Automatic Transmission (U880F) (Diagnostic Codes & Circuit Tests): Other Lexus RX III рестайлинг

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

Scheme 1275

PROCEDURE

1. CHECK DTC OUTPUT (SFI SYSTEM) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to No DTC A P0560 is output (SFI system) B B --> See step 4 A: Go to next step
2. INSPECT TCM (POWER SOURCE, GROUND) Disconnect the A73 TCM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A73-6 (BATT) - A73-2 (E1) Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A73-2 (E1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A73 TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (TCM - BATTERY, BODY GROUND) OK: Go to next step
3. REPLACE TCM Replace the TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000) . NEXT --> See step 5
4. GO TO DTC P0560 (SFI SYSTEM). Refer to «DTC P0560: System Voltage»(ref-602711-S24691284862014030500000)
5. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

Scheme 1276

1. READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . Turn the engine switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Select the following menu items: Powertrain / ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P062F B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE [03/2012 - ]»(ref-602551-S37588723142014030500000)
3. REPLACE TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000)

1. When either condition below is met: Condition (A) or (B) Condition (A) Any two of the following conditions are met: Conditions 1, 2 and 3 1. One of the following condition is met: Conditions (a) or (b) (a). P position switch ON (b). N position switch ON 2. R position switch ON 3. D position switch ON Condition (B) When all conditions below are met: P position switch OFF N position switch OFF R position switch OFF D position switch OFF

COMPONENT OPERATING RANGE

Scheme 1277

ALL

CONDITION A

CONDITION B

CONDITION C

CONDITION D

CONDITION E

HINT

*1: Following conditions are met

*2: Time after engine start except for continuing

*3: Driving distance is cleared when following condition met

*4: Minimum select of following IAT

CONDITION A, B, C AND D

CONDITION E

Scheme 1278

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0711) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to Only P0711 is output A P0711 and P0713 are output B P0711 and other DTC C HINT: If any other codes besides P0711 are output, perform troubleshooting for those DTCs first. B --> See step 7 C --> See step 5 A: Go to next step
2. CHECK TRANSMISSION FLUID LEVEL Check the transmission fluid level. Refer to «ADJUSTMENT [07/2012 - ]»(ref-602718-S15100388022014030500000) . OK Automatic transmission fluid level is correct. NG --> ADJUST FLUID LEVEL OK: Go to next step
3. CHECK TRANSMISSION WIRE CIRCUIT Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-12 (THO1) - A74-13 (E2) ATF Temperature 10°C (50°F) 5 to 8 kohms ATF Temperature 110°C (230°F) 0.22 to 0.28 kohms A74-13 (E2) - Body ground Always 10 kohms or higher A74-12 (THO1) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) HINT: If the resistance is out of the specified range with the ATF temperature shown in the table below, the driveability of the vehicle may decrease. Tester Connection ATF Temperature Specified Condition A74-12 (THO1) - A74-13 (E2) 25°C (77°F) 2.5 to 4.5 kohms NG --> See step 4 OK --> See step 8
4. CHECK HARNESS AND CONNECTOR (TCM - TRANSMISSION WIRE) Disconnect the transmission wire connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-8 (OIL) - A74-12 (THO1) Always Below 1 ohms D43-9 (E2) - A74-13 (E2) Always Below 1 ohms D43-8 (OIL) or A74-12 (THO1) - Body ground Always 10 kohms or higher D43-9 (E2) or A74-13 (E2) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
6. REPLACE TRANSMISSION WIRE (ATF TEMPERATURE SENSOR). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
7. GO TO DTC (P0713). Refer to «DTC P0712: Transmission Fluid Temperature Sensor "A" Circuit Low Input; DTC P0713: Transmission Fluid Temperature Sensor "A" Circuit High Input»(ref-602721-S36076887772014030500000)
8. REPLACE TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000)

1. P0712: RANGE CHECK (LOW RESISTANCE) The monitor will run whenever these DTCs are not present. None Battery voltage 8 V or more Engine switch on (IG)

P0713: Range check (High resistance)

1. One of the following conditions is met: Condition (A) or (B) CONDITION (A) Engine coolant temperature (ECT) or intake air temperature (IAT) at engine start -29.375°C (-20.875°F) or less Time after engine start 358 seconds or more ECT sensor circuit fail (P0115, P0117, P0118) Not detected IAT sensor circuit fail (P0112, P0113) Not detected CONDITION (B) Engine coolant temperature (ECT) or intake air temperature (IAT) at engine start More than -29.375°C (-20.875°F) Time after engine start 10 seconds or more ECT sensor circuit fail (P0115, P0117, P0118) Not detected IAT sensor circuit fail (P0112, P0113) Not detected

P0712: RANGE CHECK (LOW RESISTANCE)

P0713: RANGE CHECK (HIGH RESISTANCE)

1. CHECK TRANSMISSION WIRE CIRCUIT (ATF TEMPERATURE SENSOR) Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-12 (THO1) - A74-13 (E2) Always 79 ohms to 156 kohms A74-13 (E2) - Body ground and other terminals Always 10 kohms or higher A74-12 (THO1) - Body ground and other terminals Always 10 kohms or higher TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) HINT: If the resistance is out of the specified range with the ATF temperature shown in the table below, the driveability of the vehicle may decrease. ATF Temperature Specified Condition 10°C (50°F) 5 to 8 kohms 25°C (77°F) 2.5 to 4.5 kohms 110°C (230°F) 0.22 to 0.28 kohms NG --> See step 3 OK: Go to next step
2. REPLACE TCM Replace the TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000) . NEXT --> See step 5
3. CHECK HARNESS AND CONNECTOR (TCM - TRANSMISSION WIRE) Disconnect the transmission wire connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-8 (OIL) - A74-12 (THO1) Always Below 1 ohms D43-9 (E2) - A74-13 (E2) Always Below 1 ohms D43-8 (OIL) or A74-12 (THO1) - Body ground Always 10 kohms or higher D43-9 (E2) or A74-13 (E2) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
4. REPLACE TRANSMISSION WIRE (ATF TEMPERATURE SENSOR). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
5. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

P0715

P0717

P0715

P0717

Scheme 1279

GO and STOP are defined as follows

THE STOP LIGHT SWITCH REMAINS ON DURING GO AND STOP 5 TIMES.

Scheme 1280

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D), (E) or (F) OFF MALFUNCTION (A) TCM indicated pressure value of SL1 1600 kPa (16.3 kgf/cm 2 , 232 psi) or more TCM selected gear 1st Following conditions is met: (a), (b), (c) or (d) (a) (1.43590 x Output speed - 0.52381 x Input speed) - 0.51282 x Turbine speed Less than -250 rpm (b) (1.43590 x Output speed - 0.52381 x Input speed) - 0.51282 x Turbine speed 250 rpm or more (c) (1.43590 x Output speed + 0.52381 x Input speed) - 0.51282 x Turbine speed Less than -250 rpm (d) (1.43590 x Output speed + 0.52381 x Input speed) - 0.51282 x Turbine speed 250 rpm or more Calculated load value 7.75% or more Throttle valve opening angle 2% or more OFF MALFUNCTION (B) TCM indicated pressure value of SL1 1600 kPa (16.3 kgf/cm 2 , 232 psi) or more TCM selected gear 2nd Input speed (NC3) Less than 50 rpm Calculated load value 7.75% or more Throttle valve opening angle 2% or more OFF MALFUNCTION (C) TCM indicated pressure value of SL1 1600 kPa (16.3 kgf/cm 2 , 232 psi) or more TCM selected gear 3rd Turbine speed / Input speed (NT/NC3) 1.9 or more Turbine speed / Input speed (NT/NC3) Less than 2.0 Calculated load value when A/C off 7.75% or more when A/C on 7.75% or more Throttle valve opening angle 2% or more OFF MALFUNCTION (D) TCM indicated pressure value of SL1 1600 kPa (16.3 kgf/cm 2 , 232 psi) or more TCM selected gear 4th Turbine speed / Input speed (NT/NC3) 0.95 or more Turbine speed / Input speed (NT/NC3) Less than 1.05 Calculated load value 7.75% or more Throttle valve opening angle 2% or more OFF MALFUNCTION (E) TCM indicated pressure value of SL1 1600 kPa (16.3 kgf/cm 2 , 232 psi) or more TCM selected gear 5th Following conditions is met: (a), (b), (c) or (d) (a) (1.43590 x Output speed - 0.52381 x Input speed) - 0.51282 x Turbine speed Less than -250 rpm (b) (1.43590 x Output speed - 0.52381 x Input speed) - 0.51282 x Turbine speed More than 250 rpm (c) (1.43590 x Output speed + 0.52381 x Input speed) - 0.51282 x Turbine speed Less than -250 rpm (d) (1.43590 x Output speed + 0.52381 x Input speed) - 0.51282 x Turbine speed More than 250 rpm Calculated load value 7.75% or more Throttle valve opening angle 2% or more OFF MALFUNCTION (F) TCM selected gear Less than 5th Following conditions is met: (a), (b), (c), (d), (e) or (f) (a) Input Torque when TCM selected 1st Specified value (b) Input Torque when TCM selected 2nd Specified value (c) Input Torque when TCM selected 3rd Specified value (d) Input Torque when TCM selected 4th Specified value (e) Input Torque when TCM selected 5th Specified value (f) Time after following condition met Less than 0.5 sec. Input Torque when TCM selected 1st Specified value Input Torque when TCM selected 2nd Specified value Input Torque when TCM selected 3rd Specified value Input Torque when TCM selected 4th Specified value Input Torque when TCM selected 5th Specified value

ON malfunction

1. Following conditions is met: (A), (B) or (C) ON MALFUNCTION (A) TCM selected gear 6th Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) Calculated load value 7.75% or more ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more ON MALFUNCTION (B) TCM selected gear 7th Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) Calculated load value 7.75% or more ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more ON MALFUNCTION (C) TCM selected gear 8th Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) Calculated load value 7.75% or more ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D), (E) or (F) OFF MALFUNCTION (A) Turbine speed - Output speed (NT - NO) x 1st gear ratio 400 rpm or more OFF MALFUNCTION (B) Turbine speed - Output speed (NT - NO) x 2nd gear ratio 400 rpm or more OFF MALFUNCTION (C) Turbine speed - Output speed (NT - NO) x 3rd gear ratio 400 rpm or more OFF MALFUNCTION (D) Turbine speed - Output speed (NT - NO) x 4th gear ratio 400 rpm or more OFF MALFUNCTION (E) Turbine speed - Output speed (NT - NO) x 5th gear ratio 400 rpm or more OFF MALFUNCTION (F) Shift solenoid valve SLT ON malfunction

ON malfunction

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ALL

CONDITION (A)

CONDITION (B)

CONDITION (C)

When one of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A) AND (B)

CONDITION (C)

Scheme 1281

ALL

OFF MALFUNCTION

OFF malfunction

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.712 or more and 1.962 or less (when output speed less than 400 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ALL

ON malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON malfunction (C)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 4.157 or more and 8.529 or less (when output speed less than 130 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 1st gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 130 rpm or more)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

1. CHECK DTC OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to DTC P0752 and DTC P0746, P0776, P0796, P2714 and/or P2808 are output. A Only DTC P0752 is output. B DTCs other than P0746, P0752, P0776, P0796, P2714 and P2808 are also output. C HINT: If DTCs other than P0746, P0752, P0776, P0796, P2714 and P2808 are also output, perform troubleshooting for those DTCs first. B --> See step 3 C --> See step 10 A: Go to next step
2. CLEAR DTC AND PERFORM STALL SPEED TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . HINT: Write down the currently output DTCs before clearing them. Perform the stall speed test. Refer to «HYDRAULIC TEST [07/2012 - ]»(ref-602573-S04603323302014030500000) . Result Test Condition Proceed to Stall speed test can be performed A Stall speed test cannot be performed B B --> See step 5 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE S1 Remove shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S1 connector terminal - Shift solenoid valve S1 body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve S1 Connect a battery positive (+) lead to the terminal of the solenoid valve connector, and a negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 9 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE (SL1, SL2, SL3 AND SL4) Remove the shift solenoid valve SL1, SL2, SL3 and SL4. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL1 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL3 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL1, SL2, SL3 and SL4 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 15 OK: Go to next step
5. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 11 OK: Go to next step
6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 12 OK: Go to next step
7. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter operates normally. NG --> See step 14 OK: Go to next step
8. REPLACE AUTOMATIC TRANSAXLE ASSEMBLY Replace the automatic transaxle assembly. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000) . NEXT --> See step 13
9. REPLACE SHIFT SOLENOID VALVE S1. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
11. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
12. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
13. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)
14. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)
15. REPLACE SHIFT SOLENOID VALVE (SL1, SL2, SL3 OR SL4). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)

ALL

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D), (E) or (F)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D), (E) or (F)

ON malfunction (A)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed less than 600 rpm)

ON malfunction (B)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ON malfunction (C)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ON malfunction (D)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 0.708 or more and 0.833 or less (when output speed less than 800 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 7th gear ratio (Actual 7th gear) -50 rpm or more and 50 rpm or less (when output speed 800 rpm or more)

ON malfunction (E)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ON malfunction (F)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

1. CHECK OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to DTC P0776 and DTC P0746, P0752, P0796, P2714 and/or P2817 are output. A Only DTC P0776 is output. B DTCs other than P0746, P0752, P0776, P0796, P2714 and P2817 are also output. C HINT: If DTCs other than P0746, P0752, P0776, P0796, P2714 and P2817 are also output, perform troubleshooting for those DTCs first. B --> See step 3 C --> See step 11 A: Go to next step
2. CLEAR DTC AND PERFORM STALL SPEED TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . HINT: Write down the currently output DTCs before clearing them. Perform the stall speed test. Refer to «HYDRAULIC TEST [07/2012 - ]»(ref-602573-S04603323302014030500000) . Result Test Condition Proceed to Stall speed test can be performed A Stall speed test cannot be performed B B --> See step 5 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 AND SL5) Remove shift solenoid valve SL1, SL2, SL3, SL4 and SL5. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL1 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL3 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL5 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL1, SL2, SL3, SL4 and SL5 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 9 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S1 Remove shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S1 connector terminal - Shift solenoid valve S1 body 20°C (68°F) 11 to 15 ohms Connect a battery positive (+) lead to the terminal of the solenoid valve connector, and a negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. TEXT IN ILLUSTRATION *1 Shift Solenoid Valve S1 NG --> See step 13 OK: Go to next step
5. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 14 OK: Go to next step
6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 10 OK: Go to next step
7. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter operates normally. NG --> See step 15 OK: Go to next step
8. REPLACE AUTOMATIC TRANSAXLE ASSEMBLY Replace the automatic transaxle assembly. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000) . NEXT --> See step 12
9. REPLACE SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 OR SL5). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
10. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
11. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
12. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)
13. REPLACE SHIFT SOLENOID VALVE S1. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
14. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
15. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)

ALL

CONDITION (A)

CONDITION (B)

CONDITION (C)

When one of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A) AND (B)

CONDITION (C)

Scheme 1282

1. CHECK SHIFT SOLENOID VALVE SL2 CIRCUIT (TCM - TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL2)) Disconnect the A74 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-4 (SL2+) - A74-14 (SL2-) 20°C (68°F) 5.0 to 5.6 ohms A74-4 (SL2+) - Body ground and other terminals Always 10 kohms or higher A74-14 (SL2-) - Body ground and other terminals Always 10 kohms or higher TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A74 TCM connector. NG --> See step 3 OK: Go to next step
2. REPLACE TCM See step 3 NEXT --> See step 7
3. CHECK HARNESS AND CONNECTOR (TCM - TRANSMISSION WIRE) Disconnect the A74 TCM connector. Disconnect the D43 transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-28 (SL2+) - A74-4 (SL2+) Always Below 1 ohms D43-29 (SL2-) - A74-14 (SL2-) Always Below 1 ohms D43-28 (SL2+) or A74-4 (SL2+) - Body ground Always 10 kohms or higher D43-29 (SL2-) or A74-14 (SL2-) - Body ground Always 10 kohms or higher D43-28 (SL2+) - D43-29 (SL2-) Always 10 kohms or higher Connect the A74 TCM connector. Connect the D43 transmission wire connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SL2 Remove shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL2 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 6 OK --> See step 5
5. REPLACE TRANSMISSION WIRE. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
6. REPLACE SHIFT SOLENOID VALVE SL2. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
7. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

ALL

P0791

P0793

P0791

P0793

Scheme 1283

1. INSPECT TCM (NC SENSOR CIRCUIT INSPECTION) Disconnect the A74 TCM connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Condition Condition Specified Condition A74-23 (NCB) - Body ground Engine switch on (IG) 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Condition Condition Specified Condition A74-22 (NCO) - Body ground Always 99 to 101 ohms TEXT IN ILLUSTRATION *a Component without harness connected (TCM) Connect the TCM connector. NG --> See step 4 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TCM - TRANSMISSION WIRE) Disconnect the transmission wire connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Condition Condition Specified Condition D43-21 (NCB) - A74-23 (NCB) Always Below 1 ohms D43-22 (NCO) - A74-22 (NCO) Always Below 1 ohms D43-21 (NCB) or A74-23 (NCB) - Body ground Always 10 kohms or higher D43-22 (NCO) or A74-22 (NCO) - Body ground Always 10 kohms or higher Connect the transmission wire connector. Connect the TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT TRANSMISSION WIRE Disconnect the transmission wire connector. Disconnect the transmission revolution sensor (NC) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Condition Condition Specified Condition 2 (NCB) sensor side - 21 (NCB) TCM side Always Below 1 ohms 1 (NCO) sensor side - 22 (NCO) TCM side Always Below 1 ohms 2 (NCB) sensor side - Body ground and other terminals Always 10 kohms or higher 1 (NCO) sensor side - Body ground and other terminals Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Transmission Revolution Sensor (NC)) *b Component without harness connected (Transmission Wire) Connect the transmission wire connector. Connect the transmission revolution sensor (NC) connector. NG --> See step 6 OK --> See step 5
4. REPLACE TCM Replace the TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000) . NEXT --> See step 7
5. REPLACE TRANSMISSION REVOLUTION SENSOR (NC). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S27372675032014030500000)
6. REPLACE TRANSMISSION WIRE. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
7. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

ALL

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D), (E) or (F)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF malfunction (A)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 4.157 or more and 8.529 or less (when output speed less than 130 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 1st gear ratio (Actual 1st gear) -50 rpm or more and 50 rpm or less (when output speed 130 rpm or more)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D), (E) or (F)

ON malfunction (A)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.712 or more and 1.962 or less (when output speed less than 400 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more)

ON malfunction (B)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.712 or more and 1.962 or less (when output speed less than 400 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more)

ON malfunction (C)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.712 or more and 1.962 or less (when output speed less than 400 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more)

ON malfunction (D)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 0.708 or more and 0.833 or less (when output speed less than 800 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 7th gear ratio (Actual 7th gear) -50 rpm or more and 50 rpm or less (when output speed 800 rpm or more)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

1. CHECK OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to DTC P0796 and DTC P0746, P0752, P0776, P2714, P2808 and/or P2817 are output. A Only DTC P0796 is output. B DTCs other than P0746, P0752, P0776, P0796, P2714, P2808 and P2817 are also output. C HINT: If DTCs other than P0746, P0752, P0776, P0796, P2714, P2808 and P2817 are also output, perform troubleshooting for those DTCs first. B --> See step 3 C --> See step 11 A: Go to next step
2. CLEAR DTC AND PERFORM STALL SPEED TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . HINT: Write down the currently output DTCs before clearing them. Perform the stall speed test. Refer to «HYDRAULIC TEST [07/2012 - ]»(ref-602573-S04603323302014030500000) . Result Test Condition Proceed to Stall speed test can be performed A Stall speed test cannot be performed B B --> See step 5 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 AND SL5) Remove shift solenoid valve SL1, SL2, SL3, SL4 and SL5. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL1 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL3 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL5 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL1, SL2, SL3, SL4 and SL5 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 9 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S1 Remove shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S1 connector terminal - Shift solenoid valve S1 body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve S1 Connect a battery positive (+) lead to the terminal of the solenoid valve connector, and a negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 13 OK: Go to next step
5. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 14 OK: Go to next step
6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 10 OK: Go to next step
7. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter operates normally. NG --> See step 15 OK: Go to next step
8. REPLACE AUTOMATIC TRANSAXLE ASSEMBLY Replace the automatic transaxle assembly. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000) . NEXT --> See step 12
9. REPLACE SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 OR SL5). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
10. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
11. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
12. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)
13. REPLACE SHIFT SOLENOID VALVE S1. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
14. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
15. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)

ALL

CONDITION (A)

CONDITION (B)

CONDITION (C)

When one of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A) AND (B)

CONDITION (C)

Scheme 1284

ALL

P0973: RANGE CHECK (LOW RESISTANCE)

P0974: RANGE CHECK (HIGH RESISTANCE)

P0973

P0974

Scheme 1285

ALL

P0976: RANGE CHECK (LOW RESISTANCE)

P0977: RANGE CHECK (HIGH RESISTANCE)

P0976

P0977

Scheme 1286

1. CHECK SHIFT SOLENOID VALVE S2 CIRCUIT (TCM - TRANSMISSION WIRE (SHIFT SOLENOID VALVE S2)) Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-24 (S2) - Body ground 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the TCM connector. NG --> See step 3 OK: Go to next step
2. REPLACE TCM Replace the TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000) . NEXT --> See step 7
3. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - TCM) Disconnect the transmission wire connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-7 (S2) - A74-24 (S2) Always Below 1 ohms D43-7 (S2) or A74-24 (S2) - Body ground Always 10 kohms or higher Connect the transmission wire connector. Connect the TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S2 Remove the shift solenoid valve S2. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S2 connector - Shift solenoid valve S2 body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *1 Shift solenoid valve S2 Connect a battery positive (+) lead to the terminal of the solenoid valve connector, and a negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 6 OK --> See step 5
5. REPLACE TRANSMISSION WIRE. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
6. REPLACE SHIFT SOLENOID VALVE S2. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
7. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

ALL

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

ON MALFUNCTION (G)

ON MALFUNCTION (H)

ON malfunction

1. When one of the following conditions is met: ON malfunction (A), (B), (C), (D), (E), (F), (G), (H), (I), (J), (K), (L), (M), (N), (O), (P) or (Q)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

ON MALFUNCTION (G)

ON MALFUNCTION (H)

ON MALFUNCTION (I)

ON MALFUNCTION (J)

ON MALFUNCTION (K)

ON MALFUNCTION (L)

ON MALFUNCTION (M)

ON MALFUNCTION (N)

ON MALFUNCTION (O)

ON MALFUNCTION (P)

ON MALFUNCTION (Q)

1. CHECK OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to DTC P2714 and DTC P0746, P0752, P0776, P0796 and/or P2817 are output. A Only DTC P2714 is output. B DTCs other than P0746, P0752, P0776, P0796, P2714 and P2817 are also output. C HINT: If DTCs other than P0746, P0752, P0776, P0796, P2714 and P2817 are also output, perform troubleshooting for those DTCs first. B --> See step 5 C --> See step 11 A: Go to next step
2. CLEAR DTC AND PERFORM STALL SPEED TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . HINT: Write down the currently output DTCs before clearing them. Perform the stall speed test. Refer to «HYDRAULIC TEST [07/2012 - ]»(ref-602573-S04603323302014030500000) . Result Test Condition Proceed to Stall speed test can be performed A Stall speed test cannot be performed B B --> See step 5 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 AND SL5) Remove shift solenoid valve SL1, SL2, SL3, SL4 and SL5. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL1 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL3 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL5 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL1, SL2, SL3, SL4 and SL5 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 9 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S1 Remove shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S1 connector terminal - Shift solenoid valve S1 body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve S1 Connect a battery positive (+) lead to the terminal of the solenoid valve connector, and a negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 13 OK: Go to next step
5. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 14 OK: Go to next step
6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 10 OK: Go to next step
7. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter operates normally. NG --> See step 15 OK: Go to next step
8. REPLACE AUTOMATIC TRANSAXLE ASSEMBLY Replace the automatic transaxle assembly. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000) . NEXT --> See step 12
9. REPLACE SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 OR SL5). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
10. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
11. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
12. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)
13. REPLACE SHIFT SOLENOID VALVE S1. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
14. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
15. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)

ALL

MALFUNCTION (A)

MALFUNCTION (B)

MALFUNCTION (C)

MALFUNCTION (D)

MALFUNCTION (A) AND (B)

MALFUNCTION (C)

MALFUNCTION (D)

Scheme 1287

1. CHECK SHIFT SOLENOID VALVE SLT CIRCUIT (TCM - TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLT)) Disconnect the A74 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-1 (SLT+) - A74-7 (SLT-) 20°C (68°F) 5.0 to 5.6 ohms A74-1 (SLT+) - Body ground and other terminals Always 10 kohms or higher A74-7 (SLT-) - Body ground and other terminals Always 10 kohms or higher TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A74 TCM connector. NG --> See step 3 OK: Go to next step
2. REPLACE TCM See step 3 NEXT --> See step 7
3. CHECK HARNESS AND CONNECTOR (TCM - TRANSMISSION WIRE) Disconnect the A74 TCM connector. Disconnect the D43 transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-3 (SLT+) - A74-1 (SLT+) Always Below 1 ohms D43-4 (SLT-) - A74-7 (SLT-) Always Below 1 ohms D43-3 (SLT+) or A74-1 (SLT+) - Body ground and other terminals Always 10 kohms or higher D43-4 (SLT-) or A74-7 (SLT-) - Body ground and other terminals Always 10 kohms or higher Connect the A74 TCM connector. Connect the D43 transmission wire connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SLT Remove shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 6 OK --> See step 5
5. REPLACE TRANSMISSION WIRE. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
6. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
7. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

ALL

1. When either condition below is met: Condition (1) or (2)

Condition (1)

1. When one of the following conditions is met: Condition (a), (b), (c), (d), (e), (f), (g) or (h) CONDITION (A) Turbine speed / Output speed (NT / NO) (Actual 1st gear) 4.157 or more and 8.529 or less (when output speed less than 130 rpm) CONDITION (B) Turbine speed / Output speed (NT / NO) (Actual 2nd gear) 2.549 or more and 3.049 or less (when output speed less than 200 rpm) CONDITION (C) Turbine speed / Output speed (NT / NO) (Actual 3rd gear) 1.712 or more and 1.962 or less (when output speed less than 400 rpm) CONDITION (D) Turbine speed / Output speed (NT / NO) (Actual 4th gear) 1.301 or more and 1.468 or less (when output speed less than 600 rpm) CONDITION (E) Turbine speed / Output speed (NT / NO) (Actual 5th gear) 1.067 or more and 1.233 or less (when output speed less than 600 rpm) CONDITION (F) Turbine speed / Output speed (NT / NO) (Actual 6th gear) 0.88 or more and 1.004 or less (when output speed less than 800 rpm) CONDITION (G) Turbine speed / Output speed (NT / NO) (Actual 7th gear) 0.708 or more and 0.833 or less (when output speed less than 800 rpm) CONDITION (H) Turbine speed / Output speed (NT / NO) (Actual 8th gear) 0.596 or more and 0.696 or less (when output speed less than 1000 rpm)

Condition (2)

1. When all conditions below are met: Condition (a), (b), (c), (d), (e), (f), (g) and (h) CONDITION (A) Turbine speed - Output speed (NT - NO) x 1st gear ratio (Actual 1st gear) -50 or more and 50 or less (when output speed less than 130 rpm) CONDITION (B) Turbine speed - Output speed (NT - NO) x 2nd gear ratio (Actual 2nd gear) -50 or more and 50 or less (when output speed less than 200 rpm) CONDITION (C) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 or more and 50 or less (when output speed less than 400 rpm) CONDITION (D) Turbine speed - Output speed (NT - NO) x 4th gear ratio (Actual 4th gear) -50 or more and 50 or less (when output speed less than 600 rpm) CONDITION (E) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 or more and 50 or less (when output speed less than 600 rpm) CONDITION (F) Turbine speed - Output speed (NT - NO) x 6th gear ratio (Actual 6th gear) -50 or more and 50 or less (when output speed less than 800 rpm) CONDITION (G) Turbine speed - Output speed (NT - NO) x 7th gear ratio (Actual 7th gear) -50 or more and 50 or less (when output speed less than 800 rpm) CONDITION (H) Turbine speed - Output speed (NT - NO) x 8th gear ratio (Actual 8th gear) -50 or more and 50 or less (when output speed less than 1000 rpm)

OFF MALFUNCTION

ON MALFUNCTION

OFF MALFUNCTION

ON MALFUNCTION

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P2757) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to Only "P2757" is output A "P2757" and other DTCs are output B HINT: If any other codes besides "P2757" are output, perform troubleshooting for those DTCs first. B --> See step 6 A: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SLU Remove shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLU Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 7 OK: Go to next step
3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 8 OK: Go to next step
4. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter operates normally. NG --> See step 9 OK: Go to next step
5. REPLACE AUTOMATIC TRANSAXLE ASSEMBLY Replace the automatic transaxle assembly. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000) . NEXT --> See step 10
6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
7. REPLACE SHIFT SOLENOID VALVE SLU. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
8. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
9. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)
10. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

ALL

CONDITION (A)

CONDITION (B)

CONDITION (C)

When one of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A) AND (B)

CONDITION (C)

Scheme 1288

1. CHECK SHIFT SOLENOID VALVE SLU CIRCUIT (TCM - TRANSMISSION WIRE (SHIFT SOLENOID VALVE SLU)) Disconnect the A74 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-2 (SLU+) - A74-8 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms A74-2 (SLU+) or A74-8 (SLU-) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A74 TCM connector. NG --> See step 3 OK: Go to next step
2. REPLACE TCM See step 3 NEXT --> See step 5
3. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - TCM) Disconnect the D43 transmission wire connector. Disconnect the A74 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-13 (SLU+) - A74-2 (SLU+) Always Below 1 ohms D43-14 (SLU-) - A74-8 (SLU-) Always Below 1 ohms D43-13 (SLU+) or A74-2 (SLU+) - Body ground Always 10 kohms or higher D43-14 (SLU-) or A74-8 (SLU-) - Body ground Always 10 kohms or higher D43-13 (SLU+) - D43-14 (SLU-) Always 10 kohms or higher Connect the D43 transmission wire connector. Connect the A74 TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLU - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift solenoid valve SLU Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes operating sound. NG --> See step 7 OK --> See step 6
5. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)
6. REPLACE TRANSMISSION WIRE. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
7. REPLACE SHIFT SOLENOID VALVE SLU. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)

P2765

P2767

P2765

P2767

Scheme 1289

ALL

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF MALFUNCTION (A)

1. Count up time (*1) stops when following conditions met: (a) and ((b) or (c)) HINT: *1: Duration (0.5 sec.) CONDITION (A) Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more CONDITION (B) Turbine speed / Output speed (NT / NO) Following conditions met 1.712 or more 1.962 or less (when output speed less than 400 rpm) CONDITION (C) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more)

OFF MALFUNCTION (B)

1. Count up time (*2) stops when following conditions met: (a) and ((b) or (c)) or (d) and ((e) or (f)) HINT: *2: Duration (0.5 sec.) CONDITION (A) Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more CONDITION (B) Turbine speed / Output speed (NT / NO) Following conditions met 1.067 or more 1.233 or less (when output speed less than 600 rpm) CONDITION (C) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more) CONDITION (D) Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more TCM indicate pressure value of SLT 320 kPa (3.3 kgf/cm2, 46 psi) or more CONDITION (E) Turbine speed / Output speed (NT / NO) Following conditions met 1.712 or more 1.962 or less (when output speed less than 400 rpm) CONDITION (F) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D), (E), (F), (G), (H), (I) or (J)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

ON MALFUNCTION (G)

ON MALFUNCTION (H)

ON MALFUNCTION (I)

ON MALFUNCTION (J)

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF malfunction (C)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 4.157 or more and 8.529 or less (when output speed less than 130 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 1st gear ratio (Actual 1st gear) -50 rpm or more and 50 rpm or less (when output speed 130 rpm or more)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B), (C), (D), (E), (F), (G), (H), (I) or (J)

ON malfunction (A)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.301 or more and 1.468 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 4th gear ratio (Actual 4th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ON malfunction (B)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.301 or more and 1.468 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 4th gear ratio (Actual 4th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ON malfunction (C)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.301 or more and 1.468 or less (when output speed less than 600 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 4th gear ratio (Actual 4th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more)

ON malfunction (D)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 0.88 or more and 1.004 or less (when output speed less than 800 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 6th gear ratio (Actual 6th gear) -50 rpm or more and 50 rpm or less (when output speed 800 rpm or more)

ON malfunction (E)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 0.88 or more and 1.004 or less (when output speed less than 800 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 6th gear ratio (Actual 6th gear) -50 rpm or more and 50 rpm or less (when output speed 800 rpm or more)

ON malfunction (F)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 0.88 or more and 1.004 or less (when output speed less than 800 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 6th gear ratio (Actual 6th gear) -50 rpm or more and 50 rpm or less (when output speed 800 rpm or more)

ON malfunction (G)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 1.712 or more and 1.962 or less (when output speed less than 400 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more)

ON MALFUNCTION (H)

ON MALFUNCTION (I)

ON MALFUNCTION (J)

1. CHECK OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to DTC P2808 and DTC P0746, P0751, P0752, P0776, P0796, P2714 and/or P2817 are output. A Only DTC P2808 is output. B DTCs other than P0746, P0751, P0752, P0776, P0796, P2714, P2808 and P2817 are also output. C HINT: If DTCs other than P0746, P0751, P0752, P0776, P0796, P2714 and P2817 are also output, perform troubleshooting for those DTCs first. B --> See step 3 C --> See step 11 A: Go to next step
2. CLEAR DTC AND PERFORM STALL SPEED TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . HINT: Write down the currently output DTCs before clearing them. Perform the stall speed test. Refer to «HYDRAULIC TEST [07/2012 - ]»(ref-602573-S04603323302014030500000) . Result Test Condition Proceed to Stall speed test can be performed A Stall speed test cannot be performed B B --> See step 5 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 AND SL5) Remove shift solenoid valve SL1, SL2, SL3, SL4 and SL5. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL1 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL3 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL5 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL1, SL2, SL3, SL4 and SL5 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 9 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S1 Remove shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Shift solenoid valve S1 connector terminal - Shift solenoid valve S1 body 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve S1 Connect a battery positive (+) lead to the terminal of the solenoid valve connector, and a negative (-) lead to the solenoid body. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 13 OK: Go to next step
5. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 14 OK: Go to next step
6. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 10 OK: Go to next step
7. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter operates normally. NG --> See step 15 OK: Go to next step
8. REPLACE AUTOMATIC TRANSAXLE ASSEMBLY Replace the automatic transaxle assembly. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000) . NEXT --> See step 12
9. REPLACE SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 OR SL5). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
10. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
11. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
12. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)
13. REPLACE SHIFT SOLENOID VALVE S1. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
14. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
15. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)

ALL

CONDITION (A)

CONDITION (B)

CONDITION (C)

When one of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A) AND (B)

CONDITION (C)

Scheme 1290

1. CHECK SHIFT SOLENOID VALVE SL4 CIRCUIT (TCM - TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL4)) Disconnect the A74 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A74-17 (SL4+) - A74-16 (SL4-) 20°C (68°F) 5.0 to 5.6 ohms A74-17 (SL4+) - Body ground and other terminals Always 10 kohms or higher A74-16 (SL4-) - Body ground and other terminals Always 10 kohms or higher TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A74 TCM connector. NG --> See step 3 OK: Go to next step
2. REPLACE TCM See step 3 NEXT --> See step 7
3. CHECK HARNESS AND CONNECTOR (TCM - TRANSMISSION WIRE) Disconnect the A74 TCM connector. Disconnect the D43 transmission wire connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D43-15 (SL4+) - A74-17 (SL4+) Always Below 1 ohms D43-16 (SL4-) - A74-16 (SL4-) Always Below 1 ohms D43-15 (SL4+) or A74-17 (SL4+) - Body ground Always 10 kohms or higher D43-16 (SL4-) or A74-16 (SL4-) - Body ground Always 10 kohms or higher D43-15 (SL4+) - D43-16 (SL4-) Always 10 kohms or higher Connect the A74 TCM connector. Connect the D43 transmission wire connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SL4 Remove shift solenoid valve SL4. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL4 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 6 OK --> See step 5
5. REPLACE TRANSMISSION WIRE. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S02406215592014030500000)
6. REPLACE SHIFT SOLENOID VALVE SL4. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
7. PERFORM A/T CODE REGISTRATION. Refer to «PRECAUTION [07/2012 - ]»(ref-602573-S15148054852014030500000)

ALL

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

1. Count up time (*1) stops when following conditions met: (a) and ((b) or (c)) or (d) and ((e) or (f)) HINT: *1: Duration (0.5 sec.) CONDITION (A) Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more CONDITION (B) Turbine speed / Output speed (NT / NO) Following conditions met 1.067 or more 1.233 or less (when output speed less than 600 rpm) CONDITION (C) Turbine speed - Output speed (NT - NO) x 5th gear ratio (Actual 5th gear) -50 rpm or more and 50 rpm or less (when output speed 600 rpm or more) CONDITION (D) Vehicle speed 3 km/h (1.8 mph) or more Throttle valve opening angle 6.5% or more at engine speed 2000 rpm (condition varies with engine speed) ECT (Engine coolant temperature) 40°C (104°F) or more Spark advance from max. retard timing by KCS control Crankshaft angle 0° or more TCM indicate pressure value of SLT 320 kPa (3.3 kgf/cm2, 46 psi) or more CONDITION (E) Turbine speed / Output speed (NT / NO) Following conditions met 1.712 or more 1.962 or less (when output speed less than 400 rpm) CONDITION (F) Turbine speed - Output speed (NT - NO) x 3rd gear ratio (Actual 3rd gear) -50 rpm or more and 50 rpm or less (when output speed 400 rpm or more) OFF MALFUNCTION (D) TCM selected gear 2nd OFF MALFUNCTION (E) TCM selected gear 8th

ON malfunction

1. Following conditions is met: (A), (B) or (C)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

OFF malfunction

1. Following conditions is met: (A), (B), (C), (D) or (E)

OFF malfunction (A)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 4.157 or more and 8.529 or less (when output speed less than 130 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 1st gear ratio (Actual 1st gear) -50 rpm or more and 50 rpm or less (when output speed 130 rpm or more)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

OFF MALFUNCTION (D)

OFF MALFUNCTION (E)

ON malfunction

1. Following conditions is met: (A), (B) or (C)

ON malfunction (A)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 2.549 or more and 3.049 or less (when output speed less than 200. rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 2nd gear ratio (Actual 2nd gear) -50 rpm or more and 50 rpm or less (when output speed 200 rpm or more)

ON malfunction (B)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 0.596 or more and 0.696 or less (when output speed less than 1000 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 8th gear ratio (Actual 8th gear) -50 rpm or more and 50 rpm or less (when output speed 1000 rpm or more)

ON malfunction (C)

1. When either condition below is met: Condition (1) or (2) CONDITION (1) Turbine speed / Output speed (NT / NO) 2.549 or more and 3.049 or less (when output speed less than 200 rpm) CONDITION (2) Turbine speed - Output speed (NT - NO) x 2nd gear ratio (Actual 2nd gear) -50 rpm or more and 50 rpm or less (when output speed 200 rpm or more)

1. CHECK DTC OUTPUT Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read the DTCs using the Techstream. Result Result Proceed to DTC P2817 and DTC P0746, P0776, P0796, P2714 and/or P2808 are output. A Only P2817 is output B DTCs other than P0746, P0776, P0796, P2714, P2808 and P2817 are also output. C HINT: If DTCs other than P0746, P0776, P0796, P2714, P2808 and P2817 are also output, perform troubleshooting for those DTCs first. B --> See step 3 C --> See step 8 A: Go to next step
2. CLEAR DTC AND PERFORM STALL SPEED TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2012 - ]»(ref-602573-S12322516782014030500000) . HINT: Write down the currently output DTCs before clearing them. Perform the stall speed test. Refer to «HYDRAULIC TEST [07/2012 - ]»(ref-602573-S04603323302014030500000) . Result Test Condition Proceed to Stall speed test can be performed A Stall speed test cannot be performed B B --> See step 4 A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 AND SL5) Remove shift solenoid valve SL1, SL2, SL3, SL4 and SL5. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SL1 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL2 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL3 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL4 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms Terminal 1 of the shift solenoid valve SL5 - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL1, SL2, SL3, SL4 and SL5 Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 7 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Terminal 1 of the shift solenoid valve SLT - terminal 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SLT Connect a battery positive (+) lead with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector. Then check that the valve moves and makes an operating sound. OK Valve moves and makes an operating sound. NG --> See step 9 OK: Go to next step
5. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000) . OK There is no foreign matter on each valve and they operate smoothly. NG --> See step 11 OK: Go to next step
6. INSPECT TORQUE CONVERTER ASSEMBLY Check the torque converter assembly. Refer to «INSPECTION [07/2012 - ]»(ref-602718-S22504254222014030500000) . OK The torque converter assembly operates normally. NG --> See step 12 OK --> See step 10
7. REPLACE SHIFT SOLENOID VALVE (SL1, SL2, SL3, SL4 OR SL5). Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
8. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2012 - ]»(ref-602573-S13543157812014030500000)
9. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S28138496302014030500000)
10. REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)
11. REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL [07/2012 - ]»(ref-602718-S31810027182014030500000)
12. REPLACE TORQUE CONVERTER ASSEMBLY. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S30956719782014030500000)

ALL

CONDITION (A)

CONDITION (B)

CONDITION (C)

When one of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A) AND (B)

CONDITION (C)

Scheme 1291

Scheme 1292

1. CHECK ECM TERMINAL VOLTAGE (+B AND +B2 TERMINALS) Disconnect the ECM connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A43-3 (+B) - Body ground Engine switch on (IG) 11 to 14 V A43-2 (+B2) - Body ground Engine switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 7 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (ECM - BODY GROUND) Turn the engine switch off. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D1-81 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (TCM - ECM) Disconnect the TCM connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A73-21 (CAN+) - D1-24 (CAN+) Always Below 1 ohms A73-13 (CAN-) - D1-1 (CAN-) Always Below 1 ohms A73-21 (CAN+) or D1-24 (CAN+) - Body ground and other terminals Always 10 kohms or higher A73-13 (CAN-) or D1-1 (CAN-) - Body ground and other terminals Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK IF DTC OUTPUT RECURS Connect the Techstream to the DLC3. Clear the DTCs. Replace the TCM. HINT: Replace the TCM with a TCM from a normally functioning vehicle of the same model. Start the engine. Read the DTCs. Result Display (DTC Output) Proceed to U0100 A No DTC B B --> See step 6 A --> See step 5
5. REPLACE ECM. Refer to «COMPONENTS [03/2012 - ]»(ref-602706-S35023244152014030500000)
6. REPLACE TCM. Refer to «COMPONENTS [07/2012 - ]»(ref-602718-S19851063702014030500000)
7. GO TO ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-602700-S09013138302014030500000)

1. CHECK HARNESS AND CONNECTOR (TCM - BODY GROUND) Disconnect the A73 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A73-2 (E1) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A73 TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT ECU TERMINAL VOLTAGE (+B TERMINAL) Disconnect the A73 TCM connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A73-5 (+B) - Body ground Engine switch on (IG) 11 to 14 V TEXT IN ILLUSTRATION *a Rear view of wire harness connector (to TCM) Connect the A73 TCM connector. NG --> See step 3 OK --> See step 4
3. CHECK HARNESS AND CONNECTOR (TCM - JUNCTION CONNECTOR) Disconnect the A59 junction connector. Disconnect the A73 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition A73-5 (+B) - A59-5 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition A73-5 (+B) or A59-5 - Body ground Always 10 kohms or higher Connect the A59 junction connector. Connect the A73 TCM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [07/2012 - ]»(ref-602573-S32918774452014030500000)
5. GO TO ECM POWER SOURCE CIRCUIT (ENGINE CONTROL SYSTEM / SFI SYSTEM). Refer to «ECM Power Source Circuit»(ref-602700-S09013138302014030500000)
