PRECAUTION
Note. When disconnecting the negative (-) battery terminal, initialize the following system(s) after the terminal is reconnected.
Scheme 379
Scheme 380
Scheme 381
Scheme 382
Scheme 383
Scheme 384
Scheme 385
Scheme 386
Scheme 387
Scheme 388
Scheme 389
Scheme 390
Scheme 391
Scheme 392
Scheme 393
Scheme 394
Scheme 395
- Basic of MPX General The LEXUS LS430 multiplex communication uses serial communication, which converts multiple pieces of information into serial communication data. As a result, they can be transmitted through a single communication wire. Serial communication data consists of bits and frames. A bit is the basic unit that represent the amount of information. A bit is represented by binary values "0" or "1". A frame is a body of data that is transmitted together. A frame contains a "header" that indicates the beginning of the data and an "end" message that indicates the end of the data. Network Style Based on serial communication, various ECUs are connected on a network to exchange various pieces of information. Such a system is called a multiplex communication system. The CAN uses the multi star style bus connection. The 3 junction connectors are connected with a main bus line. The junction connector extends a sub bus line and enables communication between all the connected ECUs. The BEAN uses the ring and bus styles of networks to connect ECUs. This style of connection method is called a daisy chain. In a daisy chain, communication can be maintained even if there is an area that has an open circuit. The AVC-LAN uses a star style, which is centered on the multi display or audio head unit. Difference of CAN, BEAN and AVC-LAN General The protocols, which are the rules for establishing data communication, differ between the CAN, BEAN and the AVC-LAN. If ECUs use different types of data such as communication speed, communication wire, and signals, they will be unable to understand each other. Therefore, protocols (rules) must be established among them. Communication Wire A single, Automobile Vinyl (AV) wire is used for BEAN communication. A twisted-pair wire is used for CAN and AVC-LAN communication.
- Gateway ECU General The gateway ECU of the LEXUS LS430 has the following functions.
