Windshield/windowglass: Removal & Installation Lexus LS IV

Windows 58 illustrations ~6079 words

REMOVAL

HINT

  1. Use the same procedures for the LH side and RH side.
  2. The procedures listed below are for the RH side.

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104
  1. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY Using a screwdriver, detach the 2 clamps. HINT: Tape the screwdriver tip before use. Detach the armrest base panel assembly. Disconnect the connector. Detach the 2 claws and remove the power window regulator switch assembly.

Scheme 105

Scheme 105: INSPECTION
Scheme 105: INSPECTION
  1. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Measure the resistance according to the value (s) in the table below. Standard resistance: STANDARD RESISTANCE REFERENCE CHART Tester Connection Switch Condition Specified Condition 2 (UP) - 5 (GND) Manual UP operation Below 1 ohms 10 (DOWN) - 5 (GND) Manual DOWN operation Below 1 ohms 4 (AUTO) - 5 (GND) AUTO UP/DOWN operation Below 1 ohms If the result is not as specified, replace the power window regulator switch assembly. Check that the LED illuminates. Apply battery voltage to the power window regulator switch and check that the LED illuminates. OK: MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> 8 (LED) Battery negative (-) --> 5 (GND) LED illuminates If the result is not as specified, replace the power window regulator switch assembly.

INSTALLATION

HINT

  1. Use the same procedures for the LH side and RH side.
  2. The procedures listed below are for the RH side.

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107
  1. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY Install the power window regulator switch assembly with the 2 claws. Connect the connector. Install the armrest base panel assembly with the 2 clamps.

Scheme 108

Scheme 108: COMPONENTS
Scheme 108: COMPONENTS

Scheme 109

Scheme 109
Scheme 109

HINT

  1. Use the same procedures for the LH side and RH side.
  2. The procedures listed below are for the LH side.
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE DOOR INSIDE HANDLE BEZEL PLUG (See «COMPONENTS»(ref-349743-S24561300282009120800000) )
  3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «COMPONENTS»(ref-349743-S24561300282009120800000) )
  4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (See «ON-VEHICLE INSPECTION»(ref-349743-S12698584702009120800000) )
  5. REMOVE FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH (See «ON-VEHICLE INSPECTION»(ref-349743-S12698584702009120800000) )
  6. REMOVE COURTESY LIGHT ASSEMBLY (See «ON-VEHICLE INSPECTION»(ref-349743-S12698584702009120800000) )
  7. REMOVE FRONT DOOR TRIM COVER LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
  8. REMOVE DOOR FRAME GARNISH LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
  9. REMOVE FRONT DOOR SERVICE HOLE COVER LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
  10. REMOVE FRONT DOOR GLASS SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
  11. REMOVE FRONT DOOR WINDOW REGULATOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )
  12. REMOVE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH (See «REMOVAL»(ref-349743-S08783415772009120800000) )

Scheme 110

Scheme 110: INSPECTION
Scheme 110: INSPECTION

Scheme 111

Scheme 111
Scheme 111
  1. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front LH) Apply positive (+) battery voltage to the connector terminal 2. NOTE: Do not apply positive (+) battery voltage to any terminals, except terminal 2, to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to the connector terminals 1 and 7/10. Check that the motor gear rotates smoothly as follows. OK MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 10 (within 1 second) --> 1 (within 1 second) --> 1 and 10 Motor gear rotates clockwise (UP) Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 7 (within 1 second) --> 1 (within 1 second) --> 1 and 7 Motor gear rotates counterclockwise (DOWN) If the result is not as specified, replace the regulator motor assembly. CAUTION: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.
  2. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front RH) Apply positive (+) battery voltage to the connector terminal 2. NOTE: Do not apply positive (+) battery voltage to any terminals, except terminal 2, to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to the connector terminals 1 and 7/10. Check that the motor gear rotates smoothly as follows. OK MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 10 (within 1 second) --> 1 (within 1 second) --> 1 and 10 Motor gear rotates counterclockwise (UP) Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 7 (within 1 second) --> 1 (within 1 second) --> 1 and 7 Motor gear rotates clockwise (DOWN) If the result is not as specified, replace the regulator motor assembly. CAUTION: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.

HINT

  1. Use the same procedures for the LH side and RH side.
  2. The procedures listed below are for the LH side.
  1. INSTALL FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  2. INSTALL FRONT DOOR WINDOW REGULATOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  3. INSTALL FRONT DOOR GLASS SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  4. INSTALL FRONT DOOR SERVICE HOLE COVER LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  5. INSTALL DOOR FRAME GARNISH LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  6. INSTALL FRONT DOOR TRIM COVER LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  7. INSTALL COURTESY LIGHT ASSEMBLY (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  8. INSTALL FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  9. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  10. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  11. INSTALL DOOR INSIDE HANDLE BEZEL PLUG (See «INSTALLATION»(ref-349743-S35863977312009120800000) )
  12. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  13. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal. NOTE: When the power window regulator motor is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the AUTO UP function is used. In such cases, the AUTO UP function can be resumed by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window switch and holding it in the AUTO UP position. Open the power window by fully pushing down the switch.

Scheme 112

Scheme 112: COMPONENTS
Scheme 112: COMPONENTS

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117

HINT

  1. Use the same procedures for the LH side and RH side.
  2. The procedures listed below are for the LH side.
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  3. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  4. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  5. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (w/ Rear Door Sunshade) (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  6. REMOVE REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  7. REMOVE COURTESY LIGHT ASSEMBLY (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  8. REMOVE REAR DOOR TRIM COVER LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  9. REMOVE REAR DOOR FRAME GARNISH LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  10. REMOVE REAR DOOR NO. 2 FRAME GARNISH LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  11. REMOVE REAR CURTAIN SUB-ASSEMBLY LH (w/ Rear Door Sunshade) (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  12. REMOVE NO. 1 AUTO CURTAIN RAIL BRACKET LH (w/ Rear Door Sunshade) (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  13. REMOVE SIDE TRIM BOARD COVER REAR LH (w/ Rear Door Sunshade) (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  14. REMOVE REAR INNER DOOR GLASS WEATHERSTRIP LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  15. REMOVE REAR DOOR SERVICE HOLE COVER LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  16. REMOVE REAR DOOR DIVISION BAR BRACKET LOWER LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  17. REMOVE REAR DOOR WINDOW DIVISION BAR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  18. REMOVE REAR DOOR GLASS RUN LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  19. REMOVE REAR DOOR QUARTER WINDOW GLASS LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  20. REMOVE REAR DOOR GLASS SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  21. REMOVE REAR DOOR WINDOW REGULATOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
  22. REMOVE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )

Scheme 118

Scheme 118: INSPECTION
Scheme 118: INSPECTION
  1. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH) Apply positive (+) battery voltage to the connector terminal 2. NOTE: Do not apply positive (+) battery voltage to any terminals, except terminal 2, to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to the connector terminals 1 and 7/10. Check that the motor gear rotates smoothly as follows. OK MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 10 (within 1 second) --> 1 (within 1 second) --> 1 and 10 Motor gear rotates counterclockwise (UP) Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 7 (within 1 second) --> 1 (within 1 second) --> 1 and 7 Motor gear rotates clockwise (DOWN) If the result is not as specified, replace the regulator motor assembly. CAUTION: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.
  2. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH) Apply positive (+) battery voltage to the connector terminal 2. NOTE: Do not apply positive (+) battery voltage to any terminals, except terminal 2, to avoid damaging the pulse sensor inside the motor. Apply negative (-) battery voltage to the connector terminals 1 and 7/10. Check that the motor gear rotates smoothly as follows. OK MEASUREMENT CONDITION REFERENCE CHART Measurement Condition Specified Condition Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 10 (within 1 second) --> 1 (within 1 second) --> 1 and 10 Motor gear rotates clockwise (UP) Battery positive (+) --> 2 Battery negative (-): 1 (3 seconds or more) --> 1 and 7 (within 1 second) --> 1 (within 1 second) --> 1 and 7 Motor gear rotates counterclockwise (DOWN) If the result is not as specified, replace the regulator motor assembly. CAUTION: Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor and regulator assembly onto the door.

HINT

  1. Use the same procedures for the LH side and RH side.
  2. The procedures listed below are for the LH side.
  1. INSTALL REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  2. INSTALL REAR DOOR WINDOW REGULATOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  3. INSTALL REAR DOOR GLASS SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  4. INSTALL REAR DOOR QUARTER WINDOW GLASS LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  5. INSTALL REAR DOOR GLASS RUN LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  6. INSTALL REAR DOOR WINDOW DIVISION BAR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  7. INSTALL REAR DOOR DIVISION BAR BRACKET LOWER LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  8. INSTALL REAR DOOR SERVICE HOLE COVER LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  9. INSTALL REAR INNER DOOR GLASS WEATHERSTRIP LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  10. INSTALL SIDE TRIM BOARD COVER REAR LH (w/ Rear Door Sunshade) (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  11. INSTALL NO. 1 AUTO CURTAIN RAIL BRACKET LH (w/ Rear Door Sunshade) (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  12. INSTALL REAR CURTAIN SUB-ASSEMBLY LH (w/ Rear Door Sunshade) (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  13. INSTALL REAR DOOR NO. 2 FRAME GARNISH LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  14. INSTALL REAR DOOR FRAME GARNISH LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  15. INSTALL REAR DOOR TRIM COVER LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  16. INSTALL COURTESY LIGHT ASSEMBLY (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  17. INSTALL REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  18. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  19. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (w/ Rear Door Sunshade) (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  20. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  21. INSTALL REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
  22. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  23. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal. NOTE: When the power window regulator motor is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the AUTO UP function is used. In such cases, the AUTO UP function can be resumed by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window switch and holding it in the AUTO UP position. Open the power window by fully pushing down the switch.

Scheme 119

Scheme 119: COMPONENTS
Scheme 119: COMPONENTS

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121

Scheme 122

Scheme 122
Scheme 122

Scheme 123

Scheme 123
Scheme 123

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 124

Scheme 124: INSTALLATION
Scheme 124: INSTALLATION

Scheme 125

Scheme 125
Scheme 125

Scheme 126

Scheme 126
Scheme 126

Scheme 127

Scheme 127
Scheme 127

Scheme 128

Scheme 128
Scheme 128

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130

Scheme 131

Scheme 131
Scheme 131

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133

Scheme 134

Scheme 134
Scheme 134

Scheme 135

Scheme 135
Scheme 135
  1. INSTALL NO. 1 WINDSHIELD GLASS STOPPER Install 2 new stoppers to the vehicle body as shown in the illustration.
  2. INSTALL NO. 2 WINDSHIELD GLASS STOPPER Apply Primer G to the glass where the stopper will be installed. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Install 2 new stoppers onto the glass as shown in the illustration.
  3. INSTALL UPPER WINDSHIELD OUTSIDE MOLDING Using a brush or sponge, coat the contact surface of the glass and molding with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the adhesive with Primer G. Throw away any leftover primer. Apply adhesive to the molding as shown in the illustration. Adhesive: Toyota Genuine Windshield Glass Adhesive or equivalent HINT: Use all adhesive within the time written in the table below. Usage timeframe ADHESIVE REFERENCE CHART Temperature Usage Timeframe 35°C (95°F) 15 minutes 20°C (68°F) 1 hour 40 minutes 5°C (41 °F) 8 hours Install the windshield outside molding, as shown in the illustration. Remove any unnecessary adhesive before it hardens. NOTE: Make sure that no adhesive remains on the molding and glass.
  4. INSTALL WINDSHIELD GLASS RETAINER Apply Primer G to the glass where the retainer will be installed. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Install 2 new retainers onto the glass as shown in the illustration. Specification SPECIFICATION CHART Area Measurement a 30 mm (1.18 in.)
  5. INSTALL WINDSHIELD GLASS ADHESIVE DAM Apply Primer G to the glass where the glass adhesive dams will be installed. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Remove the peeling paper from the adhesive part of the dam. Install the dam (adhesive side) to the glass (Primer G area), but exclude the area above the notches on the upper part of the glass.
  6. INSTALL WINDSHIELD GLASS SEAL Apply Primer G to the glass where the windshield glass seal will be installed. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Remove the peeling paper from the windshield glass seal. Install the seal to the glass. Specification SPECIFICATION CHART Area Measurement a 30.0 mm (1.1 Sin.) b 20.0 mm (0.787 in.) c 10.0 mm (0.394 in.) d 13.0 mm (0.512 in.) e 88.7 mm (3.49 in.)
  7. INSTALL WINDSHIELD GLASS Position the glass. Using suction cups, place the glass in the correct position. Check that the entire contact surface of the glass rim is perfectly even. Place matchmarks on the glass and vehicle body on the locations indicated in the illustration. HINT: Placing matchmarks is only necessary when installing new glass. If it is the reused glass, matchmarks should already be present. When reusing the glass, check and correct the matchmark positions. NOTE: Check that the stoppers are attached to the vehicle body correctly. Using suction cups, remove the glass. Using a brush, apply Primer M to the exposed part of the vehicle body. NOTE: Allow the primer to dry for 3 minutes or more. Do not apply primer to the adhesive. Throw away any leftover primer. Do not apply too much primer. Using a brush or sponge, apply Primer G to the contact surface of the glass. Specification SPECIFICATION CHART Area Measurement a 6.5 mm (0.258 in.) b 7.0 mm (0.276 in.) c 3.0 mm (0.118 in.) d 4.0 mm (0.157 in.) e 8.0 mm (0.315 in.) HINT: If the primer is applied to an area that is not specified, apply non-residue solvent to a clean cloth and wipe off the excess primer before it dries. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Apply adhesive to the glass. Adhesive: Toyota Genuine Windshield Glass Adhesive or equivalent Cut off the tip of the cartridge nozzle as shown in the illustration. HINT: After cutting off the tip, use all adhesive within the time written in the table below. Usage timeframe USAGE TIMEFRAME Temperature Usage Timeframe 35°C (95°F) 15 minutes 20°C (68°F) 1 hour 40 minutes 5°C (41°F) 8 hours Load the sealer gun with the cartridge. Apply adhesive to the glass as shown in the illustration. Specification SPECIFICATION CHART Area Measurement a 12.0 mm (0.472 in.) b 8.0 mm (0.315 in.) c 6.5 mm (0.258 in.) d 3.0 mm (0.118 in.) Install the glass to the vehicle body. Using suction cups, position the glass so that the matchmarks are aligned. Press it in gently along the rim. Lightly press the outer surface of the glass to ensure that it is securely fit to the vehicle body. NOTE: Check that the stoppers are attached to the vehicle body correctly. Check that the vehicle body and glass have a small gap between them. Hold the glass in place securely with protective tape or equivalent until the adhesive hardens. NOTE: Do not drive the vehicle for the amount of time written in the table below. Minimum time MINIMUM TIME REFERENCE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour 30 minutes 20°C (68°F) 5 hours 5°C (41 °F) 24 hours w/ Windshield Deicer System: Connect the windshield deicer connector.
  8. CHECK FOR WATER LEAKS Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
  9. INSTALL ROOF HEADLINING ASSEMBLY Return the roof headlining to its original position. For Standard Body, refer to the following procedures (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). For Long Body, refer to the following procedures (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
  10. INSTALL RAIN SENSOR TAPE (w/ Rain Sensor) (See «INSTALLATION»(ref-349735-S27949833742009120800000) )
  11. INSTALL RAIN SENSOR (w/ Rain Sensor) (See «INSTALLATION»(ref-349735-S27949833742009120800000) )
  12. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
  13. INSTALL INNER REAR VIEW MIRROR COVER (w/o Rain Sensor) (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
  14. INSTALL RAIN SENSOR COVER (w/ Rain Sensor) (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
  15. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  16. INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  17. INSTALL VISOR HOLDER (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  18. INSTALL VISOR ASSEMBLY LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  19. INSTALL VISOR ASSEMBLY RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  20. INSTALL VISOR BRACKET COVER (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  21. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  22. INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  23. INSTALL NO. 1 ROOF DRIP SIDE FINISH MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  24. INSTALL NO. 3 WINDSHIELD OUTSIDE MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  25. INSTALL NO. 2 ROOF DRIP SIDE FINISH MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  26. INSTALL NO. 2 WINDSHIELD OUTSIDE MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  27. INSTALL NO. 1 WINDSHIELD OUTSIDE MOLDING CLIP HINT: Use the same procedures described for the No. 2 windshield outside molding clip.
  28. INSTALL CENTER ROOF DRIP SIDE FINISH MOLDING LH (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  29. INSTALL CENTER ROOF DRIP SIDE FINISH MOLDING RH HINT: Use the same procedures described for the LH side.
  30. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  31. INSTALL COWL TOP VENTILATOR LOUVER PROTECTOR LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  32. INSTALL HOOD TO COWL TOP SEAL (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  33. INSTALL FRONT FENDER TO COWL SIDE SEAL LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  34. INSTALL FRONT FENDER TO COWL SIDE SEAL RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  35. INSTALL FRONT WIPER ARM LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  36. INSTALL FRONT WIPER ARM RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
  37. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
  38. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )

Scheme 136

Scheme 136: COMPONENTS
Scheme 136: COMPONENTS

Scheme 137

Scheme 137
Scheme 137

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143

HINT

When removing the molding, heat the vehicle body and molding using a heat light.

Heating temperature

ItemTemperature
Vehicle Body40 to 60°C (104 to 140°F)
Molding20 to 30°C (68 to 86°F)

HEATING TEMPERATURE REFERENCE CHART

Note. Do not heat the vehicle body and molding excessively.

Scheme 144

Scheme 144
Scheme 144

Scheme 145

Scheme 145
Scheme 145

Scheme 146

Scheme 146
Scheme 146

Scheme 147

Scheme 147
Scheme 147

Scheme 148

Scheme 148
Scheme 148

Scheme 149

Scheme 149
Scheme 149

Scheme 150

Scheme 150
Scheme 150
  1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
  2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
  3. REMOVE REAR SEAT ASSEMBLY for Power Seat: Remove the rear seat (see «REMOVAL»(ref-349741-S26853688812009120800000) ). for Ottoman: Remove the rear seat (see «REMOVAL»(ref-349741-S19112888892009120800000) ). for Fixed Seat Type: Remove the rear seat (see «REMOVAL»(ref-349741-S36365163922009120800000) ).
  4. REMOVE REAR DOOR SCUFF PLATE LH for Standard Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S03706653952009120800000) ). for Long Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
  5. REMOVE REAR DOOR SCUFF PLATE RH for Standard Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S03706653952009120800000) ). for Long Body: Remove the rear door scuff plate (see «REMOVAL»(ref-349734-S29426050782009120800000) ).
  6. REMOVE REAR SEAT SIDE GARNISH LH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  7. REMOVE REAR SEAT SIDE GARNISH RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  8. REMOVE ROOF SIDE GARNISH INNER LH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  9. REMOVE ROOF SIDE GARNISH INNER RH (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  10. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY w/Rear Sunshade: Remove the package tray trim panel assembly (see «REMOVAL»(ref-349734-S29129796022009120800000) ). w/o Rear Sunshade: Remove the package tray trim panel assembly (see «REMOVAL»(ref-349752-S03119614232009120800000) ).
  11. REMOVE NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «REMOVAL»(ref-349734-S29129796022009120800000) )
  12. REMOVE ROOF CONSOLE BOX ASSEMBLY (w/ Rear Seat Entertainment System) (See «REMOVAL»(ref-349734-S29426050782009120800000) )
  13. REMOVE SPOT LIGHT ASSEMBLY (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  14. REMOVE REAR VANITY LIGHT ASSEMBLY (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  15. REMOVE COAT HOOK (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  16. REMOVE ROOF SIDE REGISTER BEZEL LH (w/Rear Cooler) (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  17. REMOVE ROOF SIDE REGISTER BEZEL RH (w/ Rear Cooler) (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  18. REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(ref-349734-S03706653952009120800000) )
  19. REMOVE ROOF HEADLINING ASSEMBLY for Standard Body: HINT: It is not necessary to completely remove the roof headlining. Slightly lower the rear section of the roof headlining (see «REMOVAL»(ref-349734-S03706653952009120800000) ) so that the back window glass can be removed in a later step. for Long Body: HINT: It is not necessary to completely remove the roof headlining. Slightly lower the rear section of the roof headlining (see «REMOVAL»(ref-349734-S29426050782009120800000) ) so that the back window glass can be removed in a later step.
  20. REMOVE AMPLIFIER ANTENNA ASSEMBLY (See «REMOVAL»(ref-349754-S06848860872009120800000) )
  21. REMOVE ROOF DRIP SIDE FINISH MOLDING CENTER LH (See «REMOVAL»(ref-349736-S10538419072009120800000) )
  22. REMOVE ROOF DRIP SIDE FINISH MOLDING CENTER RH Use the same procedures described for the LH side.
  23. REMOVE NO. 2 WINDSHIELD OUTSIDE MOLDING CLIP (See «REMOVAL»(ref-349736-S10538419072009120800000) )
  24. REMOVE NO. 1 WINDSHIELD OUTSIDE MOLDING CLIP Use the same procedures described for the No. 2 clip.
  25. REMOVE ROOF NO. 2 DRIP SIDE FINISH MOLDING CLIP (See «REMOVAL»(ref-349736-S10538419072009120800000) )
  26. REMOVE NO. 3 WINDSHIELD OUTSIDE MOLDING CLIP (See «REMOVAL»(ref-349736-S10538419072009120800000) )
  27. REMOVE ROOF NO. 1 DRIP SIDE FINISH MOLDING CLIP
  28. REMOVE LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  29. REMOVE ROPE HOOK ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  30. REMOVE ROPE HOOK (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  31. REMOVE DECK TRIM SIDE BOARD LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  32. REMOVE DECK TRIM SIDE BOARD RH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  33. REMOVE LUGGAGE COMPARTMENT NO. 1 LIGHT ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  34. REMOVE LUGGAGE COMPARTMENT NO. 2 TRIM HOOK (w/o Rear Cooler) (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  35. REMOVE FRONT LUGGAGE COMPARTMENT TRIM COVER (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  36. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  37. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  38. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY RH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  39. REMOVE REAR COMBINATION LIGHT ASSEMBLY LH (See «REMOVAL»(ref-349731-S35321606872009120800000) )
  40. REMOVE REAR COMBINATION LIGHT ASSEMBLY RH Use the same procedures described for the RH side.
  41. REMOVE BACK WINDOW MOLDING OUTSIDE LOWER Using a screwdriver, detach the 2 claws, 4 fasteners and double-sided tape (3 areas). Slide the molding toward the vehicle front along the back window glass to detach the clip. Then remove the molding. NOTE: If reusing the molding, take care not to damage the molding. Be careful not to damage the vehicle body. Do not lift the molding or slide it toward vehicle rear when detaching the clip. HINT: Tape the screwdriver tip before use.
  42. REMOVE LUGGAGE COMPARTMENT DOOR HINGE COVER LH Using a screwdriver, detach the double-sided tape (2 areas) and 2 clips. Then remove the hinge cover. NOTE: If reusing the hinge cover, take care not to damage the hinge cover. Be careful not to damage the vehicle body. HINT: Tape the screwdriver tip before use.
  43. REMOVE LUGGAGE COMPARTMENT DOOR HINGE COVER RH Use the same procedures described for the LH side.
  44. REMOVE NO. 2 CENTER STOP LIGHT COVER (See «REMOVAL»(ref-349731-S06878114452009120800000) )
  45. REMOVE CENTER STOP LIGHT COVER (See «REMOVAL»(ref-349731-S06878114452009120800000) )
  46. REMOVE CENTER STOP LIGHT CLIP (See «REMOVAL»(ref-349731-S06878114452009120800000) )
  47. REMOVE CENTER STOP LIGHT ASSEMBLY (See «REMOVAL»(ref-349731-S06878114452009120800000) )
  48. REMOVE BACK WINDOW GLASS NOTE: As the stopper, bracket and harness are not supplied individually, be careful not to damage them when installing the back window glass. Apply protective tape to the outer surface of the vehicle body to prevent scratches. NOTE: When separating the back window glass from the vehicle, be careful not to damage the vehicle's paint or interior/exterior ornaments. From the interior, insert a piano wire between the vehicle body and back window glass as shown in the illustration. CAUTION: If the stopper is damaged, the back window glass assembly must be replaced. Be careful when performing the procedure. Make sure not to deform the upper brackets. Make sure not to damage the wire harness. Tie objects that can serve as handles (for example, wooden blocks) to both wire ends. Place matchmarks over the glass and vehicle body on the locations indicated in the illustration. HINT: Matchmarks do not need to be placed if the glass is not going to be reused. Cut through the adhesive by pulling the piano wire around the back window glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the back window glass. Using suction cups, remove the back window glass. NOTE: If the stopper is damaged, the back window glass assembly must be replaced. Be careful when performing the procedure.
  49. CLEAN BACK WINDOW GLASS Clean the outer edge of the back window glass with a non-residue solvent. NOTE: Do not touch the back window glass surface after cleaning it. Be careful not to damage the glass. Even if using new back window glass, clean the back window glass with a non-residue solvent.
  50. CLEAN VEHICLE BODY Using a scraper, remove the molding and adhesive from the back window glass. Clean and shape the contact surface of the vehicle body. On the contact surface of the vehicle body, use a knife to cut away excess adhesive as shown in the illustration. HINT: Leave as much adhesive on the vehicle body as possible. NOTE: Be careful not to damage the vehicle body. Clean the contact surface of the vehicle body with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 151

Scheme 151: INSTALLATION
Scheme 151: INSTALLATION

Scheme 152

Scheme 152
Scheme 152

Scheme 153

Scheme 153
Scheme 153

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157

Scheme 158

Scheme 158
Scheme 158

Scheme 159

Scheme 159
Scheme 159
  1. INSTALL BACK WINDOW GLASS DAM Apply Primer G to the installation part of the window glass dam. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Remove the peeling paper from the adhesive part of the dam. Install the dam (adhesive side) to the glass (Primer G area). Standard measurement STANDARD MEASUREMENT CHART Area Specified Condition a 1.0 mm (0.0393 in.) or less b 159.0 mm (6.25 in.) c 146.0 mm (5.74 in.) d 192.0 mm (7.55 in.) e 9.5 mm (0.377 in.) f 7.5 mm (0.295 in.) g (Reference) 8.0 mm (0.315 in.)
  2. INSTALL BACK WINDOW GLASS Using a brush or sponge, apply Primer M to the exposed part of the vehicle body. NOTE: Allow the primer to dry for 3 minutes or more. Do not apply primer to the adhesive. Throw away any leftover primer. Do not apply too much primer. Using a brush or sponge, apply Primer G to the contact surface of the back window glass. Standard measurement STANDARD MEASUREMENT CHART Area Specified Condition a 19.0 mm (0.748 in.) HINT: If primer is applied to an area that is not specified, wipe off the primer with a non-residue solvent before it dries. NOTE: Allow the primer to dry for 3 minutes or more. Throw away any leftover primer. Do not apply too much primer. Apply adhesive to the back window glass. Adhesive: Toyota Genuine Windshield Glass Adhesive or equivalent Cut off the tip of the cartridge nozzle as shown in the illustration below. HINT: After cutting off the tip, use all adhesive within the time written in the table below. Usage time frame USAGE TIME FRAME CHART Temperature Usage Time Frame 35°C (95°F) 15 minutes 20°C (68°F) 1 hour 40 minutes 5°C (41 °F) 8 hours Load the sealer gun with the cartridge. Apply adhesive to the back window glass as shown in the illustration. Standard measurement STANDARD MEASUREMENT CHART Area Specified Condition a 12.0 mm (0.472 in.) b 8.0 mm (0.315 in.) c 12.1 mm (0.480 in.) d 3.0 mm (0.119 in.) e 14.0 mm (0.555 in.) Install the back window glass to the vehicle body. Hold the back window glass securely in place with tape or equivalent until the adhesive has hardened. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the clips are attached to the vehicle body correctly. Check the clearance between the vehicle body and glass. Lightly press the front surface of the back window glass to ensure that the back window glass is securely fit to the vehicle body. Using a scraper, remove any excess or protruding adhesive. HINT: Apply adhesive onto the glass rim. NOTE: Do not drive the vehicle within the time written in the table below. Minimum time MINIMUM TIME REFERENCE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour 30 minutes 20°C (68°F) 5 hours 5°C (41 °F) 24 hours Install the defogger wire with the nut and 2 clamps. Connect the 2 connectors.
  3. CHECK FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
  4. INSTALL CENTER STOP LIGHT ASSEMBLY (See «INSTALLATION»(ref-349731-S15058440102009120800000) )
  5. INSTALL CENTER STOP LIGHT CLIP (See «INSTALLATION»(ref-349731-S15058440102009120800000) )
  6. INSTALL CENTER STOP LIGHT COVER (See «INSTALLATION»(ref-349731-S15058440102009120800000) )
  7. INSTALL NO. 2 CENTER STOP LIGHT COVER (See «INSTALLATION»(ref-349731-S15058440102009120800000) )
  8. INSTALL LUGGAGE COMPARTMENT DOOR HINGE COVER LH Clean the vehicle body surface. Using a heat light, heat the vehicle body surface. Remove the double-sided tape from the vehicle body. Wipe off any tape adhesive residue with cleaner. If reusing the molding: Clean the molding. Using a heat light, heat the molding. Remove the double-sided tape from the molding. Wipe off any tape adhesive residue with cleaner. Apply new double-sided tape to the molding, as shown in the illustration. Install the molding. Using a heat light, heat the vehicle body and molding. Remove the peeling paper from the face of the molding. HINT: After removing the peeling paper, keep the exposed adhesive free from foreign matter. Attach the 2 clips to install the molding.
  9. INSTALL LUGGAGE COMPARTMENT DOOR HINGE COVER RH Use the same procedures described for the LH side.
  10. INSTALL BACK WINDOW MOLDING OUTSIDE LOWER Clean the vehicle body surface. Using a heat light, heat the vehicle body surface. Remove the double-sided tape from the vehicle body. Wipe off any tape adhesive residue with cleaner. If reusing the molding: Clean the molding. Using a heat light, heat the molding. Remove the double-sided tape from the molding. Wipe off any tape adhesive residue with cleaner. Apply new double-sided tape to the molding, as shown in the illustration. Install the molding. Using a heat light, heat the molding. Remove the peeling paper from the face of the molding. HINT: After removing the peeling paper, keep the exposed adhesive free from foreign matter. Attach the clip on the center of the molding. Use the back window glass bottom edge's stoppers (left and right position setting stoppers) to determine the moldings front to rear position. Then attach the 2 claws and 4 fasteners to install the molding. HINT: As the glass bottom edge's stoppers are only for determining the moldings position, they do not attach to the molding.
  11. INSTALL REAR COMBINATION LIGHT ASSEMBLY LH (See «INSTALLATION»(ref-349731-S14864716142009120800000) )
  12. INSTALL REAR COMBINATION LIGHT ASSEMBLY RH Use the same procedures described for the LH side.
  13. INSTALL LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  14. INSTALL LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY RH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  15. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  16. INSTALL FRONT LUGGAGE COMPARTMENT TRIM COVER (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  17. INSTALL LUGGAGE COMPARTMENT NO. 2 TRIM HOOK (w/o Rear Cooler) (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  18. INSTALL LUGGAGE COMPARTMENT NO. 1 LIGHT ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  19. INSTALL DECK TRIM SIDE BOARD LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  20. INSTALL DECK TRIM SIDE BOARD RH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  21. INSTALL ROPE HOOK ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  22. INSTALL ROPE HOOK (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  23. INSTALL LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  24. INSTALL ROOF NO. 1 DRIP SIDE FINISH MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  25. INSTALL NO. 3 WINDSHIELD OUTSIDE MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  26. INSTALL ROOF NO. 2 DRIP SIDE FINISH MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  27. INSTALL NO. 2 WINDSHIELD OUTSIDE MOLDING CLIP (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  28. INSTALL NO. 1 WINDSHIELD OUTSIDE MOLDING CLIP Use the same procedures described for the No. 2 clip.
  29. INSTALL ROOF DRIP SIDE FINISH MOLDING CENTER LH (See «INSTALLATION»(ref-349736-S01712591262009120800000) )
  30. INSTALL ROOF DRIP SIDE FINISH MOLDING CENTER RH Use the same procedures described for the LH side.
  31. INSTALL AMPLIFIER ANTENNA ASSEMBLY (See «INSTALLATION»(ref-349754-S02360118952009120800000) )
  32. INSTALL ROOF HEADLINING ASSEMBLY Return the roof headlining to its original position. For Standard Body, refer to the following procedures (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). For Long Body, refer to the following procedures (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
  33. INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  34. INSTALL ROOF SIDE REGISTER BEZEL LH (w/ Rear Cooler) (See «INSTALLATION»(ref-349734-S24814211142009120800000) )
  35. INSTALL ROOF SIDE REGISTER BEZEL RH (w/ Rear Cooler) (See «INSTALLATION»(ref-349734-S24814211142009120800000) )
  36. INSTALL COAT HOOK (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  37. INSTALL REAR VANITY LIGHT ASSEMBLY (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  38. INSTALL SPOT LIGHT ASSEMBLY (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  39. INSTALL ROOF CONSOLE BOX ASSEMBLY (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-349734-S24814211142009120800000) )
  40. INSTALL NO. 2 PACKAGE TRAY TRIM PANEL ASSEMBLY (w/ Rear Sunshade) (See «INSTALLATION»(ref-349734-S21460801522009120800000) )
  41. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY w/ Rear Sunshade: Install the package tray trim panel assembly (see «INSTALLATION»(ref-349734-S21460801522009120800000) ). w/o Rear Sunshade: Install the package tray trim panel assembly (see «INSTALLATION»(ref-349752-S08859520182009120800000) ).
  42. INSTALL ROOF SIDE GARNISH INNER LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  43. INSTALL ROOF SIDE GARNISH INNER RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  44. INSTALL REAR SEAT SIDE GARNISH LH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  45. INSTALL REAR SEAT SIDE GARNISH RH (See «INSTALLATION»(ref-349734-S14494944522009120800000) )
  46. INSTALL REAR DOOR SCUFF PLATE LH for Standard Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). for Long Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
  47. INSTALL REAR DOOR SCUFF PLATE RH for Standard Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S14494944522009120800000) ). for Long Body: Install the rear door scuff plate (see «INSTALLATION»(ref-349734-S24814211142009120800000) ).
  48. INSTALL REAR SEAT ASSEMBLY for Power Seat: Install the rear seat (see «INSTALLATION»(ref-349741-S24840229242009120800000) ). for Ottoman: Install the rear seat (see «INSTALLATION»(ref-349741-S09487469022009120800000) ). for Fixed Seat Type: Install the rear seat (see «INSTALLATION»(ref-349741-S36437420052009120800000) ).
  49. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
