Automatic Transaxle (Diagnostics - Introduction): Diagnosis Lexus ES XV40 facelift

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. The TCM of this system is connected to the CAN communication system. Therefore, before starting troubleshooting, make sure to check that there is no trouble in the CAN communication system.
2. *: Use Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. INSPECT BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
4. CONNECT TECHSTREAM TO THE DLC3* NEXT: Go to next step
5. CHECK AND CLEAR DTCS AND FREEZE FRAME DATA* Refer to the DTC CHECK / CLEAR. Refer to «DTC CHECK / CLEAR»(ref-396631-S37801878482011050900000) . NEXT: Go to next step
6. VISUAL INSPECTION NEXT: Go to next step
7. SETTING CHECK MODE DIAGNOSIS* Refer to the CHECK MODE PROCEDURE. Refer to «CHECK MODE PROCEDURE»(ref-396631-S14632339232011050900000) . NEXT: Go to next step
8. PROBLEM SYMPTOM CONFIRMATION Refer to the ROAD TEST. Refer to «ROAD TEST»(ref-396631-S01665294802011050900000) . Result Result Proceed to Symptom does not occur A Symptom occurs B B --> GO TO STEP 10 A: Go to next step
9. SYMPTOM SIMULATION Refer to the ELECTRONIC CIRCUIT INSPECTION PROCEDURE. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-396530-S14650221532011050900000) . NEXT: Go to next step
10. DTC CHECK* Refer to the DTC CHECK / CLEAR. Refer to «DTC CHECK / CLEAR»(ref-396631-S37801878482011050900000) . Result Result Proceed to DTC is not output A DTC is output B B --> GO TO STEP 18 A: Go to next step
11. BASIC INSPECTION Refer to the AUTOMATIC TRANSMISSION FLUID. Refer to «ON-VEHICLE INSPECTION»(ref-396649-S07287436702011050900000) . Refer to the PARK/NEUTRAL POSITION SWITCH. Refer to «ON-VEHICLE INSPECTION»(ref-396649-S12015337302011050900000) . Refer to the SHIFT LEVER ASSEMBLY. Refer to «ON-VEHICLE INSPECTION»(ref-396649-S00240088292011050900000) . NG --> GO TO STEP 21 OK: Go to next step
12. MECHANICAL SYSTEM TEST Refer to the MECHANICAL SYSTEM TEST. Refer to «MECHANICAL SYSTEM TESTS»(ref-396631-S18625248092011050900000) . NG --> GO TO STEP 17 OK: Go to next step
13. HYDRAULIC TEST Refer to the HYDRAULIC TEST. Refer to «HYDRAULIC TEST»(ref-396631-S21262630252011050900000) . NG --> GO TO STEP 17 OK: Go to next step
14. MANUAL SHIFTING TEST Refer to the MANUAL SHIFTING TEST. Refer to «MANUAL SHIFTING TEST»(ref-396631-S13186089672011050900000) . NG --> GO TO STEP 16 OK: Go to next step
15. PROBLEM SYMPTOMS TABLE CHAPTER 1 Refer to the PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396631-S11523954722011050900000) . NG --> GO TO STEP 19 OK: Go to next step
16. PROBLEM SYMPTOMS TABLE CHAPTER 2 Refer to the PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-396631-S11523954722011050900000) . NEXT: Go to next step
17. PART INSPECTION NEXT --> GO TO STEP 21
18. DTC CHART Refer to the DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S34666535322011050900000) . NEXT: Go to next step
19. CIRCUIT INSPECTION NEXT: Go to next step
20. IDENTIFICATION OF PROBLEM NEXT: Go to next step
21. REPAIR OR REPLACE NEXT: Go to next step
22. CONFIRMATION TEST NEXT --> END

ROAD TEST

1. PROBLEM SYMPTOM CONFIRMATION Based on the result of the customer problem analysis, try to reproduce the symptoms. If the problem is that the transaxle does not shift up or down, or the shift point is too high or too low, conduct the following road test referring to the automatic shift schedule and attempt to duplicate the problem symptoms.
2. ROAD TEST NOTE: Perform the test at the ATF (Automatic Transmission Fluid) temperature 50 to 80°C (122 to 176°F) in the normal operation. D position test: Shift into the D position and check the following: Check up-shift operation. Check that 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6 up-shifts take place, and that the shift points conform to the automatic shift schedule. Refer to «SERVICE DATA»(ref-396594-S26856346062011050900000) . HINT: 6th Gear Up-shift Prohibition Control ATF temperature is 0°C (32°F) or less. 5th Gear Up-shift Prohibition Control ATF temperature is 0°C (32°F) or less. Lock-up Prohibition Control Brake pedal is depressed. Accelerator pedal is released. Engine coolant temperature is 60°C (140°F) or less. Check for shift shock and slip. Check for shock and slip at the 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6th up-shifts. Check for abnormal noise and vibration. Check for abnormal noise and vibration when up-shifting from 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6 while driving with the shift lever in the D position, and also while driving in the lock-up condition. HINT: The check for the cause of abnormal noise and vibration must be done thoroughly as it could also be due to loss of balance in the differential, torque converter clutch, etc. Check for abnormal shock and slip at kick-down. Check the lock-up mechanism. Drive the vehicle with the shift lever in the D position (6th gear) at a steady speed (lock-up ON). Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: There is no lock-up in the 1st, 2nd, 3rd, 4th and 5th gear. If there is a jump in engine speed, this indicates that lock-up is not operating. S position test Shift to the S position, depress the accelerator pedal and check the following: Check shift operation. With the shift lever in the S position (while the vehicle is stopped), shift into the "+" position to check that the shift position on the combination meter changes as follows: 1 to 2, 2 to 3, 3 to 4, 4 to 5 and 5 to 6. While driving in the 5 (S) position and 5th gear (at a vehicle speed of approximately 34 to 40 mph (55 to 65 km/h), shift into the "-" position and check if the 4th gear down-shift occurs and proper engine braking occurs. While driving in the 4 (S) position and 4th gear (at a vehicle speed of approximately 19 to 25 mph (30 to 40 km/h), shift into the "-" position and check if the 3rd gear down-shift occurs and proper engine braking occurs. While driving in the 3 (S) position and 3rd gear (at a vehicle speed of approximately 12 to 19 mph (20 to 30 km/h), shift into the "-" position and check if the 2nd gear down-shift occurs and proper engine braking occurs. While driving in the 2 (S) position and 2nd gear (at a vehicle speed of approximately 6 to 12 mph (10 to 20 km/h), shift into the "-" position and check if the 1st gear down-shift occurs and proper engine braking occurs. HINT: Manual shift (S position) is prohibited under either of the following conditions: Down-shifting may cause engine overrun. The driver continuously down-shifts. (Down-shifting to 1st gear may not be performed.) R position test: Shift into the R position, lightly depress the accelerator pedal, and check that the vehicle moves backward without any abnormal noise or vibration. WARNING: Before conducting this test ensure that the test area is free from people and obstruction. P position test: Stop the vehicle on a grade (more than 5°) and after shifting into the P position, release the parking brake. Then, check that the parking lock pawl holds the vehicle in place.

MANUAL SHIFTING TEST

1. PERFORM MANUAL SHIFTING TEST HINT: With this test, it can be determined whether trouble occurs in the electrical circuit. Also, trouble can be a mechanical problem in the transaxle. If any abnormalities are found in the following test, the problem is in the transaxle itself. Disconnect the TCM connector. Drive the vehicle with the TCM disconnected. Shifting the shift lever to the D position to check whether the shifting condition changes as shown in the table below. Shift Position Shifting Condition D No Shift (No Change) HINT: When driving the vehicle with the TCM disconnected, the gear position will be as follows: When the shift lever is in the D position, the transmission will stay in 3rd gear. When the shift lever is in the R or P position, the transmission will also be in the R or P position respectively. Connect the connector of the TCM. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-396631-S37801878482011050900000) .

PROBLEM SYMPTOMS TABLE

HINT

If a normal code is displayed during the diagnostic trouble code check although the problem or symptom still occurs, check the electrical circuits for each symptom in the order given in the charts below. Proceed to the reference given in the chart and perform troubleshooting.

The Matrix Chart is divided into 2 chapters.

Chapter 1

Refer to the table below when the trouble cause is considered to be electrical.

If the instruction "Proceed to next circuit inspection shown on matrix chart" is given in the flow chart of each circuit, inspect the suspected areas in descending order for each symptom.

If the trouble still occurs even though there are no abnormalities in any of the other circuits, check and replace the TCM.

Chapter 2

Chapter 2 covers on-and off-vehicle repair of the transaxle. Contents specified in the table below may not match while fail-safe control is operating.

1. CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART

HINT

*1: When the circuit is defective, a DTC may be output.

2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR

HINT

*1: When the circuit is defective, a DTC may be output.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. TCM HINT: Each TCM terminal's standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Terminals No. (Symbols)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration above as a reference for the TCM terminals. Terminals No. (Symbols) Wiring Color Terminal Description Condition Specified Condition B40-15 (R) - B40-8 (E1) W - B-W R shift position switch signal Engine switch on (IG) and shift lever in R position 11 to 14 V Engine switch on (IG) and shift lever except R position Below 1 V B40-16 (D) - B40-8 (E1) R - B-W D shift position switch signal Engine switch on (IG) and shift lever in D and S position 11 to 14 V Engine switch on (IG) and shift lever except D and S position Below 1 V B40-12 (STP) - B40-8 (E1) B - B-W Stop light switch signal Brake pedal is depressed 7.5 to 14 V Brake pedal is released Below 1.5 V B40-11 (NSW) - B40-8 (E1) L - B-W Park/neutral switch signal Engine switch on (IG) and shift lever in P or N position Below 1 V Engine switch on (IG) and shift lever except P or N position 11 to 14 V B40-10 (STA) - B40-8 (E1) Y - B-W Starter signal Cranking (shift lever position in P or N position, engine switch START) 11 to 14 V Engine switch on (IG) and shift lever except P or N position Below 2 V B40-3 (SPD1) - B40-8 (E1) BR - B-W Speed signal from combination meter Vehicle speed 12 mph (20 km/h) Pulse generation (See waveform 1 in (Scheme 34) ) B40-1 (BATT) - B40-8 (E1) W-L - B-W Battery (for measuring battery voltage and for TCM memory) Always 9 to 14 V B40-13 (IG2) - B40-8 (E1) L-B - B-W Engine switch Engine switch on (IG) 9 to 14 V B40-18 (+B) - B40-8 (E1) W - B-W Power source of TCM Engine switch on (IG) 9 to 14 V B40-6 (CAN+) - B40-8 (E1) B - B-W CAN communication line Engine switch on (IG) Pulse generation (See waveform 2 in (Scheme 35) ) B40-7 (CAN-) - B40-8 (E1) Y - B-W CAN communication line Engine switch on (IG) Pulse generation (See waveform 3 in (Scheme 36) ) Waveform 1 REFERENCE: Terminal SPD1 - E1 Tool setting 2 V/DIV., 20 ms./DIV. Vehicle condition Vehicle speed 12 mph (20 km/h) Waveform 2 REFERENCE: Terminal CAN+ - E1 Tool setting 1 V/DIV., 10 ms./DIV. Vehicle condition Engine is stopped, engine switch ON (IG) Waveform 3 REFERENCE: Terminal CAN- - E1 Tool setting 1 V/DIV., 10 ms./DIV. Vehicle condition Engine is stopped, engine switch ON (IG)
2. ECM HINT: Each ECM terminal's standard voltage is shown in the table below. In the table, first follow the information under "Condition". Look under "Terminals No. (Symbols)" for the terminals to be inspected. The standard voltage between the terminals is shown under "Specified Condition". Use the illustration below as a reference for the ECM terminals. Terminals No. (Symbols) Wiring Color Terminal Description Condition Specified Condition A10-25 (S) - B12-81 (E1) Y - W-B S shift position switch signal Engine switch on (IG) and shift lever in S position 11 to 14 V Engine switch on (IG) and shift lever except S position Below 1 V A10-16 (SFTU) - B12-81 (E1) R - W-B Up shift switch signal Engine switch on (IG) and shift lever in S position 11 to 14 V Engine switch on (IG) and shift lever in "+" position (Up shift) Below 1 V A10-51 (SFTD) - B12-81 (E1) L - W-B Down shift switch signal Engine switch on (IG) and shift lever in S position 11 to 14 V Engine switch on (IG) and shift lever in "-" position (Down shift) Below 1 V

Scheme 38

Scheme 39

Scheme 40

1. DESCRIPTION When troubleshooting On-Board Diagnostic (OBD II) vehicles, the vehicle must be connected to Techstream. Various data output from the vehicle's TCM can be read then. OBD II regulations require that the vehicle's on-board computer illuminate the Malfunction Indicator Lamp (MIL) on the instrument panel when the computer detects a malfunction in: The emission control system/components The power train control components (which affect vehicle emissions) The computer In addition, the applicable Diagnostic Trouble Codes (DTCs) prescribed by SAE J2012 are recorded in the TCM memory. If the malfunction does not reoccur in 3 consecutive trips, the MIL turns off automatically but the DTCs remain recorded in the TCM memory. To check DTCs, connect Techstream to the Data Link Connector 3 (DLC3) of the vehicle. The Techstream displays DTCs, the freeze frame data and a variety of the engine data. The DTCs and freeze frame data can be erased with Techstream. Refer to «DTC CHECK / CLEAR»(ref-396631-S37801878482011050900000) .
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in "normal mode" during normal vehicle use. In normal mode, "2 trip detection logic" is used to ensure accurate detection of malfunctions. "Check mode" is also available to technicians as an option. In check mode, "1 trip detection logic" is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent malfunctions.
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the TCM memory (1st trip). If the engine switch is turned off and then on (IG) again, and the same malfunction is detected again, the MIL will illuminate.
4. FREEZE FRAME DATA The TCM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air/fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction. The Techstream displays freeze frame data recorded at five different points: 1) 3 points before the DTC is set, 2) once when the DTC is set, and 3) once after the DTC is set. The data can be used to simulate the vehicle's condition around the time of the malfunction. The data may be helpful in determining the cause of a malfunction. It may also be helpful in determining whether a DTC is being caused by a temporary malfunction.
5. DLC3 (Data Link Connector 3) The vehicle's TCM uses the ISO 15765-4 for communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format. HINT: Connect the cable of Techstream to the DLC3, turn the engine switch on (IG) and attempt to use Techstream. If the screen displays a communication error message, a problem exists in the vehicle side or the tester side. If the communication is normal when the tester is connected to another vehicle, inspect the DLC3 on the original vehicle. If the communication is still impossible when the tester is connected to another vehicle, the problem is probably in the tester itself. Consult the Service Department listed in the tester's instruction manual. Terminals of DLC 3 Terminal No. Symbol Name Reference Terminal Result Condition 7 SIL Bus "+" line 5 - Signal ground Pulse generation During transmission 4 CG Chassis ground Body ground Below 1 ohms Always 5 SG Signal ground Body ground Below 1 ohms Always 16 BAT Battery positive Body ground 11 to 14 V Always 6 CANH CAN bus line CANL 54 to 69 ohms IG switch OFF * 6 CANH HIGH-level CAN bus line Battery positive 6 Kohms or higher IG switch OFF * 6 CANH HIGH-level CAN bus line CG 200 ohms or higher IG switch OFF * 14 CANL LOW-level CAN bus line Battery positive 6 Kohms or higher IG switch OFF * 14 CANL LOW-level CAN bus line CG 200 ohms or higher IG switch OFF * NOTE: *: Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the engine switch, any other switches or the doors.
6. CHECK BATTERY VOLTAGE Battery voltage 11 to 14 V If the voltage is below 11 V, replace or recharge the battery before proceeding.
7. CHECK MIL Check that the MIL illuminates when turning the engine switch on (IG). If the MIL does not illuminate, there is a problem in the MIL circuit. Refer to «MIL Circuit»(ref-396633-S39502831992011050900000) . When the engine is started, the MIL should turn off.

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are cleared. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the TCM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the TCM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs can be cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed.

2 TRIP DETECTION EXAMPLES

Scheme 41

Scheme 42

Scheme 43

1. CHECK DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Check the DTC(s) and freeze frame data, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S34666535322011050900000) .
2. CLEAR DTC (Pending and Current DTC) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Clear the DTCs.
3. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared if no malfunction are detected during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the universal trip. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. When accelerating through the gears, make sure the vehicle is driven so all gears are used in order and no gears are skipped. Allow 10 minutes or more to elapse from the time the engine is started. Turn the engine switch off. Wait 15 seconds. Turn the engine switch on (IG). Enter the following menus: Powertrain / ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: If the permanent DTCs have not been cleared, perform the universal trip again. The permanent DTCs are cleared when the universal trip is completed.

Scheme 44

1. DESCRIPTION Check mode has a higher sensitivity to malfunctions and can detect malfunctions that normal mode cannot detect. Check mode can also detect all the malfunctions that normal mode can detect. In check mode, DTCs are detected with 1-trip detection logic.
2. CHECK MODE PROCEDURE Make sure that the items below are satisfied: Battery positive voltage is 11 V or more Throttle valve is fully closed Transaxle is in the P or N position A/C is switched OFF Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Enter the following menus: Powertrain / ECT / Utility / Check Mode. Change the TCM to check mode. Make sure that the MIL flashes as shown in the illustration. NOTE: All DTCs and freeze frame data recorded will be erased if: 1) Techstream is used to change the TCM from normal mode to check mode or vice-versa; or 2) during check mode, the engine switch is turned from on (IG) to on (ACC) or off. Before entering check mode, make notes of any DTCs and freeze frame data that are present. Start the engine. The MIL should turn off after the engine starts. Perform "MONITOR DRIVE PATTERN" for the ECT test. Refer to «MONITOR DRIVE PATTERN»(ref-396631-S13122417492011050900000) . (Or, duplicate the conditions of the malfunction described by the customer.) After duplicating the malfunction conditions, use the Techstream diagnosis selector to check the DTC and freeze frame data.

DATA LIST / ACTIVE TEST

1. DATA LIST HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: "Powertrain / ECT / Data List". According to the display on the tester, read "Data List". Tester Display Measurement Item/Range Normal Condition Diagnostic Note Vehicle Speed Vehicle speed / Min.: 0 km/h (0 mph), Max.: 255 km/h (158 mph) Actual vehicle speed - Engine Speed Engine speed / Min.: 0 rpm, Max.: 16383.75 rpm 550 to 800 rpm: Idling - Calculate Load Calculated load by ECM / Min.: 0%, Max.: 100% 15.0 to 35.0%: Idling 10.0 to 30.0%: Running without load (2000 rpm) - Coolant Temp Engine coolant temperature / Min.: -40°C (-40°F), Max.: 140°C (284°F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Engine Run Time Engine run time / Min.: 0 second, Max.: 65535 seconds Time after engine start - Battery Voltage Battery voltage / Min.: 0, Max.: 65.535 V 9 to 14 V: Idling - Throttle Sensor Volt % Throttle position sensor output/ Min.: 0%, Max.: 100% 10 to 22%: Idling Calculated value based on VTA1 Starter Signal Starter signal/ Open or Close - - Neutral Position SW Signal PNP switch status/ ON or OFF ON: Shift lever is in P or N OFF: Shift lever is not in P or N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «PROCEDURE - Step 1»(ref-396680-S35534965542011050900000) . Stop Light Switch Stop light switch status/ ON or OFF Brake pedal is ON: Depressed OFF: Released - Check Mode Check mode / ON or OFF ON: Check mode ON - SPD Test Result Check mode result for vehicle speed sensor / Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor / 0: NOT AVL, 1: AVAIL - Comprehensive Component Monitor Fuel System Monitor Fuel system monitor / Not Avl or Avail - Fuel System Monitor Misfire Monitor Misfire monitor / Not Avl or Avail - Misfire Monitor EGR/VVT Monitor EGR/VVT monitor / Not Avl or Avail - - EGR/VVT Monitor EGR/VVT monitor / Compl or Incmpl - - O2S (A/FS) Heater Monitor Heated oxygen sensor (air fuel ratio sensor) heater monitor / Not Avl or Avail - - O2S (A/FS) Heater Monitor Heated oxygen sensor (air fuel ratio sensor) heater monitor / Compl or Incmpl - - O2S (A/FS) Monitor Heated oxygen sensor (air fuel ratio sensor) monitor / Not Avl or Avail - - O2S (A/FS) Monitor Heated oxygen sensor (air fuel ratio sensor) monitor / Compl or Incmpl - - A/C Monitor A/C monitor / Not Avl or Avail - - A/C Monitor A/C monitor / Compl or Incmpl - - 2nd Air Monitor 2nd air monitor / Not Avl or Avail - - 2nd Air Monitor 2nd air monitor / Compl or Incmpl - - EVAP Monitor EVAP monitor / Not Avl or Avail - - EVAP Monitor EVAP monitor / Compl or Incmpl - - Heated Catalyst Monitor Heated catalyst monitor / Not Avl or Avail - - Heated Catalyst Monitor Heated catalyst monitor / Compl or Incmpl - - Catalyst Monitor Catalyst monitor / Not Avl or Avail - - Catalyst Monitor Catalyst monitor / Compl or Incmpl - - Component Monitor ENA Comprehensive component monitor / Unable or Enable - - Component Monitor CMPL Comprehensive component monitor / Compl or Incmpl - - Fuel System Monitor ENA Fuel system monitor / Unable or Enable - - Fuel System Monitor CMPL Fuel system monitor / Compl or Incmpl - - Misfire Monitor ENA Misfire monitor / Unable or Enable - - Misfire Monitor CMPL Misfire monitor / Compl or Incmpl - - EGR/VVT Monitor ENA EGR/VVT monitor / Unable or Enable - - EGR/VVT Monitor CMPL EGR/VVT monitor / Compl or Incmpl - - Heater Monitor ENA Heated oxygen sensor (air fuel ratio sensor) heater monitor / Unable or Enable - - Heater Monitor CMPL Heated oxygen sensor (air fuel ratio sensor) heater monitor / Compl or Incmpl - - O2S (A/FS) Monitor ENA Heated oxygen sensor (air fuel ratio sensor) monitor / Unable or Enable - - O2S (A/FS) Monitor CMPL Heated oxygen sensor (air fuel ratio sensor) monitor / Compl or Incmpl - - A/C Monitor ENA A/C monitor / Unable or Enable - - A/C Monitor CMPL A/C monitor / Compl or Incmpl - - 2nd Air Monitor ENA 2nd air monitor / Unable or Enable - - 2nd Air Monitor CMPL 2nd air monitor / Compl or Incmpl - - EVAP Monitor ENA EVAP monitor / Unable or Enable - - EVAP Monitor CMPL EVAP monitor / Compl or Incmpl - - Heated Cat Monitor ENA Heated catalyst monitor / Unable or Enable - - Heated Cat Monitor CMPL Heated catalyst monitor / Compl or Incmpl - - Catalyst Monitor ENA Catalyst monitor / Unable or Enable - - Catalyst Monitor CMPL Catalyst monitor / Compl or Incmpl - - TC terminal TC terminal Status / ON or OFF - - #Codes (Include History) # of Codes / Min.: 0, Max.: 255 - Number of detected DTCs MIL MIL status / ON or OFF ON: MIL ON - MIL ON Run Distance MIL ON run distance / Min.: 0 km (0 mile), Max.: 65535 km (40723 mile) Distance after DTC detected - Running Time from MIL ON Running time from MIL ON / Min.: 0 minute, Max.: 65535 minutes Equivalent to running time after MIL ON - Time after DTC Cleared Time after DTC cleared / Min.: 0 minute, Max.: 65535 minutes Equivalent to time after DTCs cleared - Distance from DTC Cleared Distance after DTC cleared / Min.: 0 km (0 mile) Max.: 65535 km (40723 mile) Equivalent to time after DTCs cleared - Warm-up Cycle Cleared DTC Warm-up cycle after DTC cleared / Min.: 0, Max.: 255 - Number of warm-up cycles after DTCs cleared OBD Requirements OBD requirement - - Number of Emission DTC Emission related DTCs / Min.: 0, Max.: 127 - - TC and TE1 TC and TE1 terminals of DLC3 / ON or OFF - Active Test support data Model Code Model code - - Engine Type Engine type - - Cylinder Number Cylinder number - - Transmission (Engine) Type Transmission type - - Destination Destination - - Model Year Model year / Min.: 1900, Max.: 2155 - - Engine Speed from EFI Engine speed / Min.: 0 rpm, Max.: 51199 rpm 550 to 800 rpm: Idling - Intake-Air Temp from EFI Intake air temperature / Min.: -40°C (-40°F), Max.: 215°C (419°F) Equivalent to ambient air temperature If value -40°C (-40°F): sensor circuit open If value 215°C (419°F): sensor circuit shorted Coolant Temp from EFI Engine coolant temperature / Min.: -40°C (-40°F), Max.: 215°C (419°F) 80 to 105°C (176 to 221°F): After warming up If value -40°C (-40°F): sensor circuit open If value 140°C (284°F): sensor circuit shorted Throttle Position from EFI Throttle sensor position / Min.: 0%, Max.: 100% 0%: Accelerator pedal released 64 to 96%: Accelerator pedal fully depressed Recognition value for throttle opening angle on ECM Accel Position from EFI Absolute Accelerator Pedal Position / Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 54 to 86%: Accelerator pedal fully depressed - SPD (NT) Input turbine speed/ Min.: 0 rpm, Max.: 12750 rpm Lock-up is ON (After warming up the engine): Input turbine speed (NT) is equal to engine speed OFF (idling with shift lever in N): Input turbine speed (NT) is nearly equal to engine speed - SPD (NC) Counter gear speed / Min.: 0 rpm, Max.: 12750 rpm - - Shift SW Status (P Range) PNP switch status/ ON or OFF ON: Shift lever is in P OFF: Shift lever is not in P When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «Park / Neutral Position Switch Circuit»(ref-396680-S15320162632011050900000) Shift SW Status (R Range) PNP switch status/ ON or OFF ON: Shift lever is in R OFF: Shift lever is not in R When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «Park / Neutral Position Switch Circuit»(ref-396680-S15320162632011050900000) Shift SW Status (N Range) PNP switch status/ ON or OFF ON: Shift lever is in N OFF: Shift lever is not in N When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «Park / Neutral Position Switch Circuit»(ref-396680-S15320162632011050900000) Sports Shift Up SW Sport shift up switch status/ ON or OFF ON: Continuously shift to "+" (up-shift) OFF: Release "+" (up-shift) - Sports Shift Down SW Sport shift down switch status/ ON or OFF ON: Continuously shift to "-" (down-shift) OFF: Release "-" (down-shift) - Sports Mode Selection SW Sport mode select switch status/ ON or OFF Shift lever is: ON: S, "+" or "-" OFF: Not in S, "+" or "-" - Shift SW Status (D Range) PNP switch status/ ON or OFF ON: Shift lever is in D or S OFF: Shift lever is not in D or S When the shift lever position displayed on the Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. HINT: When the failure still occurs even after adjusting these parts. Refer to «Park / Neutral Position Switch Circuit»(ref-396680-S15320162632011050900000) A/T Oil Temperature 1 ATF temp. sensor value/ min.: -40°C (-40°F) max.: 215°C (419°F) After stall test; Approx. 80°C (176°F) Equal to ambient temperature when cold soak If the value is "-40°C (-40°F)" or "215°C (419°F)", ATF temp. sensor circuit is open or shorted. NT Sensor Voltage Input turbine speed sensor output voltage / Min.: 0 V, Max.: 5 V 0.1 to 1.9 V - NC Sensor Voltage Counter gear speed sensor output voltage / Min.: 0 V, Max.: 5 V 0.1 to 1.9 V - TPS 3 Switch ATF pressure switch No. 3 status/ 0: OFF / 1: ON ON: Shift solenoid valve SLU is ON OFF: Shift solenoid valve SLU is OFF - Lock Up Lock up / 0: OFF / 1: ON Lock up: ON - Shift Status TCM gear shift command/ 1st, 2nd, 3rd, 4th, 5th or 6th Same as actual gear - SLT Solenoid Status Shift solenoid SLT status/ ON or OFF Shift solenoid SLT is Operating: ON Not operating: OFF - SLU Solenoid Status Shift Solenoid SLU Status/ ON or OFF Shift solenoid SLU is Operating: ON Not operating: OFF - SL Solenoid Status Shift Solenoid SL Status/ ON or OFF Shift solenoid SL is Operating: ON Not operating: OFF - AT Fluid Flex lockup judder judgment flag / 0: OFF / 1: ON
2. ACTIVE TEST HINT: Using Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following items: "Powertrain / ECT / Active Test". According to the display on tester, perform "Active Test". Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less Activate the Solenoid (SL1) Operates shift solenoid SL1 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL2) Operates shift solenoid SL2 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL3) Operates shift solenoid SL3 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SL4) Operates shift solenoid SL4 ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Lock Up Controls the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. ON/OFF Can be used to check SLU and SL solenoid operation. [Vehicle Condition] Throttle valve opening angle: Less than 20% Vehicle speed: 60 km/h (37 mph) or more, and 6th gear Activate the Solenoid (SL) Operates shift solenoid SL ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SLU) Operates shift solenoid SLU ON/OFF [Vehicle Condition] Engine stopped Shift lever in P or N Activate the Solenoid (SLT)* Operates shift solenoid SLT to raise the line pressure. ON/OFF HINT: ON: No action (normal operation) OFF: Line pressure up (When the Active Test of "Activate the Solenoid (SLT)" is performed, the TCM commands the SLT solenoid to turn off). [Vehicle Condition] Vehicle Stopped IDL: ON Connect the TC and TE1 Connects and disconnects TC and TE1. (transitions into the fluid temperature detection mode) ON/OFF The MIL will not blink when "Connect the TC and TE1 / ON" is selected. *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transaxle. The same SST is used for the HYDRAULIC TEST. Refer to «HYDRAULIC TEST»(ref-396631-S21262630252011050900000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST will be different from each other.

DIAGNOSTIC TROUBLE CODE CHART

If a DTC is displayed during the DTC check, check the parts listed in the table below and proceed to the reference given.

HINT

1. *1: MIL (Malfunction Indicator Lamp) comes on.
2. *2: "DTC stored" mark means TCM memorizes the trouble code if the TCM detects that the DTC detection condition is satisfied.
3. A DTC may be output when the clutch, brake and gear components, etc. inside the automatic transaxle are damaged.

AUTOMATIC TRANSAXLE SYSTEM
