Cellular Communication System (Service Information): Removal & Installation Lexus RX III рестайлинг

Entertainment Systems 29 illustrations ~2985 words

REMOVAL [07/2012 - ]

  1. REMOVE FRONT DOOR SCUFF PLATE LH . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602734-S11710244312014030500000)
  2. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602734-S11710244312014030500000)
  3. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side.
  4. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure as for the LH side.
  5. REMOVE REAR CONSOLE BOX ASSEMBLY Refer to «REMOVAL [07/2012 - ]»(ref-602734-S22572969452014030500000)
  6. REMOVE INSTRUMENT PANEL GARNISH LH . Refer to «REMOVAL [07/2012 - ] - Step 20»(ref-602734-S19624177272014030500000)
  7. REMOVE NO. 1 SWITCH HOLE BASE . Refer to «REMOVAL [07/2012 - ] - Step 21»(ref-602734-S19624177272014030500000)
  8. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 22»(ref-602734-S19624177272014030500000)
  9. REMOVE INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL [07/2012 - ] - Step 34»(ref-602734-S19624177272014030500000)
  10. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL [07/2012 - ] - Step 35»(ref-602734-S19624177272014030500000)
  11. REMOVE FRONT CONSOLE BOX COVER . Refer to «REMOVAL [07/2012 - ] - Step 39»(ref-602734-S19624177272014030500000)
  12. REMOVE CONSOLE BOX . Refer to «REMOVAL [07/2012 - ] - Step 40»(ref-602734-S19624177272014030500000)
  13. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Disengage the 3 clamps. Disengage the claw and turn back the floor carpet as shown in the illustration. Disengage the 3 clamps. Disengage the claw and turn back the floor carpet as shown in the illustration. w/o Rear Seat Entertainment System: Disconnect the 4 connectors. Remove the 3 bolts. Disengage the guide and remove the DCM (telematics transceiver) with bracket. w/ Rear Seat Entertainment System: Disconnect the 7 connectors. Remove the 3 bolts. Disengage the guide and remove the DCM (telematics transceiver) with bracket.
  14. REMOVE MULTI-DISPLAY CONTROLLER ASSEMBLY WITH BRACKET (w/ Rear Seat Entertainment System) . Refer to «REMOVAL [07/2012 - ] - Step 14»(ref-602782-S06270057662014030500000)
  15. REMOVE TELEPHONE BRACKET Remove the 3 nuts and telephone bracket.
  16. REMOVE NO. 1 TELEPHONE BRACKET Remove the 2 bolts and No. 1 telephone bracket.
  17. REMOVE NO. 2 TELEPHONE BRACKET Remove the 2 bolts and No. 2 telephone bracket.
  18. REMOVE DCM (TELEMATICS TRANSCEIVER)

Scheme 186

Scheme 186: INSTALLATION [03/2012 - 07/2012]
Scheme 186: INSTALLATION [03/2012 - 07/2012]

Scheme 187

Scheme 187
Scheme 187
  1. INSTALL DCM (TELEMATICS TRANSCEIVER)
  2. INSTALL NO. 2 TELEPHONE BRACKET Install the No. 2 telephone bracket with the 2 bolts.
  3. INSTALL NO. 1 TELEPHONE BRACKET Install the No. 1 telephone bracket with the 2 bolts.
  4. INSTALL TELEPHONE BRACKET Install the telephone bracket with the 3 nuts.
  5. INSTALL MULTI-DISPLAY CONTROLLER ASSEMBLY WITH BRACKET (w/ Rear Seat Entertainment System) . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 4»(ref-602782-S29063829432014030500000)
  6. INSTALL DCM (TELEMATICS TRANSCEIVER) WITH BRACKET w/o Rear Seat Entertainment System: Engage the guide. Install the DCM (telematics transceiver) with bracket with the 3 bolts. Connect the 4 connectors. w/ Rear Seat Entertainment System: Engage the guide. Install the DCM (telematics transceiver) with bracket with the 3 bolts. Connect the 7 connectors. Engage the claw and 3 clamps to install the floor carpet to the original position. Engage the claw and 3 clamps to install the floor carpet to the original position.
  7. INSTALL CONSOLE BOX . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 23»(ref-602734-S07649861932014030500000)
  8. INSTALL FRONT CONSOLE BOX COVER . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 24»(ref-602734-S07649861932014030500000)
  9. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 28»(ref-602734-S07649861932014030500000)
  10. INSTALL INSTRUMENT PANEL FINISH PANEL . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 29»(ref-602734-S07649861932014030500000)
  11. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 41»(ref-602734-S07649861932014030500000)
  12. INSTALL NO. 1 SWITCH HOLE BASE . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 42»(ref-602734-S07649861932014030500000)
  13. INSTALL INSTRUMENT PANEL GARNISH LH . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 43»(ref-602734-S07649861932014030500000)
  14. INSTALL REAR CONSOLE BOX ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 1»(ref-602734-S01936488892014030500000)
  15. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH . Refer to «INSTALLATION [03/2012 - ] - Step 57»(ref-602734-S41277548442014030500000)
  16. INSTALL FRONT DOOR SCUFF PLATE LH . Refer to «INSTALLATION [03/2012 - ] - Step 58»(ref-602734-S41277548442014030500000)
  17. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure as for the LH side.
  18. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side.
  19. REPLACED OPERATION Refer to «DCM ACTIVATION [03/2012 - ]»(ref-602568-S31924659552014030500000)

INSTALLATION [07/2012 - ]

  1. INSTALL DCM (TELEMATICS TRANSCEIVER)
  2. INSTALL NO. 2 TELEPHONE BRACKET Install the No. 2 telephone bracket with the 2 bolts.
  3. INSTALL NO. 1 TELEPHONE BRACKET Install the No. 1 telephone bracket with the 2 bolts.
  4. INSTALL TELEPHONE BRACKET Install the telephone bracket with the 3 nuts.
  5. INSTALL MULTI-DISPLAY CONTROLLER ASSEMBLY WITH BRACKET (w/ Rear Seat Entertainment System) . Refer to «INSTALLATION [07/2012 - ] - Step 4»(ref-602782-S30861358462014030500000)
  6. INSTALL DCM (TELEMATICS TRANSCEIVER) WITH BRACKET w/o Rear Seat Entertainment System: Engage the guide. Install the DCM (telematics transceiver) with bracket with the 3 bolts. Connect the 4 connectors. w/ Rear Seat Entertainment System: Engage the guide. Install the DCM (telematics transceiver) with bracket with the 3 bolts. Connect the 7 connectors. Engage the claw and 3 clamps to install the floor carpet to the original position. Engage the claw and 3 clamps to install the floor carpet to the original position.
  7. INSTALL CONSOLE BOX . Refer to «INSTALLATION [07/2012 - ] - Step 23»(ref-602734-S19338030442014030500000)
  8. INSTALL FRONT CONSOLE BOX COVER . Refer to «INSTALLATION [07/2012 - ] - Step 24»(ref-602734-S19338030442014030500000)
  9. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL . Refer to «INSTALLATION [07/2012 - ] - Step 28»(ref-602734-S19338030442014030500000)
  10. INSTALL INSTRUMENT PANEL FINISH PANEL . Refer to «INSTALLATION [07/2012 - ] - Step 29»(ref-602734-S19338030442014030500000)
  11. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 41»(ref-602734-S19338030442014030500000)
  12. INSTALL NO. 1 SWITCH HOLE BASE . Refer to «INSTALLATION [07/2012 - ] - Step 42»(ref-602734-S19338030442014030500000)
  13. INSTALL INSTRUMENT PANEL GARNISH LH . Refer to «INSTALLATION [07/2012 - ] - Step 43»(ref-602734-S19338030442014030500000)
  14. INSTALL REAR CONSOLE BOX ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 1»(ref-602734-S31055203672014030500000)
  15. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH . Refer to «INSTALLATION [03/2012 - ] - Step 57»(ref-602734-S41277548442014030500000)
  16. INSTALL FRONT DOOR SCUFF PLATE LH . Refer to «INSTALLATION [03/2012 - ] - Step 58»(ref-602734-S41277548442014030500000)
  17. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure as for the LH side.
  18. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side.
  19. REPLACED OPERATION Refer to «DCM ACTIVATION [03/2012 - ]»(ref-602568-S31924659552014030500000)

Scheme 188

Scheme 188: ILLUSTRATION
Scheme 188: ILLUSTRATION

Scheme 189

Scheme 189
Scheme 189

Scheme 190

Scheme 190: REMOVAL [03/2012 - 07/2012]
Scheme 190: REMOVAL [03/2012 - 07/2012]

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192
Scheme 192
  1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-602551-S11461672722014030500000) .
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the battery negative (-) terminal to disable the SRS system. NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000) .
  3. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and LH side. Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602734-S11710244312014030500000) .
  4. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and LH side. Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602734-S11710244312014030500000) .
  5. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 43»(ref-602734-S10268845232014030500000)
  6. REMOVE INSTRUMENT PANEL GARNISH RH . Refer to «REMOVAL [03/2012 - 07/2012] - Step 44»(ref-602734-S10268845232014030500000)
  7. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 10»(ref-602553-S40421341422014030500000)
  8. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 46»(ref-602734-S10268845232014030500000)
  9. REMOVE BACK-UP BATTERY WITH BRACKET Disconnect the connector. Remove the 2 bolts and back-up battery with bracket.
  10. REMOVE NO. 1 TELEPHONE BRACKET Remove the nut. Disengage the 2 guides and remove the No. 1 telephone bracket as shown in the illustration.
  11. REMOVE NO. 2 TELEPHONE BRACKET Remove the No. 2 telephone bracket as shown in the illustration.
  12. REMOVE BACK-UP BATTERY
  1. PRECAUTION NOTE: After turning the engine switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-602551-S11461672722014030500000) .
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the battery negative (-) terminal to disable the SRS system. NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) .
  3. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and LH side. Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602734-S11710244312014030500000) .
  4. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and LH side. Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602734-S11710244312014030500000) .
  5. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 43»(ref-602734-S19624177272014030500000)
  6. REMOVE INSTRUMENT PANEL GARNISH RH . Refer to «REMOVAL [07/2012 - ] - Step 44»(ref-602734-S19624177272014030500000)
  7. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 10»(ref-602553-S25483277822014030500000)
  8. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «REMOVAL [07/2012 - ] - Step 46»(ref-602734-S19624177272014030500000)
  9. REMOVE BACK-UP BATTERY WITH BRACKET Disconnect the connector. Remove the 2 bolts and back-up battery with bracket.
  10. REMOVE NO. 1 TELEPHONE BRACKET Remove the nut. Disengage the 2 guides and remove the No. 1 telephone bracket as shown in the illustration.
  11. Remove No. 2 Telephone Bracket Remove the No. 2 telephone bracket as shown in the illustration.
  12. REMOVE BACK-UP BATTERY

Scheme 193

Scheme 193: INSTALLATION [03/2012 - 07/2012]
Scheme 193: INSTALLATION [03/2012 - 07/2012]

Scheme 194

Scheme 194
Scheme 194
  1. INSTALL BACK-UP BATTERY
  2. INSTALL NO. 2 TELEPHONE BRACKET Install the No. 2 telephone bracket as shown in the illustration.
  3. INSTALL NO. 1 TELEPHONE BRACKET Engage the 2 guides as shown in the illustration. Install the No. 1 telephone bracket with the nut.
  4. INSTALL BACK-UP BATTERY WITH BRACKET Install the back-up battery with bracket with the 2 bolts. Connect the connector.
  5. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 17»(ref-602734-S07649861932014030500000)
  6. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 1»(ref-602553-S09683985262014030500000)
  7. INSTALL INSTRUMENT PANEL GARNISH RH . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 19»(ref-602734-S07649861932014030500000)
  8. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 20»(ref-602734-S07649861932014030500000)
  9. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and LH side. Refer to «INSTALLATION [03/2012 - ] - Step 57»(ref-602734-S41277548442014030500000) .
  10. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and LH side. Refer to «INSTALLATION [03/2012 - ] - Step 58»(ref-602734-S41277548442014030500000) .
  11. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - 07/2012]»(ref-602551-S24591545042014030500000) .
  12. INSPECT SRS WARNING LIGHT Refer to «DIAGNOSIS SYSTEM [03/2012 - ]»(ref-602724-S41651414302014030500000)
  1. INSTALL BACK-UP BATTERY
  2. INSTALL NO. 2 TELEPHONE BRACKET Install the No. 2 telephone bracket as shown in the illustration.
  3. INSTALL NO. 1 TELEPHONE BRACKET Engage the 2 guides as shown in the illustration. Install the No. 1 telephone bracket with the nut.
  4. INSTALL BACK-UP BATTERY WITH BRACKET Install the back-up battery with bracket with the 2 bolts. Connect the connector.
  5. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 17»(ref-602734-S19338030442014030500000)
  6. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 1»(ref-602553-S28461968562014030500000)
  7. INSTALL INSTRUMENT PANEL GARNISH RH . Refer to «INSTALLATION [07/2012 - ] - Step 19»(ref-602734-S19338030442014030500000)
  8. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION [07/2012 - ] - Step 20»(ref-602734-S19338030442014030500000)
  9. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and LH side. Refer to «INSTALLATION [03/2012 - ] - Step 57»(ref-602734-S41277548442014030500000) .
  10. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and LH side. Refer to «INSTALLATION [03/2012 - ] - Step 58»(ref-602734-S41277548442014030500000) .
  11. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [07/2012 - ]»(ref-602551-S38908041872014030500000) .
  12. INSPECT SRS WARNING LIGHT Refer to «DIAGNOSIS SYSTEM [03/2012 - ]»(ref-602724-S41651414302014030500000)

Scheme 195

Scheme 195: ILLUSTRATION
Scheme 195: ILLUSTRATION

Scheme 196

Scheme 196
Scheme 196

Scheme 197

Scheme 197: REMOVAL [03/2012 - ]
Scheme 197: REMOVAL [03/2012 - ]
  1. REMOVE MAP LIGHT ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602785-S29655097102014030500000)
  2. REMOVE MANUAL (SOS) SWITCH Remove the 2 screws and manual (SOS) switch.

INSTALLATION [03/2012 - ]

  1. INSTALL MANUAL (SOS) SWITCH Install the manual (SOS) switch with the 2 screws.
  2. INSTALL MAP LIGHT ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 2»(ref-602785-S16096054962014030500000)

Scheme 198

Scheme 198: ILLUSTRATION
Scheme 198: ILLUSTRATION

Scheme 199

Scheme 199
Scheme 199

Scheme 200

Scheme 200: REMOVAL [03/2012 - ]
Scheme 200: REMOVAL [03/2012 - ]

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202

Scheme 203

Scheme 203
Scheme 203

Scheme 204

Scheme 204
Scheme 204
  1. REMOVE ROOF HEADLINING ASSEMBLY HINT: Refer to the procedure up to Remove Roof Headlining Assembly. Refer to «REMOVAL [03/2012 - ]»(ref-602734-S37033497262014030500000) .
  2. REMOVE TELEPHONE AND GPS ANTENNA ASSEMBLY Disconnect the connector. Disengage the 2 claws and disconnect the antenna cord connector. Disengage the 2 claws and remove the protector. Remove the antenna nut. Disengage the 2 claws and remove the telephone and GPS antenna assembly.

Scheme 205

Scheme 205
Scheme 205
  1. INSTALL TELEPHONE AND GPS ANTENNA ASSEMBLY Align the guide pin of the telephone and GPS antenna assembly to the guide hole of the roof, and then engage the 2 claws to install the telephone and GPS antenna assembly. Engage the harness to the notch of the antenna nut as shown in the illustration and install the antenna nut. TEXT IN ILLUSTRATION *1 Notch Torque: 4.5 N*m (45 kgf*cm, 40 in.*lbf) Engage the 2 claws to install the protector. Engage the 2 claws to connect the antenna cord connector to the protector. Connect the connector.
  2. INSTALL ROOF HEADLINING ASSEMBLY HINT: Refer to the procedure from Install Roof Headlining Assembly. Refer to «INSTALLATION [03/2012 - ]»(ref-602734-S38419929412014030500000) .

Scheme 206

Scheme 206
Scheme 206

Scheme 207

Scheme 207: REMOVAL [03/2012 - ]
Scheme 207: REMOVAL [03/2012 - ]

Scheme 208

Scheme 208
Scheme 208

Scheme 209

Scheme 209
Scheme 209

Scheme 210

Scheme 210
Scheme 210

Scheme 211

Scheme 211
Scheme 211
  1. REMOVE ROOF HEADLINING ASSEMBLY Refer to «REMOVAL [03/2012 - ]»(ref-602734-S37033497262014030500000)
  2. REMOVE NO. 5 ANTENNA CORD SUB-ASSEMBLY Peel the strips of the tape used to secure the antenna cord only to the extent that allows removal of the antenna cord. TEXT IN ILLUSTRATION *A w/o Sliding Roof *B w/ Sliding Roof *1 Adhesive tape - - *a Front - - Remove the No. 5 antenna cord sub-assembly.
  3. REMOVE NO. 4 ANTENNA CORD SUB-ASSEMBLY Disengage the 5 clamps. Disengage the 3 clamps. TEXT IN ILLUSTRATION *a Front Disengage the 2 claws. Disengage the 3 clamps. TEXT IN ILLUSTRATION *a Front Disengage the 3 clamps to remove the No. 4 antenna cord sub-assembly.

Scheme 212

Scheme 212: INSTALLATION [03/2012 - ]
Scheme 212: INSTALLATION [03/2012 - ]

Scheme 213

Scheme 213
Scheme 213
  1. INSTALL NO. 4 ANTENNA CORD SUB-ASSEMBLY Engage the 6 clamps. Engage the 2 claws to connect the antenna cord connector. Engage the 3 clamps. Engage the 5 clamps to install the No. 4 antenna cord sub-assembly.
  2. INSTALL NO. 5 ANTENNA CORD SUB-ASSEMBLY HINT: Double-sided tape and tape are not available as supply parts. If the tape still has enough adhesion to secure the roof headlining and antenna cord, reuse it. If the roof headlining has been replaced with a new one, or if the tape and/or the double-sided tape is no longer sticky, apply new tape following the procedure below. If the double-sided tape cannot be reused: Peel off the release paper from one side of new double-sided tape and apply the new double-sided tape to the position indicated in the illustration. Be careful not to touch the adhesive surface. NOTE: Be sure to apply the double-sided tape carefully so that the tape will not be misaligned or come off. Peel off the release paper from the double-sided tape. Be careful not to touch the adhesive surface. TEXT IN ILLUSTRATION *A w/o Sliding Roof *B w/ Sliding Roof *1 Double-sided Tape - - *a Front *b Double-sided Tape Size DOUBLE-SIDED TAPE SIZE Area Dimension X 1.0 mm (0.0394 in.) Y 15.0 mm (0.591 in.) Align the vehicle front side marking (yellow) on the No. 5 antenna cord sub-assembly with the vehicle front side tab on the roof headlining, and wrap the tape over the antenna cord to install it. (A) TEXT IN ILLUSTRATION *A w/o Sliding Roof *B w/ Sliding Roof *1 Double-sided Tape *2 Adhesive Tape *3 Marking (Yellow) - - *a Front *b Double-sided Tape Size *c Extra Cord Storage Area - - DOUBLE-SIDED TAPE SIZE Area Dimension X 1.0 mm (0.0394 in.) Y 15.0 mm (0.591 in.) HINT: If the tape cannot be reused, packing tape can be used as a substitute. Temporarily install the No. 5 antenna cord sub-assembly by placing it on the double-sided tape from the front of the vehicle to the point just before the extra cord storage area. Align the vehicle rear marking (yellow) on the No. 5 antenna cord sub-assembly with the tape attachment location (scribe line) of the roof headlining, and wrap the tape over the antenna cord to install it. (B) HINT: If the tape cannot be reused, packing tape can be used as a substitute. Temporarily install the No. 5 antenna cord sub-assembly by placing it on the double-sided tape from the rear of the vehicle to the point just before the extra cord storage area. Using double-sided tape, place any excess No. 5 antenna cord sub-assembly in the extra cord storage area to finish installing the antenna cord. HINT: Attach 3 pieces of double-sided tape to the extra cord storage area as shown in the illustration.
  3. INSTALL ROOF HEADLINING ASSEMBLY Refer to «INSTALLATION [03/2012 - ]»(ref-602734-S38419929412014030500000)

Scheme 214

Scheme 214
Scheme 214

REMOVAL [03/2012 - ]

  1. REMOVE MAP LIGHT ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-602785-S29655097102014030500000)
  2. REMOVE TELEPHONE MICROPHONE ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-602782-S01472995092014030500000)
  1. INSTALL TELEPHONE MICROPHONE ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 1»(ref-602782-S17490613812014030500000)
  2. INSTALL MAP LIGHT ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 2»(ref-602785-S16096054962014030500000)
