Automatic Transmission (U660E) (Service Information): Overview Lexus RX III рестайлинг

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

1. PRECAUTIONS AND WORK DESCRIPTION The U660E automatic transaxle does not have an oil filler tube and oil level gauge. When adding fluid, add fluid through the refill hole on the transaxle case. The fluid level can be adjusted by draining excess fluid (allowing excess fluid to overflow) through the No. 1 transmission oil filler tube of the oil pan. HINT: "Overflow" indicates the condition under which fluid comes out of the overflow plug hole. Before adjusting the fluid level, add the specified amount of fluid when the engine is cold and warm up the engine to circulate the fluid in the transaxle. Ensure that the fluid temperature is as specified and the engine is idling. The U660E automatic transaxle requires Toyota Genuine ATF WS. The adjustment should be performed according to the procedures and notes.
2. WORK FLOW The adjustment should be performed according to the procedures referenced in the work flow below.
3. BEFORE FILLING TRANSAXLE WITH FLUID Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up. Remove the 2 bolts, clip and front fender apron seal LH.
4. PERFORM INITIAL FILLING NOTE: If the transaxle is hot (ATF temperature is high), wait until the fluid temperature becomes the same as the ambient temperature before starting the following procedure. (Recommended ATF temperature: around 20°C [68°F]) Remove the refill plug and gasket from the automatic transaxle. NOTE: After performing any of the following operations, it is not necessary to perform the initial filling procedure. Proceed to the Add Specified Amount of Fluid procedure. Operations that do not require initial filling Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new transaxle with torque converter (filled fluid parts) Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket from the automatic transaxle. NOTE: If ATF comes out after removing the overflow plug, wait until the fluid flow slows and only drips come out. If ATF comes out, it is not necessary to perform the initial filling procedure. After checking the tightening torque of the No. 1 transmission oil filler tube, temporarily tighten the overflow plug. Using a 6 mm hexagon socket wrench, check that the No. 1 transmission oil filler tube is tightened to the specified torque. TEXT IN ILLUSTRATION *1 No. 1 Transmission Oil Filler Tube *2 Hexagon Socket Wrench *3 Overflow Plug Hole Torque: 1.7 N*m (17 kgf*cm, 15 in.*lbf) NOTE: If the No. 1 transmission oil filler tube is not tightened to the specified torque, the amount of fluid cannot be precisely adjusted. HINT: To check the torque of the No. 1 transmission oil filler tube, insert the socket hexagon wrench into the overflow plug hole. Perform initial filling. Fill the transaxle through the refill hole until fluid begins to trickle out of the overflow plug hole. NOTE: Use Toyota Genuine ATF WS. Wait until the fluid flow slows and only drips come out. Temporarily install the overflow plug. HINT: Reuse the old gasket. The plug will be removed again to adjust the fluid level.
5. ADD SPECIFIED AMOUNT OF FLUID Fill the transaxle with the correct amount of fluid as listed in the table below. NOTE: Refill amount differs depending on the operation that was performed. Standard Capacity Performed Repair Fill Amount Disconnection of the oil cooler tube or oil cooler hose Repair of fluid leak due to a loose case plug, or a faulty plug gasket or O-ring Installation of a new transaxle with torque converter (filled fluid parts) 0.5 liters (0.5 US qts, 0.4 lmp. qts) Removal and installation of the drive shaft Removal and installation of the transaxle case oil seal Removal and installation of the oil pan 2.8 liters (3.0 US qts, 2.5 lmp. qts) Removal and installation of the valve body 3.2 liters (3.4 US qts, 2.8 lmp. qts) Removal and installation of the transaxle (not including removal of the torque converter) 3.4 liters (3.6 US qts, 3.0 lmp. qts) Removal and installation of the torque converter (torque converter reused) 4.8 liters (5.1 US qts, 4.2 lmp. qts) Installation of a new torque converter 5.3 liters (5.6 US qts, 4.7 lmp. qts) Temporarily install the refill plug to avoid fluid spillage. HINT: Reuse the old gasket. The plug will be removed again to adjust the fluid level. Lower the vehicle.
6. ADJUST FLUID TEMPERATURE When using the Techstream: HINT: The actual ATF temperature can be checked on the Data List using the Techstream. Connect the Techstream to the DLC3 with the engine switch off. Turn the engine switch on (IG) and turn the Techstream on. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. Enter the following menus: Powertrain / ECT / Active Test / Connect the TC and TE1. Select the Active Test menu: Connect the TC and TE1 / ON. Select the Data List menu: A/T Oil Temperature 1. Check the ATF temperature. NOTE: If the fluid temperature is below 45°C (113°F), proceed to the next step. (Recommended ATF temperature: 40°C [104°F] or less) If the fluid temperature is 45°C (113°F) or more, turn the engine switch off and wait until the fluid temperature drops below 45°C (113°F). Depress and hold the brake pedal. Start the engine. Slowly move the shift lever from P to D, then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter the fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When the fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the step where terminal TC is first connected and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Select the Active Test menu: Connect the TC and TE1 / OFF. NOTE: Be sure that terminals TC and TE1 are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and TE1 activates the engine idle speed control mode. In the engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 RPM. Even after terminals TC and TE1 are disconnected, the fluid temperature detection mode is active until the engine switch off. Warm up the engine with the engine idling until the fluid temperature reaches the normal operating temperature (40 to 45°C [104 to 113°F]). Below Normal Operating Temperature Normal Operating Temperature Above Normal Operating Temperature 40°C or less (104°F or less) 40 to 45°C (104 to 113°F) 45°C or more (113°F or more) NOTE: If the fluid temperature is within the normal operating temperature range, immediately proceed to the Adjust Fluid Level procedure. If the fluid temperature is 45°C (113°F) or more, stop the engine and wait until the fluid temperature drops to 40°C (104°F) or less. Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In the fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. D SHIFT INDICATOR Below Normal Operating Temperature (40°C or less) (104°F or less) Normal Operating Temperature (40 to 45°C) (104 to 113°F) Above Normal Operating Temperature (45°C or more) (113°F or more) OFF ON Blinks When not using the Techstream: Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3 with the engine switch off. TEXT IN ILLUSTRATION *1 DLC3 SST: 09843-18040 Depress and hold the brake pedal. Start the engine. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. HINT: The indicator lights on the combination meter blink to indicate the DTC output when terminals TC and CG are connected. Slowly move the shift lever from P to D, then back to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transaxle. While observing the D shift indicator on the combination meter, move the shift lever back and forth between N and D at an interval of 1.5 seconds for 6 seconds or more. NOTE: Do not pause for more than 1.5 seconds. HINT: Performing this operation will cause the vehicle to enter the fluid temperature detection mode. Check that the D shift indicator comes on for 2 seconds. HINT: When the fluid temperature detection mode is activated, the D shift indicator on the combination meter comes on for 2 seconds. If the D shift indicator does not come on for 2 seconds, return to the step where terminal TC is first connected and perform the procedure again. Move the shift lever from N to P. Release the brake pedal. Remove SST from terminals 13 (TC) and 4 (CG). TEXT IN ILLUSTRATION *1 DLC3 SST: 09843-18040 NOTE: Be sure that terminals TC and CG are not connected. If the terminals are connected, the fluid level cannot be precisely adjusted due to fluctuations in engine speed. HINT: Disconnecting terminals TC and CG activates the engine idle control mode. In the engine idle speed control mode, engine idle speed control starts when the fluid temperature becomes 35°C (95°F) or more and the engine speed is maintained at approximately 800 RPM. Even after terminals TC and CG are disconnected, the fluid temperature detection mode is active until the engine switch is turned off. Allow the engine to idle until the D shift indicator comes on again. D SHIFT INDICATOR Below Normal Operating Temperature (40°C or less) (104°F or less) Normal Operating Temperature (40 to 45°C) (104 to 113°F) Above Normal Operating Temperature (45°C or more) (113°F or more) OFF ON Blinks NOTE: If the D shift indicator is on, immediately proceed to the Adjust Fluid Level procedure. If the D shift indicator blinks, stop the engine and wait until the fluid temperature drops to 40°C (104°F) or less (the indicator goes off). Then perform the Adjust Fluid Temperature procedure again from the beginning. HINT: In the fluid temperature detection mode, the D shift indicator comes on, goes off, or blinks depending on the fluid temperature. Fluid filling procedure should be performed when the D shift indicator is on (the fluid temperature is within the normal operating temperature range).
7. ADJUST FLUID LEVEL WARNING: Use caution while the engine is idling and the radiator fan is operating. Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up. Adjust the fluid level. Using a 6 mm hexagon socket wrench, remove the overflow plug and gasket. WARNING: Be careful as the fluid coming out of the overflow plug hole is hot. Check the amount of fluid that comes out of the overflow plug hole. NOTE: If only a small amount of fluid (approximately 1 cc) comes out of the overflow plug hole, then only fluid remaining in the No. 1 transmission oil filler tube has come out. This condition is not considered as overflow, so it is necessary to add fluid. If the amount of fluid that comes out of the overflow plug hole is large, wait until the fluid flow slows and only drips come out. If no fluid comes out of the overflow plug hole, remove the refill plug and gasket. Then add transaxle fluid through the refill hole until fluid comes out of the overflow plug hole. Wait until the fluid flow slows and only drips come out. NOTE: Use Toyota Genuine ATF WS. Check that the fluid flow has slowed and only drips come out. HINT: The fluid flow will not completely stop because the fluid expands as its temperature increases. Install the overflow plug with a new gasket. Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) Install the refill plug with a new gasket. Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf) Lower the vehicle. Turn the engine switch off. HINT: Turning the engine switch off exits the fluid temperature detection mode. Remove the Techstream from the DLC3 (when using the Techstream).
8. AFTER FILLING TRANSAXLE Lift the vehicle. Clean each part. Check for fluid leaks. Install the front fender apron seal LH with the 2 bolts and clip. Lower the vehicle.

Scheme 181

Scheme 182

Scheme 183

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Remove Engine Assembly with Transaxle" through "Remove Automatic Transaxle Assembly". Refer to «REMOVAL [03/2012 - 07/2012]».
2. REMOVE TORQUE CONVERTER ASSEMBLY See step 13
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 3
4. REMOVE VALVE BODY OIL STRAINER ASSEMBLY See step 4
5. REMOVE TRANSMISSION VALVE BODY ASSEMBLY See step 5
6. REMOVE SPEED SENSOR Disconnect the connector. Remove the 2 bolts and speed sensor from the valve body.

Scheme 184

1. INSTALL SPEED SENSOR Coat the 2 bolts with ATF. Install the speed sensor to the valve body with the 2 bolts. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) Connect the connector.
2. INSTALL TRANSMISSION VALVE BODY ASSEMBLY See step 2
3. INSTALL VALVE BODY OIL STRAINER ASSEMBLY See step 3
4. INSTALL AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 4
5. INSTALL TORQUE CONVERTER ASSEMBLY See step 1
6. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Install Automatic Transaxle Assembly" through "Install Engine Assembly with Transaxle". Refer to «INSTALLATION [03/2012 - 07/2012]».

Scheme 185

Scheme 186

Scheme 187

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Remove Engine Assembly with Transaxle" through "Remove Automatic Transaxle Assembly". Refer to «REMOVAL [03/2012 - 07/2012]».
2. REMOVE TORQUE CONVERTER ASSEMBLY See step 13
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 3
4. REMOVE VALVE BODY OIL STRAINER ASSEMBLY See step 4
5. REMOVE ATF TEMPERATURE SENSOR ASSEMBLY Disconnect the connector. Remove the 4 bolts, ATF temperature sensor assembly and clamp from the valve body. TEXT IN ILLUSTRATION *1 Clamp Remove the O-ring from the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring

Scheme 188

1. INSPECT ATF TEMPERATURE SENSOR ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition THO1 - E2 10°C (50°F) 5 to 8 kohms THO1 - E2 25°C (77°F) 2.5 to 4.5 kohms THO1 - E2 110°C (230°F) 0.22 to 0.28 kohms THO1 - Body ground Always 10 kohms or higher If the resistance is out of the specified range with the ATF temperature shown in the preceding table, replace the ATF temperature sensor assembly. Otherwise, the driveability of the vehicle may decrease.

Scheme 189

1. INSTALL ATF TEMPERATURE SENSOR ASSEMBLY Coat a new O-ring with ATF and install it to the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring Coat the 4 bolts with ATF. Install the ATF temperature sensor assembly and clamp to the valve body with the 4 bolts. TEXT IN ILLUSTRATION *1 Connector *2 Clamp Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) Bolt length Bolt A 25 mm (0.984 in.) Bolt B 85 mm (3.35 in.) Connect the connector.
2. INSTALL VALVE BODY OIL STRAINER ASSEMBLY See step 3
3. INSTALL AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 4
4. INSTALL TORQUE CONVERTER ASSEMBLY See step 1
5. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Install Automatic Transaxle Assembly" through "Install Engine Assembly with Transaxle". Refer to «INSTALLATION [03/2012 - 07/2012]».

Scheme 190

Scheme 191

Scheme 192

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Remove Engine Assembly with Transaxle" through "Remove Automatic Transaxle Assembly". Refer to «REMOVAL [03/2012 - 07/2012]».
2. REMOVE TORQUE CONVERTER ASSEMBLY See step 13
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 3
4. REMOVE VALVE BODY OIL STRAINER ASSEMBLY See step 4
5. REMOVE TRANSMISSION VALVE BODY ASSEMBLY See step 5
6. REMOVE TRANSMISSION WIRE Disconnect the 9 connectors. Remove the transmission wire from the clamp. Remove the bolt, lock plate and transmission wire from the valve body.

Scheme 193

1. INSTALL TRANSMISSION WIRE Coat the O-ring with ATF. Coat the bolt with ATF. Install the transmission wire and lock plate to the valve body with the bolt. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) Install the transmission wire to the clamp. Connect the 9 connectors.
2. INSTALL TRANSMISSION VALVE BODY ASSEMBLY See step 2
3. INSTALL VALVE BODY OIL STRAINER ASSEMBLY See step 3
4. INSTALL AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY See step 4
5. INSTALL TORQUE CONVERTER ASSEMBLY See step 1
6. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Install Automatic Transaxle Assembly" through "Install Engine Assembly with Transaxle". Refer to «INSTALLATION [03/2012 - 07/2012]».

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

1. REMOVE AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Remove Engine Assembly with Transaxle" through "Remove Automatic Transaxle Assembly". Refer to «REMOVAL [03/2012 - 07/2012]».
2. REMOVE TORQUE CONVERTER ASSEMBLY See step 13
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY Remove the 18 bolts and oil pan from the transaxle. NOTE: Some fluid will remain in the oil pan. Remove all the pan bolts, and carefully remove the oil pan sub-assembly. Remove the gasket from the oil pan. Remove the 2 magnets from the oil pan. TEXT IN ILLUSTRATION *1 Magnet Examine particles in the oil pan. Collect any steel chips with the removed magnets. Look carefully at the chips and particles in the oil pan and on the magnets to see the type of wear which might be found in the transaxle. Result Steel (magnetic) Bearing, gear and plate wear Brass (non-magnetic) Bushing wear
4. REMOVE VALVE BODY OIL STRAINER ASSEMBLY Remove the 2 bolts and oil strainer from the valve body. Remove the O-ring from the oil strainer. TEXT IN ILLUSTRATION *1 O-ring
5. REMOVE TRANSMISSION VALVE BODY ASSEMBLY Remove the 11 bolts and valve body from the transaxle. NOTE: When removing the transmission valve body assembly, be careful not to allow the transmission revolution sensor and the transaxle case to interfere with each other.
6. REMOVE MANUAL VALVE Remove the manual valve from the valve body.

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

1. REMOVE TRANSMISSION WIRE See step 6
2. REMOVE ATF TEMPERATURE SENSOR ASSEMBLY Remove the 4 bolts, ATF temperature sensor assembly and clamp from the valve body assembly. TEXT IN ILLUSTRATION *1 Clamp Remove the O-ring from the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring
3. REMOVE SHIFT SOLENOID VALVE SL Remove the shift solenoid valve SL from the valve body assembly.
4. REMOVE SHIFT SOLENOID VALVE SLT Remove the lock plate and shift solenoid valve SLT from the valve body assembly. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SLT *3 Solenoid Valve SLU
5. REMOVE SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU from the valve body assembly.
6. REMOVE SHIFT SOLENOID VALVE SL2 Remove the bolt, lock plate and shift solenoid valve SL2 from the valve body assembly. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SL2 *3 Solenoid Valve SL1
7. REMOVE SHIFT SOLENOID VALVE SL1 Remove the shift solenoid valve SL1 from the valve body assembly.
8. REMOVE SHIFT SOLENOID VALVE SL3 Remove the bolt, lock plate and shift solenoid valve SL3 from the valve body assembly. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SL3
9. REMOVE SHIFT SOLENOID VALVE SL4 Remove the bolt, lock plate and shift solenoid valve SL4 from the valve body assembly. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SL4

Scheme 209

Scheme 210

1. INSPECT SHIFT SOLENOID VALVE SL Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Solenoid Connector (SL) - Solenoid Body (SL) 20°C (68°F) 11 to 15 ohms TEXT IN ILLUSTRATION *1 Shift Solenoid Valve SL If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery to the terminal of the solenoid connector, and a negative (-) lead to the solenoid body, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
2. INSPECT SHIFT SOLENOID VALVE SLT Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Shift Solenoid Valve SLT) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
3. INSPECT SHIFT SOLENOID VALVE SLU Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Shift Solenoid Valve SLU) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
4. INSPECT SHIFT SOLENOID VALVE SL1 Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Shift Solenoid Valve SL1) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
5. INSPECT SHIFT SOLENOID VALVE SL2 Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Shift Solenoid Valve SL2) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
6. INSPECT SHIFT SOLENOID VALVE SL3 Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Shift Solenoid Valve SL3) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.
7. INSPECT SHIFT SOLENOID VALVE SL4 Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Shift Solenoid Valve SL4) If the value is not as specified, replace the shift solenoid valve. Connect a positive (+) lead from the battery with a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, and check the operation of the valve. NOTE: When using battery voltage during the inspection, do not bring the positive (+) and negative (-) tester probes too close to each other as a short circuit may occur. OK The valve moves and makes an operating sound. If the operation cannot be done as specified, replace the shift solenoid valve.

Scheme 211

1. INSTALL SHIFT SOLENOID VALVE SL4 Coat the shift solenoid valve SL4 and bolt with ATF. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SL4 Install the shift solenoid valve SL4 and lock plate to the valve body assembly with the bolt. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
2. INSTALL SHIFT SOLENOID VALVE SL3 Coat the shift solenoid valve SL3 and bolt with ATF. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SL3 Install the shift solenoid valve SL3 and lock plate to the valve body assembly with the bolt. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
3. INSTALL SHIFT SOLENOID VALVE SL1 Coat the shift solenoid valve SL1 with ATF. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SL2 *3 Solenoid Valve SL1 Install the shift solenoid valve SL1 to the valve body assembly.
4. INSTALL SHIFT SOLENOID VALVE SL2 Coat the shift solenoid valve SL2 and bolt with ATF. Install the shift solenoid valve SL2 and lock plate to the valve body assembly with the bolt. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
5. INSTALL SHIFT SOLENOID VALVE SLU Coat the shift solenoid valve SLU with ATF. TEXT IN ILLUSTRATION *1 Lock Plate *2 Solenoid Valve SLT *3 Solenoid Valve SLU Install the shift solenoid valve SLU to the valve body assembly.
6. INSTALL SHIFT SOLENOID VALVE SLT Coat the shift solenoid valve SLT with ATF. Install the shift solenoid valve SLT and lock plate to the valve body assembly.
7. INSTALL SHIFT SOLENOID VALVE SL Coat the shift solenoid valve SL with ATF. Install the shift solenoid valve SL to the valve body assembly.
8. INSTALL ATF TEMPERATURE SENSOR ASSEMBLY Coat a new O-ring with ATF and install it to the ATF temperature sensor assembly. TEXT IN ILLUSTRATION *1 O-ring Coat the 4 bolts with ATF. TEXT IN ILLUSTRATION *1 Clamp Install the ATF temperature sensor assembly and clamp to the valve body assembly with the 4 bolts. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) Bolt length Bolt A 25 mm (0.984 in.) Bolt B 85 mm (3.35 in.)
9. INSTALL TRANSMISSION WIRE See step 1

Scheme 212

1. INSTALL MANUAL VALVE Coat the manual valve with ATF and install it to the valve body.
2. INSTALL TRANSMISSION VALVE BODY ASSEMBLY Coat the O-ring of the transmission wire with ATF. Confirm that the manual valve lever is positioned as shown in the illustration and install the valve body assembly to the transaxle case with the 11 bolts. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) Bolt length Bolt A 25 mm (0.984 in.) Bolt B 30 mm (1.18 in.) Bolt C 35 mm (1.38 in.) Bolt D 45 mm (1.77 in.) Bolt E 55 mm (2.17 in.) NOTE: When installing the transmission valve body assembly, be careful not to allow the transmission revolution sensor and transaxle case to interfere with each other. Be sure to insert the pin of the manual valve lever into the groove on the end of the manual valve. First, temporarily tighten the bolts marked *1 in the illustration because they are positioning bolts.
3. INSTALL VALVE BODY OIL STRAINER ASSEMBLY Coat a new O-ring with ATF and install it to the oil strainer. TEXT IN ILLUSTRATION *1 O-ring NOTE: Ensure that the O-ring is not twisted or pinched. Install the oil strainer to the valve body with the 2 bolts. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
4. INSTALL AUTOMATIC TRANSAXLE OIL PAN SUB-ASSEMBLY Install the 2 magnets to the oil pan. TEXT IN ILLUSTRATION *1 Magnet Install a new gasket to the oil pan. Apply adhesive to the 18 bolts. Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Install the oil pan to the automatic transaxle with the 18 bolts. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) NOTE: In order to ensure proper sealing of the transmission oil pan bolts, apply adhesive to the bolts and install them within 10 minutes of adhesive application. Completely remove any oil or grease from the contact surface of the transaxle case and oil pan sub-assembly with the gasket before installation.
5. INSTALL TORQUE CONVERTER ASSEMBLY See step 1
6. INSTALL AUTOMATIC TRANSAXLE ASSEMBLY HINT: See the steps from "Install Automatic Transaxle Assembly" through "Check Automatic Transaxle System". Refer to «INSTALLATION [03/2012 - 07/2012]».

Scheme 213

Scheme 214

Scheme 215
