MONITOR STRATEGY
| Related DTCs | P0500: Vehicle Speed Sensor Circuit |
|---|
| Required sensors/components (Main) | Vehicle speed sensor, Combination meter, Skid control ECU |
| Required sensors/components (Sub) | Counter gear Speed (CS) sensor, ECT sensor |
| Frequency of operation | Continuous |
| Duration | 2 seconds |
| MIL operation | Immediately |
| Sequence operation | None |
TYPICAL ENABLING CONDITIONS
| Engine | Running |
|---|
| Transmission counter gear revolution | 300 rpm or more |
| Battery voltage | 8 V or more |
| Engine switch | ON |
| Starter | OFF |
| Either a or b is met (See below) | |
| A. All of the following conditions are met | |
| ECT | 20°C (68°F) or more |
| ECT sensor fail | Not detected |
| Time after PNP switch ON to OFF | 2 sec. or more |
| B. All of the following conditions are met | |
| ECT | Less than 20°C (68°F) |
| ECT sensor fail | Detected |
| Time after PNP switch ON to OFF | 30 sec. or more |
TYPICAL MALFUNCTION THRESHOLDS
| Vehicle speed sensor signal | No pulse input |
| Related DTCs | P0560: TCM system voltage |
|---|
| Required Sensors/Components (Main) | TCM |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
|---|
| Stand-by RAM | Initialized |
| TCM power source | Less than 3.5 V |
Scheme 496
Scheme 496: WIRING DIAGRAM
| Related DTCs | P0617: Starter signal |
|---|
| Required Sensors/Components (Main) | STARTER relay, PMP switch, Engine switch |
| Required Sensors/Components (Sub) | Vehicle speed sensor (VSS), Crankshaft Position (CKP) sensor |
| Frequency of Operation | Continuous |
| Duration | 20 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever these DTCs are not present | None |
|---|
| Battery voltage | 10.5 V or more |
| Vehicle speed | 12.43 mph (20 km/h) or more |
| Engine speed | 1,000 rpm or more |
Scheme 497
Scheme 497: WIRING DIAGRAM
| Related DTCs | P062F: Internal control module EEPROM error |
|---|
| Required sensors/Components (Main) | TCM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 11 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
|---|
| Time after engine start | 10 seconds or more |
| Battery voltage | 8 V or higher |
| Engine switch | On (IG) |
| Starter | OFF |
| Permanent fault code data | Mismatch (3 times or more) |
PROCEDURE
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-396631-S37801878482011050900000) . Turn the engine switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Select the following menu items: Powertrain / ECT / Trouble Codes. Read DTCs. Result Result Proceed to No output A P062F B B --> See step 3 A: Go to next step
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-396530-S30973998832011050900000)
- REPLACE TCM. Refer to «REMOVAL»(ref-396649-S41403644072011050900000)
| Related DTCs | P0705: Park/neutral position switch/Verify switch input |
|---|
| Required sensors/Components | Park/neutral position switch |
| Frequency of operation | Continuous |
| Duration | Condition (A): 2 sec. Condition (B): 60 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever the following DTCs are not present | None |
|---|
| Engine switch | ON |
| Battery voltage | 10.5 V or more |
- When either condition below is met: Condition (A) or (B) Condition (A) When 2 or more of the following signals are input at the same time: Park neutral position switch ON R position switch ON D position switch ON Condition (B) When all conditions below are met: Park neutral position switch OFF R position switch OFF D position switch OFF
COMPONENT OPERATING RANGE
| Park/neutral Position switch | The park/neutral position switch sends only one signal to the TCM. |
Scheme 498
Scheme 498: WIRING DIAGRAM
| Related DTCs | P0711: ATF temperature sensor |
|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | Condition A, B, C and D: 3 sec. Condition E: Continuous |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0112, P0113 (IAT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) P2610 (Soak timer circuit) |
|---|
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| IAT (Intake air temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| Soak timer circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| Time after engine start | 12 sec. or more |
| ECT (Engine coolant temperature) | 15°C (5°F) or more |
| Time after engine start | 10 min. |
|---|
| Driving distance after engine start | 3 miles (5 km) or more |
| IAT (12 sec. after engine start) | 15°C (59°F) or more |
| ECT (12 sec. after engine start) | 15°C (59°F) or more |
| Soak time | 5 hours |
| Accumulated driving time *1 | 115 sec. or more |
| *1: Following conditions are met | |
| Engine speed - Turbine speed | 50 rpm or more |
| Output speed | 400 rpm or more |
| Throttle valve opening angle | 3% or more |
| Shift position | Not "N" or "P" |
| Time after engine start | 18 min. and 20 sec. |
|---|
| Driving distance after engine start | 5 miles (8 km) or more |
| IAT (12 sec. after engine start) | 10°C (14°F) or more |
| ECT (12 sec. after engine start) | 10°C (14°F) or more |
| Accumulated driving time *1 | 200 sec. or more |
| Time after engine start | 30 min. |
|---|
| Driving distance after engine start | 9.3 miles (15 km) |
| IAT (12 sec. after engine start) | 15°C (5°F) or more |
| ECT (12 sec. after engine start) | 15°C (5°F) or more |
| Accumulated driving time *1 | 400 sec. or more |
| Time after engine start | 40 min. |
|---|
| Driving distance after engine start | 12.4 miles (20 km) |
| Accumulated driving time *1 | 550 sec. or more |
| Time after ECT reaches 60°C (140°F) | 10 sec. or more |
|---|
| TFT (12 sec. after engine start) | 110°C (230°F) or more |
| ECT (12 sec. after engine start) | 35°C (95°F) or less |
| TFT | Less than 20°C (68°F) (THO = -10°C (14°F) at engine start) (Conditions vary with THO at engine) |
| TFT | ATF temperature - approx. 130°C (266°F) |
Scheme 499
Scheme 499: WIRING DIAGRAM
| Related DTCs | P0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance) |
|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 0.5 sec. |
| MIL operation | Immediately |
| Sequence of operation | None |
- P0712: RANGE CHECK (LOW RESISTANCE) The monitor will run whenever these DTCs are not present. None Battery voltage. 8 V or more Engine switch ON
- P0713: RANGE CHECK (HIGH RESISTANCE) The monitor will run whenever this DTC is not present. None Time after engine start 10 sec. or more
Range check (Low resistance)
| TFT sensor resistance | Less than 79 ohms |
Range check (High resistance)
| TFT sensor resistance | More than 156 kohms |
| TFT sensor | Atmospheric temperature to approx. 130°C (266°F) |
- INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Remove the TCM from the transaxle. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 17 (E2) - 18 (THO1) Always 79 ohms to 156 kohms 17 (E2) - Body ground Always 10 kohms or higher 18 (THO1) - Body ground Always 10 kohms or higher HINT: If the resistance is out of the specified range with the ATF temperature shown in the table below, the driveability of the vehicle may decrease. Tester Connection ATF Temperature Specified Condition 17 (E2) - 18 (THO1) 10°C (50°F) 5 to 8 kohms 17 (E2) - 18 (THO1) 25°C (77°F) 2.5 to 4.5 kohms 17 (E2) - 18 (THO1) 110°C (230°F) 0.22 to 0.28 kohms OK --> REPLACE TCM NG: Go to next step
- INSPECT ATF TEMPERATURE SENSOR Disconnect the ATF temperature sensor connector from the transmission wire. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition E2 - THO1 Always 79 ohms to 156 kohms E2 - Body ground Always 10 kohms or higher THO1 - Body ground Always 10 kohms or higher HINT: If the resistance is out of the specified range with the ATF temperature shown in the table below, the driveability of the vehicle may decrease. Tester Connection ATF Temperature Specified Condition 17 (E2) - 18 (THO1) 10°C (50°F) 5 to 8 kohms 17 (E2) - 18 (THO1) 25°C (77°F) 2.5 to 4.5 kohms 17 (E2) - 18 (THO1) 110°C (230°F) 0.22 to 0.28 kohms NG --> REPLACE ATF TEMPERATURE SENSOR ASSEMBLY OK --> REPLACE TRANSMISSION WIRE
| Related DTCs | P0715: Speed sensor (NT)/Range check P0717: Speed sensor (NT)/Verify pulse input |
|---|
| Required sensors/Components | Speed sensor (NT), Speed sensor (NC) |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| Battery voltage | 8 V or more |
|---|
| Engine switch | ON |
| Starter | OFF |
| The monitor will run whenever this DTC is not present. | P0500 (VSS) P0748, P0778, P0798 (Shift solenoid valve (range)) |
|---|
| Shift change | Shift change is completed before starting next shift change operation |
| TCM selected gear | 2nd, 3rd, 4th, 5th or 6th |
| Output shaft rpm | 1,000 rpm or more |
| R switch | OFF |
| Engine | Running |
| Battery voltage | 8 V or more |
| Engine switch | ON |
| Starter | OFF |
| Transmission range switch circuit | Not malfunction |
| Turbine speed sensor range check | Not malfunction |
| Sensor voltage | Less than 0.1 V or more than 1.9 V |
| Sensor signal rpm | Less than 300 rpm |
| Speed sensor (NT) | Turbine speed is equal to engine speed with lock-up ON |
Scheme 500
Scheme 500: WIRING DIAGRAM
| Related DTCs | P0724: Stop light switch/Range check/Rationality |
|---|
| Required sensors/Components | Stop light switch |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
GO and STOP are defined as follows
| The monitor will run whenever this DTC is not present. | None |
|---|
| GO: (Vehicle speed is 18.63 mph (30 km/h) or more) | 18.7 mph (30 km/h) or more |
| STOP: (Vehicle speed is less than 1.86 mph (3 km/h)) | Less than 1.86 mph (3 km/h) |
| Starter | OFF |
| Battery voltage | 8 V or more |
| Engine switch | ON |
THE STOP LIGHT SWITCH REMAINS ON DURING GO AND STOP 5 TIMES.
Scheme 501
Scheme 501: WIRING DIAGRAM
| Related DTCs | P0741: Shift solenoid valve SL OFF malfunction Shift solenoid valve SL ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SL, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE), Throttle position sensor (VPA1), Mass air flow sensor (MAF), Transmission temperature sensor (THO1), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction 3.5 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P2759 (Shift solenoid valve SLU circuit) P2769, P2770 (Shift solenoid valve SL circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| Shift solenoid valve SLU circuit | No circuit malfunction |
| Shift solenoid valve SL circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| TCM selected gear | Not 1st |
| Vehicle speed | 15.5 mph (25 km/h) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| Following conditions are met | (a) and (b) |
|---|
| (a) Engine Speed - Turbine speed | 70 rpm or more |
| (b) Transmission fluid pressure switch | ON |
| Related DTCs | P0746: Shift solenoid valve SL1 OFF malfunction Shift solenoid valve SL1 ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SL1, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | ON malfunction: 0.8 sec. OFF malfunction: 0.5 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| TCM selected gear | 1st, 2nd, 3rd or 4th |
|---|
| TCM indicated pressure value of SL1 | 1,200 kPa |
| Throttle valve opening angle | 3% or more |
| TCM selected gear | 5th or 6th |
|---|
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Throttle valve opening angle | 4.5% or more at engine speed 2,000 rpm (Varies with engine speed) |
Either of the following conditions is met
- OFF MALFUNCTION: Turbine speed - Output speed x Gear ratio 1,000 rpm or more ON MALFUNCTION: Input (turbine) speed/Intermediate shaft speed when output speed less than 1,000 rpm 0.998 to 1.138
| Related DTCs | P0748: Shift solenoid valve SL1/Range check |
|---|
| Required sensors/Components | Shift solenoid valve SL1 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present | None |
|---|
| Engine switch | ON |
| Starter | OFF |
| Battery voltage | 12 V or more |
| Battery voltage | 10 V or more and less than 12 V |
| Output signal duty | 100% or more |
| Output signal duty | More than 3% and less than 100% |
Scheme 502
Scheme 502: WIRING DIAGRAM
| Related DTCs | P0776: Shift solenoid valve SL2/OFF malfunction Shift solenoid valve SL2/ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SL2, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction 0.5 sec. ON malfunction 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| TCM selected gear | 4th, 5th or 6th |
|---|
| TCM indicated pressure value of SL2 | 1,200 kPa |
| Throttle valve opening angle | 3% or more |
| TCM selected gear | 1st |
|---|
| Vehicle speed | 1.2 mph (2 km/h) to 24.9 mph (40 km/h) |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Engine speed - Turbine speed | 50 rpm or more |
| TCM selected gear | 2nd |
|---|
| Throttle valve opening angle | 4.5% or more at engine speed 2,000 rpm (Varies with engine speed) |
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| TCM selected gear | 3rd |
|---|
| Throttle valve opening angle | 4.5% or more at engine speed 2,000 rpm (Varies with engine speed) |
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Input (turbine) speed-Intermediate shaft speed x Gear ratio | 1,000 rpm or more |
| Input (turbine) speed/Intermediate shaft speed when output speed less than 1,000 rpm | 0.998 to 1.138 |
| Related DTCs | P0778: Shift solenoid valve SL2/Range check |
|---|
| Required sensors/Components | Shift solenoid valve SL2 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present | None |
|---|
| Engine switch | ON |
| Starter | OFF |
| Battery voltage | 12 V or more |
| Battery voltage | 10 V or more and less than 12 V |
| Output signal duty | 100% or more |
| Output signal duty | More than 3% and less than 100% |
Scheme 503
Scheme 503: WIRING DIAGRAM
| Related DTCs | P0791: Speed sensor (NC)/Range check P0793: Speed sensor (NC)/Verify pulse input |
|---|
| Required sensors/Components | Speed sensor (NT), Speed sensor (NC) |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. | P0500 (VSS) P0748, P0778, P0798 (Shift solenoid valve (range)) |
|---|
| Vehicle speed | 15.5 mph (25 km/h) or more |
| Battery voltage | 8 V or more |
| Engine switch | ON |
| Starter | OFF |
| Sensor voltage | Less than 0.1 V or more than 1.9 V |
| Sensor signal rpm | Less than 300 rpm |
Scheme 504
Scheme 504: WIRING DIAGRAM
| Related DTCs | P0796: Shift solenoid valve SL3/OFF malfunction Shift solenoid valve SL3/ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SL3, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (A) and (B) 0.5 sec. OFF malfunction (C) and (D) 0.8 sec. ON malfunction 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| TCM selected gear | 2nd |
|---|
| Throttle valve opening angle | 3% or more |
| TCM indicated pressure value of SL1 | 1,200 kPa |
| TCM indicated pressure value of SL2 | 0 kPa |
| TCM indicated pressure value of SL3 | 1,200 kPa |
| TCM selected gear | 6th |
|---|
| Throttle valve opening angle | 3% or more |
| TCM indicated pressure value of SL1 | 0 kPa |
| TCM indicated pressure value of SL2 | 1,200 kPa |
| TCM indicated pressure value of SL3 | 1,200 kPa |
| TCM selected gear | 2nd |
|---|
| Throttle valve opening angle | |
| (When condition "D" is not detected) | 4.5% or more at engine speed 2,000 rpm (condition varies with engine speed) |
| (When condition "D" is detected) | 0.5% or more at engine speed 750 rpm (condition varies with output speed) |
| ECT (engine coolant temperature) | 40°C (104°F) or more |
| Throttle valve opening angle | 0.5% or more at engine speed 750 rpm (condition varies with output speed) |
| TCM selected gear | 1st |
|---|
| Vehicle speed | 1.2 mph (2 km/h) or more |
| Engine speed - Turbine speed | 50 rpm or more |
| ECT (engine coolant temperature) | 40°C (104°F) or more |
Either of the following conditions is met: OFF malfunction (A) or (B) or ((C) and (D)), or ON malfunctions
- 2 detections are necessary per driving cycle: 1st detection; temporary flag ON 2nd detection; pending fault code ON
| Turbine speed - Output speed x 2nd gear ratio | 1,000 rpm or more |
| Turbine speed - Output speed x 6th gear ratio | 1,000 rpm or more |
| Input (turbine) speed/Intermediate shaft speed | 3.304 to 7.724 |
| Input (turbine) speed/Intermediate shaft speed | 3.304 to 7.724 |
| Input (turbine) speed/Intermediate shaft speed | 1.901 to 2.340 |
| Related DTCs | P0798: Shift solenoid valve SL3/Range check |
|---|
| Required sensors/Components | Shift solenoid valve SL3 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present | None |
|---|
| Engine switch | ON |
| Starter | OFF |
| Battery voltage | 12 V or more |
| Battery voltage | 10 V or more and less than 12 V |
| Output signal duty | 100% or more |
| Output signal duty | More than 3% and less than 100% |
Scheme 505
Scheme 505: WIRING DIAGRAM
| Related DTCs | P0989: Transmission fluid pressure switch No. 3 OFF malfunction P0990: Transmission fluid pressure switch No. 3 ON malfunction |
|---|
| Required sensors/Components | Transmission fluid pressure switch No. 3 |
| Frequency of operation | Continuous |
| Duration | P0989: 1.8 sec. P0990 (a): 1.2 sec. P0990 (b): 0.6 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P2759 (Shift solenoid valve SLU circuit) P2769, P2770 (Shift solenoid valve SL circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| Shift solenoid valve SLU circuit | No circuit malfunction |
| Shift solenoid valve SL circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| TCM selected gear | Not 1st |
| Vehicle speed | 15.5 mph (25 km/h) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| TCM lock-up command | ON |
|---|
| Engine speed - Turbine speed | Less than 35 rpm |
| Throttle valve opening angle | 7% or more |
| Vehicle speed | Less than 62 mph (100 km/h) |
| Shift solenoid valve SLU | Not ON malfunction |
| TCM indicated pressure valve of SLU | Less than 4 kPa |
|---|
| TCM lock-up command | OFF |
| Shift solenoid valve SLU | Not malfunction |
| Shift solenoid valve SL | Not OFF malfunction |
| Transmission fluid pressure switch No. 3 | OFF |
| Following conditions are met | (a) and (b) |
|---|
| (a) Engine speed - Turbine speed | 35 rpm or more |
| (b) Transmission fluid pressure switch No. 3 | ON |
Scheme 506
Scheme 506: WIRING DIAGRAM
| Related DTCs | P2714: Shift solenoid valve SLT/ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 2 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P2716 (Shift solenoid valve SLT circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| Shift solenoid valve SLT circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| Input turbine torque | 100 N*m or more |
| Turbine speed | 250 rpm or more |
| Output speed | 250 rpm or more |
| Detection criteria | Threshold |
|---|
| Turbine speed - Output speed x Gear ratio at output speed 1,000 rpm (Condition varies with output speed) | 75 rpm or more |
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present | None |
|---|
| Solenoid current cut status | Not cut |
| Engine switch | ON |
| Starter | OFF |
| Battery voltage | 12 V or more |
|---|
| Target current | 1 A |
| Battery voltage | 10 V or more and less than 12 V |
|---|
| Target current | 0.75 A |
| Battery voltage | 8 V or more |
|---|
| Target current | 1 A |
| Battery voltage | 11 V or more |
|---|
| Target current | 1 A or more |
| Battery voltage | 11 V or more |
|---|
| Target current | 0.1 A or more |
| Commanded voltage - Last commanded voltage | Less than 0.000019 V |
| Output signal duty | 100% or more |
| Output signal duty | 0% or less |
| Output signal monitor | No signal |
| Commanded voltage - Last commanded voltage | 0.035 V or more |
| Output signal duty | Less than 100% |
Scheme 507
Scheme 507: WIRING DIAGRAM
| Related DTCs | P2757: Shift solenoid valve SLU OFF malfunction Shift solenoid valve SLU ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SLU |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (a): 3.5 sec. OFF malfunction (b): 0.05 sec. ON malfunction (a): 1.8 sec. ON malfunction (b): 0.6 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P2759 (Shift solenoid valve SLU circuit) P2769, P2770 (Shift solenoid valve SL circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Spark advance from Max. retard timing by KCS control | 0°CA or more |
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| Shift solenoid valve SLU circuit | No circuit malfunction |
| Shift solenoid valve SL circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| TCM selected gear | Not 1st |
| Vehicle speed | 15.5 mph (25 km/h) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.
| TCM lock-up command | ON |
|---|
| Duration time from lock-up on command | 3 sec. or more |
| Shift solenoid valve SLU | Not ON malfunction |
| TCM lock-up command | OFF (SLU pressure: less than 4 kPa (0.04 kgf cm 2 , 0.6 psi) |
|---|
| Duration time from lock-up on command | 0.064 sec. or more |
| Throttle valve opening angle | 7% or more |
| Vehicle speed | Less than 37.3 mph (60 km/h) |
| Shift solenoid valve SLU | Not malfunction |
| Shift solenoid valve SL | Not OFF malfunction |
| Following conditions are met | (a) and (b) |
|---|
| (a) Engine speed - Turbine speed | 70 rpm or more |
| (b) Transmission fluid pressure switch | OFF |
| Following conditions are met | (a) and (b) |
|---|
| (a) Engine speed - Turbine speed | Less than 35 rpm |
| (b) Transmission fluid pressure switch | ON |
| Speed sensor (NT) | Input speed is equal to engine speed when lock-up is ON. |
| Related DTCs | P2759: Shift solenoid valve SLU/Range check |
|---|
| Required sensors/Components | Shift solenoid valve SLU |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present | None |
|---|
| Engine switch | ON |
| Starter | OFF |
| Battery voltage | 12 V or more |
| Battery voltage | 10 V or more and less than 12 V |
| Output signal duty | 100% or more |
| Output signal duty | More than 3% and less than 100% |
Scheme 508
Scheme 508: WIRING DIAGRAM
| Related DTCs | P2769: Shift solenoid valve SL/Range check (Low resistance) P2770: Shift solenoid valve SL/Range check (High resistance) |
|---|
| Required sensors/Components | Shift solenoid valve SL |
| Frequency of operation | Continuous |
| Duration | 1 time |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever the following DTCs are not present | None |
|---|
| Solenoid | ON |
| Time after solenoid OFF to ON | More than 0.008 sec. |
P2769: RANGE CHECK (LOW RESISTANCE)
| The monitor will run whenever the following DTCs are not present | None |
|---|
| Solenoid | ON |
| Time after solenoid ON to OFF | More than 0.008 sec. |
P2770: RANGE CHECK (HIGH RESISTANCE)
| Intelligent power MOS diagnosis fail signals detected while the solenoid is operated | Fail at solenoid resistance: 8 ohms or less |
P2769: RANGE CHECK (LOW RESISTANCE)
| Intelligent power MOS diagnosis fail signals detected while the solenoid is not operated | Fail at solenoid resistance: 100 kohms or more |
P2770: RANGE CHECK (HIGH RESISTANCE)
| Shift solenoid valve SL | Resistance: 11 to 15 ohms at 20°C (68°F) |
Scheme 509
Scheme 509: WIRING DIAGRAM
| Related DTCs | P2808: Shift solenoid valve SL4/OFF malfunction Shift solenoid valve SL4/ON malfunction |
|---|
| Required sensors/Components | Shift solenoid valve SL4, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction (A): 0.5 sec. OFF malfunction (B): 0.8 sec. ON malfunction: 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. (Not circuit malfunction) | P0712, P0713 (ATF temperature sensor circuit (TFT sensor)) P0115, P0117, P0118 (ECT sensor circuit) P0715, P0717 (Turbine speed sensor circuit) P0791, P0793 (Intermediate shaft speed sensor circuit) P0748 (Shift solenoid valve SL1 circuit) P0778 (Shift solenoid valve SL2 circuit) P0798 (Shift solenoid valve SL3 circuit) P2810 (Shift solenoid valve SL4 circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060B, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135 ((ETCS) Electronic throttle control system) U0100 (CAN communication system) |
|---|
| Transmission range | "D" |
| TFT (Transmission fluid temperature) | 10°C (14°F) or more |
| TFT (Transmission fluid temperature) sensor circuit | No circuit malfunction |
| ECT (Engine coolant temperature) sensor circuit | No circuit malfunction |
| Turbine speed sensor circuit | No circuit malfunction |
| Intermediate shaft speed sensor circuit | No circuit malfunction |
| Shift solenoid valve SL1 circuit | No circuit malfunction |
| Shift solenoid valve SL2 circuit | No circuit malfunction |
| Shift solenoid valve SL3 circuit | No circuit malfunction |
| Shift solenoid valve SL4 circuit | No circuit malfunction |
| (KCS) Knock control sensor circuit | No circuit malfunction |
| (ETCS) Electronic throttle control system | Not system down |
| CAN communication system | Not system down |
| Engine | Starting |
| TCM select gear | 3rd or 5th |
|---|
| Throttle valve opening angle | 3% or more |
| TCM select gear | 3rd |
|---|
| Throttle valve opening angle | 4.5% or more |
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| TCM select gear | 1st |
|---|
| Time after transmission to 1st gear | 0.1 sec. or more |
| Vehicle speed | 1.2 mph (2 km/h) to 24.9 mph (40 km/h) |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| TCM select gear | 2nd |
|---|
| Throttle valve opening angle | 4.5% or more at engine speed 2,000 rpm (condition varies with engine speed) |
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| TCM select gear | 6th |
|---|
| Throttle valve opening angle | 4.5% or more at engine speed 2,000 rpm (condition varies with engine speed) |
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| TCM select gear | 4th |
|---|
| Throttle valve opening angle | 4.5% or more at engine speed 2,000 rpm (condition vary with engine speed) |
| Vehicle speed | 1.2 mph (2 km/h) or more |
| ECT (Engine coolant temperature) | 40°C (104°F) or more |
| Turbine speed/Output speed (NT/NO) with 1st | 3.304 to 7.724 |
| Turbine speed/Output speed (NT/NO) with 2nd | 1.901 to 2.340 |
| Turbine speed/Output speed (NT/NO) with 3rd | 1.399 to 1.649 |
| Turbine speed/Output speed (NT/NO) with 4th | 0.998 to 1.138 |
| Turbine speed/Output speed (NT/NO) with 5th | 0.705 to 0.836 |
| Turbine speed/Output speed (NT/NO) with 6th | 0.568 to 0.695 |
| Turbine speed - Output speed x Gear ratio | 1,000 rpm or more |
| Turbine speed / Output speed | 3.304 to 7.724 |
| Turbine speed / Output speed | 1.399 to 1.649 |
ON MALFUNCTION (A) AND (B)
| Turbine speed / Output speed | 0.705 to 0.836 |
| Turbine speed / Output speed | 0.998 to 1.138 |
| Related DTCs | P2810: Shift solenoid valve SL4/Range check |
|---|
| Required sensors/Components | Shift solenoid valve SL4 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present | None |
|---|
| Engine switch | ON |
| Starter | OFF |
| Battery voltage | 12 V or more |
| Battery voltage | 10 V or more and less than 12 V |
| Output signal duty | 100% or more |
| Output signal duty | More than 3% and less than 100% |
Scheme 510
Scheme 510: WIRING DIAGRAM
| Related DTCs | U0100: Verify communication |
|---|
| Required Sensors/Components (Main) | TCM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1.25 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
|---|
| Battery Voltage | 10.5 V or more |
| Engine Switch | ON |
| Starter | OFF |
| Communication between TCM and ECM | No communication |
Scheme 511
Scheme 511: WIRING DIAGRAM
