Pre-Collision System (Diagnostic Codes & Circuit Tests): Diagnosis Lexus IS II facelift

Collision/avoidance 11 illustrations ~2322 words

INSPECTION PROCEDURE

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Scheme 19

Scheme 19: PROCEDURE
Scheme 19: PROCEDURE

Scheme 20

Scheme 20
Scheme 20
  1. INSPECT FRONT SEAT OUTER BELT ASSEMBLY RH Disconnect the P8 connector of the front seat outer belt assembly RH. Turn the engine switch to on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition P8-1 - Body ground Engine switch on (IG) Below 1 V P8-2 - Body ground Engine switch on (IG) Below 1 V Reconnect the P8 connector of the front seat outer belt assembly RH. NG --> See step 4 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY RH - SEAT BELT CONTROL ECU) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the P8 connector of the front seat outer belt assembly RH. Disconnect the Q58 connector of the seat belt control ECU. Connect the negative (-) terminal to the battery. Turn the engine switch to on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition P8-1 - Body ground Engine switch on (IG) Below 1 V P8-2 - Body ground Engine switch on (IG) Below 1 V Disconnect the negative (-) battery terminal. Reconnect the Q58 connector of the seat belt control ECU and P8 connector of the front seat outer belt assembly RH. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY RH - SEAT BELT CONTROL ECU) OK --> See step 3
  3. REPLACE SEAT BELT CONTROL ECU. Refer to «REMOVAL»(ref-387199-S23033253832011022400000)
  4. REPLACE FRONT SEAT OUTER BELT ASSEMBLY RH. Refer to «REMOVAL»(ref-387199-S03101934742011022400000)

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Scheme 21

Scheme 21
Scheme 21
  1. INSPECT FRONT SEAT OUTER BELT ASSEMBLY RH Disconnect the P8 connector of the front seat outer belt assembly RH. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition P8-1 - P8-2 Always Below 1 Mohms Reconnect the P8 connector of the front seat outer belt assembly RH. NG --> See step 4 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY RH - SEAT BELT CONTROL ECU) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the P8 connector of the front seat outer belt assembly RH. Disconnect the Q58 connector of the seat belt control ECU. Using a service wire, connect P8-1 and P8-2 of the connector on the front seat outer belt assembly RH. NOTE: Do not forcibly insert the service wire into the terminals of the connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition Q58-1 (MOR-) - Q58-2 (MOR+) Always Below 1 ohms Reconnect the Q58 connector of the seat belt control ECU and P8 connector of the front seat outer belt assembly RH. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY RH - SEAT BELT CONTROL ECU) OK --> See step 3
  3. REPLACE SEAT BELT CONTROL ECU. Refer to «REMOVAL»(ref-387199-S23033253832011022400000)
  4. REPLACE FRONT SEAT OUTER BELT ASSEMBLY RH. Refer to «REMOVAL»(ref-387199-S03101934742011022400000)

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Scheme 22

Scheme 22: PROCEDURE
Scheme 22: PROCEDURE

Scheme 23

Scheme 23
Scheme 23
  1. INSPECT FRONT SEAT OUTER BELT ASSEMBLY LH Disconnect the Q13 connector of the front seat outer belt assembly LH. Turn the engine switch to on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition Q13-1 - Body ground Engine switch on (IG) Below 1 V Q13-2 - Body ground Engine switch on (IG) Below 1 V Reconnect the Q13 connector of the front seat outer belt assembly LH. NG --> See step 4 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY LH - SEAT BELT CONTROL ECU) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the Q13 connector of the front seat outer belt assembly LH. Disconnect the Q58 connector of the seat belt control ECU. Connect the negative (-) battery terminal. Turn the engine switch to on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition Q13-1 - Body ground Engine switch on (IG) Below 1 V Q13-2 - Body ground Engine switch on (IG) Below 1 V Disconnect the negative (-) battery terminal. Reconnect the Q13 connector of the front seat outer belt assembly LH and Q58 connector of the seat belt control ECU. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY LH - SEAT BELT CONTROL ECU) OK --> See step 3
  3. REPLACE SEAT BELT CONTROL ECU. Refer to «REMOVAL»(ref-387199-S23033253832011022400000)
  4. REPLACE FRONT SEAT OUTER BELT ASSEMBLY LH. Refer to «REMOVAL»(ref-387199-S03101934742011022400000)

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Scheme 24

Scheme 24
Scheme 24
  1. INSPECT FRONT SEAT OUTER BELT ASSEMBLY LH Disconnect the connector Q13 of the front seat outer belt assembly LH. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition Q13-1 - Q13-2 Always Below 1 Mohms Reconnect the Q13 connector of the front seat outer belt assembly LH. NG --> See step 4 OK: Go to next step
  2. CHECK HARNESS AND CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY LH - SEAT BELT CONTROL ECU) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the Q13 connector of the front seat outer belt assembly LH. Disconnect the connector Q58 of the seat belt control ECU. Using a service wire, connect Q13-1 and Q13-1 of the connector on the front seat outer belt assembly LH. NOTE: Do not forcibly insert the service wire into the terminals of the connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition Q58-3 (MOL+) - Q58-4 (MOL-) Always Below 1 ohms Reconnect the Q13 connector of the front seat outer belt assembly LH and Q58 connector of the seat belt control ECU. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FRONT SEAT OUTER BELT ASSEMBLY LH - SEAT BELT CONTROL ECU) OK --> See step 3
  3. REPLACE SEAT BELT CONTROL ECU. Refer to «REMOVAL»(ref-387199-S23033253832011022400000)
  4. REPLACE FRONT SEAT OUTER BELT ASSEMBLY LH. Refer to «REMOVAL»(ref-387199-S03101934742011022400000)

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. The pretensioner is built into the front seat outer belt assembly. Be sure to follow the correct inspection procedure, as failure to follow the correct procedure (such as inspection of incorrect connectors) may deploy the pretensioner.

Scheme 25

Scheme 25: PROCEDURE
Scheme 25: PROCEDURE

Scheme 26

Scheme 26
Scheme 26
  1. INSPECT FUSE (PSB FUSE) Remove the PSB fuse from the cowl side J/B LH. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition PSB fuse Always Below 1 ohms Reinstall the PSB fuse to the cowl side J/B LH. NG --> REPLACE FUSE (PSB FUSE) OK: Go to next step
  2. INSPECT SEAT BELT CONTROL ECU (+B TERMINAL VOLTAGE) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the Q58 connector of the seat belt control ECU. Connect the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition Q58-7 (+B) - Body ground Engine switch OFF 11 to 14 V Disconnect the negative (-) battery terminal. Reconnect the Q58 seat belt control ECU connector. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
  3. REPLACE SEAT BELT CONTROL ECU. Refer to «REMOVAL»(ref-387199-S23033253832011022400000)

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the distance control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INSTALLATION - Step 4 . When the seat belt control ECU is replaced with a new one. INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Refer to the U0100 (CAN communication system). Refer to ECM Communication Stop Mode .

Refer to the U0122 (CAN communication system). Refer to Skid Control ECU Communication Stop Mode .

Refer to the U0146 (CAN communication system). Refer to Gateway ECU Communication Stop Mode .

Refer to the U0151 (CAN communication system). Refer to Center Airbag Sensor Communication Stop Mode .

Refer to the U1101 (CAN communication system). Refer to Distance Control ECU Communication Stop Mode .

Refer to the U0235 (Dynamic radar cruise control system). Refer to DTC U0235: Lost Communication with Cruise Control Front Distance Range Sensor .

Refer to the U1102 (Dynamic radar cruise control system). Refer to DTC U1102: Lost Communication with Radar Sensor .

Note. When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. Refer to INITIALIZATION .

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. INSPECT SEAT BELT CONTROL ECU (+B TERMINAL VOLTAGE) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the Q58connector of the seat belt control ECU. Connect the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition Q58-7 (+B) - Body ground Always 10 to 14 V Disconnect the negative (-) battery terminal. Reconnect the Q58 connector of the seat belt control ECU. Connect the negative (-) battery terminal. NG --> See step 4 OK: Go to next step
  2. INSPECT SEAT BELT CONTROL ECU (IG1 TERMINAL VOLTAGE) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the Q59 connector of the seat belt control ECU. Connect the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition Q59-8 (IG1) - Body ground Engine switch on (IG) 10 to 14 V Q59-8 (IG1) - Body ground Engine switch off Below 1 V Disconnect the negative (-) battery terminal. Reconnect the Q59 connector of the seat belt control ECU. Connect the negative (-) battery terminal. NG --> See step 5 OK: Go to next step
  3. INSPECT SEAT BELT CONTROL ECU (PGND CIRCUIT) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the Q58 connector of the seat belt control ECU. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition Q58-8 (PGND) - Body ground Always Below 1 ohms Reconnect the Q58 connector of the seat belt control ECU. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PGND CIRCUIT) OK --> See step 6
  4. INSPECT FUSE (PSB FUSE) Remove the PSB fuse from the cowl side J/B LH. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition PSB fuse Always Below 1 ohms Reinstall the PSB fuse to the cowl side J/B LH. NG --> REPLACE FUSE (PSB FUSE) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (SEAT BELT CONTROL ECU - BATTERY)
  5. INSPECT FUSE (ECU-IG RH FUSE) Remove the ECU-IG RH fuse from the cowl side J/B RH. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition ECU-IG RH fuse Always Below 1 ohms Reinstall the ECU-IG RH fuse to the cowl side J/B RH. NG --> REPLACE FUSE (ECU-IG RH FUSE) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (SEAT BELT CONTROL ECU - RH-IG1 RELAY)
  6. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-387434-S21158664412011022400000)
