Pre-Collision - Supplemental Restraint System: Removal & Installation Lexus LS IV

Collision/avoidance 5 illustrations ~345 words

INSTALLATION

  1. INSTALL PRE-COLLISION BRAKE CANCEL SWITCH ASSEMBLY Attach the 2 claws to install the switch.
  2. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )

Scheme 21

Scheme 21: COMPONENTS
Scheme 21: COMPONENTS

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23: REMOVAL
Scheme 23: REMOVAL
  1. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  2. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  3. REMOVE INSTRUMENT SIDE PANEL LH (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  4. REMOVE NO. 1 INSTRUMENT CLUSTER MOLDING (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  5. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  6. REMOVE NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «REMOVAL»(ref-349746-S04541701892009120800000) )
  7. REMOVE DRIVER SIDE KNEE AIRBAG ASSEMBLY (See «REMOVAL»(ref-349738-S31284329952009120800000) )
  8. REMOVE DRIVER MONITOR ECU Disconnect the connectors. Remove the 2 nuts and ECU.
  1. INSTALL DRIVER MONITOR ECU Install the ECU with the 2 nuts. Connect the connectors.
  2. INSTALL DRIVER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-349738-S41995772282009120800000) )
  3. INSTALL NO. 1 INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
  4. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
  5. INSTALL NO. 1 INSTRUMENT CLUSTER MOLDING (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
  6. INSTALL INSTRUMENT SIDE PANEL LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
  7. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-349746-S09854143102009120800000) )
  8. INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-349746-S09854143102009120800000) )

Scheme 24

Scheme 24: COMPONENTS
Scheme 24: COMPONENTS

Scheme 25

Scheme 25: REMOVAL
Scheme 25: REMOVAL
  1. REMOVE LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  2. REMOVE LUGGAGE COMPARTMENT NO. 1 TRIM HOOK (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  3. REMOVE ROPE HOOK (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  4. REMOVE DECK TRIM SIDE BOARD LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  5. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  6. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «REMOVAL»(ref-349743-S29102114712009120800000) )
  7. REMOVE SEAT BELT CONTROL ECU Disconnect the 2 connectors. Remove the 2 nuts and ECU.
  1. INSTALL SEAT BELT CONTROL ECU Install the ECU with the 2 nuts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) Connect the 2 connectors.
  2. INSTALL LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  3. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  4. INSTALL DECK TRIM SIDE BOARD LH (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  5. INSTALL ROPE HOOK (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  6. INSTALL LUGGAGE COMPARTMENT NO. 1 TRIM HOOK (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
  7. INSTALL LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY (See «INSTALLATION»(ref-349743-S30157791022009120800000) )
