DESCRIPTION
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-21 | A ROM malfunction exists. | Radio receiver assembly |
| 01-22 | A RAM malfunction exists. | |
| 01-2E | A checksum malfunction exists. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-D5*1, *3 | A device indicated by the sub-code is (was) disconnected from the system while the engine switch is on (IG) or (ACC). The communication condition with the device that the DTC shows cannot be obtained when the engine was started. | Power source circuit of the component shown by the sub-code AVC-LAN circuit between the radio receiver assembly and component shown by the sub-code Component shown by the sub-code |
| 01-D8*2, *3 | The device indicated by the sub-code is (was) disconnected from the system after the engine was started. | |
| 01-D9*1, *3 | The device that had functioned before the engine stopped is (was) disconnected from the system with the engine switch on (IG) or (ACC). | |
| 01-DA*3 | No response is identified when changing mode. Sound and image do not change by switch operation. | |
| 01-DB*1, *3 | A dual alarm is detected. | |
| 01-DE*3, *4 | A slave device has been disconnected after the engine was started. |
HINT
- *1: Even if no fault is present, this DTC may be stored depending on the battery condition or engine start voltage.
- *2: If the power connector is disconnected after the engine was started, this DTC is stored after 180 seconds.
- *3: If the device is reported as not existing during verification, check the power source circuit and AVC-LAN circuit for the device.
- *4: This DTC may be stored if the engine is started and the engine switch is pressed again.
Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-D6*1 | Either condition is met: The device that stores (stored) the DTC has (had) been disconnected with the engine switch on (IG) or (ACC). The master device has (had) been disconnected when this DTC is (was) stored. | Radio receiver assembly power source circuit Power source circuit of the component which has stored this code AVC-LAN circuit between the radio receiver assembly and component which has stored this code Component which has stored this code Radio receiver assembly |
| 01-D7*2 | Either condition is met: The device that stored the code has (had) been disconnected after the engine starts (started). The master device has (had) been disconnected when this DTC is (was) stored. |
HINT
- *1: Even if no fault is present, this DTC may be stored depending on the battery condition or engine start voltage.
- *2: When 210 seconds have elapsed after disconnecting the power supply connector of the master component with the engine switch on (IG) or (ACC), this DTC is stored.
Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-DC*1 | Transmission to component shown by sub-code failed. (Detecting this DTC does not always mean actual failure.) | If the same sub-code is stored in other components, check power source circuit and communication system of all components shown by sub-code |
HINT
*1: If the engine switch is turned off after idling for 60 seconds, this DTC may be stored when the engine is started again.
Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reason described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-DD*1 | The device that should be the master has been disconnected after the engine was started. | Radio receiver assembly power source circuit AVC-LAN circuit between the radio receiver assembly and component which has stored this code Radio receiver assembly Component which has stored this code |
| 01-E1*2 | The AMP device stores that the AMP output does not function even while the source device operates. |
HINT
- *1: If the engine switch is turned off after idling for 60 seconds, this DTC may be stored when the engine is started again.
- *2: Even if no fault is present, this DTC may be stored depending on the battery condition or engine start voltage.
Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-DF*1 | The device with a display fails and the master unit is switched to the audio device. Also when a communication error between the sub-master unit (audio) and master unit occurs, this DTC is stored. | Radio receiver assembly power source circuit AVC-LAN circuit between the radio receiver assembly and component which has stored this code Radio receiver assembly Component which has stored this code |
HINT
*1: When 210 seconds have elapsed after disconnecting the power supply connector of the master component with the engine switch on (IG) or (ACC), this DTC is stored.
Note. Before starting troubleshooting, be sure to clear the DTCs stored due to the reason described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver assembly is the master unit. Be sure to clear and recheck for DTCs after the inspection is completed to confirm that no DTCs are output.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-E0 | "Registration complete" signal from the master device cannot be received. | |
| 01-E3 | Either condition is met: The registration demand signal from the slave device is output. The registration demand signal is output by receiving connection confirmation signal from the sub-master device. | |
| 01-E4 | The multiple frame transmission is incomplete. |
HINT
Even if no fault is present, these DTCs may be stored depending on the battery condition or engine start voltage.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-E2 | The command for ON/OFF control from the master device has a problem. | Radio receiver assembly |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 01-F2 | Any reply to a system inspection instruction, system inspection result request or diagnosis memory request could not be completed within a designated time. | Stereo component amplifier assembly |
| 01-FF | No response to a diagnosis request |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 57-10 | "Bluetooth" module malfunction | Radio receiver assembly |
| 57-47 | "Bluetooth" module is not installed. Problem with "Bluetooth" module Problem in communication line to "Bluetooth" module |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 60-10 | The AM tuner PLL (Phase Locked Loop) synchronization is impossible. | Radio receiver assembly |
| 60-11 | The FM tuner PLL (Phase Locked Loop) synchronization is impossible. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 60-42 | The power source of the tuner is abnormal. | Radio receiver assembly |
| 60-43 | The AM tuner is abnormal. | |
| 60-44 | The FM tuner is abnormal. | |
| 60-50 | A problem occurs in the IC inside the tuner unit and radio reception is not normal. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-10 | A mechanical error in the CD changer is detected while a CD is not being inserted or ejected. | Radio receiver assembly |
| 63-11 | CDs cannot be inserted or ejected. | |
| 63-12 | CD read problem occurs. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-41 | An unsuitable disc is inserted. | CD Radio receiver assembly |
| 63-42 | The disc cannot be read. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-43 | CD-ROM operation is abnormal. | CD Radio receiver assembly |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-44 | Operation error in the CD mechanism | Radio receiver assembly |
| 63-48 | Excess current is present in the CD changer. | |
| 63-50 | Malfunction in insertion/ejection system |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-45 | Magazine cannot be ejected. | Radio receiver assembly |
| 63-51 | Mechanical error occurs during elevator operation. | |
| 63-52 | Error occurs in CD changer clamp. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-46 | Scratches or dirt is found on CD surface or CD is inserted upside down. | CD Radio receiver assembly |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-47 | Sensor detects that CD unit temperature is high (Over 80°C (176°F)). | Radio receiver assembly |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-78 | An error occurs during the decode process (MP3/WMA). |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 63-7D | An incompatible MP3/WMA file is used. Although the file has an extension of ".mp3" or ".wma", the header information cannot be read. | CD Radio receiver assembly |
| 63-7E | A disc with no music data is used. Playable files are not on the disc (MP3/WMA). | |
| 63-7F | Copyright protection exists and playback is not possible. |
This DTC is stored when a malfunction occurs in the speakers.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| 74-40 | A short is detected in the speaker output circuit. | Wire harness or connector Speaker DCM (Telematics transceiver)*1 Stereo component amplifier assembly |
- *1: w/ Manual (SOS) Switch
Scheme 46
Scheme 47
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| C0-11 | Tuner PLL synchronization is impossible. | Radio receiver assembly |
| C0-12 | A communication error occurred in CDED. | |
| C0-13 | A communication error occurred in SSDEC. | |
| C0-14 | No response received from SSDEC. | |
| C0-15 | An error occurred in CAP internal NVM. | |
| C0-16 | An error occurred in CAP. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| C0-40 | Antenna is not connected. | Antenna cord sub-assembly No. 2 antenna cord sub-assembly No. 4 antenna cord sub-assembly Telephone antenna assembly Radio receiver assembly |
| C0-41 | Short in antenna circuit |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| CB-10 | System microcomputer malfunction | Radio receiver assembly "iPod" or USB device |
| CB-11 | Media interface microcomputer malfunction | |
| CB-12 | CD-LSI (Large Scale Integration) Malfunction |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| CB-13 | "iPod" or USB device overcurrent malfunction | "iPod" or USB device No. 1 stereo jack adapter assembly Wire harness or connector Radio receiver assembly |
Scheme 48
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| CB-43 | When a non mass-storage class or incompatible protocol USB device is connected. | Radio receiver assembly USB device |
| CB-44 | When a USB device with an incompatible file system, corrupted or incompatible File Allocation Table (FAT) is connected. | |
| CB-50 | "iPod" malfunction | Radio receiver assembly "iPod" |
| CB-51 | When an "iPod" with an unsupported firmware is connected. | |
| CB-7D | When an unsupported model of "iPod" is connected. |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| CB-45 | Communication error with USB device | Radio receiver assembly USB device |
| CB-46 | "iPod" control software malfunction | Radio receiver assembly "iPod" |
| CB-47 | Communication error with "iPod" |
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| CB-52 | No playable files on the "iPod" | "iPod" |
| CB-7E | No playable files on the USB device | USB device |
When a USB device or "iPod" is connected to the USB jack of the No. 1 stereo jack adapter assembly, it must have playable files. The device must also communicate with and be recognized by the radio receiver assembly. This diagnosis procedure is for when a device is not recognized, or files from the device cannot be played normally.
Scheme 49
Vehicle speed signals are received from the combination meter assembly and used to cancel "Bluetooth" function operation.
The radio receiver assembly recognizes that the vehicle is being driven and makes it impossible to connect or register a "Bluetooth" device while driving.
HINT
- A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter assembly. The signal is changed to a pulse signal at the transistor in the combination meter assembly. Each ECU controls the respective system based on the pulse signal.
- If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the following diagram will not operate normally.
Scheme 50
Vehicle speed signals are received from the combination meter assembly and used to cancel "Bluetooth" function operation.
The radio receiver assembly recognizes that the vehicle is being driven and makes it impossible to connect or register a "Bluetooth" device while driving.
HINT
- A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter assembly. The signal is changed to a pulse signal at the transistor in the combination meter assembly. Each ECU controls the respective system based on the pulse signal.
- If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the following diagram will not operate normally.
Scheme 51
This circuit sends an operation signal from the steering pad switch assembly to the radio receiver assembly.
If there is an open in this circuit, the audio system cannot be operated using the steering pad switch assembly.
If there is a short in this circuit, the same condition as when a switch is continuously depressed occurs.
Therefore, the radio receiver assembly cannot be operated using the steering pad switch assembly, and also the radio receiver assembly itself cannot function.
Scheme 52
This circuit sends an operation signal from the steering pad switch assembly to the radio receiver assembly.
If there is an open in this circuit, the audio system cannot be operated using the steering pad switch assembly.
If there is a short in this circuit, the same condition as when a switch is continuously depressed occurs.
Therefore, the radio receiver assembly cannot be operated using the steering pad switch assembly, and also the radio receiver assembly itself cannot function.
Power is supplied to the radio receiver assembly and steering pad switch assembly illumination when the light control switch is in the tail or head position.
Scheme 53
Power is supplied to the radio receiver assembly and steering pad switch assembly illumination when the light control switch is in the tail or head position.
If there is a short in a speaker circuit, the stereo component amplifier assembly detects the short and stops output to the speakers.
Thus sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier assembly or speakers.
The radio receiver assembly sends a sound signal to the stereo component amplifier assembly through this circuit.
The sound signal that has been sent is amplified by the stereo component amplifier assembly, and then is sent to the speakers.
If there is an open or short in the circuit, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier assembly, DCM (telematics transceiver)*1 or speakers.
- *1: w/ Manual (SOS) Switch
Scheme 54
The No. 1 stereo jack adapter assembly sends the sound signal from an external device to the radio receiver assembly through this circuit.
The sound signal that has been sent is amplified by the radio receiver assembly, and then is sent to the speakers.
If there is an open or short in this circuit, sound cannot be heard from the speakers even if there is no malfunction in the radio receiver assembly or speakers.
Scheme 55
Scheme 56
- CHECK HARNESS AND CONNECTOR (RADIO RECEIVER ASSEMBLY - NO. 1 STEREO JACK ADAPTER ASSEMBLY) Disconnect the U13 No. 1 stereo jack adapter assembly connector. Disconnect the G9 and G52 radio receiver assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition U13-9 (AUXO) - G9-19 (ADPG) Always Below 1 ohms U13-6 (ARO) - G9-16 (VA-) Always Below 1 ohms U13-7 (ALO) - G9-17 (VAL+) Always Below 1 ohms U13-8 (ASGN) - G9-15 (VAR+) Always Below 1 ohms U13-10 (AGND) - G9-18 (AGND) Always Below 1 ohms U13-2 (UDO-) - G52-2 (US1-) Always Below 1 ohms U13-3 (UDO+) - G52-3 (US1+) Always Below 1 ohms U13-5 (UJSS) - G52-5 (USG1) Always Below 1 ohms U13-9 (AUXO) - Body ground Always 10 kohms or higher U13-6 (ARO) - Body ground Always 10 kohms or higher U13-7 (ALO) - Body ground Always 10 kohms or higher U13-8 (ASGN) - Body ground Always 10 kohms or higher U13-10 (AGND) - Body ground Always 10 kohms or higher U13-2 (UDO-) - Body ground Always 10 kohms or higher U13-3 (UDO+) - Body ground Always 10 kohms or higher U13-5 (UJSS) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to No. 1 Stereo Jack Adapter Assembly) *b Front view of wire harness connector (to Radio Receiver Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - 07/2012]»
This circuit sends a signal to the stereo component amplifier assembly to mute noise. Because of that, the noise produced by changing the sound source ceases.
If there is an open in this circuit, noise can be heard from the speakers when changing the sound source.
If there is a short in this circuit, even though the stereo component amplifier assembly is functioning, no sound, or only an extremely faint sound, can be heard.
Scheme 57
The DCM (telematics transceiver) sends a mute signal to the stereo component amplifier assembly.
The stereo component amplifier assembly controls the volume according to the mute signal from the DCM (telematics transceiver).
Scheme 58
Each audio system component connected to the AVC-LAN (communication bus) transfers switch signals by the audio visual communication local area network.
If a short to +B or short to ground occurs in this AVC-LAN, the audio system will not function normally as communication is stopped.
This circuit is necessary for the Automatic Sound Levelizer (ASL) built into the stereo component amplifier assembly.
The Automatic Sound Levelizer (ASL) function automatically adjusts the audio system volume level in order to compensate for increased vehicle noise (vehicle noise tends to increase as vehicle speed increases). The ASL adjusts the volume level based upon vehicle speed signals that it receives from the combination meter assembly.
HINT
- A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter assembly. The signal is changed to a pulse signal at the transistor in the combination meter assembly. Each ECU controls the respective system based on the pulse signal.
- If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the following diagram will not operate normally.
This circuit is necessary for the Automatic Sound Levelizer (ASL) built into the stereo component amplifier assembly.
The Automatic Sound Levelizer (ASL) function automatically adjusts the audio system volume level in order to compensate for increased vehicle noise (vehicle noise tends to increase as vehicle speed increases). The ASL adjusts the volume level based upon vehicle speed signals that it receives from the combination meter assembly.
HINT
- A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter assembly. The signal is changed to a pulse signal at the transistor in the combination meter assembly. Each ECU controls the respective system based on the pulse signal.
- If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the following diagram will not operate normally.
This circuit is used when an incoming cellular phone voice in the "Bluetooth" handsfree system is received.
Scheme 59
- w/o Manual (SOS) Switch Using this circuit, the radio receiver assembly sends power to the map light assembly (telephone microphone assembly), and the map light assembly (telephone microphone assembly) sends microphone signals to the radio receiver assembly.
- w/ Manual (SOS) Switch Using this circuit, the DCM (telematics transceiver) sends power to the map light assembly (telephone microphone assembly), and the map light assembly (telephone microphone assembly) sends microphone signals to the radio receiver assembly via the DCM (telematics transceiver). The radio receiver assembly and map light assembly (telephone microphone assembly) are connected to each other using the microphone connection detection signal lines.
Scheme 60
The radio receiver assembly uses this circuit to communicate with the main body ECU (multiplex network body ECU) via a direct line. The main body ECU (multiplex network body ECU) uses this circuit to send an auto dimmer signal to the radio receiver assembly. The main body ECU (multiplex network body ECU) detects the position of the light control switch according to the resistance. When the light control switch is set to the head or tail position, the resistance between the head or tail terminal and body ground is below 1ohms. When the light control switch is set to the head or tail position, the main body ECU (multiplex network body ECU) sends an auto dimmer signal to the radio receiver assembly. When the radio receiver assembly receives an auto dimmer signal from the main body ECU (multiplex network body ECU), the radio receiver assembly causes the instrument panel illumination to be dimmed.
Scheme 61
This circuit provides power to the radio receiver assembly.
Scheme 62
This circuit provides power to the stereo component amplifier assembly.
Scheme 63
