme 58

Scheme 58
Scheme 58
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-520457-S25870967302013010300000).)
  3. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
  4. Partially peel back the seaming welts.
  5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S23919795892013010300000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S07354545692013010300000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-520454-S26286324672013010300000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-520454-S04870739352013010300000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-520454-S06447723592013010300000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-520454-S26302889922013010300000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-520371-S41700704732013010300000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-520454-S00315961612013010300000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-520454-S22445118832013010300000).) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-520454-S33729404272013010300000).) Center roof antenna (See «CENTER ROOF ANTENNA REMOVAL/INSTALLATION»(ref-520392-S23499665282013010300000).)
  6. Verify that there is no continuity between the center roof antenna terminals A and B using an ohmmeter. (Scheme 57): Identifying Center Roof Antenna Connector Terminals A And B
  7. Inspect for continuity between the center roof antenna terminals using an ohmmeter. If not as indicated in the table, replace the center roof antenna. (Scheme 58): Center Roof Antenna Terminals Continuity Chart

GPS ANTENNA FEEDER REMOVAL/INSTALLATION

Note. GPS antenna feeder is removed with the multi information display.

  1. Refer to «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-520387-S06200430132013010300000) .

Scheme 59

Scheme 59: GPS ANTENNA FEEDER INSPECTION
Scheme 59: GPS ANTENNA FEEDER INSPECTION

Scheme 60

Scheme 60
Scheme 60
  1. Verify that the continuity is as indicated in the table. (Scheme 60): Identifying GPS Antenna Feeder Connector Terminals If not as indicated in the table, replace the GPS antenna feeder. (Scheme 61): GPS Antenna Feeder Terminals Continuity Chart

STEERING SWITCH REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally deploy the air bag module, which may seriously injure you. Read the air bag system service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. Disconnect the negative battery cable and wait for 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S30398979032013010300000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520390-S38458334842013010300000).)
  3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S38694288302013010300000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S21804587892013010300000).)
  4. Remove the screw. (Scheme 62): Steering Wheel And Screws
  5. Remove the wiring harness from the cover hook. (Scheme 63): Wiring Harness And Cover Hook
  6. Remove the cover tabs and pins from the steering wheel. (Scheme 64): Cover Tab, Pins And Steering Wheel
  7. Remove the cover.
  8. Disconnect the connector. (Scheme 65): Steering Wheel Connector And Screws
  9. Remove the screw.
  10. Remove the steering switch pins from the steering wheel. see scheme 97: Steering Switch Pins
  11. Remove the steering switch.
  12. Install in the reverse order of removal.

More articles — Entertainment System
