Automatic Transmission (U660E) (Service Information): Adjustments Lexus RX III рестайлинг

ADJUSTMENT [03/2012 - ]

1. INSPECT SHIFT LEVER POSITION When moving the shift lever from P to R with the engine switch on (IG) and the brake pedal depressed, make sure that the shift lever moves smoothly and correctly into position. Start the engine and make sure that the vehicle moves forward when moving the shift lever from N to D and moves rearward when moving the shift lever to R. If the operation cannot be performed as specified, inspect the park/neutral position switch assembly and check the shift lever assembly installation condition.
2. ADJUST SHIFT LEVER POSITION Apply the parking brake and move the shift lever to N. Remove the console box. Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602716-S11988075562014030500000) . Disconnect the shift lock control ECU connector and transmission control switch wire connector. Disconnect the 3 clamps. Remove the 4 nuts and shift lever assembly. Disconnect the end of the transmission control cable assembly from the shift lever assembly. Turn the lock nut counterclockwise. While holding the lock nut, disconnect the transmission control cable from the shift lever retainer. Slide the slider of the transmission control cable in the direction indicated by the arrow and pull the lock piece outward. TEXT IN ILLUSTRATION *1 Slide *2 Pull *3 Slider *4 Lock Piece Turn the lock nut of the transmission control cable counterclockwise. While holding the lock nut, push in the stopper. TEXT IN ILLUSTRATION *1 Lock Nut *2 Push in *3 Stopper Connect the outer part of the transmission control cable to the shift lever retainer. TEXT IN ILLUSTRATION *1 Shift Lever Retainer *2 Stopper *3 Lock Nut - - NOTE: The lock nut is fully seated against the shift lever retainer. Install the transmission control cable end to the shift lever assembly. TEXT IN ILLUSTRATION *1 Lock Piece NOTE: Check that the lock piece is pulled up. Install the cable end all the way to the base of the pin. Install the shift lever assembly with the 4 nuts. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Connect the 3 clamps to the shift lever assembly. Connect the 2 connectors. Push the lock piece into the adjuster case. NOTE: Check that the park/neutral position switch and the shift lever are in neutral. Securely push in the lock piece until the slider lock is engaged. After adjusting the shift lever position, check the operation and function of the shift lever. If there is a problem, adjust the position again. Install the console box See step 2 .

Scheme 216

1. INSTALL TRANSMISSION CONTROL CABLE ASSEMBLY NOTE: Before installing the transmission control cable assembly, check that the park/neutral position switch and the shift lever are in neutral. Pass the control cable from the cabin to the engine compartment. Install the transmission control cable assembly with the 3 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Connect the transmission control cable to the clamp. Install a new clip to the control cable bracket. Install the control cable to the control cable bracket. TEXT IN ILLUSTRATION *1 Claw A *2 Claw B *3 Control Cable NOTE: Make sure that the claws A on the clip are securely fit into the bracket holes. Make sure that the cable is securely installed inside of the claws B of the clip. Connect the transmission control cable to the control shaft lever with the nut. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) NOTE: Before connecting the transmission control cable assembly, check that the park/neutral position switch and the shift lever are in neutral.
2. INSTALL AIR CLEANER ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 2»(ref-602706-S25789599832014030500000)
3. INSTALL INLET NO. 1 AIR CLEANER . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 69»(ref-602689-S39902766612014030500000)
4. INSTALL INLET NO. 2 AIR CLEANER . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 70»(ref-602689-S39902766612014030500000)
5. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 108»(ref-602689-S39902766612014030500000)
6. INSTALL BATTERY . Refer to «INSTALLATION [03/2012 - 07/2012] - Step 68»(ref-602689-S39902766612014030500000)
7. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY WITH AIR CONDITIONING UNIT ASSEMBLY HINT: See the steps from "Install Instrument Panel Reinforcement Assembly with Air Conditioning Unit Assembly" through "Inspect SRS Warning Light". Refer to «INSTALLATION [03/2012 - 07/2012]»(ref-602698-S10031620262014030500000) .
8. INSPECT SHIFT LEVER POSITION See step 1
9. ADJUST SHIFT LEVER POSITION See step 2
