Intuitive Parking Assist (Diagnostics - Introduction): Other Lexus IS II facelift

PRECAUTION

1. PRECAUTIONS FOR INTUITIVE PARKING ASSIST SYSTEM Under the following conditions, the detection function may not function properly: The sensor is covered with foreign matter, such as mud or snow (detection function returns to normal when sensor is cleaned). The sensor is frozen (detection function returns to normal when the temperature of the sensor rises). A hand is blocking the sensor. HINT: In very cold weather where a malfunction display appears, the sensor may not be able to detect obstacles. If the malfunction display appears, visually check the sensor first. If the sensor is free of foreign matter but the malfunction display remains, the sensor may have a malfunction. The detection range may be affected by the following conditions: The sensor is covered with foreign matter, such as mud or snow. The vehicle is in an excessively not or excessively cold area. Under the following conditions, a detection error may occur: Driving on a bumpy road, an unpaved road, or in tall grass. Ultrasonic waves from items such as another vehicle's horn, motorcycle engine sounds, a large vehicle's air brake sound, or another vehicle's sonar are transmitted near the vehicle. It is raining heavily or the sensor comes into contact with water (sprayed). The vehicle is tilted at a long angle. The vehicle is equipped with a commercial fender pole or a wireless mechanism antenna. The sensor is covered with foreign matter, such as mud or snow. The vehicle is moved forward or backward towards high curbs or objects that are perpendicular to the ground. The sensor cannot detect the following objects: Thin objects, such as wires and ropes. Materials that absorb ultrasonic waves, such as cotton, snow, etc. Objects with sharp edges. Short objects. Objects with a part that projects upward a large distance. Other objects. Other notices: The sensor cannot detect objects directly under the bumper. (The sensor may detect low objects and thin poles, and then lose track of the objects.) The sensor may not be able to detect obstacles that are too close to the sensor. The sensor may not be able to detect obstacles if it is dropped or subjected to a strong impact.

Scheme 71

Scheme 72

Scheme 73

Scheme 74

TRANSMITTING ECU - COMMUNICATION

RECEIVING ECU - COMMUNICATION

CUSTOMIZE PARAMETERS

1. CUSTOMIZE PARAMETERS (TECHSTREAM) The following items can be customized: NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. CUSTOMIZING - WARNING BUZZER Tester Display Default Contents Setting Rear Buzzer Onset Range Wide Function to set rear buzzer activation range / NARROW or WIDE NARROW: 600 mm(23.62 in.) WIDE: 1,500 mm (59.06 in.) Keep Sense Status Buzzer ON Function to make buzzer sound when distance between vehicle and obstacle does not change for more than 3 seconds ON / OFF Fr & Rr Buzzer Volume M2 Function to change volume of buzzer / L, M1, M2, M3 or H L: Low volume M1: medium low volume M2: medium volume M3: medium high volume H: High volume CUSTOMIZING - SENSOR Tester Display (ITEM) Default Contents Setting Non P/R Range Sensor F Function to set available sensors when shift position is not in P or R / F, Rcrn2 or F F, Rcrn2: Corner sensors are available F: front sensors are available
