SYSTEM CONTROLS
A/C-heater control assembly consists of a liquid crystal display, a temperature control knob, and various buttons which activate A/C-heater system, set desired temperature, direct discharged air to appropriate outlets, activate rear defogger, control fan speed and check ambient air temperature. (Scheme 4)
Scheme 4
HEATER WATER CONTROL VALVE
Disconnect heater water control valve cable, located in heater inlet line near firewall. Turn ignition on. Press A/C button. Set temperature control knob to maximum cool position (counterclockwise). Set heater water control valve to cool position. Install control cable, and secure with clamp. (Scheme 5)
Scheme 5
AIR CONDITIONING FILTER
Note. This filter is may also be called a cabin air filter. For air conditioning filter location (Scheme 6)
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
- Open the glove box. Remove the screw with a Phillips-head screwdriver. (Scheme 7)
- Remove the 2 pins installed on the upper part of the glove box and lower the glove box. (Scheme 8)
- Take out the filter case. (Scheme 9)
- Remove the filter from the filter case. (Scheme 10)
- Inspect the filter on the surface.
- To install, reverse the removal procedures.
HEATER CORE
| CAUTION | When removing heater core use care not to spill engine coolant inside vehicle. |
Scheme 11
- Drain coolant from radiator. Remove dashboard lower finish panel, safety pad, and driver's side air duct. Release 3 claws and remove heater protector cover. Remove screws, clips and clamps at heater core connections. (Scheme 11) Disconnect heater core connections. Remove "O" rings and discard. Remove heater core.
- To install, reverse removal procedure. Use new heater core connection "O" rings. Refill cooling system. Start and warm engine to operating temperature. Inspect system for leaks.
