SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Tension |
| New | 139-191 lbs. (63-87 kg) |
| Used | 66-110 lbs. (30-50 kg) |
| Compressor Oil Capacity | (1) 4.1 ozs. |
| Refrigerant (R-134a) Capacity | 17.6-21.1 ozs. |
| System Operating Pressures (2) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Use Denso/ND-OIL 8 refrigerant oil. (2) At 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Use Denso/ND-OIL 8 refrigerant oil. |
| (2) | At 86-95°F (30-35°C) and engine speed at 1500 RPM. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor-To-Bracket Bolts | 18 (25) |
| A/C Compressor Bracket-To-Engine Bolts | 18 (25) |
| Alternator Pivot Bolt | 43 (58) |
| Drive Belt Adjusting Bar Bracket Nut | 18 (25) |
| Drive Belt Adjusting Bar Bracket-To-Adjusting Bar | 13 (18) |
| Drive Belt Adjusting Lock Bolt | 13 (18) |
| INCH Lbs. (N.m) |
| Compressor Hoses | 89 (10) |
| Condenser Lines | 48 (5.4) |
| Evaporator Lines | 30 (3.5) |
| Expansion Valve Bolts | 48 (5.4) |
Automatic A/C-Heater System Wiring Diagram (2000-01 ES 300 - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2000-01 ES 300 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000-01 ES 300 - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000-01 ES 300 - 2 Of 2)
