INSPECTION PROCEDURE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 441

Scheme 442

1. INSPECT SPEEDOMETER (METER OPERATION) Drive the vehicle and check if operation of the speedometer in the combination meter is normal. HINT: The vehicle speed sensor is operating normally if the speedometer display is normal. NG --> CHECK SPEEDOMETER CIRCUIT OK: Go to next step
2. INSPECT TCM Shift the lever to the neutral position. Jack up the vehicle. Disconnect the TCM connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below as the wheel is turned slowly. Standard Voltage Tester Connection Switch Condition Specified Condition B40-3 (SPD1) - B40-8 (E1) Engine switch on (IG) Voltage is generated intermittently HINT: The output voltage should fluctuate up and down similarly to the diagram when the wheel is turned slowly. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE TCM

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 443

Scheme 444

1. INSPECT TERMINAL VOLTAGE (BATT VOLTAGE OF TCM) Disconnect the TCM connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B40-1 (BATT) - B40-8 (E1) Engine switch on (IG) 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI NO. 1 FUSE - TCM) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition B40-8 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (TCM - BODY GROUND) OK: REPLACE TCM

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

1. The following troubleshooting flowchart is based on the premise that the engine is cranked normally. If the engine does not crank, proceed to the problem symptoms table. Refer to «REMOVAL»(ref-396649-S41403644072011050900000) .
2. Read freeze frame data using Techstream. The TCM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame data can be helpful in determining whether the vehicle was running or stopped, whether the engine was warmed up or not, whether the air-fuel ratio was lean or rich, as well as other data recorded at the time of a malfunction. Refer to «FREEZE FRAME DATA»(ref-396630-S23203956252011050900000) .

Scheme 445

Scheme 446

1. READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the tester on. Enter the following menus: Powertrain / Engine / Data List. Check the value displayed on the tester when the engine switch is turned on (IG) and the engine is started. OK Engine Switch Condition ON (IG) ENGINE START Starter Signal OFF ON OK --> See step 3 NG: Go to next step
2. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the Park/neutral Position switch. Disconnect the B36 switch connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Gear Selector Lever Position Specified Condition 4 - 9 P Below 1 ohms 4 - 9 N Below 1 ohms Reconnect the Park/neutral Position switch connector. NG --> See step 5 OK --> See step 6
3. CHECK HARNESS AND CONNECTOR Disconnect the B40 switch connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below when the shift lever is P or N position. Standard voltage Tester Connection Shift Position Specified Condition 8 - 10 P or N Below 2 V Connect the B40 switch connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. REPLACE TCM. Refer to «REMOVAL»(ref-396649-S41403644072011050900000)
5. REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-396649-S20158942132011050900000)
6. CHECK CRANKING HOLDING FUNCTION CIRCUIT. Refer to «Cranking Holding Function Circuit»(ref-396633-S09391807402011050900000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time.

Note. In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not.

1. READ DATA LIST Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Select the item "Powertrain / ECT / Data List". According to the display on the tester, read the "Data List". Tester Display Measurement Item / Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status / ON or OFF Shift lever position is; P and N: ON Except P and N: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (R Range) PNP switch status / ON or OFF Shift lever position is; R: ON Except R: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (D Range) PNP switch status / ON or OFF Shift lever position is; D and S: ON Except D and S: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect.

Scheme 447

Scheme 448

Scheme 449

Scheme 450

Scheme 451

Scheme 452

Scheme 453

Scheme 454

1. CHECK HARNESS AND CONNECTOR (D, R POSITION CIRCUIT) Disconnect the park/neutral position switch connector. Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B36-1 (RB) - Body ground Engine switch on (IG) 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (NSW CIRCUIT) Turn the engine switch on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B36-4 (B) - Body ground Engine switch on (IG) Below 3 V NG --> See step 8 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ST RELAY) Disconnect the park / neutral position switch connector. Remove the ST relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition B36-9 (L) - ST relay terminal 1 Always Below 1 ohms B36-9 (L) - Body ground Always 10 kohms or higher Install the ST relay. Reconnect the park/neutral position switch connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT ST RELAY ASSEMBLY Remove the ST relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 3 - 5 Always 10 kohms or higher 3 - 5 Always Below 1 ohms Apply battery voltage between terminals 1 and 2 Install the ST relay. NG --> REPLACE ST RELAY ASSEMBLY OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (ST RELAY - BODY GROUND) Remove the ST relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition ST relay terminal 2 - Body ground Always Below 1 ohms Install the ST relay. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. INSPECT PARK / NEUTRAL POSITION SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance Tester Connection Shift Position Specified Condition 1 - 3 and 4 - 9 P Below 1 ohms Except P 10 kohms or higher 1 - 2 R Below 1 ohms Except R 10 kohms or higher 1 - 8 and 4 - 9 N Below 1 ohms Except N 10 kohms or higher 1 - 7 D, S, "+" and "-" Below 1 ohms Except D, S, "+" and "-" 10 kohms or higher NG --> See step 10 OK: Go to next step
7. CHECK HARNESS AND CONNECTOR Connect the park / neutral position switch connector. Disconnect the TCM connectors. Turn the engine switch on (IG), and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage Tester Connection Shift Position Specified Condition B40-15 (R) - Body ground R 11 to 14 V * Except R Below 1 V B40-16 (D) - Body ground D 11 to 14 V Except D Below 1 V HINT: * : The voltage will drop slightly due to lighting up of the back up light. OK --> See step 11 NG: REPAIR OR REPLACE HARNESS OR CONNECTOR
8. CHECK HARNESS AND CONNECTOR (PARK / NEUTRAL POSITION SWITCH - TCM) Disconnect the TCM connectors. Turn the engine switch off. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B36-4 (B) - B40-11 (NSW) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B36-4 (B) or B40-11 (NSW) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. REPLACE TCM. Refer to «REMOVAL»(ref-396649-S41403644072011050900000)
10. REPLACE PARK/NEUTRAL POSITION SWITCH. Refer to «REMOVAL»(ref-396649-S20158942132011050900000)
11. REPLACE TCM. Refer to «REMOVAL»(ref-396649-S41403644072011050900000)

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR . If DTCs P0711 and P2610 are output simultaneously, confirm that the ATF temperature is as specified in "Normal Condition" using the Techstream first. When the ATF temperature is as specified in "Normal Condition", perform troubleshooting for DTC P2610. Refer to DIAGNOSTIC TROUBLE CODE CHART . In the table below, the value listed under "Normal Condition" are reference values.

HINT

Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time.

1. Warm up the engine.
2. Turn the engine switch off.
3. Connect the Techstream to the DLC3.
4. Turn the engine switch on (IG).
5. Turn the Techstream on.
6. Enter the following menus: Powertrain / ECT / Data List.
7. According to the display on the Techstream, read the Data List. TCM Tester Display Measurement Item/Range Normal Condition Diagnostic Note A/T Oil Temperature 1 ATF temperature sensor value/ Min.: -40°C (-40°F) Max.: 215°C (419°F) After stall speed test: Approximately 80°C (176°F) While engine is cold: Equal to ambient temperature If value is -40°C (-40°F) or 150°C (302°F), ATF temperature sensor circuit is open or short circuited HINT: When DTC P0712 is output and the Techstream indicates 150°C (302°F) or more, there is a short circuit. When DTC P0713 is output and the Techstream indicates -40°C (-40°F), there is an open circuit. Measure the resistance between terminal THO1 (OT) and body ground. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or more Short circuit HINT: If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately set (in 0.5 seconds). When P0713 is set, P0711 cannot be detected. It is not necessary to inspect the circuit when P0711 is set.

Scheme 455

Scheme 456

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0711) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Select the items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0711 A P0711 and other DTCs B HINT: If any other codes besides "P0711" are output, perform troubleshooting for those DTCs first. B --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S01544685412011050900000) A: Go to next step
2. CHECK TRANSMISSION FLUID LEVEL Check the transmission fluid level. OK Automatic transmission fluid level is correct. NG --> ADD FLUID OK: Go to next step
3. INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 17 (E2) - 18 (THO1) Always 79 ohms to 156 kohms 17 (E2) - Body ground Always 10 kohms or higher 18 (THO1) - Body ground Always 10 kohms or higher HINT: If the resistance is out of the specified range with the ATF temperature shown in the table below, the driveability of the vehicle may decrease. Tester Connection ATF Temperature Specified Condition 17 (E2) - 18 (THO1) 10°C (50°F) 5 to 8 kohms 17 (E2) - 18 (THO1) 25°C (77°F) 2.5 to 4.5 kohms 17 (E2) - 18 (THO1) 110°C (230°F) 0.22 to 0.28 kohms OK --> REPLACE TCM NG: Go to next step
4. CHECK ATF TEMPERATURE SENSOR Disconnect the ATF temperature sensor connector from the transmission wire. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition E2 - THO1 Always 79 ohms to 156 kohms E2 - Body ground Always 10 kohms or higher THO1 - Body ground Always 10 kohms or higher HINT: If the resistance is out of the specified range with the ATF temperature shown in the table below, the driveability of the vehicle may decrease. Tester Connection ATF Temperature Specified Condition 17 (E2) - 18 (THO1) 10°C (50°F) 5 to 8 kohms 17 (E2) - 18 (THO1) 25°C (77°F) 2.5 to 4.5 kohms 17 (E2) - 18 (THO1) 110°C (230°F) 0.22 to 0.28 kohms NG --> REPLACE ATF TEMPERATURE SENSOR ASSEMBLY OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Enter the following items: "Powertrain / ECT / Data List". According to the display on the tester, read "Data List". Tester Display Measurement Item / Range Normal Condition Diagnostic Note A/T Oil Temperature 1 ATF temp. sensor value/ min.: -40°C (-40°F) max.: 215°C (419°F) After stall test; Approx. 80°C (176°F) Equal to ambient temperature when cold soak If the value is "-40°C (-40°F)" or "215°C (419°F)", ATF temp. sensor circuit is open or shorted. HINT: When DTC P0712 is output and Techstream indicates 150°C (302°F) or more, there is a short circuit. When DTC P0713 is output and Techstream indicates -40°C (-40°F), there is an open circuit. Measure the resistance between terminal OIL and body ground. Temperature Displayed Malfunction -40°C (-40°F) Open circuit 150°C (302°F) or more Short circuit HINT: If the circuit related to the ATF temperature sensor becomes open, P0713 is immediately set (in 0.5 seconds). When P0713 is set, P0711 cannot be detected. It is not necessary to inspect the circuit when P0711 is set.

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty. HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Enter the following items: "Powertrain / ECT / Data List". According to the display on the tester, read "Data List". Tester Display Measurement Item / Range Normal Condition Diagnostic Note SPD (NT) Input turbine speed/ Min.: 0 rpm, Max.: 12750 rpm HINT: Lock-up ON (After warming up the engine): Input turbine speed (NT) equal to the engine speed. Lock-up OFF (Idling at N position): Input turbine speed (NT) nearly equal to the engine speed. - HINT: SPD (NT) is always 0 while driving: Open or short in the sensor or circuit. SPD (NT) is always more than 0 and less than 300 rpm while driving the vehicle at 31 mph (50 km/h) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Scheme 457

Scheme 458

1. INSPECT SPEED SENSOR (SENSOR INSTALLATION) Make sure that the connector is properly connected, and check the speed sensor installation. OK The installation bolt is tightened properly and there is no clearance between the sensor and transaxle case. NG --> REPAIR OR REPLACE SPEED SENSOR OK: Go to next step
2. CHECK TRANSMISSION WIRE Remove the TCM. Disconnect the speed sensor connector from the transmission wire. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition NTO - NTO Always Below 1 ohms NTB - NTB Always Below 1 ohms NTO - NTB Always 10 kohms or higher NG --> REPLACE TRANSMISSION WIRE OK: Go to next step
3. REPLACE SPEED SENSOR NEXT: Go to next step
4. CHECK IF DTC OUTPUT RECURS (SEE IF DTC P0715 AND/OR P0717 IS OUTPUT AGAIN) Connect Techstream to the DLC3. Start the engine and turn the Techstream main switch ON. Perform the monitor drive pattern. Refer to «MONITOR DRIVE PATTERN»(ref-396631-S13122417492011050900000) . When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0715 or P0717 A No output B A --> REPLACE TCM B: END

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 459

Scheme 460

1. READ VALUE USING DATA LIST (STP SIGNAL) HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Enter the following items: "Powertrain / ECT / Data List". According to the display on the tester, read "Data List". Tester Display Measurement Item / Range Normal Condition Diagnostic Note Stop Light Switch Stop light switch status/ ON or OFF Brake pedal is depressed: ON Brake pedal is released: OFF - NOTE: In the table above, the conditions listed under "Normal Condition" are reference conditions. Do not depend solely on these reference conditions when deciding whether a part is faulty. OK --> See step 3 NG: Go to next step
2. INSPECT STOP LIGHT SWITCH ASSEMBLY Remove the stop light switch assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Switch Position Specified Condition 1 - 2 Switch pin free Below 1 ohms 1 - 2 Switch pin pushed in 10 kohms or higher 3 - 4 Switch pin free 10 kohms or higher 3 - 4 Switch pin pushed in Below 1 ohms NG --> REPLACE STOP LIGHT SWITCH ASSEMBLY OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - TCM) Install the stop light switch assembly. Disconnect the TCM connector. Measure the voltage according to the value(s) in the table below when the brake pedal is depressed and released. Standard voltage Tester Connection Condition Specified Condition B40-12 (STP) - Body ground Brake pedal is depressed 11 to 14 V B40-12 (STP) - Body ground Brake pedal is released Below 1 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE TCM

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

Using Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test.

Scheme 461

1. PERFORM ACTIVE TEST Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn Techstream on. When using Techstream: Enter the following items: "Powertrain / ECT / Active Test". According to the display on the tester, perform "Active Test". Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up [Test Details] Control the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. [Vehicle Condition] Throttle valve opening angle: Less than 20% Vehicle speed: 37 mph (60 km/h) or more, and 6th gear [Lock-up] 0: OFF 1: ON Possible to check the SLU and SL solenoid operation. HINT: This test can be conducted when the vehicle speed is 37 mph (60 km/h) or more. This test can be conducted in the 6th gear. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change, lock-up is on. Slowly release, but not fully, the accelerator pedal in order to decelerate. (Fully releasing the pedal will close the throttle valve and lock-up may be turned off.)

Scheme 462

Scheme 463

Scheme 464

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0741) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0741 A P0741 and other DTCs B HINT: If any other codes besides "P0741" are output, perform the troubleshooting for those DTCs first. B --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S01544685412011050900000) A: Go to next step
2. CHECK TRANSMISSION WIRE Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 6 (SL) - Body ground 20°C (68°F) 11 to 15 ohms OK --> See step 4 NG: Go to next step
3. CHECK SHIFT SOLENOID VALVE SL (RESISTANCE) Remove the shift solenoid valve SL. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition Solenoid Connector (SL) - Solenoid Body (SL) 20°C (68°F) 11 to 15 ohms NG --> REPLACE SHIFT SOLENOID VALVE SL OK --> REPAIR OR REPLACE TRANSMISSION WIRE
4. CHECK SHIFT SOLENOID VALVE SL (OPERATION) Remove the shift solenoid valve SL. Connect a positive (+) lead to the terminal of the solenoid connector, and a negative (-) lead to the solenoid body. OK The solenoid valve makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE SL OK: Go to next step
5. CHECK TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve and they operate smoothly. NG --> REPAIR OR REPLACE TRANSMISSION WIRE OK: Go to next step
6. CHECK TORQUE CONVERTER CLUTCH ASSEMBLY OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 465

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0746) Connect Techstream to the DLC3. Start the engine and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0746 A P0746 and other DTCs B HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. A --> See step 3 B: Go to next step
2. PERFORM ACTIVE TEST USING SHIFT NOTE: This test should always be performed with at least 2 people. Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Active Test". HINT: Comparing the shift position commanded by the Active Test with the actual shift position enables confirmation of the problem. Refer to «FAIL-SAFE CHART»(ref-396631-S33760914302011050900000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less NOTE: This test can be conducted when the vehicle is stopped. When shifting gears using the Active Test function, do not operate the accelerator pedal for 2 seconds before and after shifting gears. HINT: The shift position commanded by the TCM is shown in the Data List/Shift Status display on Techstream. Check the vehicle speed and the gear position when the engine speed is 1,000 rpm. HINT: Because the torque converter clutch has not engaged, it may be difficult to obtain the speeds specified in 4th, 5th, and 6th gear, however a difference of speed should still be evident following each gear change. Standard 1st 2nd 3rd 4th 5th 6th 5 to 7.5 mph (8 to 12 km/h) 9.3 to 11.8 mph (15 to 19 km/h) 13.0 to 15.5 mph (21 to 25 km/h) 19.3 to 21.7 mph (31 to 35 km/h) 27.3 to 29.8 mph (44 to 48 km/h) 32.3 to 34.8 mph (52 to 56 km/h) Compare the TCM gear shift command and the actual gear position. Result Actuator gear position under malfunction TCM gear shift command Proceed to 1st 2nd 3rd 4th 5th 6th Shift solenoid SL1 Stuck ON 1st 2nd 3rd 4th 4th 4th A Stuck OFF N *1 N *1 N *1 N *1 5th 6th Shift solenoid SL2 Stuck ON 4th 4th 4th 4th 5th 6th B Stuck OFF 1st 2nd 3rd 1st N *1 N *1 Shift solenoid SL3 Stuck ON 2nd 2nd 3rd 4th 5th 6th C Stuck OFF 1st 1st 3rd 4th 5th N *1 Shift solenoid SL4 Stuck ON *3 3rd 3rd 3rd 4th 5th 5th D Stuck OFF 1st 2nd 1st 4th N *1 6th Shift solenoid SLT Stuck ON N *2 N *2 N *2 N *2 N *2 N *2 E Stuck OFF *3 1st 2nd 3rd 4th 5th 6th HINT: *1: Neutral *2: If the shift solenoid SLT is stuck on, the line pressure will be low. Therefore, the amount of torque that can be transmitted by each gear is lower than the normal limit. When the engine power exceeds this lowered limit, the engine speed will increase freely. *3: When the shift solenoid SLT is stuck OFF, gear shifting is normal. E --> GO TO DTC CHART «DTC P2714: Pressure Control Solenoid "D" Performance (Shift Solenoid Valve SLT)»(ref-396680-S10038020342011050900000) D --> GO TO DTC CHART «DTC P2808: Pressure Control Solenoid "G" Performance (Shift Solenoid Valve SL4)»(ref-396680-S36925527132011050900000) C --> GO TO DTC CHART «DTC P0796: Pressure Control Solenoid "C" Performance (Shift Solenoid Valve SL3)»(ref-396680-S24913719132011050900000) B --> GO TO DTC CHART «DTC P0776: Pressure Control Solenoid "B" Performance (Shift Solenoid Valve SL2)»(ref-396680-S40735103882011050900000) A: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL1) Remove the shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE (SL1) OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve and they operate smoothly. NG --> REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
5. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The shift solenoid valve SL1 is turned on or off automatically when the shift lever is in the D position

Scheme 466

1. INSPECT TRANSMISSION WIRE (SL1) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 14 (SL1+) - 13 (SL1-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance Check for short Tester Connection Condition Specified Condition 14 (SL1+) - Body ground Always 10 kohms or higher 13 (SL1-) - Body ground Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SL1 Remove the shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SL1 OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 467

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0776) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0776 A P0776 and other DTCs B HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. A --> See step 3 B: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM NOTE: This test should always be performed with at least 2 people. Connect Techstream to the DLC3. Start the engine and turn Techstream on. Enter the following items: "Powertrain / ECT / Active Test". HINT: Comparing the shift position commanded by the Active Test with the actual shift position enables confirm of the problem. Refer to «FAIL-SAFE CHART»(ref-396631-S33760914302011050900000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less NOTE: This test can be conducted when the vehicle is stopped. When shifting gears using the Active Test function, do not operate the accelerator pedal for 2 seconds before and after shifting gears. HINT: The shift position commanded by the TCM is shown in the Data List/Shift Status display on Techstream. Check the vehicle speed and the gear position when the engine speed is 1,000 rpm. HINT: Because the torque converter clutch has not engaged, it may be difficult to obtain the speeds specified in 4th, 5th, and 6th gear, however a difference of speed should still be evident following each gear change. Standard 1st 2nd 3rd 4th 5th 6th 5 to 7.5 mph (8 to 12 km/h) 9.3 to 11.8 mph (15 to 19 km/h) 13.0 to 15.5 mph (21 to 25 km/h) 19.3 to 21.7 mph (31 to 35 km/h) 27.3 to 29.8 mph (44 to 48 km/h) 32.3 to 34.8 mph (52 to 56 km/h) Compare the TCM gear shift command and the actual gear position. Result Actuator gear position under malfunction TCM gear shift command Proceed to 1st 2nd 3rd 4th 5th 6th Shift solenoid SL1 Stuck ON 1st 2nd 3rd 4th 4th 4th A Stuck OFF N *1 N *1 N *1 N *1 5th 6th Shift solenoid SL2 Stuck ON 4th 4th 4th 4th 5th 6th B Stuck OFF 1st 2nd 3rd 1st N *1 N *1 Shift solenoid SL3 Stuck ON 2nd 2nd 3rd 4th 5th 6th C Stuck OFF 1st 1st 3rd 4th 5th N *1 Shift solenoid SL4 Stuck ON *3 3rd 3rd 3rd 4th 5th 5th D Stuck OFF 1st 2nd 1st 4th N *1 6th Shift solenoid SLT Stuck ON N *2 N *2 N *2 N *2 N *2 N *2 E Stuck OFF *3 1st 2nd 3rd 4th 5th 6th HINT: *1: Neutral *2: If the shift solenoid SLT is stuck on, the line pressure will be low. Therefore, the amount of torque that can be transmitted by each gear is lower than the normal limit. When the engine power exceeds this lowered limit, the engine speed will increase freely. *3: When the shift solenoid SLT is stuck OFF, gear shifting is normal. E --> GO TO DTC CHART «DTC P2714: Pressure Control Solenoid "D" Performance (Shift Solenoid Valve SLT)»(ref-396680-S10038020342011050900000) D --> GO TO DTC CHART «DTC P2808: Pressure Control Solenoid "G" Performance (Shift Solenoid Valve SL4)»(ref-396680-S36925527132011050900000) C --> GO TO DTC CHART «DTC P0796: Pressure Control Solenoid "C" Performance (Shift Solenoid Valve SL3)»(ref-396680-S24913719132011050900000) A --> GO TO DTC CHART «DTC P0746: Pressure Control Solenoid "A" Performance (Shift Solenoid Valve SL1)»(ref-396680-S39610069282011050900000) B: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL2) Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE (SL2) OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve and they operate smoothly. NG --> REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
5. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPLACE AUTOMATIC TRANSAXLE ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

The shift solenoid valve SL2 is turned on or off automatically when the shift lever is in the D position

Scheme 468

Scheme 469

1. INSPECT TRANSMISSION WIRE (SL2) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 9 (SL2+) - 8 (SL2-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance Check for short Tester Connection Condition Specified Condition 9 (SL2+) - Body ground Always 10 kohms or higher 8 (SL2-) - Body ground Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SL2 Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SL2 OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

1. DATA LIST NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty. HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Enter the following items: "Powertrain / ECT / Data List". According to the display on the tester, read "Data List". Tester Display Measurement Item / Range Normal Condition Diagnostic Note SPD (NC) Min.: 0 rpm, Max.: 12,750 rpm - - HINT: SPD (NC) is always 0 while driving: Open or short in the sensor or circuit. SPD (NC) is always more than 0 and less than 300 rpm while driving the vehicle at 31 mph (50 km/h) or more: Sensor trouble, improper installation, or intermittent connection trouble of the circuit.

Scheme 470

1. INSPECT SPEED SENSOR (SENSOR INSTALLATION) Make sure that the connector is properly connected, and check the speed sensor installation. OK The installation bolts are tightened properly and there is no clearance between the sensor and transaxle case. NG --> REPAIR OR REPLACE SPEED SENSOR OK: Go to next step
2. CHECK TRANSMISSION WIRE Remove the TCM. Disconnect the speed sensor connector from the transmission wire. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition NCO - NCO Always Below 1 ohms NCB - NCB Always Below 1 ohms NCO - NCB Always 10 kohms or higher NG --> REPLACE TRANSMISSION WIRE OK: Go to next step
3. REPLACE SPEED SENSOR NEXT: Go to next step
4. CHECK IF DTC OUTPUT RECURS (SEE IF DTC P0791 AND/OR P0793 IS OUTPUT AGAIN) Connect Techstream to the DLC3. Start the engine and turn the Techstream main switch ON. Perform the monitor drive pattern. Refer to «MONITOR DRIVE PATTERN»(ref-396631-S13122417492011050900000) . When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0791 or P0793 A No output B A --> REPLACE TCM B: END

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 471

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0796) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0796 A P0796 and other DTCs B HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. A --> See step 3 B: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM NOTE: This test should always be performed with at least 2 people. Connect Techstream to the DLC3. Start the engine and turn Techstream on. Enter the following items: "Powertrain / ECT / Active Test". HINT: Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-396631-S33760914302011050900000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less NOTE: This test can be conducted when the vehicle is stopped. When shifting gears using the Active Test function, do not operate the accelerator pedal for 2 seconds before and after shifting gears. HINT: The shift position commanded by the TCM is shown in the Data List/Shift Status display on Techstream. Check the vehicle speed and the gear position when the engine speed is 1,000 rpm. HINT: Because the torque converter clutch has not engaged, it may be difficult to obtain the speeds specified in 4th, 5th, and 6th gears, however a difference of speed should still be evident following each gear change. Standard 1st 2nd 3rd 4th 5th 6th 5 to 7.5 mph (8 to 12 km/h) 9.3 to 11.8 mph (15 to 19 km/h) 13.0 to 15.5 mph (21 to 25 km/h) 19.3 to 21.7 mph (31 to 35 km/h) 27.3 to 29.8 mph (44 to 48 km/h) 32.3 to 34.8 mph (52 to 56 km/h) Compare the TCM gear shift command and the actual gear position. Result Actuator gear position under malfunction TCM gear shift command Proceed to 1st 2nd 3rd 4th 5th 6th Shift solenoid SL1 Stuck ON 1st 2nd 3rd 4th 4th 4th A Stuck OFF N *1 N *1 N *1 N *1 5th 6th Shift solenoid SL2 Stuck ON 4th 4th 4th 4th 5th 6th B Stuck OFF 1st 2nd 3rd 1st N *1 N *1 Shift solenoid SL3 Stuck ON 2nd 2nd 3rd 4th 5th 6th C Stuck OFF 1st 1st 3rd 4th 5th N *1 Shift solenoid SL4 Stuck ON *3 3rd 3rd 3rd 4th 5th 5th D Stuck OFF 1st 2nd 1st 4th N *1 6th Shift solenoid SLT Stuck ON N *2 N *2 N *2 N *2 N *2 N *2 E Stuck OFF *3 1st 2nd 3rd 4th 5th 6th HINT: *1: Neutral *2: If the shift solenoid SLT is stuck on, the line pressure will be low. Therefore, the amount of torque that can be transmitted by each gear is lower than the normal limit. When the engine power exceeds this lowered limit, the engine speed will increase freely. *3: When shift solenoid SLT is stuck OFF, gear shifting is normal. E --> GO TO DTC CHART «DTC P2714: Pressure Control Solenoid "D" Performance (Shift Solenoid Valve SLT)»(ref-396680-S10038020342011050900000) D --> GO TO DTC CHART «DTC P2808: Pressure Control Solenoid "G" Performance (Shift Solenoid Valve SL4)»(ref-396680-S36925527132011050900000) B --> GO TO DTC CHART «DTC P0776: Pressure Control Solenoid "B" Performance (Shift Solenoid Valve SL2)»(ref-396680-S40735103882011050900000) A --> GO TO DTC CHART «DTC P0746: Pressure Control Solenoid "A" Performance (Shift Solenoid Valve SL1)»(ref-396680-S39610069282011050900000) C: Go to next step
3. INSPECT SHIFT SOLENOID VALVE (SL3) Remove the shift solenoid valve SL3. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE (SL3) OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve and they operate smoothly. NG --> REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
5. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPLACE AUTOMATIC TRANSAXLE ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 472

1. INSPECT TRANSMISSION WIRE (SL3) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 16 (SL3+) - 15 (SL3-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance Check for short Tester Connection Condition Specified Condition 16 (SL3+) - Body ground Always 10 kohms or higher 15 (SL3-) - Body ground Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE (SL3) Remove the shift solenoid valve SL3. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE (SL3) OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 473

Scheme 474

Scheme 475

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0872 OR P0873) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0873 A P0872 B P0872 or P0873 and other DTCs C HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. C --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S01544685412011050900000) B --> See step 4 A: Go to next step
2. CHECK TRANSMISSION WIRE (SHORT TO GROUND) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 10 (TPS1) - Body ground (Valve body assembly) Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
3. CHECK ATF TEMPERATURE SENSOR ASSEMBLY (ATF PRESSURE SWITCH NO. 1) Disconnect the transmission wire connector from the ATF temperature sensor assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 3 (TPS1) - Body ground (Valve body assembly) Always 10 kohms or higher NG --> REPLACE ATF TEMPERATURE SENSOR ASSEMBLY OK: REPLACE TRANSMISSION WIRE
4. CHECK TRANSMISSION WIRE Remove the TCM. Disconnect the connector from the ATF temperature sensor assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 10 (TPS1) - 3 (TPS1) Always Below 1 ohms 10 (TPS1) or 3 (TPS1) - Body ground (Valve body assembly) Always 10 kohms or higher NG --> REPLACE TRANSMISSION WIRE OK: REPLACE ATF TEMPERATURE SENSOR ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 476

Scheme 477

Scheme 478

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0877 OR P0878) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0878 A P0877 B P0877 or P0878 and other DTCs C HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. C --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S01544685412011050900000) B --> See step 4 A: Go to next step
2. CHECK TRANSMISSION WIRE (SHORT TO GROUND) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 20 (TPS2) - Body ground (Valve body assembly) Always 10 kohms or higher OK --> REPAIR OR REPLACE TCM NG: Go to next step
3. CHECK ATF TEMPERATURE SENSOR ASSEMBLY (ATF PRESSURE SWITCH NO. 2) Disconnect the transmission wire connector from the ATF temperature sensor assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 4 (TPS2) - Body ground (Valve body assembly) Always 10 kohms or higher NG --> REPLACE ATF TEMPERATURE SENSOR ASSEMBLY OK: REPLACE TRANSMISSION WIRE
4. CHECK TRANSMISSION WIRE Remove the TCM. Disconnect the connector from the ATF temperature sensor assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 20 (TPS2) - 2 (TPS2) Always Below 1 ohms 20 (TPS2) or 2 (TPS2) - Body ground (Valve body assembly) Always 10 kohms or higher NG --> REPLACE TRANSMISSION WIRE OK: REPLACE ATF TEMPERATURE SENSOR ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 479

Scheme 480

Scheme 481

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0989 OR P0990) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P0990 A P0989 B P0989 or P0990 and other DTCs C HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. C --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S01544685412011050900000) B --> See step 4 A: Go to next step
2. CHECK TRANSMISSION WIRE (SHORT TO GROUND) Remove the TCM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 19 (TPS3) - Body ground (Valve body assembly) Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
3. CHECK ATF TEMPERATURE SENSOR ASSEMBLY (ATF PRESSURE SWITCH NO. 3) Disconnect the connector from the ATF temperature sensor assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 5 (TPS3) - Body ground (Valve body assembly) Always 10 kohms or higher NG --> REPLACE ATF TEMPERATURE SENSOR ASSEMBLY OK: REPLACE TRANSMISSION WIRE
4. CHECK TRANSMISSION WIRE Remove the TCM. Disconnect the connector from the ATF temperature sensor assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Condition Condition Specified Condition 19 (TPS3) - 1 (TPS3) Always Below 1 ohms 19 (TPS3) or 1 (TPS3) - Body ground (Valve body assembly) Always 10 kohms or higher NG --> REPLACE TRANSMISSION WIRE OK: REPLACE ATF TEMPERATURE SENSOR ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 482

Scheme 483

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P2714) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P2714 A P2714 and other DTCs B HINT: If a solenoid is stuck ON, DTCs for several solenoids including the malfunctioning solenoid will be detected. A --> See step 4 B: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be sure to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting the engine. Perform the test with the A/C OFF. HINT: Using Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn on the tester. Enter the following items: Powertrain / ECT / Active Test". Follow the instructions on the tester and perform the Active Test. Measure the line pressure with SST. Tester Display Test Part Control Range Diagnostic Note Activate the Solenoid (SLT)* Operates shift solenoid SLT to raise the line pressure. ON/OFF HINT: ON: No action (normal operation) OFF: Line pressure up (When the Active Test of "Activate the Solenoid (SLT)" is performed, the TCM commands the SLT solenoid to turn off). [Vehicle Condition] Vehicle Stopped IDL: ON *: "Activate the Solenoid (SLT)" in the Active Test is performed to check that the line pressure changes by connecting the SST to the automatic transaxle. The same SST is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST»(ref-396631-S21262630252011050900000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> See step 5 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFTING TEST) NOTE: This test should always be performed with at least 2 people. HINT: Using Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Start the engine. Turn on the tester. Enter the following items: "Powertrain / ECT / Active Test". Follow the instructions on the tester and read the Active Test. Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less NOTE: This test can be conducted when the vehicle is stopped. When shifting gears using the Active Test function, do not operate the accelerator pedal for 2 seconds before and after shifting gears. HINT: The shift position commanded by the TCM is shown on the Data List/Shift Status display on Techstream. Check the vehicle speed and the gear position when the engine speed is 1,000 rpm. HINT: Because the torque converter clutch has not engaged, it may be difficult to obtain the speeds specified in 4th, 5th, and 6th gears, however a difference of speed should still be evident following each gear change. Standard 1st 2nd 3rd 4th 5th 6th 5 to 7.5 mph (8 to 12 km/h) 9.3 to 11.8 mph (15 to 19 km/h) 13.0 to 15.5 mph (21 to 25 km/h) 19.3 to 21.7 mph (31 to 35 km/h) 27.3 to 29.8 mph (44 to 48 km/h) 32.3 to 34.8 mph (52 to 56 km/h) Compare the TCM gear shift command and the actual gear position. Result Actuator gear position under malfunction TCM gear shift command Proceed to 1st 2nd 3rd 4th 5th 6th Shift solenoid SL1 Stuck ON 1st 2nd 3rd 4th 4th 4th A Stuck OFF N *1 N *1 N *1 N *1 5th 6th Shift solenoid SL2 Stuck ON 4th 4th 4th 4th 5th 6th B Stuck OFF 1st 2nd 3rd 1st N *1 N *1 Shift solenoid SL3 Stuck ON 2nd 2nd 3rd 4th 5th 6th C Stuck OFF 1st 1st 3rd 4th 5th N *1 Shift solenoid SL4 Stuck ON *3 3rd 3rd 3rd 4th 5th 5th D Stuck OFF 1st 2nd 1st 4th N *1 6th Shift solenoid SLT Stuck ON N *2 N *2 N *2 N *2 N *2 N *2 E Stuck OFF *3 1st 2nd 3rd 4th 5th 6th HINT: *1: Neutral *2: If the shift solenoid SLT is stuck on, the line pressure will be low. Therefore, the amount of torque that can be transmitted by each gear is lower than the normal limit. When the engine power exceeds this lowered limit, the engine speed will increase freely. *3: When the shift solenoid SLT is stuck OFF, gear shifting is normal. D --> GO TO DTC CHART «DTC P2808: Pressure Control Solenoid "G" Performance (Shift Solenoid Valve SL4)»(ref-396680-S36925527132011050900000) C --> GO TO DTC CHART «DTC P0796: Pressure Control Solenoid "C" Performance (Shift Solenoid Valve SL3)»(ref-396680-S24913719132011050900000) B --> GO TO DTC CHART «DTC P0776: Pressure Control Solenoid "B" Performance (Shift Solenoid Valve SL2)»(ref-396680-S40735103882011050900000) A --> GO TO DTC CHART «DTC P0746: Pressure Control Solenoid "A" Performance (Shift Solenoid Valve SL1)»(ref-396680-S39610069282011050900000) E: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
5. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
6. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-396649-S01694405762011050900000) . OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 484

1. INSPECT TRANSMISSION WIRE (SLT) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 12 (SLT+) - 7- (SLT) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance Check for short Tester Connection Condition Specified Condition 12 (SLT+) - Body ground Always 10 kohms or higher 7 (SLT-) - Body ground Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 485

1. ACTIVE TEST HINT: Using Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Enter the following items: "Powertrain / ECT / Active Test". According to the display on the tester, perform "Active Test". Tester Display Test Part Control Range Diagnostic Note Activate the Lock Up [Test Details] Control the shift solenoid SLU and SL to set the automatic transaxle to the lock-up condition. [Vehicle Condition] Throttle valve opening angle: Less than 20% Vehicle speed: 37 mph (60 km/h) or more, and 6th gear [Lock-up] 0: OFF 1: ON Possible to check the SLU and SL solenoid operation. HINT: This test can be conducted when the vehicle speed is 37 mph (60 km/h) or more. This test can be conducted with the 6th gear. Lightly depress the accelerator pedal and check that the engine speed does not change abruptly. HINT: When changing the accelerator pedal opening angle while driving, if the engine speed does not change, lock-up is on. Slowly release, but not fully, the accelerator pedal in order to decelerate. (Fully releasing the pedal will close the throttle valve and lock-up may be turned off automatically.)

Scheme 486

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P2757) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P2757 A P2757 and other DTCs B HINT: If any other codes besides "P2757" are output, perform troubleshooting for those DTCs first. B --> GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-396631-S01544685412011050900000) A: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLU OK: Go to next step
3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
4. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION»(ref-396649-S01694405762011050900000) . OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 487

1. INSPECT TRANSMISSION WIRE (SLU) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 11 (SLU+) - 5 (SLU-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance Check for short Tester Connection Condition Specified Condition 11 (SLU+) - Body ground Always 10 kohms or higher 5 (SLU-) - Body ground Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLU OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 488

1. INSPECT TRANSMISSION WIRE (SHIFT SOLENOID VALVE SL) Remove the TCM from the transaxle. Measure the resistance of the transmission wire. Standard resistance Tester Connection Condition Specified Condition 6 (SL) - Body ground 20°C (68°F) 11 to 15 ohms OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SL (RESISTANCE) Remove the shift solenoid valve SL. Measure the resistance between the solenoid valve terminal and solenoid valve body. Standard resistance Tester Connection Condition Specified Condition Solenoid Connector (SL) - Solenoid Body (SL) 20°C (68°F) 11 to 15 ohms NG --> REPLACE SHIFT SOLENOID VALVE SL OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 489

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P2808) Connect Techstream to the DLC3. Turn the engine switch on (IG) and turn Techstream on. Enter the following items: "Powertrain / ECT / Trouble Codes". Read the DTCs using Techstream. Result Result Proceed to P2808 A P2808 and other DTCs B HINT: If a solenoid is stuck OFF, DTCs for several solenoids including the malfunctioning solenoid will be detected. A --> See step 3 B: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM NOTE: This test should always be performed with at least 2 people. Connect Techstream to the DLC3. Start the engine and turn Techstream on. Enter the following items: "Powertrain / ECT / Active Test". HINT: While driving, the shift position can be forcibly changed with Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART»(ref-396631-S33760914302011050900000) . Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operates the shift solenoid valves to allow gears to selected manually. Press "-->" button: Upshift occurs Press "<--" button: Downshift occurs Can be used to check the operation of the shift solenoid valves. Upshifts and downshifts should be performed consecutively. A 10-second interval is required between gear changes. Do not downshift at high speeds. Doing so will damage the automatic transaxle. [Vehicle Condition] 50 km/h (30 mph) or less NOTE: This test can be conducted when the vehicle is stopped. When shifting gears using the Active Test function, do not operate the accelerator pedal for 2 seconds before and after shifting gears. HINT: The shift position commanded by the TCM is shown on the Data List/Shift Status display on Techstream. Check the vehicle speed and the gear position when the engine speed is 1,000 rpm. HINT: Because the torque converter clutch has not engaged, it may be difficult to obtain the speeds specified in 4th, 5th, and 6th gears, however a difference of speed should still be evident following each gear change. Standard 1st 2nd 3rd 4th 5th 6th 5 to 7.5 mph (8 to 12 km/h) 9.3 to 11.8 mph (15 to 19 km/h) 13.0 to 15.5 mph (21 to 25 km/h) 19.3 to 21.7 mph (31 to 35 km/h) 27.3 to 29.8 mph (44 to 48 km/h) 32.3 to 34.8 mph (52 to 56 km/h) Compare the TCM gear shift command and the actual gear position. Result Actuator gear position under malfunction TCM gear shift command Proceed to 1st 2nd 3rd 4th 5th 6th Shift solenoid SL1 Stuck ON 1st 2nd 3rd 4th 4th 4th A Stuck OFF N *1 N *1 N *1 N *1 5th 6th Shift solenoid SL2 Stuck ON 4th 4th 4th 4th 5th 6th B Stuck OFF 1st 2nd 3rd 1st N *1 N *1 Shift solenoid SL3 Stuck ON 2nd 2nd 3rd 4th 5th 6th C Stuck OFF 1st 1st 3rd 4th 5th N *1 Shift solenoid SL4 Stuck ON *3 3rd 3rd 3rd 4th 5th 5th D Stuck OFF 1st 2nd 1st 4th N *1 6th Shift solenoid SLT Stuck ON N *2 N *2 N *2 N *2 N *2 N *2 E Stuck OFF *3 1st 2nd 3rd 4th 5th 6th HINT: *1: Neutral *2: If the shift solenoid SLT is stuck on, the line pressure will be low. Therefore, the amount of torque that can be transmitted by each gear is lower than the normal limit. When the engine power exceeds this lowered limit, the engine speed will increase freely. *3: When the shift solenoid SLT is stuck OFF, gear shifting is normal. E --> GO TO DTC CHART «DTC P2714: Pressure Control Solenoid "D" Performance (Shift Solenoid Valve SLT)»(ref-396680-S10038020342011050900000) C --> GO TO DTC CHART «DTC P0796: Pressure Control Solenoid "C" Performance (Shift Solenoid Valve SL3)»(ref-396680-S24913719132011050900000) B --> GO TO DTC CHART «DTC P0776: Pressure Control Solenoid "B" Performance (Shift Solenoid Valve SL2)»(ref-396680-S40735103882011050900000) A --> GO TO DTC CHART «DTC P0746: Pressure Control Solenoid "A" Performance (Shift Solenoid Valve SL1)»(ref-396680-S39610069282011050900000) D: Go to next step
3. INSPECT SHIFT SOLENOID VALVE SL4 Remove the shift solenoid valve SL4. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 20°C (68°F) 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE SL4 OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve and they operate smoothly. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
5. TORQUE CONVERTER CLUTCH ASSEMBLY OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK: REPLACE AUTOMATIC TRANSAXLE ASSEMBLY

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

Scheme 490

Scheme 491

1. INSPECT TRANSMISSION WIRE (SL4 CIRCUIT) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 22 (SL4+) - 21 (SL4-) 20°C (68°F) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance Check for short Tester Connection Condition Specified Condition 22 (SL4+) - Body ground Always 10 kohms or higher 21 (SL4-) - Body ground Always 10 kohms or higher OK --> REPLACE TCM NG: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SL4 Remove the shift solenoid valve SL4. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 5.0 to 5.6 ohms Connect a positive (+) lead through a 21 W bulb to terminal 2 and a negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating noise. NG --> REPLACE SHIFT SOLENOID VALVE SL4 OK: REPLACE TRANSMISSION WIRE

Note. Perform the universal trip to clear permanent DTCs. Refer to DTC CHECK / CLEAR .

HINT

1. Refer to inspection procedure for CAN communication system. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-396655-S39167772552011050900000) .
2. If the CAN communication malfunctions, the TCM cannot receive the current data from the ECM. In this case, the freeze frame data output from the TCM has not been updated, so the data will not be useful for the inspection. However, reading the Data List as the first step in troubleshooting is effective to find malfunctions.
3. The malfunction area can be checked using the BUS CHECK function on Techstream. Refer to «DIAGNOSIS SYSTEM»(ref-396655-S14818501412011050900000) .

Scheme 492

Scheme 493

1. CHECK ECU TERMINAL VOLTAGE (+B AND E1 TERMINALS) Disconnect the TCM connector. Turn the engine switch on (IG). Measure the voltage of the TCM connector. Standard voltage Tester Connection Switch Condition Specified Condition B40-18 (+B) - B40-8 (E1) Engine switch on (IG) 9 to 14 V Turn the engine switch off. Measure the resistance of the TCM connector. Standard resistance Tester Connection Condition Specified Condition B40-8 (E1) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TCM - ECM) Disconnect the B40 TCM connector. Disconnect the B12 ECM connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Condition Specified Condition B40-6 (CAN+) - B12-2 (CAN+) Always Below 1 ohms B40-7 (CAN-) - B12-1 (CAN-) Always Below 1 ohms B40-6 (CAN+) or B12-2 (CAN+) - Body ground Always 1 Mohms or more B40-7 (CAN-) or B12-1 (CAN-) - Body ground Always 1 Mohms or more NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK IF DTC OUTPUT RECURS Connect Techstream to the DLC3. Clear the DTC. Replace the TCM. HINT: Replace the TCM with the TCM of a normally functioning vehicle of the same model. Start the engine. Read the DTCs. Result Result Proceed to P0100 A No DTC B A --> REPLACE ECM B --> REPLACE TCM

1. DATA LIST HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty. Warm up the engine. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn on the tester. Enter the following items: "Powertrain / ECT / Data List". According to the display on the tester, read "Data List". Tester Display Measurement Item / Range Normal Condition Diagnostic Note Neutral Position SW Signal PNP switch status/ ON or OFF Shift lever position is; P and N: ON Except P and N: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (R Range) PNP switch status/ ON or OFF Shift lever position is; R: ON Except R: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (P Range) PNP switch status/ ON or OFF Shift lever position is; P: ON Except P: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (N Range) PNP switch status/ ON or OFF Shift lever position is; N: ON Except N: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect. Shift SW Status (D Range) PNP switch status/ ON or OFF Shift lever position is; D and S: ON Except D and S: OFF When the shift lever position displayed on Techstream differs from the actual position, adjustment of the PNP switch or the shift cable may be incorrect.

Scheme 494

Scheme 495

1. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Disconnect the park/neutral position switch connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance Tester Connection Shift Position Specified Condition 1 - 3 and 4 - 9 P Below 1 ohms Except P 10 kohms or higher 1 - 2 R Below 1 ohms Except R 10 kohms or higher 1 - 8 and 4 - 9 N Below 1 ohms Except N 10 kohms or higher 1 - 7 D, S, "+" and "-" Below 1 ohms Except D, S, "+" and "-" 10 kohms or higher NG --> REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY OK: Go to next step
2. CHECK ECU TERMINAL VOLTAGE (STA TERMINAL) Connect the transmission control switch connector of the shift lever assembly. Measure the voltage according to the value(s) in the table below while cranking the engine. Standard voltage Tester Connection Switch Condition Specified Condition B40-10 (STA) - Body ground Engine switch on (IG) 9 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (TCM - ECM) OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TCM) Disconnect the TCM connector. Turn the engine switch on (IG), and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage Tester Connection Shift Position Specified Condition B40-15 (R) - Body ground R 11 to 14 V * Except R Below 1 V B40-16 (D) - Body ground D 11 to 14 V Except D Below 1 V HINT: *: The voltage will drop slightly because the back up light is turned on. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (PARK/NEUTRAL POSITION SWITCH - TCM) OK --> REPLACE TCM
