Pre-Collision (Service Information): Overview Lexus HS I

Scheme 19

Scheme 20

Scheme 21

1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 4»(ref-398268-S24000400702011051600000)
4. REMOVE LOWER NO. 2 STEERING COLUMN COVER . Refer to «REMOVAL - Step 5»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
5. REMOVE LOWER STEERING COLUMN COVER . Refer to «REMOVAL - Step 5»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
6. REMOVE UPPER STEERING COLUMN COVER . Refer to «REMOVAL - Step 9»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
7. REMOVE DRIVER MONITOR CAMERA Remove the 3 screws. Disengage the 2 claws and remove the driver monitor camera.

See also:
• REMOVAL - Step 5
• REMOVAL - Step 8
• REMOVAL
• REMOVAL - Step 11
