Automatic Transaxle (Service Information): Adjustments Lexus ES XV40 facelift

Automatic Trans 7 illustrations ~1053 words

ADJUSTMENT

  1. INSPECT SHIFT LEVER POSITION When shifting from P to R with the engine switch on (IG) and the brake pedal depressed, make sure that the shift lever moves smoothly and moves correctly into position. Start the engine and make sure that the vehicle moves forward when shifting from N to D and moves rearward when shifting to R. If operation cannot be done as specified, inspect the park/neutral position switch assembly and check the shift lever assembly installation condition.
  2. ADJUST SHIFT LEVER POSITION Move the shift lever to N. Remove the nut and transmission control cable from the control shaft lever. Align the protrusions of the park/neutral position switch. Move the slider in the direction indicated by arrow A and pull up the lock piece in the direction indicated by arrow B. NOTE: Do not damage the boot. Install the control cable to the control shaft with the nut. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) NOTE: If the control cable end is excessively pushed up, the shift lever cannot be adjusted. When tightening the nut, confirm that the control cable is properly stretched. Push in the lock piece. NOTE: Firmly push in the lock piece until the slider lock is engaged. Start the engine and make sure that the vehicle moves forward when moving the lever from N to D and moves rearward when moving it to R. If it becomes hard to move the shift lever, readjust the shift lever position.

Scheme 73

Scheme 73
Scheme 73
  1. INSTALL NO. 2 SHIFT CABLE GROMMET RETAINER Pass the control cable from the cabin to the engine compartment. Install the No. 2 shift cable grommet retainer with the 2 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
  2. INSTALL TRANSMISSION CONTROL CABLE ASSEMBLY Move the shift lever to N. Install the transmission control cable assembly as shown in the illustration. HINT: Install the floor shift cable with the uneven surface facing up. Securely engage the claws of the floor shift cable. Connect the control cable to the bracket with a new clip. Install the control cable to the control shaft lever with the nut. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) Push in the lock piece of the transmission control cable. NOTE: Firmly push in the lock piece until the slider lock is engaged. HINT: After pushing in the lock piece, make sure that the boot is not deformed.
  3. INSTALL CENTER AIRBAG SENSOR ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-396531-S20544654772011050900000)
  4. INSTALL NO. 1 AIR CLEANER INLET . Refer to «INSTALLATION - Step 71»(ref-396638-S39113097262011050900000)
  5. INSTALL AIR CLEANER CASE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 72»(ref-396638-S39113097262011050900000)
  6. INSTALL AIR CLEANER CAP SUB-ASSEMBLY
  7. INSTALL AIR CLEANER INLET ASSEMBLY . Refer to «INSTALLATION - Step 74»(ref-396638-S39113097262011050900000)
  8. INSTALL AIR CONDITIONING UNIT HINT
  9. INSTALL ENGINE ROOM SIDE COVER LH
  10. INSTALL COOL AIR INTAKE DUCT SEAL . Refer to «INSTALLATION - Step 100»(ref-396638-S39113097262011050900000)
  11. INSPECT SHIFT LEVER POSITION See step 1
  12. ADJUST SHIFT LEVER POSITION See step 2

Scheme 74

Scheme 74: ILLUSTRATION
Scheme 74: ILLUSTRATION

Scheme 75

Scheme 75: ILLUSTRATION
Scheme 75: ILLUSTRATION

Scheme 76

Scheme 76: REMOVAL
Scheme 76: REMOVAL

Scheme 77

Scheme 77
Scheme 77
  1. DRAIN AUTOMATIC TRANSAXLE FLUID See step 4 .
  2. REMOVE FRONT WHEELS
  3. REMOVE FRONT AXLE HUB NUT LH . Refer to «REMOVAL - Step 3»(ref-396662-S38732649992011050900000)
  4. REMOVE FRONT AXLE HUB NUT RH HINT: Use the same procedure described for the LH side.
  5. SEPARATE FRONT STABILIZER LINK ASSEMBLY LH . Refer to «REMOVAL - Step 4»(ref-396662-S38732649992011050900000)
  6. SEPARATE FRONT STABILIZER LINK ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  7. SEPARATE FRONT SPEED SENSOR LH . Refer to «REMOVAL - Step 5»(ref-396662-S38732649992011050900000)
  8. SEPARATE FRONT SPEED SENSOR RH HINT: Use the same procedure described for the LH side.
  9. SEPARATE TIE ROD ASSEMBLY LH . Refer to «REMOVAL - Step 6»(ref-396662-S38732649992011050900000)
  10. SEPARATE TIE ROD ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  11. SEPARATE FRONT SUSPENSION LOWER NO. 1 ARM LH . Refer to «REMOVAL - Step 7»(ref-396662-S38732649992011050900000)
  12. SEPARATE FRONT SUSPENSION LOWER NO. 1 ARM RH
  13. SEPARATE FRONT AXLE ASSEMBLY LH . Refer to «REMOVAL - Step 8»(ref-396662-S38732649992011050900000)
  14. SEPARATE FRONT AXLE ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  15. REMOVE FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «REMOVAL - Step 9»(ref-396662-S38732649992011050900000)
  16. REMOVE FRONT DRIVE SHAFT ASSEMBLY RH . Refer to «REMOVAL - Step 10»(ref-396662-S38732649992011050900000)
  17. SECURE FRONT AXLE HUB SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-396662-S38732649992011050900000)
  18. REMOVE TRANSAXLE CASE OIL SEAL Using SST, remove the oil seal from the transaxle case. SST: 09308-00010
  19. REMOVE FRONT TRANSAXLE CASE OIL SEAL Using SST, remove the oil seal from the transaxle housing. SST: 09308-00010

Scheme 78

Scheme 78: INSTALLATION
Scheme 78: INSTALLATION

Scheme 79

Scheme 79
Scheme 79
  1. INSTALL TRANSAXLE CASE OIL SEAL Using SST and a hammer, install a new oil seal to the transaxle case. SST: 09316-10010 SST: 09950-70010 09951-07100 Oil seal installation depth -0.5 to 0.5 mm (-0.020 to 0.020 in.) Coat the lip of the oil seal with MP grease.
  2. INSTALL FRONT TRANSAXLE CASE OIL SEAL Using SST and a hammer, install a new oil seal to the transaxle housing. SST: 09308-14010 Oil seal installation depth -0.5 to 0.5 mm (-0.020 to 0.020 in.) Coat the lip of the oil seal with MP grease.
  3. INSTALL FRONT DRIVE SHAFT ASSEMBLY LH . Refer to «INSTALLATION - Step 1»(ref-396662-S17924944292011050900000)
  4. INSTALL FRONT DRIVE SHAFT ASSEMBLY RH . Refer to «INSTALLATION - Step 2»(ref-396662-S17924944292011050900000)
  5. INSTALL FRONT AXLE ASSEMBLY LH . Refer to «INSTALLATION - Step 3»(ref-396662-S17924944292011050900000)
  6. INSTALL FRONT AXLE ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  7. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM LH . Refer to «INSTALLATION - Step 4»(ref-396662-S17924944292011050900000)
  8. INSTALL FRONT SUSPENSION LOWER NO. 1 ARM RH HINT: Use the same procedure described for the LH side.
  9. INSTALL TIE ROD ASSEMBLY LH . Refer to «INSTALLATION - Step 5»(ref-396662-S17924944292011050900000)
  10. INSTALL TIE ROD ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  11. INSTALL FRONT SPEED SENSOR LH . Refer to «INSTALLATION - Step 6»(ref-396662-S17924944292011050900000)
  12. INSTALL FRONT SPEED SENSOR RH
  13. INSTALL FRONT STABILIZER LINK ASSEMBLY LH . Refer to «INSTALLATION - Step 7»(ref-396662-S17924944292011050900000)
  14. INSTALL FRONT STABILIZER LINK ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  15. INSTALL FRONT AXLE HUB NUT LH . Refer to «INSTALLATION - Step 8»(ref-396662-S17924944292011050900000)
  16. INSTALL FRONT AXLE HUB NUT RH HINT: Use the same procedure described for the LH side.
  17. INSTALL FRONT WHEELS . Refer to «INSTALLATION - Step 9»(ref-396662-S17924944292011050900000)
  18. ADD AUTOMATIC TRANSAXLE FLUID HINT
  19. ADJUST FRONT WHEEL ALIGNMENT HINT
  20. CHECK ABS SPEED SENSOR SIGNAL HINT
