Wiper & Washer: Removal & Installation Lexus LS IV

REMOVAL

HINT

1. Use the same procedures for both the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 61

Scheme 62

1. REMOVE FRONT WIPER BLADE LH Remove the wiper blade holder. Remove the wiper blade as shown in the illustration.
2. REMOVE WIPER RUBBER LH Detach the head part (large side) of the wiper rubber from the wiper blade. Remove the wiper rubber in the direction indicated by the arrow in the illustration. Remove the 2 wiper rubber backing plates from wiper rubber.

INSTALLATION

HINT

Scheme 63

1. Use the same procedures for both the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 64

Scheme 65

Scheme 66

1. INSTALL WIPER RUBBER LH Install the 2 packing plates to the rubber. NOTE: Install the packing plates facing the proper direction. Install the wiper rubber to the claw of the wiper blade in the direction indicated by the arrow in the illustration. HINT: Install the wiper rubber so that the head part (large side) of the wiper rubber faces the arm axle side. Attach the head part (large side) of the wiper rubber to the rear end side claw of the wiper blade. HINT: Push the wiper blade into the grooves of the wiper rubber to attach if completely.
2. INSTALL FRONT WIPER BLADE LH Install the wiper blade as shown in the illustration.

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. REMOVE STEERING COLUMN COVER While turning the steering wheel to the right and left, remove the 3 screws. Detach the 2 claws to remove the lower steering column cover. NOTE: Do not damage the tilt and telescopic switch. Detach the 4 clips. Detach the claw to remove the upper steering column cover.
2. REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY Disconnect the 2 connectors. Detach the claw and remove the wiper switch. NOTE: If the claw is pushed with excessive force, it may break.

Scheme 71

Scheme 72

1. INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY Attach the claw and install the wiper switch. Connect the 2 connectors.
2. INSTALL STEERING COLUMN COVER Attach the 4 clips to install the steering column cover upper onto the instrument panel cluster finish panel. Attach the claw to install the upper steering column cover. Attach the 2 claws to install the lower steering column cover. NOTE: Do not damage the tilt and telescopic switch. Using a screwdriver, while turning the steering wheel to the right and left, install the 3 screws.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE FRONT BUMPER COVER Remove the front bumper cover (see «REMOVAL»(ref-349736-S30791494642009120800000) ).
4. REMOVE HEADLIGHT ASSEMBLY LH (w/ Headlight Cleaner System) (See «REMOVAL»(ref-349731-S20323363362009120800000) )
5. REMOVE HEADLIGHT ASSEMBLY LH (w/o Headlight Cleaner System) (See «REMOVAL»(ref-349731-S20323363362009120800000) )
6. DRAIN WASHER FLUID Remove the washer hose from the windshield washer motor and pump, and drain the washer fluid.
7. REMOVE WASHER INLET SUB-ASSEMBLY Remove the bolt and washer inlet.
8. REMOVE WINDSHIELD WASHER JAR ASSEMBLY w/o Headlight Cleaner System: Disconnect the 2 connectors. w/ Headlight Cleaner System: Disconnect the 4 connectors. Loosen the clip and disconnect the headlight cleaner hose. Remove the 3 bolts. Then remove the windshield washer jar and pump.
9. REMOVE WINDSHIELD WASHER MOTOR AND PUMP ASSEMBLY Remove the windshield washer motor and pump.
10. REMOVE HEADLIGHT CLEANER MOTOR PUMP ASSEMBLY (w/ Headlight Cleaner System) Remove the headlight cleaner motor pump.
11. REMOVE HEADLIGHT CLEANER CONTROL RELAY (w/ Headlight Cleaner System) Remove the headlight cleaner control relay.

Scheme 79

1. INSPECT WINDSHIELD WASHER MOTOR AND PUMP ASSEMBLY HINT: This check should be performed with the front washer motor and pump installed to the washer jar. Fill the washer jar with washer fluid. Connect the positive (+) battery lead to terminal 1 of the washer motor and pump and the negative (-) lead to terminal 2. Check that washer fluid flows from the washer jar. OK: Washer fluid flows from washer jar.
2. INSPECT HEADLIGHT CLEANER MOTOR AND PUMP ASSEMBLY HINT: This check should be performed with the headlight cleaner motor and pump installed to the washer jar. Fill the washer jar with washer fluid. Connect the positive (+) battery lead to terminal 1 of the headlight cleaner motor and pump and the negative (-) lead to terminal 2. Check that washer fluid flows from the washer jar. OK: Washer fluid flows from washer jar.

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. INSTALL HEADLIGHT CLEANER CONTROL RELAY Install the headlight cleaner control relay.
2. INSTALL HEADLIGHT CLEANER MOTOR AND PUMP ASSEMBLY Install the headlight cleaner motor and pump.
3. INSTALL WINDSHIELD WASHER MOTOR AND PUMP ASSEMBLY Install the windshield washer motor and pump.
4. INSTALL WINDSHIELD WASHER JAR ASSEMBLY Install the windshield washer jar and pump with the 3 bolts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) w/o Headlight Cleaner System: Connect the 2 connectors. w/ Headlight Cleaner System: Connect the headlight cleaner hose to the windshield washer jar and pump. Connect the 4 connectors.
5. INSTALL WASHER INLET SUB-ASSEMBLY Install the washer inlet with the bolt. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
6. FILL WINDSHIELD WASHER JAR AND PUMP ASSEMBLY WITH WASHER FLUID Connect the washer hose to the windshield washer motor and pump, and fill the washer jar with washer fluid.
7. INSTALL HEADLIGHT ASSEMBLY LH (w/ Headlight Cleaner System) (See «INSTALLATION»(ref-349731-S11386503292009120800000) )
8. INSTALL HEADLIGHT ASSEMBLY LH (w/o Headlight Cleaner System) (See «INSTALLATION»(ref-349731-S11386503292009120800000) )
9. INSTALL FRONT BUMPER COVER Install the front bumper cover (see «INSTALLATION»(ref-349736-S16181480572009120800000) ).
10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
11. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
12. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
13. ADJUST HEADLIGHT ASSEMBLY LH Adjust the headlight (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 84

1. REMOVE WASHER NOZZLE SUB-ASSEMBLY With the engine running, check that the center stream of washer fluid sprays on the windshield within the hatched areas shown in the illustration. Standard: Washer fluid hits the windshield in the areas shown in the illustration. If the result is not as specified, replace the washer nozzle. Standard measurement STANDARD MEASUREMENT Area Specified Condition A 325 mm (12.81 in.) B 191.3 mm (7.53 in.) C 283.6 mm (11.17 in.) D 121.5 mm (4.78 in.)

Scheme 85

Scheme 86

Scheme 87

1. ADJUST WASHER NOZZLE SUB-ASSEMBLY Using a screwdriver, disengage the 2 claws and separate the washer nozzle. NOTE: Be careful not to damage the windshield. Remove the washer nozzle from the washer hose. NOTE: Washer nozzles cannot be reused. Select a washer nozzle so that the contact area is within the standard. Replace the washer nozzle with the selected one.

Scheme 88

Scheme 89

HINT

1. Use the same procedures for both the RH and LH side.
2. The procedures listed below are for the LH side.

Scheme 90

Scheme 91

Scheme 92

Scheme 93

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-349714-S31912998822009120800000) )
4. REMOVE ENGINE ROOM SIDE COVER RH (See «REMOVAL»(ref-349714-S31912998822009120800000) )
5. REMOVE AIR CLEANER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349724-S31319866602009120800000) )
6. REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-349716-S20016930692009120800000) )
7. REMOVE RADIATOR GRILLE ASSEMBLY (See «REMOVAL»(ref-349736-S03523530332009120800000) )
8. REMOVE FRONT WHEEL OPENING EXTENSION PAD LH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
9. REMOVE FRONT WHEEL OPENING EXTENSION PAD RH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
10. REMOVE FRONT FENDER LINER LH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
11. REMOVE FRONT FENDER LINER RH (See «REMOVAL»(ref-349736-S30791494642009120800000) )
12. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-349736-S30791494642009120800000) )
13. REMOVE LH HEADLIGHT ASSEMBLY (See «REMOVAL»(ref-349731-S20323363362009120800000) )
14. REMOVE HEADLIGHT WASHER ACTUATOR SUB-ASSEMBLY Pull out the headlight cleaner actuator cover while making sure that the headlight cleaner actuator cover and holder do not separate from the headlight washer actuator, and hold the headlight washer actuator in place. NOTE: If the holder separates from the headlight washer actuator, replace the headlight washer actuator. Hold the headlight washer actuator without touching the nozzle. Using nippers, cut off the headlight cleaner actuator cover as shown in the illustration, and remove it. NOTE: After removing the headlight cleaner actuator cover, make sure to hold the headlight washer actuator in place until a new headlight cleaner actuator cover is installed. If the holder is damaged when the headlight cleaner actuator cover is cut off, replace the headlight washer actuator. Remove the 2 screws.
15. REMOVE NO. 1 HEADLIGHT CLEANER HOSE Disconnect the hose from the headlight cleaner motor and pump. Using a screwdriver, detach the 4 clamps and remove the hose. HINT: Tape the screwdriver tip before use.

Scheme 94

1. INSTALL NO. 1 HEADLIGHT CLEANER HOSE Attach the 4 clamps and install the hose to the front bumper reinforcement. Connect the hose to the headlight cleaner motor and pump.
2. INSTALL HEADLIGHT WASHER ACTUATOR SUB-ASSEMBLY Install the actuator to the headlight with the 2 screws. Install a new headlight cleaner actuator cover to the headlight washer actuator.
3. INSTALL LH HEADLIGHT ASSEMBLY (See «INSTALLATION»(ref-349731-S11386503292009120800000) )
4. INSTALL RH HEADLIGHT ASSEMBLY (See «INSTALLATION»(ref-349731-S11386503292009120800000) )
5. INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
6. INSTALL FRONT FENDER LINER RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
7. INSTALL FRONT FENDER LINER LH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
8. INSTALL FRONT WHEEL OPENING EXTENSION PAD RH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
9. INSTALL FRONT WHEEL OPENING EXTENSION PAD LH (See «INSTALLATION»(ref-349736-S16181480572009120800000) )
10. INSTALL RADIATOR GRILLE ASSEMBLY (See «INSTALLATION»(ref-349736-S28013553762009120800000) )
11. INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-349716-S01754793652009120800000) )
12. INSTALL AIR CLEANER INLET COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349724-S09859827162009120800000) )
13. INSTALL ENGINE ROOM SIDE COVER RH (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
14. INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-349714-S23488176532009120800000) )
15. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
16. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
17. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
18. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight assembly (see «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 95

Scheme 96

1. REMOVE HEADLIGHT CLEANER ACTUATOR COVER Pull out the headlight cleaner actuator cover while making sure that the headlight cleaner actuator cover and holder do not separate from the headlight washer actuator, and hold the headlight washer actuator in place. NOTE: If the holder separates from the headlight washer actuator, replace the headlight washer actuator. Hold the headlight washer actuator without touching the nozzle. Using nippers, cut off the headlight cleaner actuator cover as shown in the illustration, and remove it. NOTE: After removing the headlight cleaner actuator cover, make sure to hold the headlight washer actuator in place until a new headlight cleaner actuator cover is installed. If the holder is damaged when the headlight cleaner actuator cover is cut off, replace the headlight washer actuator.

Scheme 97

1. REMOVE HEADLIGHT CLEANER ACTUATOR COVER Install a new headlight cleaner actuator cover to the headlight washer actuator.

Scheme 98

Scheme 99

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE RAIN SENSOR COVER (See «REMOVAL»(ref-349753-S08426038372009120800000) )
4. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (See «REMOVAL»(ref-349753-S08426038372009120800000) )
5. REMOVE RAIN SENSOR Pull the stopper in the direction shown in the illustration, and release the lock. Disconnect the connector, and remove the rain sensor.

Scheme 100

Scheme 101

1. INSTALL RAIN SENSOR TAPE If reusing the rain sensor: Install new rain sensor tape. Remove the used rain sensor tape from the windshield glass or rain sensor. Apply new rain sensor tape on the rain sensor lens surface indicated by the hatched area. NOTE: Keep the tape's exposed adhesive free from dust and fingerprints. Apply the tape exactly according to the specifications below. Specification SPECIFICATION CHART Area Measurement A 15 mm (0.591 in.) B 8 mm (0.315 in.)
2. INSTALL RAIN SENSOR NOTE: Make sure the adhesive between the bracket and windshield glass is normal. If there is any residue left from the rain sensor tape on the windshield, remove it. Clean the glass surface with a cloth or similar material. Make sure there are no air bubbles between the rain sensor and windshield. Peel the separation paper from the rain sensor tape. Securely attach the rain sensor to the bracket. Push the stopper upward. Connect the connector.
3. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
4. INSTALL RAIN SENSOR COVER (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
7. PERFORM INITIALIZATION Perform initialization (See «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
