Audio / Video (Diagnostic Codes & Circuit Tests): Other Lexus LX J200

Entertainment Systems 14 illustrations ~7822 words

PROCEDURE

  1. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY OR MULTI-DISPLAY ASSEMBLY w/ Navigation System: Replace the display and navigation module display. Refer to «REMOVAL»(ref-385267-S21347152882011021400000) . w/o Navigation System: Replace the multi-display. Refer to «REMOVAL»(ref-385268-S00404269842011021400000) . NEXT --> END
  1. CHECK VEHICLE EQUIPMENT Check if the vehicle is equipped with the Navigation System. RESULT Result Proceed to w/ Navigation System A w/o Navigation System B B --> See step 3 A: Go to next step
  2. CHECK "DISPLAY AND NAVIGATION ASSEMBLY COMMUNICATION ERROR" IN FLOWCHART Refer to the communication error. Refer to «Display and Navigation Assembly Communication Error»(ref-385265-S34069300652011021400000) . NEXT --> END
  3. CHECK "MULTI-DISPLAY COMMUNICATION ERROR" IN FLOWCHART Refer to the communication error. Refer to «Multi-display Communication Error»(ref-385265-S16758473352011021400000) . NEXT --> END
  1. CHECK POWER SOURCE CIRCUIT w/ Navigation System: Refer to the Display and Navigation Assembly Power Source Circuit. Refer to «Display and Navigation Assembly Power Source Circuit»(ref-385266-S09151538372011021400000) . w/o Navigation System: Refer to the Multi-display Power Source Circuit. Refer to «Multi-display Power Source Circuit»(ref-385265-S19327313492011021400000) . If the power source circuit is operating normally, proceed to the next step. NEXT: Go to next step
  2. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the F1, F23 and F24 receiver connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F1-5 (ATX+) - F1-15 (ATX-) Always 60 to 80 ohms F23-9 (TX+) - F23-10 (TX-) Always 60 to 80 ohms F24-9 (TXM+) - F24-10 (TXM-) Always 60 to 80 ohms NG --> See step 7 OK: Go to next step
  3. IDENTIFY COMPONENT WHICH HAS STORED THIS CODE Enter the diagnostic mode. Press the "LAN Mon" switch to change to "LAN Monitor" mode. Identify the component which has stored this code. COMPONENT TABLE Display Component AUDIO Radio receiver DSP-AMP Stereo component amplifier EMVN*1 Display and navigation module display EMV*2 Multi-display CAMERA-C*3 Parking assist ECU XM*4 Stereo component tuner RSE*5 Television display *1: w/ Navigation System *2: w/o Navigation System *3: w/ Wide View Front and Side Monitor System *4: w/ SDARS System *5: w/ Rear Seat Entertainment System HINT: "NAVI" is the component which has stored this code in the example shown in the illustration. NEXT: Go to next step
  4. CHECK HARNESS AND CONNECTOR (MULTI-DISPLAY - COMPONENT WHICH HAS STORED THIS CODE) HINT: For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check the AVC-LAN circuit between the multi-display and the component which has stored this code. Disconnect all connectors between the multi-display and the component which has stored this code. Check for an open or short in the AVC-LAN circuit between the multi-display and the component which has stored this code. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. CHECK HARNESS AND CONNECTOR (MULTI-DISPLAY - RADIO RECEIVER) HINT: For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check the AVC-LAN circuit between the multi-display and the radio receiver. Disconnect all connectors between the multi-display and the radio receiver. Check for an open or short in the AVC-LAN circuit between the multi-display and the radio receiver. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  6. REPLACE MULTI-DISPLAY WITH NORMAL ONE AND CHECK w/ Navigation System: Replace the display and navigation module display with a normal one and check if the same problem occurs again. Refer to «REMOVAL»(ref-385267-S21347152882011021400000) . w/o Navigation System: Replace the multi-display with a normal one and check if the same problem occurs again. Refer to «REMOVAL»(ref-385268-S00404269842011021400000) . OK Same problem does not occur. NG --> REPLACE COMPONENT WHICH HAS STORED THIS CODE OK --> END
  7. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY OR MULTI-DISPLAY ASSEMBLY w/ Navigation System: Replace the display and navigation module display. Refer to «REMOVAL»(ref-385267-S21347152882011021400000) . w/o Navigation System: Replace the multi-display. Refer to «REMOVAL»(ref-385268-S00404269842011021400000) . NEXT --> END
  1. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY OR MULTI-DISPLAY ASSEMBLY w/ Navigation System: Replace the display and navigation module display. Refer to «REMOVAL»(ref-385267-S21347152882011021400000) . w/o Navigation System: Replace the multi-display. Refer to «REMOVAL»(ref-385268-S00404269842011021400000) . NEXT --> END
  1. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY OR MULTI-DISPLAY ASSEMBLY w/ Navigation System: Replace the display and navigation module display. Refer to «REMOVAL»(ref-385267-S21347152882011021400000) . w/o Navigation System: Replace the multi-display. Refer to «REMOVAL»(ref-385268-S00404269842011021400000) . NEXT --> END
  1. REPLACE RADIO RECEIVER ASSEMBLY Replace the radio receiver. Refer to «REMOVAL»(ref-385264-S14664248812011021400000) . NEXT --> END
  1. CHECK IF PROPER DISC IS INSERTED Make sure that the DVD is a video DVD or a CD with an MP3 or WMA file, and that it is not deformed, flawed, stained, burred, or otherwise defective. OK Normal disc. HINT: Translucent or uniquely-shaped DVDs or CDs cannot be played. For details on playable DVDs or CDs, refer to the Owner's service information. NG --> DISC IS FAULTY OK: Go to next step
  2. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc and recheck. Replace the disc with a normal one. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 3 OK --> END
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  2. RECHECK DTC Recheck for DTCs and check if the same trouble code is output. HINT: If DTCs are output frequently, replace the radio receiver. OK No DTC is output. NG --> See step 4 OK --> See step 3
  3. USE SIMULATION METHOD TO CHECK. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-385196-S04310778802011021400000)
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK RADIO RECEIVER ASSEMBLY Check if a disc can be changed, inserted, or ejected normally. OK Malfunction disappears. NG --> See step 2 OK --> END
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK THAT DISC IS INSERTED PROPERLY Check whether or not the disc is inserted upside down. OK Disc is properly inserted. NG --> INSERT DISC PROPERLY OK: Go to next step
  2. CHECK DISC Check that the disc is not deformed or cracked. OK No deformation or cracks on the disc. NG --> CHANGE DISC OK: Go to next step
  3. DISC CLEANING If dirt is on the disc surface, wipe it clean with a soft cloth from the inside to the outside in a radial direction. NOTE: Do not use a conventional record cleaner or antistatic preservative. NEXT: Go to next step
  4. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  5. RECHECK DTC Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 6 OK --> DISC WAS DIRTY
  6. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc with a normal one. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 7 OK --> DISC IS FAULTY
  7. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK RADIO RECEIVER ASSEMBLY Park the vehicle in a cool place. Check that the temperature of the radio receiver has become sufficiently low, and start the engine. Check that the malfunction disappears. OK Malfunction disappears. NG --> See step 2 OK --> END
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  2. RECHECK DTC Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 3 OK --> END (THIS CODE MAY BE OUTPUT EVEN IF THERE IS NO MALFUNCTION)
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHANGE DISC Insert a disc with a playable file and check if the disc can be played correctly. HINT: For details on playable files and discs, refer to the Owner's service information. OK The disc can be played correctly. NG --> See step 2 OK --> DISC IS FAULTY
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY OR MULTI-DISPLAY ASSEMBLY w/ Navigation System: Replace the display and navigation module display. Refer to «REMOVAL»(ref-385267-S21347152882011021400000) . w/o Navigation System: Replace the multi-display. Refer to «REMOVAL»(ref-385268-S00404269842011021400000) . NEXT --> END
  1. REPLACE RADIO RECEIVER ASSEMBLY Replace the radio receiver. Refer to «REMOVAL»(ref-385264-S14664248812011021400000) . NEXT --> END
  1. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  2. RECHECK FOR DTC Recheck for DTCs and check if the same trouble code is output. HINT: If DTCs are output frequently, replace the radio receiver. OK No DTC is output. NG --> See step 4 OK --> See step 3
  3. USE SIMULATION METHOD TO CHECK. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-385196-S04310778802011021400000)
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. REPLACE RADIO RECEIVER ASSEMBLY Replace the radio receiver. Refer to «REMOVAL»(ref-385264-S14664248812011021400000) . NEXT --> END
  1. CHECK DISC Check that the disc is not deformed or cracked. OK No deformations or cracks on the disc. NG --> CHANGE DISC OK: Go to next step
  2. DISC CLEANING Disc cleaning If dirt is on the disc surface, wipe it clean with a soft cloth from the inside to the outside in a radial direction. NOTE: Do not use a conventional record cleaner or antistatic preservative. NEXT: Go to next step
  3. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  4. RECHECK FOR DTC Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 5 OK --> END
  5. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc and recheck. Replace the disc with a normal one. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 6 OK --> END
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK IF A PROPER CD IS INSERTED Make sure that the CD is an audio CD or a CD with an MP3 or WMA file, and that it is not deformed, flawed, stained, burred, or otherwise defective. OK Normal CD. HINT: Translucent or uniquely-shaped CDs cannot be played. CDs with adhesive paper labels should not be played. Commercial audio CDs can be played. CD-DA files on CD-ROMs, CD-Rs, and CD-RWs can be played. MP3 and WMA files on CD-ROMs, CD-Rs, and CD-RWs can be played. For details on playable CDs, refer to the Owner's service information. NG --> CD IS FAULTY OK: Go to next step
  2. REPLACE CD WITH ANOTHER AND RECHECK Replace the CD and recheck. Replace the CD with a normal one. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 3 OK --> END
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  2. RECHECK FOR DTC Recheck for DTCs and check if the same trouble code is output. HINT: If DTCs are output frequently, replace the radio receiver. OK No DTC is output. NG --> See step 3 OK --> END
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK RADIO RECEIVER ASSEMBLY Check if a disc can be changed, inserted, or ejected normally. OK Malfunction disappears. NG --> See step 2 OK --> END
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK THAT CD IS INSERTED PROPERLY Check that the CD is not inserted upside down. OK CD is properly inserted. NG --> INSERT CD PROPERLY OK: Go to next step
  2. CHECK DISC Check that the disc is not deformed or cracked. OK No deformations or cracks on the disc. NG --> CHANGE DISC OK: Go to next step
  3. DISC CLEANING Disc cleaning If dirt is on the disc surface, wipe it clean with a soft cloth from the inside to the outside in a radial direction. NOTE: Do not use a conventional record cleaner or antistatic preservative. NEXT: Go to next step
  4. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  5. RECHECK FOR DTC Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 6 OK --> END
  6. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc and recheck. Replace the disc with a normal one. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 7 OK --> END
  7. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK RADIO RECEIVER ASSEMBLY Park the vehicle in a cool place. Check that the temperature of the radio receiver has become sufficiently low, then start the engine. Check that the malfunction disappears. OK Malfunction disappears. NG --> See step 2 OK --> END
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CLEAR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-385262-S11806598312011021400000) . NEXT: Go to next step
  2. RECHECK DTC Recheck for DTCs and check if the same trouble code is output. OK No DTC is output. NG --> See step 3 OK --> END
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHANGE DISC Insert a disc with a playable file and check if the disc can be played correctly. HINT: For details on playable files and discs, refer to the Owner's service information. OK The disc can be played correctly. NG --> See step 2 OK --> DISC IS FAULTY
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. IDENTIFY COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the "LAN Mon" switch to change to "LAN Monitor" mode. Identify the component shown by the sub-code. HINT: "118 (display and navigation module display)" is the component shown by the sub-code in the example shown in the illustration. The sub-code will be indicated by its physical address. For the component list, refer to Diagnosis Display Detailed Description in the System Description. Refer to «SYSTEM DESCRIPTION»(ref-385262-S28647305572011021400000) . NEXT: Go to next step
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. COMPONENT TABLE Display Proceed to Radio receiver (190) Radio receiver power source circuit. Refer to «Radio Receiver Power Source Circuit»(ref-385265-S21688277082011021400000) Stereo component amplifier (440) Stereo component amplifier power source circuit. Refer to «Stereo Component Amplifier Power Source Circuit»(ref-385265-S06475065432011021400000) Parking assist ECU (1AC)*1 Parking assist ECU power source circuit. Refer to «ECU Power Source Circuit»(ref-385270-S04161577302011021400000) Stereo component tuner (1F1)*2 Satellite radio tuner power source circuit. Refer to «Satellite Radio Tuner Power Source Circuit»(ref-385265-S41934865682011021400000) Television display (1F6)*3 Television display power source circuit. Refer to «Television Display Power Source Circuit»(ref-385271-S38533421322011021400000) If the power source circuit is operating normally, proceed to the next step. *1: w/ Wide View Front and Side Monitor System *2: w/ SDARS System *3: w/ Rear Seat Entertainment System NEXT: Go to next step
  3. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the F1, F23 and F24 receiver connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F1-5 (ATX+) - F1-15 (ATX-) Always 60 to 80 ohms F23-9 (TX+) - F23-10 (TX-) Always 60 to 80 ohms F24-9 (TXM+) - F24-10 (TXM-) Always 60 to 80 ohms NG --> See step 6 OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (DISPLAY AND NAVIGATION MODULE DISPLAY - COMPONENT SHOWN BY SUB CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check the AVC-LAN circuit between the display and navigation module display and the component shown by the sub-code. Disconnect all connectors between the display and navigation module display and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the display and navigation module display and the component shown by the sub-code. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK Same problem does not occur. NG --> See step 7 OK --> END
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  7. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  1. CHECK SPEAKER INSTALLATION Check that each speaker is securely installed. OK Each speaker is securely installed. NG --> INSTALL SPEAKER PROPERLY OK: Go to next step
  2. IDENTIFY NOISE SOURCE Check the noise condition. HINT: The radio has a noise prevention function to reduce noise when listening to the radio. If a loud noise occurs, check whether the ground at the antenna mounting base and the noise prevention unit are installed and wired correctly. Condition in Which Noise Occurs Noise Type Depressing accelerator pedal increases noise, and stopping engine stops noise immediately Generator noise When A/C or heater is operating Blower motor noise When rapidly accelerating on unpaved road When engine switch is turned on (IG) Fuel pump noise When horn switch is pressed and released When horn switch is pressed and held down Horn noise Running engine causes soft noise, and stopping engine stops noise immediately Ignition noise Noise occurs synchronously with turn signal flash Flasher noise Noise occurs during window washer operation Washer noise Running engine causes noise, but stopping engine does not stop noise Water temperature sensor noise When wiper is operating Wiper noise When brake pedal is depressed Stop light switch noise Other Static electricity on vehicle HINT: In the left column of the chart, find the situation that matches the vehicle of the customer. Then, in the right column, find the part that is causing the noise. Check the noise filter on the part. To save time and avoid a misdiagnosis, first make sure that the noise is not originating from outside the vehicle. Troubleshoot noise problems in order of loudness, starting with the loudest noise. Setting the radio to a frequency that receives no signal may make recognition of the noise problem easier. OK The noise source can be determined. NG --> See step 3 OK --> REPAIR NOISE SOURCE
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)

Scheme 316

Scheme 316: PROCEDURE
Scheme 316: PROCEDURE
  1. CHECK SOUND SETTING Enter the sound adjustment screen by pressing the "SOUND" switch on the AUDIO display. Set volume, fader, and balance to the initial values and check that the sound is normal. OK Sound returns to normal. HINT: Sound quality adjustment items vary depending on the type of the amplifier. NG --> See step 2 OK --> END
  2. GO TO "SPEAKER CIRCUIT". Refer to «Speaker Circuit»(ref-385265-S25644903472011021400000)
  1. REPLACE CD WITH ANOTHER AND RECHECK Replace the CD with a normal one and check if the same problem occurs again. OK Malfunction disappears. NG --> See step 2 OK --> CD IS FAULTY
  2. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CHECK IF PROPER DISC IS INSERTED Make sure that the disc is a normal audio disc, and that it is not deformed, flawed, burred or otherwise defective. OK Normal audio disc. HINT: For details on playable discs, refer to the Owner's service information. NG --> DISC IS FAULTY OK: Go to next step
  2. CHECK THAT DISC IS INSERTED PROPERLY Check whether or not the disc is inserted upside down. OK Disc is properly inserted. NG --> INSERT DISC PROPERLY OK: Go to next step
  3. CLEAN DISC Clean the disc by wiping the disc underside radially with a soft cloth. OK Malfunction disappears. NOTE: Do not use a conventional record cleaner or antistatic preservative. NG --> See step 4 OK --> DISC WAS DIRTY
  4. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc with a normal one and check if the same problem occurs again. OK Malfunction disappears. NG --> See step 5 OK --> DISC IS FAULTY
  5. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  1. PRESS "EJECT" AND CHECK OPERATION Press the disc eject switch of the radio receiver for 5 seconds or more, and check that the disc ejects. OK Disc ejects. NG --> See step 3 OK: Go to next step
  2. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc with a normal one and check that the disc ejects. OK Disc ejects. NG --> See step 4 OK --> DISC IS FAULTY
  3. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. CLEAN DISC Clean the disc by wiping the disc underside radially with a soft cloth. OK Malfunction disappears. NOTE: Do not use a conventional record cleaner or antistatic preservative. NG --> See step 2 OK --> DISC WAS DIRTY
  2. REPLACE DISC WITH ANOTHER AND RECHECK Replace the disc with a normal one and check if the same problem occurs again. OK Malfunction disappears. NG --> See step 3 OK --> DISC IS FAULTY
  3. CHECK WHEN PROBLEM OCCURS Check the location in which disc skipping occurs. RESULT Result Proceed to Driving surface is bumpy or rough A Driving surface is normal B B --> See step 5 A: Go to next step
  4. CHECK RADIO RECEIVER INSTALLATION Check the installation condition of the radio receiver. OK Installed properly. NG --> See step 7 OK: Go to next step
  5. INSTALL RADIO RECEIVER IN ANOTHER VEHICLE OF SAME MODEL AND COMPARE Remove the radio receiver and install it in another vehicle of the same model. Check if the disc sound skips. OK Disc sound does not skip. NG --> See step 6 OK --> MALFUNCTIONS MAY NOT BE PRESENT
  6. DID TEMPERATURE IN CABIN CHANGE RAPIDLY? Check whether or not a rapid temperature change occurred in the cabin. OK Rapid temperature change occurred. HINT: A rapid temperature change creates condensation inside the disc player, which may disable disc playback. NG --> See step 8 OK --> CONDENSATION DUE TO TEMPERATURE CHANGE (LEAVE AS IS FOR A WHILE BEFORE USING)
  7. INSTALL RADIO RECEIVER PROPERLY. Refer to «INSTALLATION»(ref-385264-S22417331622011021400000)
  8. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)

Scheme 317

Scheme 317: PROCEDURE
Scheme 317: PROCEDURE
  1. CHECK IF RADIO AUTO-SEARCH FUNCTIONS PROPERLY Perform the auto-search of the radio and check that it functions normally. OK Radio auto-search functions normally. NG --> See step 2 OK --> See step 6
  2. CHECK OPTIONAL COMPONENTS Check if a telephone antenna or other optional components are installed. OK Optional component(s) is installed. NG --> See step 3 OK --> EFFECT FROM OPTIONAL COMPONENTS
  3. CHECK ANTENNA FOR NOISE PRODUCTION With the engine switch on (ACC), turn on the radio and choose the AM mode. Place the tip of a screwdriver on the antenna and check that noise is heard from the speakers. OK Noise is heard. NG --> See step 4 OK --> See step 7
  4. CHECK RADIO RECEIVER ASSEMBLY (ANTENNA) Remove the antenna plug of the radio receiver. With the radio receiver connector connected, turn the engine switch on (ACC). Turn on the radio and choose the AM mode. Place a flat-head screwdriver or a piece of metal, such as a thin wire, on the antenna jack of the radio receiver. Check that noise is heard from the speakers. OK Noise is heard. NG --> See step 8 OK --> See step 5
  5. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  7. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  8. REPLACE ANTENNA ASSEMBLY AND ANTENNA CORD SUB-ASSEMBLY. Refer to «REMOVAL»(ref-385264-S01260114432011021400000)
  1. CHECK DISPLAY SETTING Check that the display is not in "Screen Off" mode. OK The display setting is not in "Screen Off" mode. NG --> CHANGE SCREEN TO "SCREEN ON" MODE OK: Go to next step
  2. CHECK IMAGE QUALITY SETTING Check that the screen color quality can be set. OK Setting is possible. NG --> See step 3 OK --> PRESS PANEL SWITCH "DISPLAY" AND SET SCREEN COLOR QUALITY TO NORMAL
  3. CHECK CABIN Check that condensation is not likely to occur in the cabin, and that the temperature is not high or extremely low in the cabin. HINT: A humid cabin and a rapid change in temperature may lead to condensation. Condensation in the cabin may short circuit the screen. The appropriate cabin temperature is 20 to 30°C (68 to 86°F). OK Condensation is not likely and temperature is not high or extremely low. NG --> SET CABIN TO APPROPRIATE TEMPERATURE OK --> See step 4
  4. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)

Scheme 318

Scheme 318: PROCEDURE
Scheme 318: PROCEDURE
  1. CHECK VEHICLE SIGNAL (DISPLAY CHECK MODE) Enter the "Display Check" mode and select "Vehicle Signal Check Mode". Refer to «OPERATION CHECK»(ref-385262-S03827024692011021400000) . Check that the display changes between ON and OFF according to the light control switch operation. OK Light Control Switch Display Tail or head ON Off OFF HINT: This display is updated once per second. As a result, it is normal for the display to lag behind the actual change in the switch. RESULT Result Proceed to OK (w/ Navigation System) A OK (w/o Navigation System) B NG C C --> See step 2 B --> See step 4 A --> See step 3
  2. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  3. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  4. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)

Scheme 319

Scheme 319: PROCEDURE
Scheme 319: PROCEDURE

Scheme 320

Scheme 320
Scheme 320
  1. CHECK IMAGE QUALITY SETTING Enter the display adjustment screen by pressing the "DISP" switch. Turn the light control switch to the tail position. Check if "Day Mode" on the display is on. OK "Day Mode" is on. NG --> See step 2 OK --> TURN "Day Mode" SETTING OFF
  2. CHECK VEHICLE SIGNAL (DISPLAY VEHICLE SIGNAL) Enter the "Display Check" mode and select "Vehicle Signal Check Mode". Refer to «OPERATION CHECK»(ref-385262-S03827024692011021400000) . Cover the automatic light control sensor on the instrument panel with a cloth. Set the instrument panel light control to less than the maximum (to activate the dimmer function that works when the light control switch is in the tail position). Check that the display changes between DIM and BRIGHT according to the light control switch operation. OK Light Control Switch Condition Display Condition Tail or head ON Off OFF HINT: The display is updated once per second. It is normal for the display to lag behind the actual switch operation. RESULT Result Proceed to OK (w/ Navigation System) A OK (w/o Navigation System) B NG C C --> See step 3 B --> See step 5 A --> See step 4
  3. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  4. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  5. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)

Scheme 321

Scheme 321: PROCEDURE
Scheme 321: PROCEDURE
  1. CHECK PANEL SWITCH Check for foreign matter around the switch that might prevent operation. OK No foreign matter is found. NG --> REMOVE ANY FOREIGN MATTER OK: Go to next step
  2. CHECK PANEL SWITCH (DISPLAY CHECK MODE) Enter the "Display Check" mode and select "Panel Switch Check Mode". Refer to «OPERATION CHECK»(ref-385262-S03827024692011021400000) . Operate the abnormal switch and check if the switch name and status are correctly displayed. OK The switch name and status are correctly displayed as operated. RESULT Result Proceed to OK (w/ Navigation System) A OK (w/o Navigation System) B NG C C --> See step 3 B --> See step 5 A --> See step 4
  3. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  4. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  5. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)

Scheme 322

Scheme 322: PROCEDURE
Scheme 322: PROCEDURE
  1. CHECK TOUCH PANEL Check for foreign matter on the display. OK The display is clean. NG --> CLEAN DISPLAY AND RECHECK TOUCH PANEL OK: Go to next step
  2. CHECK TOUCH SWITCH (DISPLAY CHECK MODE) Enter the "Display Check" mode and select "Touch Switch Check". Refer to «OPERATION CHECK»(ref-385262-S03827024692011021400000) . Touch the display in the area where the switch malfunction occurs. OK A "+" mark appears at the touched position. RESULT Result Proceed to OK A NG (w/ Navigation System) B NG (w/o Navigation System) C C --> See step 5 B --> See step 4 A --> See step 3
  3. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  4. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  5. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)
  1. ADJUST SOUND QUALITY Operate the radio receiver to adjust the sound quality. OK Sound quality returns to normal. NG --> See step 2 OK --> SYSTEM IS OK (BAD SOUND QUALITY)
  2. COMPARE VEHICLE WITH ANOTHER VEHICLE OF SAME MODEL Compare the vehicle with another vehicle that has a normally functioning audio system. Check if there is any difference in the problem. OK No difference is found. NG --> See step 3 OK --> SYSTEM IS OK (BAD SOUND QUALITY)
  3. GO TO "SOUND SIGNAL CIRCUIT BETWEEN RADIO RECEIVER AND STEREO COMPONENT AMPLIFIER". Refer to «Sound Signal Circuit between Radio Receiver and Stereo Component Amplifier»(ref-385265-S27031867812011021400000)
  1. CHECK CURRENT CONDITION Check for "Bluetooth" capable cellular phones and vehicles in the area. RESULT Result Proceed to Another "Bluetooth" compatible cellular phone is present A Another "Bluetooth" compatible vehicle is present B None of the above C C --> See step 4 B --> See step 3 A: Go to next step
  2. CHECK USING ANOTHER CELLULAR PHONE Check if the system functions using another "Bluetooth" compatible cellular phone. HINT: Confirm that either the same or a different version of another "Bluetooth" compatible cellular phone complies with the system. Depending on the version, some "Bluetooth" compatible cellular phones cannot be used. OK System functions. RESULT Result Proceed to OK A NG (w/ Navigation System) B NG (w/o Navigation System) C C --> See step 9 B --> See step 6 A --> USE "BLUETOOTH" COMPATIBLE CELLULAR PHONE (DEPENDING ON THE VERSION)
  3. CHECK USING ANOTHER "BLUETOOTH" CAPABLE VEHICLE Register the cellular phone with another vehicle and check if the system functions normally. HINT: Depending on the version, some "Bluetooth" compatible cellular phones cannot be used. OK System functions. RESULT Result Proceed to OK (w/ Navigation System) A OK (w/o Navigation System) B NG C C --> USE "BLUETOOTH" COMPATIBLE CELLULAR PHONE B --> See step 9 A --> See step 7
  4. CHECK CELLULAR PHONE Check if the cellular phone is "Bluetooth" compatible. HINT: Some versions of "Bluetooth" compatible cellular phones may not function. OK The phone is "Bluetooth" compatible. NG --> USE "BLUETOOTH" COMPATIBLE CELLULAR PHONE OK: Go to next step
  5. CHECK CELLULAR PHONE Check if a call can be made from the cellular phone. HINT: When the battery is low, registration or directory transfer cannot be performed. OK A call can be made from the cellular phone. RESULT Result Proceed to OK (w/ Navigation System) A OK (w/o Navigation System) B NG C C --> REPLACE CELLULAR PHONE B --> See step 9 A --> See step 8
  6. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  7. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  8. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  9. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)
  1. CHECK "BLUETOOTH" SETTING Check if the "Bluetooth" settings are correct. OK "Bluetooth" settings are correct. NG --> SET SETTINGS CORRECTLY OK: Go to next step
  2. CHECK CELLULAR PHONE Check if the cellular phone is "Bluetooth" compatible. HINT: Some versions of "Bluetooth" compatible cellular phones may not function. OK Phone is "Bluetooth" compatible. NG --> END (ONLY A "BLUETOOTH" COMPATIBLE CELLULAR PHONE CAN BE USED) OK: Go to next step
  3. CHECK SETTING Check if the cellular phone functions. HINT: The cellular phone is unable to call under any of the following conditions. The cellular phone is locked. The directory is being transferred. The line is crossed. Transmission is regulated. The engine is off. The cellular phone is not connected to "Bluetooth" ("Bluetooth" mark is displayed while connected). OK Above conditions do not exist. NG --> SET CORRECTLY OK: Go to next step
  4. CHECK CELLULAR PHONE Check if the cellular phone can make calls. HINT: When the battery is low, calls cannot be made or received. OK Cellular phone can make calls. NG --> REPLACE CELLULAR PHONE OK: Go to next step
  5. CHECK RECEPTION Set the cellular phone so that it can receive calls. Place the cellular phone close to the multi-display. Check if the cellular phone has reception according to the multi-display. OK Cellular phone has reception. RESULT Result Proceed to OK A NG (w/ Navigation System) B NG (w/o Navigation System) C C --> See step 8 B --> See step 7 A --> See step 6
  6. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  7. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  8. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)

Scheme 323

Scheme 323: PROCEDURE
Scheme 323: PROCEDURE

Scheme 324

Scheme 324
Scheme 324
  1. CHECK SURROUNDING CONDITION Check if the cellular phone can make calls in a certain location. OK Cellular phone can make calls. NG --> END (CELLULAR PHONES CAN ONLY FUNCTION IN CELLULAR SERVICE AREAS) OK: Go to next step
  2. CHECK RECEPTION Enter the "Information" screen by pressing the "INFO" switch. Select "Telephone". Check the "BT" mark. RESULT Result Proceed to Yellow color A Blue color (w/ Navigation System) B Blue color (w/o Navigation System) C No connection mark is displayed D D --> SELECT REGISTERED CELLULAR PHONE OR REGISTER "BLUETOOTH" COMPATIBLE PHONE C --> See step 4 B --> See step 3 A --> BRING CELLULAR PHONE TO LOCATION WHERE BT MARK TURNS BLUE
  3. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  4. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)

Scheme 325

Scheme 325: PROCEDURE
Scheme 325: PROCEDURE

Scheme 326

Scheme 326
Scheme 326
  1. CHECK CELLULAR PHONE Check if the voice on the other side can be heard using a cellular phone. OK Voice can be heard. NG --> REPLACE CELLULAR PHONE OK: Go to next step
  2. CHECK NAVIGATION SYSTEM Check that voice guidance can be heard from the driver side speaker. OK Voice guidance can be heard. NG --> See step 6 OK: Go to next step
  3. CHECK SETTINGS Check if the volume level is set to a low level on the Call screen. OK The level is not low. NG --> SET VOLUME TO HIGH OK: Go to next step
  4. CHECK SETTINGS Enter the "Handsfree Voice Quality Set" mode. Refer to «OPERATION CHECK»(ref-385262-S03827024692011021400000) . Check if the Receive Voice Level is set to "0". HINT: The Receive Voice Level can be set to 11 different levels, -5 to +5, with a 3 dB difference. Check if the Receive Voice Level is set to the minimum or maximum level. HINT: When the Receive Voice Level is set to the minimum or maximum level, the sound may be distorted. OK The Receive Voice Level is set to "0". NG --> SET RECEIVE VOICE LEVEL TO "0" OK --> See step 5
  5. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  6. GO TO "VOICE GUIDANCE DOES NOT FUNCTION". Refer to «Voice Guidance does not Function»(ref-385266-S07981464672011021400000)

Scheme 327

Scheme 327: PROCEDURE
Scheme 327: PROCEDURE

Scheme 328

Scheme 328
Scheme 328

Scheme 329

Scheme 329
Scheme 329
  1. CHECK CELLULAR PHONE Check if the other side can hear your voice properly. OK Your voice can be heard correctly. NG --> REPLACE CELLULAR PHONE OK: Go to next step
  2. CHECK SETTINGS Check if the mute switch is on. OK Mute switch is not on. NG --> TURN MUTE SWITCH OFF OK: Go to next step
  3. CHECK SETTINGS Enter the "Handsfree Voice Quality Set" mode. Refer to «OPERATION CHECK»(ref-385262-S03827024692011021400000) . Check if the Send Voice Level is set to "0". HINT: The Send Voice Level can be set to 11 different levels, -5 to +5, with a 3 dB difference. Check if the Send Voice Level is set to the minimum or maximum level. HINT: When the Send Voice Level is set to the minimum or maximum level, the sound may be distorted. OK The Send Voice Level is set to "0". NG --> SET SEND VOICE LEVEL TO "0" OK: Go to next step
  4. CHECK MICROPHONE (NAVIGATION CHECK MODE) Enter the "Mic & Voice Recognition Check" mode. Refer to «SYSTEM DESCRIPTION»(ref-385262-S28647305572011021400000) . When a voice is input into the microphone, check that the microphone input level meter changes according to the input voice. Push the recording switch and perform voice recording. HINT: The recording limit is 5 seconds. Check that the recording indicator remains on while recording and that the recorded voice is played normally without noise or distortion. OK All check results are normal. RESULT Result Proceed to OK (w/ Navigation System) A OK (w/o Navigation System) B NG C C --> See step 6 B --> See step 7 A --> See step 5
  5. REPLACE DISPLAY AND NAVIGATION MODULE DISPLAY. Refer to «REMOVAL»(ref-385267-S21347152882011021400000)
  6. GO TO "MICROPHONE CIRCUIT BETWEEN OVERHEAD J/B AND MULTI-DISPLAY". Refer to «Microphone Circuit between Overhead J/B and Multi-display»(ref-385265-S11082704292011021400000)
  7. REPLACE MULTI-DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385268-S00404269842011021400000)
  1. CHECK RADIO RECEIVER ASSEMBLY Disconnect the F1, F23 and F24 receiver connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F1-5 (ATX+) - F1-15 (ATX-) Always 60 to 80 ohms F23-9 (TX+) - F23-10 (TX-) Always 60 to 80 ohms F24-9 (TXM+) - F24-10 (TXM-) Always 60 to 80 ohms NG --> See step 4 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR HINT: For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check all AVC-LAN circuits. Disconnect all connectors in all AVC-LAN circuits. Check for an open or short in all AVC-LAN circuits. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
  3. PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385262-S37323008262011021400000)
  4. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. IDENTIFY COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the "LAN Mon" switch to change to "LAN Monitor" mode. Identify the component shown by the sub-code. HINT: "110 (multi-display)" or "118 (display and navigation module display)" is the component shown by the sub-code in the example shown in the illustration. The sub-code will be indicated by its physical address. For the component list, refer to Diagnosis Display Detailed Description in the System Description. Refer to «SYSTEM DESCRIPTION»(ref-385262-S28647305572011021400000) . NEXT: Go to next step
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. COMPONENT TABLE Display Proceed to Stereo component amplifier (440) Stereo component amplifier power source circuit. Refer to «Stereo Component Amplifier Power Source Circuit»(ref-385265-S06475065432011021400000) Display and navigation module display (118)*1 Display and navigation assembly power source circuit. Refer to «Display and Navigation Assembly Power Source Circuit»(ref-385266-S09151538372011021400000) Multi-display (110)*2 Multi-display power source circuit. Refer to «Multi-display Power Source Circuit»(ref-385265-S19327313492011021400000) Parking assist ECU (1AC)*3 Parking assist ECU power source circuit. Refer to «ECU Power Source Circuit»(ref-385270-S04161577302011021400000) Stereo component tuner (1F1)*4 Satellite radio tuner power source circuit. Refer to «Satellite Radio Tuner Power Source Circuit»(ref-385265-S41934865682011021400000) Television display (1F6)*5 Television display power source circuit. Refer to «Television Display Power Source Circuit»(ref-385271-S38533421322011021400000) If the power source circuit is operating normally, proceed to the next step. *1: w/ Navigation System *2: w/o Navigation System *3: w/ Wide View Front and Side Monitor System *4: w/ SDARS System *5: w/ Rear Seat Entertainment System NEXT: Go to next step
  3. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the F1, F23 and F24 receiver connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F1-5 (ATX+) - F1-15 (ATX-) Always 60 to 80 ohms F23-9 (TX+) - F23-10 (TX-) Always 60 to 80 ohms F24-9 (TXM+) - F24-10 (TXM-) Always 60 to 80 ohms NG --> See step 6 OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check the AVC-LAN circuit between the radio receiver and the component shown by the sub-code. Disconnect all connectors between the radio receiver and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the radio receiver and the component shown by the sub-code. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK Same problem does not occur. NG --> See step 6 OK --> END
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  1. IDENTIFY COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the "LAN Mon" switch to change to "LAN Monitor" mode. Identify the component shown by the sub-code. HINT: "110 (multi-display)" or "118 (display and navigation module display)" is the component shown by the sub-code in the example shown in the illustration. The sub-code will be indicated by its physical address. For the component list, refer to Diagnosis Display Detailed Description in the System Description. Refer to «SYSTEM DESCRIPTION»(ref-385262-S28647305572011021400000) . NEXT: Go to next step
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. COMPONENT TABLE Display Proceed to Radio receiver (190) Radio receiver power source circuit. Refer to «Radio Receiver Power Source Circuit»(ref-385265-S21688277082011021400000) Display and navigation module display (118)*1 Display and navigation assembly power source circuit. Refer to «Display and Navigation Assembly Power Source Circuit»(ref-385266-S09151538372011021400000) Multi-display (110)*2 Multi-display power source circuit. Refer to «Multi-display Power Source Circuit»(ref-385265-S19327313492011021400000) Parking assist ECU (1AC)*3 Parking assist ECU power source circuit. Refer to «ECU Power Source Circuit»(ref-385270-S04161577302011021400000) Stereo component tuner (1F1)*4 Satellite radio tuner power source circuit. Refer to «Satellite Radio Tuner Power Source Circuit»(ref-385265-S41934865682011021400000) Television display (1F6)*5 Television display power source circuit. Refer to «Television Display Power Source Circuit»(ref-385271-S38533421322011021400000) If the power source circuit is operating normally, proceed to the next step. *1: w/ Navigation System *2: w/o Navigation System *3: w/ Wide View Front and Side Monitor System *4: w/ SDARS System *5: w/ Rear Seat Entertainment System NEXT: Go to next step
  3. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the F1, F23 and F24 receiver connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F1-5 (ATX+) - F1-15 (ATX-) Always 60 to 80 ohms F23-9 (TX+) - F23-10 (TX-) Always 60 to 80 ohms F24-9 (TXM+) - F24-10 (TXM-) Always 60 to 80 ohms NG --> See step 6 OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (STEREO COMPONENT AMPLIFIER - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check the AVC-LAN circuit between the stereo component amplifier and the component shown by the sub-code. Disconnect all connectors between the stereo component amplifier and the component shown by sub-code. Check for an open or short in the AVC-LAN circuit between the stereo component amplifier and the component shown by the sub-code. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK Same problem does not occur. NG --> See step 7 OK --> END
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  7. REPLACE STEREO COMPONENT AMPLIFIER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S03076087542011021400000)
  1. IDENTIFY COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the "LAN Mon" switch to change to "LAN Monitor" mode. Identify the component shown by the sub-code. HINT: "110 (multi-display)" or "118 (display and navigation module display)" is the component shown by the sub-code in the example shown in the illustration. The sub-code will be indicated by its physical address. For the component list, refer to Diagnosis Display Detailed Description in the System Description. Refer to «SYSTEM DESCRIPTION»(ref-385262-S28647305572011021400000) . NEXT: Go to next step
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. COMPONENT TABLE Display Proceed to Radio receiver (190) Radio receiver power source circuit. Refer to «Radio Receiver Power Source Circuit»(ref-385265-S21688277082011021400000) Stereo component amplifier (440) Stereo component amplifier power source circuit. Refer to «Stereo Component Amplifier Power Source Circuit»(ref-385265-S06475065432011021400000) Multi-display (110)*1 Multi-display power source circuit. Refer to «Multi-display Power Source Circuit»(ref-385265-S19327313492011021400000) Display and navigation module display (118)*2 Display and navigation assembly power source circuit. Refer to «Display and Navigation Assembly Power Source Circuit»(ref-385266-S09151538372011021400000) Parking assist ECU (1AC)*3 Parking assist ECU power source circuit. Refer to «ECU Power Source Circuit»(ref-385270-S04161577302011021400000) Stereo component tuner (1F1)*4 Satellite radio tuner power source circuit. Refer to «Satellite Radio Tuner Power Source Circuit»(ref-385265-S41934865682011021400000) If the power source circuit is operating normally, proceed to the next step. *1: w/ Navigation System *2: w/o Navigation System *3: w/ Wide View Front and Side Monitor System *4: w/ SDARS System NEXT: Go to next step
  3. INSPECT RADIO RECEIVER ASSEMBLY Disconnect the F1, F23 and F24 receiver connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F1-5 (ATX+) - F1-15 (ATX-) Always 60 to 80 ohms F23-9 (TX+) - F23-10 (TX-) Always 60 to 80 ohms F24-9 (TXM+) - F24-10 (TXM-) Always 60 to 80 ohms NG --> See step 6 OK: Go to next step
  4. CHECK HARNESS AND CONNECTOR (TELEVISION DISPLAY - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385262-S02192398962011021400000) . Referring to the AVC-LAN wiring diagram, check the AVC-LAN circuit between the television display and the component shown by the sub-code. Disconnect all connectors between the television display and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the television display and the component shown by the sub-code. OK There is no open or short circuit. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK Same problem does not occur. NG --> See step 7 OK --> END
  6. REPLACE RADIO RECEIVER ASSEMBLY. Refer to «REMOVAL»(ref-385264-S14664248812011021400000)
  7. REPLACE TELEVISION DISPLAY ASSEMBLY. Refer to «REMOVAL»(ref-385264-S16985882572011021400000)

More articles — Audio / Video (Diagnostic Codes & Circuit Tests)
