1. PRECAUTIONS AND WORK DESCRIPTION The U880F automatic transaxle assembly does not have an oil filler tube and oil level gauge. When adding fluid, add fluid through the refill hole on the transaxle case. The fluid level can be adjusted by draining excess fluid (allowing excess fluid to overflow) through the No. 1 transmission oil filler tube of the transaxle housing sub-assembly. HINT: "Overflow" indicates the condition under which fluid comes out of the overflow plug hole. Before adjusting the fluid level, add the specified amount of fluid when the engine is cold and warm up the engine to circulate the fluid in the transaxle. Ensure that the fluid temperature is as specified and the engine is idling. The U880F automatic transaxle assembly requires Toyota Genuine ATF WS. The adjustment should be performed according to the procedures and notes.
2. WORK FLOW The adjustment should be performed according to the procedures referenced in the work flow below.
3. BEFORE FILLING TRANSAXLE WITH FLUID Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear of the vehicle is within +/- 1°). Remove the 2 bolts, clip and front fender apron seal LH.
4. PERFORM INITIAL FILLING NOTE: If the transaxle is hot (ATF temperature is high), wait until the fluid temperature becomes the same as the ambient temperature before starting the following procedure. (Recommended ATF temperature: around 20°C [68°F]) Remove the refill plug and gasket from the automatic transaxle assembly. NOTE: After performing any of the following operations, it is not necessary to perform the initial filling procedure. Proceed to the Add Specified Amount of Fluid procedure. Operations that do not require initial filling Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new automatic transaxle assembly with torque converter assembly (filled fluid parts) Using a T40 "TORX" socket wrench, remove the drain plug and O-ring from the automatic transaxle assembly. NOTE: If ATF comes out after removing the overflow plug, wait until the fluid flow slows and only drips come out. If ATF comes out, it is not necessary to perform the initial filling procedure. After checking the tightening torque of the overflow plug, temporarily tighten the drain plug. Using a 17 mm straight hexagon wrench, check that the overflow plug is tightened to the specified torque. Torque: 47 N*m (479 kgf*cm, 35 ft.*lbf) NOTE: If the overflow plug is not tightened to the specified torque, the amount of fluid cannot be precisely adjusted. Perform initial filling. Fill the transaxle through the refill hole until fluid begins to come out of the overflow plug hole. NOTE: Use Toyota Genuine ATF WS. Wait until the fluid flow slows and only drips come out. Using a T40 "TORX" socket wrench, temporarily install the O-ring and the drain plug to the automatic transaxle assembly. HINT: Reuse the old O-ring as the plug will be removed again to adjust the fluid level.
5. ADD SPECIFIED AMOUNT OF FLUID Fill the transaxle with the correct amount of fluid as listed in the table below. NOTE: Refill amount differs depending on the operation that was performed. Standard Capacity Performed Repair Fill Amount Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new automatic transaxle assembly with torque converter assembly (filled fluid parts) 0.5 liters (0.5 US qts., 0.4 Imp. qts.) Removal and installation of the drive shaft Removal and installation of the transaxle case oil seal Removal and installation of the transaxle side cover or oil drain 3.0 liters (3.2 US qts., 2.6 Imp. qts.) Removal and installation of the transmission valve body assembly Removal and installation of the automatic transaxle assembly (not including removal of the torque converter assembly) Removal and installation of the torque converter assembly (torque converter assembly reused) Installation of a new torque converter assembly 4.2 liters (4.4 US qts., 3.7 Imp. qts.) Temporarily install the gasket and refill plug to avoid fluid spillage. HINT: Reuse the old gasket as the plug will be removed again to adjust the fluid level. Lower the vehicle.
6. ADJUST FLUID TEMPERATURE When using the Techstream: HINT: The actual ATF temperature can be checked on the Data List using the Techstream. Connect the Techstream to the DLC3 with the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. Enter the following menus: Powertrain / ECT / Active Test / Connect the TC and TE1. Select the Active Test menu: Connect the TC and TE1 / ON. Select the Data List menu: A/T Oil Temperature 1. Check the ATF temperature. NOTE: If the fluid temperature is below 45°C (113°F), proceed to the next step. (Recommended ATF temperature: 35°C [95°F] or less) If the fluid temperature is 45°C (113°F) or more, turn the engine switch off and wait until the fluid temperature drops below 45°C (113°F). Depress and hold the brake pedal. Start the engine. Slowly move the shift lever from P to D, then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the step where terminal TC is first connected and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Select the Active Test menu: Connect the TC and TE1 / OFF. NOTE: Be sure that terminals TC and TE1 are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and TE1 activates engine idle speed control mode. In engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 RPM. Even after terminals TC and TE1 are disconnected, fluid temperature detection mode is active until the engine switch is turned off. Warm up the engine with the engine idling until the fluid temperature reaches the normal operating temperature (35 to 45°C [95 to 113°F]). Below Normal Operating Temperature Normal Operating Temperature Above Normal Operating Temperature 35°C or less (95°F or less) 35 to 45°C (95 to 113°F) 45°C or more (113°F or more) NOTE: If the fluid temperature is within the normal operating temperature range, immediately proceed to the Adjust Fluid Level procedure. If the fluid temperature is 45°C (113°F) or more, stop the engine and wait until the fluid temperature drops to 35°C (95°F) or less. Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. D SHIFT INDICATOR Below Normal Operating Temperature (35°C or less (95°F or less)) Normal Operating Temperature (35 to 45°C (95 to 113°F)) Above Normal Operating Temperature (45°C or more (113°F or more)) OFF ON Blinks TEXT IN ILLUSTRATION *a Turned Off *b Turned On *c Blinking When not using the Techstream: Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3 with the engine switch off. SST: 09843-18040 TEXT IN ILLUSTRATION *1 DLC3 Depress and hold the brake pedal. Start the engine. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. HINT: The indicator lights on the combination meter blink to indicate DTCs output when terminals TC and CG are connected. Slowly move the shift lever from P to D, then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the step where terminal TC is first connected and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Remove SST from terminals 13 (TC) and 4 (CG). SST: 09843-18040 NOTE: Be sure that terminals TC and CG are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and CG activates engine idle speed control mode. In engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 RPM. Even after terminals TC and CG are disconnected, fluid temperature detection mode is active until the engine switch is turned off. TEXT IN ILLUSTRATION *1 DLC3 Allow the engine to idle until the D shift indicator comes on again. D SHIFT INDICATOR Below Normal Operating Temperature (35°C or less (95°F or less)) Normal Operating Temperature (35 to 45°C (95 to 113°F)) Above Normal Operating Temperature (45°C or more (113°F or more)) OFF ON Blinks NOTE: If the D shift indicator is on, immediately proceed to the Adjust Fluid Level procedure. If the D shift indicator blinks, stop the engine and wait until the fluid temperature drops to 35°C (95°F) or less (the indicator goes off). Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. Fluid filling procedure should be performed when the D shift indicator is on (the fluid temperature is within the normal operating temperature range). TEXT IN ILLUSTRATION *a Turned Off *b Turned On *c Blinking
7. ADJUST FLUID LEVEL WARNING: Use caution while the engine is idling and the radiator fan is operating. Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear and side to side of the vehicle is within +/- 1°). Adjust the fluid level. Using a T40 "TORX" socket wrench, remove the drain plug and O-ring from the automatic transaxle assembly. WARNING: Be careful as the fluid coming out of the overflow plug hole is hot. Check the amount of fluid that comes out of the overflow plug hole. NOTE: If only a small amount of fluid (approximately 1 cc) comes out of the overflow plug hole, then only fluid remaining in the No. 1 transmission oil filler tube has come out. This condition is not considered as overflow, so it is necessary to add fluid. If the amount of fluid that comes out of the overflow plug hole is large, wait until the fluid flow slows and only drips come out. If no fluid comes out of the overflow plug hole, remove the refill plug and gasket. Then add transaxle fluid through the refill hole until fluid comes out of the overflow plug hole. Wait until the fluid flow slows and only drips come out. NOTE: Use Toyota Genuine ATF WS. Check that the fluid flow has slowed and only drips come out. HINT: The fluid flow will not completely stop because the fluid expands as its temperature increases. Using a T40 "TORX" socket wrench, install a new O-ring and the drain plug to the automatic transaxle assembly. Torque: 7.4 N*m (75 kgf*cm, 65 in.*lbf) Install the refill plug to the automatic transaxle assembly with a new gasket. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf) Lower the vehicle. Turn the engine switch off. HINT: Turning the engine switch off exits fluid temperature detection mode. Disconnect the Techstream from the DLC3 (when using the Techstream).
8. AFTER FILLING TRANSAXLE Lift the vehicle. Clean each part. Check for fluid leaks. Install the front fender apron seal LH with the 2 bolts and clip. Lower the vehicle.
