Meter: Removal & Installation Lexus LS IV

REMOVAL

Note. Make sure the combination meter glass and meter display panel does not become dirty with fingerprints, oil, etc. If dirty, clean with a soft cloth. Be careful of static electricity when handling the meter ECU and meter display panel. Make sure the work area has static electricity prevention measures.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349732-S04425564642009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Disable the AUTO TILT AWAY function by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349706-S40935619612009120800000) ). NOTE: Record the current customize parameter setting (whether the AUTO TILT AWAY function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the AUTO TILT AWAY function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column assembly. Turn the engine switch off and disconnect the cable from the negative (-) battery terminal. CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal.
3. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-349735-S05206456932009120800000) )
4. REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY (See «REMOVAL»(ref-349735-S05206456932009120800000) )
5. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY Apply protective tape to the area shown in the illustration. Remove the 2 clips. Using a molding remover, detach the 2 clips. Disconnect the connector and remove the finish panel.
6. REMOVE COMBINATION METER ASSEMBLY Remove the 4 screws. Disconnect the connector and remove the combination meter.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. REMOVE NO. 1 COMBINATION METER BRACKET Remove the 4 screws and bracket.
2. REMOVE COMBINATION METER GLASS Remove the 2 screws. Detach the 6 claws and remove the meter glass.
3. REMOVE COMBINATION METER COVER Remove the 12 screws and meter cover.
4. REMOVE METER DISPLAY PANEL Detach the 6 claws and disconnect each wire harness. Remove the display panel from the meter ECU.

Scheme 34

Scheme 35

Scheme 36

1. INSTALL METER DISPLAY PANEL Temporarily install the meter ECU. Attach the 6 claws to connect each wire harness.
2. INSTALL COMBINATION METER COVER Install the meter cover with the 12 screws.
3. INSTALL COMBINATION METER GLASS Attach the 6 claws to install the meter glass. Install the 2 screws.
4. INSTALL NO. 1 COMBINATION METER BRACKET Install the bracket with the 4 screws.

Scheme 37

Scheme 38

Scheme 39

1. INSTALL COMBINATION METER ASSEMBLY Connect the connector. Install the combination meter with the 4 screws.
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY Apply protective tape to the area shown in the illustration. Connect the connector. Attach the 2 clips to install the finish panel. Install the 2 clips.
3. INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY (See «INSTALLATION»(ref-349735-S22037755312009120800000) )
4. INSTALL STEERING COLUMN COVER (See «INSTALLATION»(ref-349735-S22037755312009120800000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: Reset the AUTO TILT AWAY function setting to the previous condition by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349706-S40935619612009120800000) ).
6. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 40

Scheme 41

1. DISABLE AUTO TILT AWAY FUNCTION Disable the AUTO TILT AWAY function by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349706-S40935619612009120800000) ). NOTE: Record the current customize parameter setting (whether the AUTO TILT AWAY function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the AUTO TILT AWAY function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column. Turn the engine switch off.
2. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-349735-S05206456932009120800000) )
3. REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY (See «REMOVAL»(ref-349735-S05206456932009120800000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-349730-S08161846402009120800000) )
5. REMOVE LIGHT CONTROL RHEOSTAT Detach the 2 claws and remove the rheostat.

Scheme 42

Scheme 43

1. INSPECT LIGHT CONTROL RHEOSTAT (w/o Headlight Cleaner System) Measure the resistance according to the value (s) in the table below. Standard resistance STANDARD RESISTANCE REFERENCE CHART Tester Connection Switch Condition Specified Condition 3 (UP) - 5 (E) UP ON (Pushed) Below 200 ohms 3 (UP) - 5 (E) UP OFF (Not pushed) 1Mohms or higher 7 (DOWN) - 5 (E) DOWN ON (Pushed) Below 200 ohms 7 (DOWN) - 5 (E) DOWN OFF (Not pushed) 1Mohms or higher If the result is not as specified, replace the rheostat. Inspect the switch illumination. Connect the battery positive (+) lead to terminal 8 (ILL+) and the negative (-) lead to terminal 6 (ILL-), then check that the light comes on. OK: LED comes on. If the result is not as specified, replace the rheostat.
2. INSPECT LIGHT CONTROL RHEOSTAT (w/ Headlight Cleaner System) Measure the resistance according to the value (s) in the table below. Standard resistance STANDARD RESISTANCE REFERENCE CHART Tester Connection Switch Condition Specified Condition 3 (UP) - 5 (E) UP ON (Pushed) Below 200 ohms 3 (UP) - 5 (E) UP OFF (Not pushed) 1Mohms or higher 7 (DOWN) - 5 (E) DOWN ON (Pushed) Below 200 ohms 7 (DOWN) - 5 (E) DOWN OFF (Not pushed) 1Mohms or higher 2 (B) - 5 (E) CLEANER ON (Pushed) Below 200 ohms 2 (B) - 5 (E) CLEANER OFF (Not pushed) 1 Mohms or higher If the result is not as specified, replace the rheostat. Inspect the switch illumination. Connect the battery positive (+) lead to terminal 8 (ILL+) and the negative (-) lead to terminal 6 (ILL-), then check that the light comes on. OK: LED comes on. If the result is not as specified, replace the rheostat.

Scheme 44

1. INSTALL LIGHT CONTROL RHEOSTAT Attach the 2 claws to install the rheostat.
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-349730-S17456814532009120800000) )
3. INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY (See «INSTALLATION»(ref-349735-S22037755312009120800000) )
4. INSTALL STEERING COLUMN COVER (See «INSTALLATION»(ref-349735-S22037755312009120800000) )

Scheme 45

Scheme 46

1. DISABLE AUTO TILT AWAY FUNCTION Disable the AUTO TILT AWAY function by changing the customize parameter (see «CUSTOMIZE PARAMETERS»(ref-349706-S40935619612009120800000) ). NOTE: Record the current customize parameter setting (whether the AUTO TILT AWAY function is enabled or disabled) in order to restore the current setting after finishing the operation. HINT: Performing the above operation causes the AUTO TILT AWAY function to be disabled when the engine switch is turned off. Turn the engine switch on (IG). Operate the tilt and telescopic switch to fully extend and lower the steering column. Turn the engine switch off.
2. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-349735-S05206456932009120800000) )
3. REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY (See «REMOVAL»(ref-349735-S05206456932009120800000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-349730-S08161846402009120800000) )
5. REMOVE TRIP SWITCH Detach the 2 claws and remove the switch.

Scheme 47

1. INSPECT TRIP SWITCH Measure the resistance according to the value (s) in the table below. Standard resistance STANDARD RESISTANCE REFERENCE CHART Tester Connection Switch Condition Specified Condition 5 (RSET) - 6 (E) RESET ON (Pushed) Below 200 ohms 5 (RSET) - 6 (E) RESET OFF (Not pushed) 1Mohms or higher 7 (A/B) - 6 (E) TRIP ON (Pushed) Below 200 ohms 7 (A/B) - 6 (E) TRIP OFF (Not pushed) 1Mohms or higher If the result is not as specified, replace the switch. Inspect the switch illumination. Connect the battery positive (+) lead to terminal 2 (ILL+) and the negative (-) lead to terminal 8 (ILL-), then check that the light comes on. OK: LED comes on. If the result is not as specified, replace the LED.

INSTALLATION

1. INSTALL TRIP SWITCH Attach the 2 claws to install the switch.
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-349730-S17456814532009120800000) )
3. INSTALL WINDSHIELD WIPER SWITCH ASSEMBLY (See «INSTALLATION»(ref-349735-S22037755312009120800000) )
4. INSTALL STEERING COLUMN COVER (See «INSTALLATION»(ref-349735-S22037755312009120800000) )
