Lexus Link System - Diagnosis: Wiring Lexus LS III рестайлинг

WIRING DIAGRAM

See WIRING DIAGRAM .

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. INSPECT TELEPHONE SWITCH ASSY Disconnect the O6 switch connector. Measure the resistance between the terminals of the switch connector when each switch is pressed. Standard: NG: REPLACE TELEPHONE SWITCH ASSY (See «MAYDAY SYSTEM»(ref-215703) ) OK: Go to next step.
2. CHECK WIRE HARNESS (TELEPHONE SWITCH ASSY - TELEPHONE ECU ASSY) Disconnect the A ECU and O6 switch connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step.
3. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - REAR SPEAKER ASSY (REAR DOOR LH)) Disconnect the A ECU and R16 speaker connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step.
4. CHECK REAR SPEAKER ASSY (REAR DOOR LH) Check that sound is emitted from the rear speaker LH when a radio switch is ON. OK: Radio sound is emitted from the rear speaker LH. NG: GO TO AUDIO SYSTEM (See «PRECAUTION»(ref-209361-S30107638982005120900000) ) OK: REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )

See DTC 8-1 ECU RECEIVED A DIAGNOSTICS ERROR FROM TRANSCEIVER, DTC 8-2 TRANSCEIVER DOES NOT RESPOND TO ANY REQUEST FOR A PERIOD OF 10S .

Scheme 63

Scheme 64

1. CHECK WHERE THIS HAPPENS Check if malfunction occurs in the service area or outside the service area. If malfunction occurs in the service area, proceed to A. If malfunction occurs outside the service area, proceed to B. B: CHECK AND OPERATE AGAIN (IN SERVICE AREA) A: Go to next step
2. CHECK WIRE HARNESS (TELEPHONE TRANSCEIVER ASSY - TELEPHONE ECU ASSY) Disconnect the A ECU and G transceiver connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step.
3. CHECK ANTENNA SYSTEM If the malfunction disappears, proceed to B. B: REPLACE TELEPHONE TRANSCEIVER ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - TELEPHONE TRANSCEIVER ASSY) Disconnect the A ECU and G transceiver connectors. Measure the resistance between wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
2. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - TELEPHONE SWITCH ASSY, TELEPHONE SWITCH ASSY - BODY GROUND) Disconnect the A ECU and O6 switch connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK
3. CHECK MICROPHONE ASSY Check that the malfunction disappears when a normal microphone is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE MICROPHONE ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A CHECK MICROPHONE AMPLIFIER ASSY Check that the malfunction disappears when normal microphone amplifier is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE MICROPHONE AMPLIFIER ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step CHECK TELEPHONE TRANSCEIVER ASSY Check that the malfunction disappears when a normal telephone transceiver is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE TELEPHONE TRANSCEIVER ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. CHECK WIRE HARNESS (TELEPHONE TRANSCEIVER ASSY - TELEPHONE ECU ASSY) Disconnect the A ECU and G transceiver connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step.
2. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - REAR SPEAKER ASSY (REAR DOOR)) Disconnect the A ECU and R16 speaker connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step.
3. CHECK REAR SPEAKER ASSY (REAR DOOR LH) Check that sound is emitted from the rear speaker LH when the radio switch is ON. OK: Radio sound is emitted from the rear speaker LH. NG: GO TO AUDIO SYSTEM (See «PRECAUTION»(ref-209361-S30107638982005120900000) ) OK: Go to next step.
4. CHECK ANTENNA SYSTEM Check that the malfunction disappears when a normal telephone antenna and cable are installed (see «REPLACEMENT»(ref-215676-S09975791522006011600000) and «PRECAUTION»(ref-209361-S30107638982005120900000) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE ANTENNA SYSTEM (See v «PRECAUTION»(ref-209361-S30107638982005120900000) and «PRECAUTION»(ref-209361-S30107638982005120900000) ) A: Go to next step.
5. CHECK TELEPHONE TRANSCEIVER ASSY Check that the malfunction disappears when a normal telephone transceiver is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE TELEPHONE TRANSCEIVER ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. CHECK TELEPHONE SWITCH ASSY Disconnect the O6 switch connector. Measure the resistance between the terminals of the switch connector when each switch is pressed. Standard: NG: REPLACE TELEPHONE SWITCH ASSY (See «MAYDAY SYSTEM»(ref-215703) ) OK: Go to next step
2. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - TELEPHONE SWITCH, TELEPHONE SWITCH ASSY - BODY GROUND) Disconnect the A ECU and O6 switch connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

1. INSPECT TELEPHONE SWITCH ASSY Disconnect the O6 switch connector. Measure the resistance between the terminals of the switch connector when each switch is pressed. Standard: NG: REPLACE TELEPHONE SWITCH ASSY (See «MAYDAY SYSTEM»(ref-215703) ) OK: Go to next step.
2. CHECK WIRE HARNESS (TELEPHONE TRANSCEIVER ASSY - TELEPHONE ECU ASSY) Disconnect the A ECU and G transceiver connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
3. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - TELEPHONE SWITCH ASSY, TELEPHONE SWITCH ASSY - BODY GROUND) Disconnect the A ECU and O6 switch connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
4. CHECK WIRE HARNESS (REAR SPEAKER ASSY (REAR DOOR LH) - TELEPHONE ECU ASSY) Disconnect the A ECU and R16 speaker connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
5. CHECK MICROPHONE ASSY Check that the malfunction disappears when a normal microphone is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE MICROPHONE ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step
6. CHECK MICROPHONE AMPLIFIER ASSY Check that the malfunction disappears when a normal microphone amplifier is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE MICROPHONE AMPLIFIER ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step
7. CHECK REAR SPEAKER ASSY (REAR DOOR LH) Check that sound is emitted from the rear door speaker LH when the radio switch is ON. OK: Radio sound is emitted from rear door speaker LH. NG: GO TO AUDIO SYSTEM (See «PRECAUTION»(ref-209361-S30107638982005120900000) ) OK: Go to next step.
8. CHECK TELEPHONE TRANSCEIVER ASSY Check that the malfunction disappears when a normal telephone transceiver is installed (see «MAYDAY SYSTEM»(ref-215703) ). If the malfunction does not disappear, proceed to A. If the malfunction disappears, proceed to B. B: REPLACE TELEPHONE TRANSCEIVER ASSY (See «MAYDAY SYSTEM»(ref-215703) ) A: Go to next step REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

1. CHECK DTC (MULTIPLEX COMMUNICATION SYSTEM) Using the hand-held tester, check for DTC B1275 or B1281. OK: Neither of the DTCs are set. NG: GO TO MULTIPLEX COMMUNICATION SYSTEM (See «PRECAUTION»(ref-209386-S01438270532005120900000) ) OK: Go to next step
2. CHECK WIRE HARNESS (AIRBAG SENSOR ASSY CENTER - TELEPHONE ECU ASSY) Disconnect the A 24 sensor and A ECU connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step.
3. CHECK WIRE HARNESS (TELEPHONE ECU ASSY - BUS BUFFER ECU) Disconnect the A ECU and D ECU connectors. Measure the resistance between the wire harness side connectors. Standard: NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK: Go to next step
4. CHECK AIRBAG SENSOR ASSY CENTER (See «AIR BAG SENSOR ASSEMBLY»(ref-170398-S26183153012005011000000) ) NG: GO TO «AIR BAG SENSOR ASSEMBLY»(ref-170398-S26183153012005011000000) OK: Go to next step
5. CHECK THEFT DETERRENT SYSTEM (See «PRECAUTION»(ref-209385-S13981938872005120900000) ) NG: GO TO «THEFT DETERRENT SYSTEM»(ref-209385) OK: Go to next step
6. CHECK ECU POWER SOURCE CIRCUIT (See «ECU POWER SOURCE CIRCUIT»(ref-209384-S19050641222005120900000) ) NG: GO TO «ECU POWER SOURCE CIRCUIT»(ref-209384-S19050641222005120900000) OK: Go to next step REPLACE TELEPHONE ECU ASSY (See «MAYDAY SYSTEM»(ref-215703) )
