PRECAUTION
Note. When disconnecting the negative (-) battery terminal, initialize the following systems after the terminal is reconnected.
Scheme 94
- INSPECTION PRECAUTION FOR LEXUS LINK SYSTEM The GPS antenna for the LEXUS link system is installed on the upper back panel (located on the right side of the luggage room). Attaching metallic film to the rear glass or setting any object close to the rear speakers prevents the position data from being received properly. The LEXUS link system will automatically contact the LEXUS link center if any of the following is detected: 1) the ignition switch is turned ON while the airbag sensor assy center connector is disconnected, 2) the ignition switch is turned OFF and then the +B circuit is open within 10 seconds, and/or 3) the ignition switch is ON and then the vehicle battery is removed. To prevent this, perform the following before work related to the airbag sensor assy center or battery: Disconnect the connectors of the telephone ECU assy (Mayday ECU) and the portable phone-L battery (back-up battery) before disconnecting the airbag sensor assy center connector. Be sure to remove the vehicle battery for 10 seconds or more after the ignition switch is turned OFF. HINT: When an automatic emergency call is made accidentally, contact the LEXUS link center and ask them to disregard the call. If no signal has been received from the airbag sensor assy center since the ignition switch was turned ON, a service call will be made. If signal reception from the airbag sensor assy center is interrupted while the ignition switch is ON, an emergency call will be made. When the portable phone-L battery runs low, the voltage drops and the telephone ECU sets DTC 12-1. Perform troubleshooting according to the malfunction indicated by DTC 12-1 (see «DTC 12-1 BACK-UP BATTERY FAILED LOAD TEST 10S AFTER IGNITION SWITCH ON»(ref-209384-S21604917052005120900000) ).
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
- SYSTEM DESCRIPTION Description The LEXUS link system has been adopted primarily for the purpose of saving human lives in case of an accident and as a preventive measure against theft. This system contains the following 8 functions: automatic emergency call, manual emergency call, service call, memo record, door lock/unlock, theft notification, self diagnosis, and voice message. To activate these functions, press the button for the function you would like to activate. Communication with the LEXUS link center is performed with the telephone transceiver assy and telephone antenna provided on the vehicle roof. If an accident happens and a connection with the LEXUS link center is made, the operator at the center specifies the vehicle position with GPS data from the GPS antenna located on the upper back panel, which is on the right side of the luggage room. System function Function of main components System operation LED Indicator When the ignition switch is turned ON, the telephone ECU assy (Mayday ECU) illuminates LED A and B on the telephone switch assy. LED A is amber for a few seconds and then its color changes to green. LED B is red a for few seconds and then turns off. When the ignition switch turns ON and 10 seconds have passed, the telephone ECU assy determines the operating condition of the LEXUS link system. Depending on whether or not a system malfunction is present, the ECU causes the indicator lights to illuminate or start blinking. Descriptions of the meaning of the illumination or blinking of the indicator lights are below. Automatic Emergency Call In the event of an accident in which the airbags are deployed, the telephone ECU assy (Mayday ECU) receives an airbag deployment signal from the airbag sensor assy center. Then the telephone ECU assy automatically makes an emergency call to the LEXUS link center and plays a recording indicating that an emergency call is being made. If the telephone ECU assy stops receiving signals from the airbag sensor assy center, the telephone ECU assy assumes that an open circuit in the wire harness has been caused by a collision and makes an emergency call. When the ignition switch is ON and power is no longer supplied by the battery of the vehicle, the telephone ECU assy determines that an open circuit in the wiring harness has been caused by a collision and makes an emergency call using the portable phone-L battery. Manual Emergency Call In the event of an accident in which the airbags are not deployed, or in case of an emergency, the EMERGENCY button provided on the roof console box can be manually operated to place an emergency call to the LEXUS link center. Then the telephone ECU assy plays a recording indicating that an emergency call is being made. Service Call By pressing the SERVICE button on the roof console box's telephone switch assy (Mayday switch), the telephone ECU assy (Mayday ECU) makes a service call to the LEXUS line center, and plays a recording indicating that a service call is being made. If part of the system is removed (for example, for maintenance service) or if signal output from the airbag sensor assy center to the telephone ECU assy stops after the ignition switch is turned ON, the telephone ECU assy determines that a malfunction has occurred in the circuit and makes a service call. Memo Record By pressing the REC button on the roof console box's telephone switch assy (MAYDAY switch) while a call is being made to the LEXUS link center, the conversation can be recorded into the telephone ECU assy. Pressing the REC button when no call is being made can also record audio (for example, your voice). By pressing the PLAY button on the roof console box's telephone switch assy (Mayday switch), any audio (for example, a conversation or your voice) previously recorded into the telephone ECU assy can be played back. Door Lock/Unlock If the driver is locked out of the vehicle with the key in the ignition or somewhere in the vehicle, the LEXUS link center can remotely unlock the vehicle doors. The driver only needs to contact the LEXUS link center and provide his vehicle ID code. Theft Notification If the vehicle is stolen, the theft deterrent ECU will send a warning signal to the telephone ECU assy (Mayday ECU), which will then make an emergency call to the LEXUS link center to notify of the vehicle theft. The roof console box's microphone will then turn ON automatically and be able to monitor and record any voices in the vehicle.
