Windshield/windowglass: Other Lexus LS IV

PRECAUTION

1. NOTICE FOR INITIALIZATION When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM NAME REFERENCE CHART System Name See procedure Navigation System (for DVD) «INITIALIZATION»(ref-349706-S07943075812009120800000) Advanced Parking Guidance System Power Trunk Lid System Rear Door Sunshade System
2. PRECAUTIONS WHEN USING TECHSTREAM When using the Techstream with the engine switch off to troubleshoot: Connect the Techstream to the vehicle, and turn a courtesy light switch on and off at 1.5 second intervals until communication between the Techstream and vehicle begins. After all DTCs are cleared, check if the trouble occurs again 6 seconds after the engine switch on (IG).
3. POWER WINDOW CONTROL SYSTEM PRECAUTIONS CAUTION: The power window control system prohibits the AUTO UP/DOWN function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no diagnostic codes are displayed. When the power window regulator or the power window regulator motor assembly is replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the AUTO UP function is used. In such cases, the AUTO UP function can be resumed by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window switch and holding it at the AUTO UP position. Open the power window by fully pushing down the power window switch. The jam protection function may operate unexpectedly even when the power window control system is normal, due to detection of a different operation learned value when the door glass moving speed changes sharply under any of the following conditions: A power window being opened or closed while the vehicle is driving on a rough road. A power window being opened or closed while the door is being opened or closed. A sharp voltage change. NOTE: Do not disconnect the battery while the engine switch is on (IG). Otherwise, DTC B2311 will be output.

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

CUSTOMIZE PARAMETERS

1. CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE) NOTE: When the customer requests a change in a function, first make sure the function(s) can be customized. Be sure to make note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting. Select the setting by referring to the table below. Power Window: POWER WINDOW SETTING REFERENCE CHART Display (Item) Default Contents Setting Door Key P/W Up ON Function that raises all power windows when, with engine switch off, key is used to hold driver door key cylinder to lock position for more than 2.3 seconds ON/OFF Door Key P/W Down ON Function that lowers all power windows when, with engine switch off, key is used to hold driver door key cylinder to unlock position for more than 2.3 seconds ON/OFF PAW Down W/ Transmit ON Function that lowers all power windows when, with engine switch off, unlock switch on key is pressed and held for more than 3.0 seconds ON/OFF P/W Up W/ Smart ON Function that raises all power windows when, with engine switch off, entry lock switch on driver side door outer handle is pressed and held for more than 3.0 seconds ON/OFF

INITIALIZATION

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR ASSEMBLY (ALL DOORS)) CAUTION: When the power window regulator motor assembly is reinstalled or replaced, the power window control system must be initialized. Functions such as the AUTO UP/DOWN, jam protection and key-off do not operate if the initialization is not performed. HINT: When the battery is replaced, it is not necessary to initialize the power window regulator motor. NOTE: When the power window regulator motor assembly is replaced, DTC B2313 is output. Clear the DTC after the initialization. When performing initialization, do not perform any other procedures. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the AUTO UP function is used, due to detection of the different operation learned value of the door glass movement speed. In such cases, the AUTO UP function can be resumed by repeating the following operation at least 5 times: Open the power window by fully pushing down the switch. Close the power window by fully pulling up the power window switch and holding it at the AUTO UP position. If the initialization is not completed properly, the LIN communication system may have a malfunction (see «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-349747-S33852239962009120800000) ). Initialization procedures when replacing the power window regulator motor assembly with new one Connect the battery and turn the engine switch on (IG). (At this time, the LED on the power window regulator switch blinks to indicate that it is ready for initialization.) Fully open the window by fully pushing the power window regulator switch, and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling the power window regulator switch, and hold the switch for 1 second or more after the window is fully closed to reset the glass position. The LED on the power window regulator switch changes from blinking to illuminated to indicate that the initialization is complete. Initialization procedures when removing/installing the power window regulator motor assembly Connect the battery and turn the engine switch on (IG). (At this time, the LED on the power window regulator switch blinks to indicate that it is ready for initialization.) Fully close the power window by fully pulling the power window regulator switch, and hold the switch for 6 seconds or more after the window is fully closed. (If the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again.) Fully open the window by pushing down the power window regulator switch, and hold the switch for 1 second or more after the window is fully opened. Release the power window regulator switch. Then fully push and hold the switch 4 seconds or more. Fully close the power window by fully pulling the power window regulator switch, and hold the switch 1 second or more after the window is fully closed to reset the glass position. The LED on the power window regulator switch changes from blinking to illuminated to indicate that the initialization is complete. Initialization procedures when the power window does not fully open Perform the initialization procedures when removing/installing the power window regulator motor assembly.

FAIL-SAFE CHART

1. POWER WINDOW OPERATION IN FAIL-SAFE MODE HINT: If the pulse sensor built into the power window regulator motor malfunctions, the power window control system enters fail-safe mode. The power window control system prohibits the following power window operation when the pulse sensor for the jam protection function has problems and the window position or the learned value is abnormal. Power window control system: FAIL-SAFE CHART Power window operation Engine switch on (IG) Key-off (Within approx. 45 seconds after engine switch turned off) Key-off (After approx. 45 seconds elapsed after engine switch turned off) Manual UP Operation prohibited Operation prohibited Operation prohibited Manual DOWN Operative (Jam protection not operative) Operation prohibited Operation prohibited AUTO UP (hold switch at AUTO UP position) Operative (in MANUAL mode) (Jam protection not operative) Operation prohibited Operation prohibited AUTO UP Operation prohibited Operation prohibited Operation prohibited AUTO DOWN Operation prohibited Operation prohibited Operation prohibited HINT: When the pulse sensor is normal, the AUTO UP/DOWN function can be resumed by deactivating fail-safe mode. To deactivate fail-safe mode, pull up the power window switch to the AUTO UP position and hold it for at least 1 second to fully close the window from the fully open position. If the LIN communication line malfunctions (communication stop), the power window control system prohibits the following operations. Remote UP/DOWN function does not operate. Master switch: FAIL-SAFE CHART Power window operation Engine switch on (IG) MANUAL UP Operative (Jam protection operative) MANUAL DOWN Operative (Jam protection not operative) Power window regulator switch (for front passenger side, rear LH and rear RH): FAIL-SAFE CHART Power window operation Engine switch on (IG) MANUAL UP Operative (Jam protection operative) MANUAL DOWN Operative (Jam protection not operative) AUTO UP (hold switch at AUTO UP position) Operative (Jam protection operative) AUTO UP Operative (Jam protection operative) AUTO DOWN Operative (Jam protection not operative)

1. NOTICE FOR INITIALIZATION NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM NAME REFERENCE CHART System Name See procedure Navigation System (for DVD) «INITIALIZATION»(ref-349706-S07943075812009120800000) Advanced Parking Guidance System Power Trunk Lid System Rear Door Sunshade System

Scheme 166

Scheme 167

Communication table

COMMUNICATION CHART

1. NOTICE FOR INITIALIZATION NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM NAME REFERENCE CHART System Name See procedure Navigation System (for DVD) «INITIALIZATION»(ref-349706-S07943075812009120800000) Advanced Parking Guidance System Power Trunk Lid System Rear Door Sunshade System

Scheme 168

Scheme 169

Scheme 170

Communication table

COMMUNICATION CHART
