Mirror: Diagnosis Lexus LS IV

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use the following procedures to troubleshoot the power mirror control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP
2. INSPECT BATTERY VOLTAGE Standard voltage: 11 to 14 V If the voltage is below 11V, recharge or replace the battery before proceeding.
3. INSPECT ELECTRIC POWER CONTROL SYSTEM* Using the Techstream, check the electric power control system's load control history (see «OPERATION CHECK»(ref-349751-S29657962842009120800000) ).
4. CHECK COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Result: RESULT REFERENCE CHART Result Proceed to CAN DTC is not output A CAN DTC is output B B: Go to CAN COMMUNICATION SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349742-S27214063842009120800000) ) A: Go to next step
5. PROBLEM SYMPTOMS TABLE Result: RESULT REFERENCE CHART Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B: Go to step 7 A: Go to next step
6. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check (see «OPERATION CHECK»(ref-349753-S03673779412009120800000) ) DATA LIST/ACTIVE TEST (see «DATA LIST/ACTIVE TEST»(ref-349753-S42440817922009120800000) ) Terminals of ECU (see «TERMINALS OF ECU»(ref-349753-S42697345532009120800000) )
7. ADJUST, REPAIR OR REPLACE
8. CONFIRMATION TEST NEXT: END

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. CHECK POWER MIRROR SWITCH OPERATION OF INTEGRATION CONTROL AND PANEL Turn the engine switch on (ACC). With the mirror master switch set to L, check that the mirror surface moves UP, DOWN, LEFT and RIGHT normally. With the mirror master switch set to R, check that the mirror surface moves UP, DOWN, LEFT and RIGHT normally.
2. CHECK MEMORY AND REACTIVATION FUNCTION HINT: The SET, M1, M2 and M3 switches of the seat memory switch are shown in the illustration. Turn the engine switch on (IG) and move the shift lever into the P position. Check the M1 switch. Using the mirror master switch and mirror control switch, fully turn the mirror to the left. Press and hold down switches M1 and SET. Check that the buzzer sounds for 0.5 seconds, signaling that the outer mirror position has been recorded. Change the position of the outer mirror and then press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully-turned-left position. Check the M2 switch. Using the mirror master switch and mirror control switch, fully turn the mirror to the right. Press and hold down switches M2 and SET. Check that the buzzer sounds for 0.5 seconds, signaling that the outer mirror position had been recorded. Change the position of the outer mirror and then press the M2 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully-turned-right position. Check the M3 switch. Using the mirror master switch and mirror control switch, fully turn the mirror upward. Press and hold down switches M3 and SET. Check that the buzzer sounds for 0.5 seconds, signaling that the outer mirror position has been recorded. Change the position of the outer mirror and then press the M3 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully-upward position. When the outer mirror is in the driving position: Check that the M1, M2 and M3 switches cause the outer mirror to move to the recorded outer mirror positions under these conditions: turn the engine switch OFF, open the driver side door and press the M1, M2 or M3 switch within 20 seconds. Check that the following procedures will erase the recorded outer mirror positions of the M1, M2 and M3 switches: press and hold the power seat slide switch; disconnect the battery's negative (-) terminal cable; and wait for at least 1 minute. Confirm that all recorded outer mirror positions are erased. Then attempt to record the outer mirror position by pressing and holding the SET switch and 2 other switches (among M1, M2 and M3). Check that no outer mirror positions are recorded by individually pressing M1, M2 and M3 and making sure that the outer mirror does not move.
3. CHECK POWER RETRACTABLE MIRROR Turn the engine switch on (ACC). At each position of the outer mirror body, check the retractable mirror's operation when operating the retract switch of the outer mirror. Move the mirrors to the driving position. Press the retract switch. Check that the right and left mirrors move from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the mirrors to the forward position by hand. Press the retract switch. Check that the forward position mirror moves to the retracted position, and check that the driving position mirror moves to the retracted position. Move the mirrors to the driving position. Move one of the mirrors to the retracted position by hand. Press the retract switch. Check that the driving position mirror moves to the retracted position. Move the mirrors to the retracted position. Press the retract switch. Check that the right and left mirrors move from the retracted position to the driving position. Move the mirrors to the retracted position. Move one of the mirrors to the driving position by hand. Press the retract switch. Check that the retracted position mirror moves to the driving position. Check the operation of the outer mirror body in relation to retract switch operations and engine switch position changes. When the mirror body is operating, turn the engine switch off. Check that the mirror operation does not stop and continues until the operation has finished. Repeat the step above. This time, before the mirror operation completes, turn the engine switch on (ACC) and press the retract switch. Check that the mirror operates in the opposite direction. Check the operation of the outer mirror body when it is restrained by an obstacle. When the mirror body is moving to the retracted or driving position, restrain the mirror body by hand. Check that the mirror stops moving. With the mirror body stopped partway, push the retract switch. Check that the mirror body moves in the opposite direction.
4. CHECK REVERSE-SHIFT-LINKED OPERATION OF MIRRORS Turn the engine switch on (IG). Set the mirror master switch to L or R. Check that the mirror faces downward when the shift lever is moved to R. Check that the outer rear view mirror returns to the original position when one of the following conditions is met: Shift lever is moved to position other than P. Mirror master switch is in the neutral position (OFF). Engine switch is turned off.
5. CHECK MIRROR HEATER Turn the engine switch on (IG). Check that pressing the rear defogger switch illuminates the indicator and warms the mirror surface. Check that after approximately 15 minutes, the indicator light turns off and the mirror heater deactivates.
6. AUTO ELECTRIC RETRACT INSPECTION With the engine switch off, and with the mirror retract switch ON (AUTO ON), when the doors are changed from the locked to the unlocked position through the entry, wireless or key-linked function, check that the outer rear view mirror body moves from the retracted position to the driving position, and stops in the driving position. With the engine switch off, and with the mirror retract switch ON (AUTO ON), when the doors are changed from the unlocked to the locked position through the entry, wireless or key-linked function, check that the outer rear view mirror body moves from the driving position to the retracted position, and stops in the retracted position.
7. MEMORY CALL FUNCTION AUTOMATIC MEMORY CALL OPERATION INSPECTION With the transmitter's recognition code registered into the memory system, perform an entry unlock or wireless unlock operation. Open the driver door and check that the front seat, front seat belt anchor, steering wheel and outer rear view mirror automatically move to the positions recorded in memory. MEMORY REGISTRATION (WITH WIRELESS FUNCTION) Prepare by recording the driving position through the memory switch (M1, M2 or M3). With the engine switch off and the driver door closed, press and hold both of the following: a memory switch (M1, M2 or M3) and a transmitter switch. Continue holding the switches until the answer back buzzer sounds. HINT: Either the LOCK or UNLOCK switch on the transmitter can be pressed. MEMORY REGISTRATION (WITH WIRELESS FUNCTION, CARD TYPE) Prepare by recording the driving position through the memory switch (M1, M2 or M3). Hold only the transmitter to be registered. With the engine switch off and the driver door closed, press and hold both of the following: a memory switch (M1, M2 or M3) and door lock control switch. Continue holding the switches until the answer back buzzer sounds. NOTE: Do not bring 2 or more keys into the vehicle. HINT: Either the lock or unlock switch on the door control switch can be pressed. The door control switch on the driver side or front passenger side can be used. MEMORY ERASURE (WITH WIRELESS FUNCTION) With the engine switch off and the driver door closed, press and hold both of the following: the memory SET switch and transmitter switch. Continue holding the switches until the answer back buzzer sounds. HINT: Either the LOCK or UNLOCK switch on the transmitter can be pressed. MEMORY ERASURE (WITH WIRELESS FUNCTION, CARD TYPE) Hold only the transmitter of which registration is to be erased. With the engine switch off and the driver door closed, press and hold both of the following: the memory SET switch and door lock control switch. Continue holding the switches until the answer back buzzer sounds. NOTE: Do not bring 2 or more keys into the vehicle. HINT: Either the lock or unlock switch on the door control switch can be pressed. The door control switch on the driver side or front passenger side can be used.

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to the system before inspecting the suspected areas below.
3. The electrical equipment operation may be limited by the load control of electric power control system. Follow the «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349753-S01687010972009120800000) procedures.

Power mirror control system

PROBLEM SYMPTOMS CHART

Scheme 24

Scheme 25

Scheme 26

1. CHECK FRONT DOOR ECU LH Disconnect the N10 and z10 ECU connectors. Measure the voltage and resistance of the wire harness side connectors. RESISTANCE AND VOLTAGE REFERENCE CHART Terminal No. (Symbols) Wiring Color Terminal Description Condition Specified Condition N10-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms N10-11 (CPUB) - N10-1 (GND) B - W-B Battery (ECU power source) Always 11 to 14 V N10-3 (SIG) - N10-1 (GND) L - W-B Ignition power supply Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V N10-6 (BDR) - N10-1 (GND) BE - W-B Battery (ECU power source) Always 11 to 14 V z10-12 (HTR-) - z10-4 (HTR+) B-W Mirror heater output and ground 25°C (75°F) 3.0 to 4.0 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the N10, and z10 ECU connectors. Measure the voltage of the connectors. VOLTAGE REFERENCE CHART Terminal No. (Symbols) Wiring Color Terminal Description Condition Specified Condition z10-3 (MR) - N10-1 (GND) L - W-B Mirror retract motor output (retracting) Mirror retract switch ON (Outer rear view mirror LH is retracting) 11 to 14 V z10-11 (MF) - N10-1 (GND) G - W-B Mirror retract motor output (returning) Mirror retract switch OFF (Outer rear view mirror LH is returning) 11 to 14 V z10-10 (RM+R) - N10-1 (GND) R - W-B Mirror motor output Mirror master switch L, Mirror control switch OFF Below 1 V Mirror master switch L, Mirror control switch UP or LEFT Below 1 V Mirror master switch L, Mirror control switch DOWN or RIGHT 11 to 14 V z10-9 (RMHR) - N10-1 (GND) BR - W-B Mirror motor output Mirror master switch L, Mirror control switch OFF Below 1 V Mirror master switch L, Mirror control switch RIGHT Below 1 V Mirror master switch L, Mirror control switch LEFT 11 to 14 V z10-1 (RMVR) - N10-1 (GND) V - W-B Mirror motor output Mirror master switch L, Mirror control switch OFF Below 1 V Mirror master switch L, Mirror control switch DOWN Below 1 V Mirror master switch L, Mirror control switch UP 11 to 14 V z10-4 (HTR+) - N10-1 (GND) W - W-B Mirror heater output Rear defogger switch ON 11 to 14 V Rear defogger switch OFF Below 1 V z10-6 (VSSR) - z10-14 (RE1) Y-B - GR Vertical direction position signal Mirror master switch R or L Mirror control switch UP or DOWN Voltage fluctuates between 0 and 5 V z10-13 (HSSR) - z10-14 (RE1) P - GR Horizontal direction position signal Mirror master switch R or L Mirror control switch RIGHT or LEFT Voltage fluctuates between 0 and 5 V z10-5 (RVC) - z10-14 (RE1) R-W - GR Power source for mirror position sensor Engine switch off during sleep mode Below 1 V Engine switch on (IG) 3.5 to 5.5 V N10-21 (ECI+) - N10-22 (ECI-) R - L EC mirror signal Electrochromic mirror system is operating 1.05 to 1.35 V Electrochromic mirror system is not operating Below 1 V z10-7 (EC+) - z10-15 (EC-) B-G - B-R EC mirror signal Electrochromic mirror system is operating 1.05 to 1.35 V Electrochromic mirror system is not operating Below 1 V If the result is not as specified, the ECU may have a malfunction.
2. CHECK FRONT DOOR ECU RH Disconnect the N1 and z9 ECU connectors. Measure the voltage and resistance of the wire harness side connectors. RESISTANCE AND VOLTAGE REFERENCE CHART Terminal No. (Symbols) Wiring Color Terminal Description Condition Specified Condition N1-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms N1-11 (CPUB) - NM (GND) R - W-B Battery (ECU power source) Always 11 to 14 V N1-3 (SIG) - N1-1 (GND) V - W-B Ignition power supply Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V N1-6 (BDR) - N1-1 (GND) BE - W-B Battery (ECU power source) Always 11 to 14 V z9-12 (HTR-) - z9-4 (HTR+) B-W Mirror heater output and ground 25°C (75°F) 3.0 to 4.0 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the N1 and z9 ECU connectors. Measure the voltage of the connectors. VOLTAGE REFERENCE CHART Terminal No. (Symbols) Wiring Color Terminal Description Condition Specified Condition z9-3 (MR) - N1-1 (GND) L - W-B Mirror retract motor output (retracting) Mirror retract switch ON (Outer rear view mirror RH is retracting) 11 to 14 V z9-11 (MF) - N1-1 (GND) G - W-B Mirror retract motor output (returning) Mirror retract switch OFF (Outer rear view mirror RH is returning) 11 to 14 V z9-10 (RM+R) - N1-1 (GND) R - W-B Mirror motor output Mirror master switch R, Mirror control switch OFF Below 1 V Mirror master switch R, Mirror control switch UP or LEFT Below 1 V Mirror master switch R, Mirror control switch DOWN or RIGHT 11 to 14 V z9-9 (RMHR) - N1-1 (GND) BR - W-B Mirror motor output Mirror master switch R, Mirror control switch OFF Below 1 V Mirror master switch R, Mirror control switch RIGHT Below 1 V Mirror master switch R, Mirror control switch LEFT 11 to 14 V z9-1 (RMVR) - N1-1 (GND) V - W-B Mirror motor output Mirror master switch R, Mirror control switch OFF Below 1 V Mirror master switch R, Mirror control switch DOWN Below 1 V Mirror master switch R, Mirror control switch UP 11 to 14 V z9-4 (HTR+) - N1-1 (GND) W - W-B Mirror heater output Rear defogger switch ON 11 to 14 V Rear defogger switch OFF Below 1 V z9-6 (VSSR) - z9-14 (RE1) Y-B - GR Vertical direction position signal Mirror master switch R or L Mirror control switch UP or DOWN Voltage fluctuates between 0 and 5 V z9-13 (HSSR) - z9-14 (RE1) P-GR Horizontal direction position signal Mirror master switch R or L Mirror control switch RIGHT or LEFT Voltage fluctuates between 0 and 5 V z9-5 (RVC) - z9-14 (RE1) R-W - GR Power source for mirror position sensor Engine switch on (ACC) or off during sleep mode Below 1 V Engine switch on (IG) 3.5 to 5.5 V N1-21 (ECI+) - N1-22 (ECI-) R-L EC mirror signal Electrochromic mirror system is operating 1.05 to 1.35 V Electrochromic mirror system is not operating Below 1 V z9-7 (EC+) - z9-15 (EC-) B-G - B-R EC mirror signal Electrochromic mirror system is operating 1.05 to 1.35 V Electrochromic mirror system is not operating Below 1 V If the result is not as specified, the ECU may have a malfunction.
3. CHECK OUTER MIRROR SWITCH ASSEMBLY Disconnect the L6 switch connector. Measure the voltage and resistance of the wire harness side connector. RESISTANCE AND VOLTAGE REFERENCE CHART Terminal No. (Symbols) Wiring Color Terminal Description Condition Specified Condition L6-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms L6-12 (B) - L6-1 (E) B - W-B Battery (ECU power source) Always 11 to 14 V L6-11 (IG) - L6-1 (E) G - W-B Ignition power supply Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V If the result is not as specified, there may be a malfunction on the wire harness side.

DATA LIST/ACTIVE TEST

1. READ DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical/(desired system)/Data List / According to the display on the Techstream, read the "Data List". Driver Door DATA LIST REFERENCE CHART Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Memory No. 1 Driver side mirror position memorized in seat memory switch M1/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 2 Driver side mirror position memorized in seat memory switch M2/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 3 Driver side mirror position memorized in seat memory switch M3/ON or OFF ON: Memorized OFF: Not memorized - Mirror Vertical Sensor Voltage Driver side mirror vertical sensor voltage/MIN: 0, MAX: 255 Within range from 0 to 255 - Mirror Horizontal Sensor Voltage Driver side mirror horizontal sensor voltage/MIN: 0, MAX: 255 Within range from 0 to 255 - Passenger Door DATA LIST REFERENCE CHART Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Memory No. 1 Passenger side mirror position memorized in seat memory switch M1/ ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 2 Passenger side mirror position memorized in seat memory switch M2/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 3 Passenger side mirror position memorized in seat memory switch M3/ON or OFF ON: Memorized OFF: Not memorized - Mirror Vertical Sensor Voltage Passenger side mirror vertical sensor voltage/MIN: 0, MAX: 255 Within range from 0 to 255 - Mirror Horizontal Sensor Voltage Passenger side mirror horizontal sensor voltage/MIN: 0, MAX: 255 Within range from 0 to 255 - D-SEAT SW DATA LIST REFERENCE CHART Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (Right) Mirror master switch signal for RH mirror/ON or OFF ON: Switch is in R position OFF: Switch is OFF or in L position - Mirror Selection SW (Left) Mirror master switch signal for LH mirror/ON or OFF ON: Switch is in L position OFF: Switch is OFF or in R position - Mirror Adjustment Right Mirror control switch signal (RIGHT)/ON or OFF ON: RIGHT switch is ON OFF: Any switch except RIGHT is ON or all switches are OFF - Mirror Adjustment Left Mirror control switch signal (LEFT) /ON or OFF ON: LEFT switch is ON OFF: Any switch except LEFT is ON or all switches are OFF - Mirror Adjustment Up Mirror control switch signal (UP)/ON or OFF ON: UP switch is ON OFF: Any switch except UP is ON or all switches are OFF - Mirror Adjustment Down Mirror control switch signal (DOWN)/ON or OFF ON: DOWN switch is ON OFF: Any switch except DOWN is ON or all switches are OFF - Mirror Close Switch Mirror retract switch signal/ON or OFF ON: Switch is ON (retracting) OFF: Switch is OFF - Mirror Open Switch Mirror retract switch signal/ON or OFF ON: Switch is ON (returning) OFF: Switch is OFF
2. PERFORM ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical/(desired system)/Active Test / According to the display on the Techstream, perform the "Active Test". Driver Door ACTIVE TEST REFERENCE CHART Tester Display Test Part Control Range Mirror Heater Mirror heater operation OFF/ON Mirror Fold/Return Mirror retract operation FOLD/RETURN Mirror Right/Left Mirror horizontal operation RIGHT/LEFT Mirror Up/Down Mirror vertical operation UP/DOWN Passenger Door ACTIVE TEST REFERENCE CHART Tester Display Test Part Control Range Mirror Heater Mirror heater operation OFF/ON Mirror Fold/Return Mirror retract operation FOLD/RETURN Mirror Right/Left Mirror horizontal operation RIGHT/LEFT Mirror Up/Down Mirror vertical operation UP/DOWN

INSPECTION PROCEDURE

1. CHECK DTC Use the Techstream to check if the CAN communication system is functioning normally. Result RESULT REFERENCE CHART Result Proceed to CAN DTC is not output A CAN DTC is output B B: GO TO CAN COMMUNICATION SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349742-S27214063842009120800000) ) A: Go to next step
2. READ VALUE USING TECHSTREAM (MIRROR MASTER SWITCH AND MIRROR CONTROL SWITCH) Check the Data List for proper functioning of the mirror master switch and mirror control switch. D-SEAT SW DATA LIST REFERENCE CHART Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror selection SW (Right) Mirror master switch signal for RH mirror/ON or OFF ON: Switch is in R position OFF: Switch is OFF or in L position - Mirror selection SW (Left) Mirror master switch signal for LH mirror/ON or OFF ON: Switch is in L position OFF: Switch is OFF or in R position - Mirror Adjustment Right Mirror control switch signal (RIGHT)/ON or OFF ON: RIGHT switch is ON OFF: Any switch except RIGHT is ON or all switches are OFF - Mirror Adjustment Left Mirror control switch signal (LEFT)/ON or OFF ON: LEFT switch is ON OFF: Any switch except LEFT is ON or all switches are OFF - Mirror Adjustment Up Mirror control switch signal (UP)/ON or OFF ON: UP switch is ON OFF: Any switch except UP is ON or all switches are OFF - Mirror Adjustment Down Mirror control switch signal (DOWN)/ON or OFF ON: DOWN switch is ON OFF: Any switch except DOWN is ON or all switches are OFF - OK: On screen, each item changes between ON and OFF according to above chart. NG: REPLACE OUTER MIRROR SWITCH ASSEMBLY (See «REMOVAL»(ref-349753-S37125702932009120800000) ) OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349706-S05264741182009120800000) )

1. CHECK DTC Use the Techstream to check if the CAN communication system is functioning normally. Result: RESULT REFERENCE CHART Result Proceed to CAN DTC is not output A CAN DTC is output B B: GO TO CAN COMMUNICATION SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349742-S27214063842009120800000) ) A: Go to next step
2. CHECK SEAT MEMORY SWITCH FUNCTION (SEAT POSITION MEMORY FUNCTION) Check that the driver side seat can be moved using the seat memory switch. OK: Driver side seat can be moved using seat memory switch. NG: GO TO POWER SEAT CONTROL SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349741-S09682616932009120800000) ) OK: Go to next step
3. CHECK SEAT MEMORY SWITCH FUNCTION (REGISTRATION OF SEAT MEMORY SWITCH) Check that the memory operation is properly completed. NOTE: The seat position will not be recorded if the SET switch and 2 or more of the memory switches (for example, M1 and M2) are pressed simultaneously. If the operation fails, the mirror facing direction will not be memorized until the SET switch is turned off. The mirror facing direction will not be memorized when the mirror is operated manually. OK: Driver side seat position can be memorized using seat memory switch (driver side). NG: Go to step 4 OK: SYSTEM IS OK
4. READ VALUE USING TECHSTREAM (MIRROR POSITION MEMORY) Check the Data List for proper functioning of the mirror position memory. Driver Door DATA LIST REFERENCE CHART Tester Display Measurement Item/Display Normal Condition Diagnostic Note Mirror Memory No. 1 Driver side mirror position memorized in seat memory switch M1/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 2 Driver side mirror position memorized in seat memory switch M2/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 3 Driver side mirror position memorized in seat memory switch M3/ON or OFF ON: Memorized OFF: Not memorized - Passenger Door DATA LIST REFERENCE CHART Tester Display Measurement Item/Display Normal Condition Diagnostic Note Mirror Memory No. 1 Passenger side mirror position memorized in seat memory switch M1/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 2 Passenger side mirror position memorized in seat memory switch M2/ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 3 Passenger side mirror position memorized in seat memory switch M3/ON or OFF ON: Memorized OFF: Not memorized - OK: On screen, each item changes between ON and OFF according to above chart. Result RESULT REFERENCE CHART Result Proceed to Operates normally A Driver side does not operate normally B Passenger side does not operate normally C B: REPLACE FRONT DOOR ECU LH (See «REMOVAL»(ref-349743-S08783415772009120800000) ) C: REPLACE FRONT DOOR ECU RH (See «REMOVAL»(ref-349743-S08783415772009120800000) ) A: REPLACE FRONT POWER SEAT SWITCH LH (See «DISASSEMBLY»(ref-349741-S26080968532009120800000) )

1. CHECK DTC Use the Techstream to check if the CAN communication system is functioning normally. Result: RESULT REFERENCE CHART Result Proceed to CAN DTC is not output A CAN DTC is output B B: GO TO CAN COMMUNICATION SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349742-S27214063842009120800000) ) A: Go to next step
2. CHECK OUTER MIRROR SWITCH FUNCTION (POWER MIRROR CONTROL FUNCTION) Check that the outer rear view mirror LH and RH can be moved using the outer mirror switch. OK: Outer rear view mirror LH and RH can be moved using the outer mirror switch. NG: GO TO «PROBLEM SYMPTOMS TABLE»(ref-349753-S18761548342009120800000) OK: Go to next step
3. CHECK OPERATION OF SHIFT INDICATOR Check that the shift indicator of the combination meter operates normally. OK: Shift indicator of combination meter operates normally. NG: GO TO METER/GAUGE SYSTEM (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349730-S19668506302009120800000) ) OK: Go to next step
4. CHECK FRONT DOOR ECU (OPERATION) Replace the front door ECU with a new one or normally operating one, and check if a malfunction disappears. Result: RESULT REFERENCE CHART Result Proceed to Outer rear view mirror LH does not operate normally A Outer rear view mirror RH does not operate normally B Outer rear view mirror LH operates normally C Outer rear view mirror RH operates normally D B: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH (See «REMOVAL»(ref-349753-S16673023322009120800000) ) C: REPLACE FRONT DOOR ECU LH (See «REMOVAL»(ref-349743-S08783415772009120800000) ) D: REPLACE FRONT DOOR ECU RH (See «REMOVAL»(ref-349743-S08783415772009120800000) ) A: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH (See «REMOVAL»(ref-349753-S16673023322009120800000) )

Scheme 27

Scheme 28

Scheme 29

1. COMPASS DISPLAY MODE SELECTION Turn the compass display ON and OFF by pressing and holding the AUTO switch for 3 seconds. Procedures for selecting compass mode. Turn the engine switch on (IG). Check that the inner mirror's LED illuminates green. Check that one of the following directions is displayed: N, NE, E, SE, S, SW, W, NW. Press and hold the inner mirror's AUTO switch for 3 seconds, and check that the direction display turns off. HINT: Immediately after the AUTO switch is pressed, check that the LED turns off and the inner mirror anti-glare mode turns off. Then, after the AUTO switch is pressed and held for 3 seconds, check that the LED illuminates and the inner mirror anti-glare mode turns on.
2. COMPASS ZONE SETTING HINT: The location of magnetic north and true north differs depending on the vehicle's location. Adjustment of the compass's magnetism is required. The user must select a zone as the automatic adjustment will be different depending on the vehicle's location. Change the inner mirror's zone setting using the AUTO switch procedures described below. Turn the engine switch on (IG). Check that the inner mirror's LED illuminates green. Check that one of the following directions is displayed: N, NE, E, SE, S, SW, W, NW. Press and hold the inner mirror's AUTO switch for 3 seconds, and check that the direction display turns off. Do not release the AUTO switch and hold it for another 3 seconds (total press time: 6 seconds). Check that ZONE or a number from 1 to 15 is displayed on the compass. Each press of the AUTO switch causes the number display to increase by 1. Use the zone setting map to find the appropriate zone and set the zone number. After setting the zone number, check that waiting several seconds causes the compass to return to the direction display.
3. COMPASS ZONE MAP
4. COMPASS CALIBRATION HINT: Compass calibration should be performed on each vehicle, as each vehicle has a unique magnetic field. Performing compass calibration will store information about the vehicle's magnetic field. Procedures for calibration. Turn the engine switch on (IG). Check that the inner mirror's LED illuminates green. Check that one of the following directions is displayed: N, NE, E, SE, S, SW, W, NW. Press and hold the inner mirror's AUTO switch for 3 seconds, and check that CAL is displayed on the compass. Perform calibration by driving the vehicle at 8 km/h (5 mph) or less in a circle. Drive in a circle 1 to 3 times, and check that calibration is completed by confirming that CAL is not displayed on the compass. HINT: After the calibration is performed once, calibration will not be necessary unless the vehicle's magnetic field changes drastically. If the magnetic field has changed, CAL will be displayed on the compass.

Use the table below to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.

Automatic glare-resistant EC mirror

PROBLEM SYMPTOMS CHART

Scheme 30

Scheme 31

Scheme 32

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
3. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-349734-S03706653952009120800000) )
4. REMOVE INNER REAR VIEW MIRROR COVER (w/o Rain Sensor) Detach the 2 claws and remove the inner rear view mirror cover as shown in the illustration.
5. REMOVE RAIN SENSOR COVER (w/ Rain Sensor) Pull the stopper in the direction shown in the illustration. Detach the 2 claws and remove the rain sensor cover.
6. REMOVE INNER REAR VIEW MIRROR ASSEMBLY Disconnect the connector. Using a T20 "TORX" socket wrench, remove the screw and inner rear view mirror.

Scheme 33

1. INSPECT INNER REAR VIEW MIRROR ASSEMBLY Check operation of the electrochromic inner mirror. Connect the battery positive (+) lead to terminal 4 and the negative (-) lead to terminal 1. Attach black colored tape to the forward sensor to prevent it from sensing. Shine an electric light on the mirror. Check that the mirror surface changes from bright to dark. HINT: When the environment is very bright, the antiglare operation may occur immediately after the tape is applied. If the result is not as specified, replace the mirror assembly.

Scheme 34

Scheme 35

1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY Using a T20 "TORX" socket wrench, install the inner rear view mirror with the screw. Torque: 1.8 N*m (18 kgf*cm, 16 in.*lbf) Connect the connector.
2. INSTALL INNER REAR VIEW MIRROR COVER (w/o Rain Sensor) Attach the 2 claws to install the cover.
3. INSTALL RAIN SENSOR COVER (w/ Rain Sensor) Attach the 2 claws to install the rain sensor cover. Push the stopper as shown in the illustration to fix the cover in place.
4. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
6. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )

Scheme 36

ON-VEHICLE INSPECTION

1. CHECK POWER RETRACTABLE MIRROR Turn the engine switch on (ACC). At each position of the outer mirror body, check the retractable mirror's operation when operating the retract switch of the outer mirror. Move the mirrors to the driving position. Press the retract switch. Check that the right and left mirrors move from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the mirrors to the forward position by hand. Press the retract switch. Check that the mirror moves from the forward position to the retracted position. Check that the other mirror moves from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the mirrors to the retracted position by hand. Press the retract switch. Check that the mirror moves from the driving position to the retracted position. Move the mirrors to the retracted position. Press the retract switch. Check that the right and left mirrors move from the retracted position to the driving position. Move the mirrors to the retracted position. Move one of the mirrors to the driving position by hand. Press the retract switch. Check that the mirror moves from the retracted position to the driving position. Check the operation of the outer mirror in relation to retract switch operations and engine switch position changes. When the mirror is operating, turn the engine switch off. Check that the mirror operation does not stop and continues until the operation has finished. Repeat the step above. This time, before the mirror operation completes, turn the engine switch on (ACC) and press the retract switch. Check that the mirror operates in the opposite direction. Check the operation of the outer mirror when it is restrained by an obstacle. When the mirror is moving to the retracted or driving position, restrain the mirror by hand. Check that the mirror stops moving. With the mirror stopped partway, push the retract switch. Check that the mirror moves in the opposite direction it was moving when it was restrained.
2. CHECK REVERSE-SHIFT LINKED OPERATION OF MIRRORS Turn the engine switch on (IG). Set the mirror switch to L or R. Check that the mirror faces downward when the shift lever is moved to R. When the shift lever is not on P, or the mirror switch is in the neutral position (OFF), check that the outer rear view mirror returns to the driving position.
3. CHECK MIRROR HEATER Turn the engine switch on (IG). Check that pressing the rear defogger switch illuminates the indicator and warms the mirror surface. Check that after approximately 15 minutes, the indicator light turns off and the mirror heater deactivates.

1. CHECK POWER MIRROR OPERATION Turn the engine switch on (ACC). When the L mirror select switch is pressed, check that the indicator light on the LH side illuminates. With the mirror select switch set to L, check that the mirror surface moves UP, DOWN, LEFT and RIGHT normally. After checking the mirror surface movement, check that pressing the L mirror select switch causes the indicator light on the LH side to turn off. When the R mirror select switch is pressed, check that the indicator light on the RH side illuminates. With the mirror select switch set to R, check that the mirror surface moves UP, DOWN, LEFT and RIGHT normally. After checking the mirror surface movement, check that pressing the R mirror select switch causes the indicator light on the RH side to turn off.

Scheme 37

1. REMOVE INSTRUMENT SIDE PANEL LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
2. REMOVE NO. 1 INSTRUMENT CLUSTER MOLDING (See «REMOVAL»(ref-349746-S04541701892009120800000) )
3. REMOVE NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
4. REMOVE OUTER MIRROR SWITCH ASSEMBLY Using a screwdriver, detach the 4 claws. HINT: Tape the screwdriver tip before use. Remove the switch and then disconnect the switch connector.
