Mayday System: Removal & Installation Lexus LS III рестайлинг

Communication Devices 11 illustrations ~604 words

REPLACEMENT

HINT

  1. The installation procedures are the removal procedures in reverse order.
  2. A bolt without a torque specification is shown in the standard bolt chart (see «SUSPENSION CONTROL SYSTEM»(ref-209417-S38959968142005121000000) ).

Scheme 670

Scheme 670
Scheme 670

Scheme 671

Scheme 671
Scheme 671

Scheme 672

Scheme 672
Scheme 672

Scheme 673

Scheme 673
Scheme 673

Scheme 674

Scheme 674
Scheme 674

Scheme 675

Scheme 675
Scheme 675
  1. Fixed type: REMOVE REAR SEAT CUSHION ASSY (see «OVERHAUL»(ref-215687-S29484552602006011600000) )
  2. Fixed type: REMOVE REAR SEATBACK ASSY (see «OVERHAUL»(ref-215687-S29484552602006011600000) )
  3. Power adjuster type: REMOVE REAR SEAT CUSHION ASSY LH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  4. Power adjuster type: REMOVE REAR SEAT CUSHION ASSY RH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  5. Power adjuster type: REMOVE REAR SEATBACK ASSY LH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  6. Power adjuster type: REMOVE REAR SEATBACK ASSY RH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  7. REMOVE REAR DOOR SCUFF PLATE LH (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  8. REMOVE REAR DOOR SCUFF PLATE RH (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  9. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  10. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  11. REMOVE REAR SEAT SIDE COVER LH (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  12. REMOVE REAR SEAT SIDE COVER RH (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  13. REMOVE PACKAGE TRAY TRIM PANEL ASSY (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  14. REMOVE PACKAGE TRAY TRIM PANEL ASSY NO.2 (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  15. REMOVE ROOM PARTITION NET ASSY (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  16. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  17. REMOVE ROPE HOOK ASSY (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  18. REMOVE REAR FLOOR FINISH PLATE (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  19. REMOVE TOOL CASE (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  20. REMOVE SIDE TRIM TOOL BAG COVER (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  21. REMOVE COVER, LUGGAGE COMPARTMENT TRIM, FR (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  22. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY LH (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  23. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  24. REMOVE MAYDAY ASSY Remove the 3 nuts. Disconnect the 4 connectors and 3 clamps. Remove the Mayday assy.
  25. REMOVE BUS BUFFER ECU Disconnect the connector. Remove the ECU as shown in the illustration.
  26. REMOVE MAYDAY ECU ASSY Remove the 2 bolts and mobile Phone bracket No. 1. Disconnect the 2 connectors. Remove the 3 bolts and ECU.
  27. REMOVE PORTABLE PHONE-L BATTERY Remove the nut and mobile phone bracket No. 2. Disconnect the connector and remove the portable-phone-L battery.
  28. REMOVE TELEPHONE TRANSCEIVER ASSY Disconnect the connectors. Remove the 3 screws and telephone transceiver.

HINT

  1. The installation procedures are the removal procedures in reverse order.
  2. A bolt without a torque specification is shown in the standard bolt chart (see «SUSPENSION CONTROL SYSTEM»(ref-209417-S38959968142005121000000) ).

Scheme 676

Scheme 676
Scheme 676
  1. Fixed type: REMOVE REAR SEAT CUSHION ASSY (see «OVERHAUL»(ref-215687-S29484552602006011600000) )
  2. Fixed type: REMOVE REAR SEATBACK ASSY (see «OVERHAUL»(ref-215687-S29484552602006011600000) )
  3. Power adjuster type: REMOVE REAR SEAT CUSHION ASSY LH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  4. Power adjuster type: REMOVE REAR SEAT CUSHION ASSY RH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  5. Power adjuster type: REMOVE REAR SEATBACK ASSY LH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  6. Power adjuster type: REMOVE REAR SEATBACK ASSY RH (see «OVERHAUL»(ref-215688-S25294362722006011600000) )
  7. REMOVE PACKAGE TRAY TRIM PANEL ASSY NO.2 (see «OVERHAUL»(ref-215693-S07540415162006011600000) )
  8. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY LH (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  9. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (see «OVERHAUL»(ref-215694-S04681656282006011600000) )
  10. REMOVE GPS ANTENNA Using a screwdriver, disengage the 5 clamps. HINT: Tape the screwdriver tip before use. Disconnect the connector and remove the GPS antenna.

HINT

The installation procedures are the removal procedures in reverse order.

Scheme 677

Scheme 677: REPLACEMENT
Scheme 677: REPLACEMENT

Scheme 678

Scheme 678
Scheme 678

Scheme 679

Scheme 679
Scheme 679

Scheme 680

Scheme 680
Scheme 680
  1. REMOVE MAP LAMP ASSY Using a screwdriver, disengage the 4 claws and lens cover. HINT: Tape the screwdriver tip before use. Using a screwdriver, pry out the 2 caps. HINT: Tape the screwdriver tip before use. Remove the 4 screws. Remove the map lamp and disconnect the connector.
  2. REMOVE MICROPHONE ASSY Remove the screw. Using a screwdriver, disconnect the connector and remove the microphone.
  3. REMOVE MICROPHONE AMPLIFIER ASSY Remove the screw. Remove the microphone amplifier, as shown in the illustration.
