INSPECTION PROCEDURE
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Scheme 14
Scheme 15
- CHECK WIRE HARNESS (FRONT SEAT OUTER BELT RH - SEAT BELT CONTROL ECU) Disconnect the negative (-) terminal cable from the battery. Disconnect the U8 belt connector. Disconnect the V42 ECU connector. Connect the negative (-) terminal cable to the battery. Measure the resistance and voltage of the wire harness side connector. Standard resistance Tester Connection Specified Condition U8-1 - U8-2 1 Mohms or higher Standard voltage Tester Connection Condition Specified Condition U8-1 - Body ground Power switch ON (IG) Below 1 V U8-2 - Body ground NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK FRONT SEAT OUTER BELT ASSEMBLY RH Reconnect the U8 belt connector. Disconnect the V42 ECU connector. Measure the voltage of the belt. Standard voltage Tester Connection Condition Specified Condition U8-1 - Body ground Power switch ON (IG) Below 1 V U8-2 - Body ground NG --> REPLACE FRONT SEAT OUTER BELT ASSEMBLY RH OK --> REPLACE SEAT BELT CONTROL ECU
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Scheme 16
- CHECK WIRE HARNESS (FRONT SEAT OUTER BELT RH - SEAT BELT CONTROL ECU) Disconnect the U8 belt connector. Disconnect the V42 ECU connector. Using a service wire, connect terminals U8-1 and U8-2 of the connector. NOTE: Do not forcibly insert a service wire into the terminals of the connector when connecting them. Measure the resistance of the wire harness side connector. Standard resistance Tester Connection Specified Condition V42-2 (MOR+) - V42-1 (MOR-) Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK FRONT SEAT OUTER BELT ASSEMBLY RH Disconnect the service wire from the U8 belt connector. Reconnect the U8 belt connector. Disconnect the V42 ECU connector. Measure the resistance of the belt. Standard resistance Tester Connection Specified Condition U8-1 - U8-2 Below 1 ohms NG --> REPLACE FRONT SEAT OUTER BELT ASSEMBLY RH OK --> REPLACE SEAT BELT CONTROL ECU
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Scheme 17
Scheme 18
- CHECK WIRE HARNESS (FRONT SEAT OUTER BELT LH - SEAT BELT CONTROL ECU) Disconnect the negative (-) terminal cable from the battery. Disconnect the V6 belt connector. Disconnect the V42 ECU connector. Connect the negative (-) terminal cable to the battery. Measure the resistance and voltage of the wire harness side connector. Standard resistance Tester Connection Specified Condition V6-1 - V6-2 1 Mohms or higher Standard voltage Tester Connection Condition Specified Condition V6-1 - Body ground Power switch ON (IG) Below 1 V V6-2 - Body ground NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK FRONT SEAT OUTER BELT ASSEMBLY LH Reconnect the V6 belt connector. Disconnect the V42 ECU connector. Measure the voltage of the belt. Standard voltage Tester Connection Condition Specified Condition V6-1 - Body ground Power switch ON (IG) Below 1 V V6-2 - Body ground NG --> REPLACE FRONT SEAT OUTER BELT ASSEMBLY LH OK --> REPLACE SEAT BELT CONTROL ECU
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Scheme 19
- CHECK WIRE HARNESS (FRONT SEAT OUTER BELT LH - SEAT BELT CONTROL ECU) Disconnect the negative (-) terminal cable from the battery. Disconnect the V42 ECU connector. Disconnect the V6 belt connector. Using a service wire, connect terminals V6-1 and V6-2 of the connector. NOTE: Do not forcibly insert a service wire into the terminals of the connector when connecting them. Measure the resistance of the wire harness side connector. Standard resistance: Tester Connection Specified Condition V42-3 (MOL+) - V42-4 (MOL-) Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK FRONT SEAT OUTER BELT ASSEMBLY LH Disconnect the service wire from the V6 belt connector. Reconnect the V6 belt connector. Disconnect the V42 ECU connector. Measure the resistance of the belt. Standard resistance Tester Connection Specified Condition V6-1 - V6-2 Below 1 ohms NG --> REPLACE FRONT SEAT OUTER BELT ASSEMBLY LH OK --> REPLACE SEAT BELT CONTROL ECU
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. The pretensioner is built into the front seat outer belt assembly. Be sure to follow the correct inspection procedure, as failure to follow the correct procedure (such as inspection of incorrect connectors) may deploy the pretensioner.
Scheme 20
- INSPECT SEAT BELT CONTROL ECU (+B TERMINAL VOLTAGE) Disconnect the negative (-) battery terminal. WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. Disconnect the V42 connector of the seat belt control ECU. Connect the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Condition V42-7 (+B) - Body ground Engine switch OFF 11 to 14 V Disconnect the negative (-) battery terminal. Reconnect the V42 seat belt control ECU connector. Connect the negative (-) battery terminal. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE SEAT BELT CONTROL ECU
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, initialization must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
HINT
For DTC U0100 or U0293, the Techstream displays that communication is lost with the ECM/PCM. However, for this vehicle, DTC U0100 or U0293 is output when communication is lost with the HV ECU.
Refer to U0100 (CAN communication system). Refer to HOW TO PROCEED WITH TROUBLESHOOTING .
Refer to U0293 (CAN communication system). Refer to HOW TO PROCEED WITH TROUBLESHOOTING .
Refer to U0122 (CAN communication system). Refer to HOW TO PROCEED WITH TROUBLESHOOTING .
Refer to U0146 (CAN communication system). Refer to HOW TO PROCEED WITH TROUBLESHOOTING .
Refer to U1101 (CAN communication system). Refer to HOW TO PROCEED WITH TROUBLESHOOTING .
Refer to U0235 (Dynamic radar cruise control system). Refer to DTC U0235-737: Communication Error from Radar Sensor to Distance Control ECU .
Refer to U1102 (Dynamic radar cruise control system). Refer to DTC U0235-737: Communication Error from Radar Sensor to Distance Control ECU .
Note. When the seat belt control ECU is replaced with a new one, Active Test must be performed. Refer to DATA LIST / ACTIVE TEST .
Scheme 21
Scheme 22
- CHECK WIRE HARNESS (POWER SOURCE CIRCUIT) Disconnect the negative (-) terminal cable from the battery. Disconnect the V42 and V43 ECU connectors. Connect the negative (-) terminal cable to the battery. Measure the voltage of the wire harness side connector. Standard voltage Tester Connection Condition Specified Condition V43-8 (IG1) - Battery Power switch OFF Below 1 V Power switch ON (IG) 10 to 14 V V42-7 (+B) - Battery Always 10 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK WIRE HARNESS (GROUND CIRCUIT) Disconnect the negative (-) terminal cable from the battery. Measure the resistance of the wire harness side connector. Standard resistance Tester Connection Specified Condition V42-8 (PGND) - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE SEAT BELT CONTROL ECU
