PRECAUTION
Note. When disconnecting the cable from the negative (-) battery terminal, initialize the following system(s) after the cable is reconnected.
| System Name | See procedure |
|---|---|
| Navigation System (for DVD) | INITIALIZATION |
| Advanced Parking Guidance System | |
| Power Trunk Lid System | |
| Rear Door Sunshade System |
SYSTEM NAME REFERENCE CHART
Scheme 102
Scheme 103
Scheme 104
Communication table
| Transmitter | Receiving | Signal | Line |
|---|---|---|---|
| Rain Sensor | Front Light ECU | HI continuous operation command signal LO continuous operation command signal LO single operation command signal Manual intermittent operation command signal Wipe out angle variable demand signal | LIN |
| Windshield Wiper Switch | Front Light ECU | Wiper switch INT signal Wiper switch LO signal Wiper switch HI signal Wiper switch AUTO position signal Washer switch signal Wiper switch MIST signal Wiper adjusting volume signal | CAN (MS bus) |
| Windshield Wiper Switch | Front Light ECU | Washer motor operation signal | CAN (MS bus) |
| Combination Meter | Front Light ECU | Vehicle speed signal | CAN (MS bus) |
| Front Light ECU | Rain Sensor | Wiper and washer switch signal | LIN |
| ECM | Front Light ECU | Shift position P signal Shift position N signal | CAN (V bus) |
| Front Light ECU | Combination Meter | Washer level signal | CAN (MS bus) |
COMMUNICATION CHART
HINT
- Wiper operation is controlled by the main body ECU.
- The rain sensor controls the auto wiper function.
FAIL-SAFE CHART
- FRONT WIPER SYSTEM When the wiper switch is in any position other than "OFF" and the blades are frozen, a malfunction is detected by the passenger side junction block and the wiper operation is stopped. HINT: Recovery condition: Engine switch off. When the rain sensor is broken and the wiper switch is in the AUTO position, the front wiper system is changed to the intermittent mode. HINT: Recovery condition: Signal level error cancellation from rain sensor. When the rain sensor overheats and the front wiper is in the HI operation mode, the front wiper system is changed to the LO operation mode. HINT: Recovery condition: Engine switch off or wiper operation signal is not INT and LO. When the front light ECU malfunctions, the front wiper system can be set to the HI operation mode with the combination switch only. HINT: Recovery condition: front light ECU returns to normal.
