Mirror: Removal & Installation Lexus LS IV

REMOVAL

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 38

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «REMOVAL»(ref-349743-S08783415772009120800000) )
4. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «REMOVAL»(ref-349743-S08783415772009120800000) )
5. REMOVE DOOR FRAME GARNISH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
6. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-349743-S08783415772009120800000) )
7. REMOVE MULTIPLEX NETWORK FRONT DOOR ECU (See «REMOVAL»(ref-349743-S08783415772009120800000) )
8. REMOVE FRONT NO. 2 DOOR SERVICE HOLE COVER (See «REMOVAL»(ref-349743-S08783415772009120800000) )
9. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY Disconnect the connector. Detach the 3 clamps. Remove the 3 nuts and mirror.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH Apply battery voltage and check the operation of the mirror. OK VOLTAGE REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (RMVR) Battery negative (-) --> Terminal 10 (RM+R) Turns upward (A) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 1 (RMVR) Turns downward (B) Battery positive (+) --> Terminal 9 (RMHR) Battery negative (-) --> Terminal 10 (RM+R) Turns right (C) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 9 (RMHR) Turns left (D) If the result is not as specified, replace the mirror assembly. For each position: Disconnect the battery, set the mirror position by hand, connect the battery, and check the retractable mirror's movement. OK MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Mirror Position Specified Condition Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Forward position (A) Moves from (A) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Forward position (A) Does not move Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Position between forward position (A) and driving position (C) Moves from (B) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Position between forward position (A) and driving position (C) Moves from (B) to forward position (A) Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Driving position (C) Moves from (C) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Driving position (C) Does not move Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Position between driving position (C) and retracted position (E) Moves from (D) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Position between driving position (C) and retracted position (E) Moves from (D) to driving position (C) Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Retracted position (E) Does not move Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Retracted position (E) Moves from (E) to driving position (C) NOTE: Disconnect and reconnect the battery between each mirror position check. The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. If the result is not as specified, replace the mirror assembly. Check the mirror heater. Measure the resistance between terminals 4 and 12 of the connector. Standard resistance: 3.6 to 4.0 ohms at 25°C (75°F) Apply battery voltage and check the operation of the mirror heater. OK VOLTAGE REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (HTR+) Battery negative (-) --> Terminal 12 (HTR-) Mirror becomes warm HINT: It will take a short time for the mirror to become warm. If the result is not as specified, replace the mirror assembly.
2. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH Apply battery voltage and check the operation of the mirror. OK VOLTAGE REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (RMVR) Battery negative (-) --> Terminal 10 (RM+R)) Turns upward (A) Battery negative (-) --> Terminal 10 (RM+R)) Battery positive (+) --> Terminal 1 (RMVR) Turns downward (B) Battery positive (+) --> Terminal 9 (RMHR) Battery negative (-) --> Terminal 10 (RM+R) Turns left (C) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 9 (RMHR) Turns right (D) If the result is not as specified, replace the mirror assembly. For each position: Disconnect the battery, set the mirror position by hand, connect the battery, and check the retractable mirror's movement. OK MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Mirror Position Specified Condition Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Forward position (A) Moves from (A) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Forward position (A) Does not move Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Position between forward position (A) and driving position (C) Moves from (B) to retracted position (E) Battery positive (+) - Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Position between forward position (A) and driving position (C) Moves from (B) to forward position (A) Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Driving position (C) Moves from (C) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Driving position (C) Does not move Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Position between driving position (C) and retracted position (E) Moves from (D) to retracted position (E) Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Position between driving position (C) and retracted position (E) Moves from (D) to driving position (C) Battery positive (+) --> Terminal 3 (MR) Battery negative (-) --> Terminal 11 (MF) Retracted position (E) Does not move Battery positive (+) --> Terminal 11 (MF) Battery negative (-) --> Terminal 3 (MR) Retracted position (E) Moves from (E) to driving position (C) NOTE: Disconnect and reconnect the battery between each mirror position check. The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. If the result is not as specified, replace the mirror assembly. Check the mirror heater. Measure the resistance between terminals 4 and 12 of the connector. Standard resistance: 3.6 to 4.8 ohms at 25°C (75°F) Apply battery voltage and check the operation of the mirror heater. OK VOLTAGE REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (HTR+) Battery negative (-) --> Terminal 12 (HTR-) Mirror becomes warm HINT: It will take a short time for the mirror to become warm. If the result is not as specified, replace the mirror assembly.

INSTALLATION

HINT

Scheme 44

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (see «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

1. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY Install the mirror with the 3 nuts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) Attach the 3 clamps. Connect the connector.
2. INSTALL FRONT NO. 2 DOOR SERVICE HOLE COVER (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
3. INSTALL DOOR FRAME GARNISH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
4. INSTALL FRONT DOOR TRIM COVER (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
5. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
6. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
8. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 45

HINT

1. Use the same procedures for the LH side and RH side.
2. The procedures listed below are for the LH side.

Scheme 46

Scheme 47

1. REMOVE OUTER MIRROR GLASS Push the upper part of the mirror surface and tilt it. Using a molding remover, detach the 4 claws and separate the outer rear view mirror glass. HINT: Apply protective tape to the outer rear view mirror to prevent it from being damaged. Disconnect the 3 connectors and remove the mirror glass.

Scheme 48

1. INSTALL OUTER MIRROR GLASS Connect the 3 connectors. Attach the 4 claws to install the mirror glass.

Scheme 49

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

1. INSTALL OUTER MIRROR SWITCH ASSEMBLY Attach the 4 claws to install the switch. Connect the switch connector.
2. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
3. INSTALL NO. 1 INSTRUMENT CLUSTER MOLDING (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
4. INSTALL INSTRUMENT SIDE PANEL LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
