1. REMOVE FRONT DOOR SCUFF PLATE LH . Refer to «REMOVAL [03/2012 - ] - Step 1»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
2. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
3. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure as for the LH side.
4. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure as for the LH side.
5. REMOVE REAR CONSOLE BOX ASSEMBLY Refer to «REMOVAL [03/2012 - 07/2012]»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
6. REMOVE INSTRUMENT PANEL GARNISH LH . Refer to «REMOVAL [03/2012 - 07/2012] - Step 20»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
7. REMOVE NO. 1 SWITCH HOLE BASE . Refer to «REMOVAL [03/2012 - 07/2012] - Step 21»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
8. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - 07/2012] - Step 22»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
9. REMOVE INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL [03/2012 - 07/2012] - Step 34»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
10. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL [03/2012 - 07/2012] - Step 35»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
11. REMOVE FRONT CONSOLE BOX COVER . Refer to «REMOVAL [03/2012 - 07/2012] - Step 39»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
12. REMOVE CONSOLE BOX . Refer to «REMOVAL [03/2012 - 07/2012] - Step 40»(/lexus/rx/iii-2012-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
13. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Disengage the 3 clamps. Disengage the claw and turn back the floor carpet as shown in the illustration. Disengage the 3 clamps. Disengage the claw and turn back the floor carpet as shown in the illustration. w/o Rear Seat Entertainment System: Disconnect the 4 connectors. Remove the 3 bolts. Disengage the guide and remove the DCM (telematics transceiver) with bracket. w/ Rear Seat Entertainment System: Disconnect the 7 connectors. Remove the 3 bolts. Disengage the guide and remove the DCM (telematics transceiver) with bracket.
14. REMOVE MULTI-DISPLAY CONTROLLER ASSEMBLY WITH BRACKET (w/ Rear Seat Entertainment System). Refer to «REMOVAL [03/2012 - 07/2012] - Step 14»
15. REMOVE TELEPHONE BRACKET Remove the 3 nuts and telephone bracket.
16. REMOVE NO. 1 TELEPHONE BRACKET Remove the 2 bolts and No. 1 telephone bracket.
17. REMOVE NO. 2 TELEPHONE BRACKET Remove the 2 bolts and No. 2 telephone bracket.
18. REMOVE DCM (TELEMATICS TRANSCEIVER)
