Engine Mechanical: Diagnosis Lexus ES XV30

TROUBLE SHOOTING

To trouble shoot mechanical engine components, see ENGINE MECHANICAL article under BASIC TROUBLESHOOTING in GENERAL INFORMATION.

Inspection

1. Inspect cylinder head warpage at cylinder block and manifold areas. Replace cylinder head if warpage exceeds specification. See «WARPAGE SPECIFICATIONS»(ref-159137-S26305206542003111300000) table.
2. Inspect air intake chamber-to-intake manifold surface and exhaust manifold for warpage. Inspect intake manifold-to-cylinder head and air intake chamber surfaces for warpage. Replace components if warpage exceeds specification. See «WARPAGE SPECIFICATIONS»(ref-159137-S26305206542003111300000) table. WARPAGE SPECIFICATIONS Application In. (mm) Cylinder Block 0.002 (0.05) Cylinder Head Cylinder Block Side 0.002 (0.05) Exhaust Manifold Side .0039 (0.10) Intake Manifold Side .0039 (0.10)
3. Using caliper, measure 12-point cylinder head bolt diameter, just below bolt head. Replace cylinder head bolt if diameter is less than .3445 in. (8.750 mm).
4. Inspect cylinder block deck surface for warpage. Replace cylinder block if deck surface warpage exceeds specification. See «CYLINDER BLOCK»(ref-159137-S12609165022003111300000) table under ENGINE SPECIFICATIONS. Inspect camshaft and components. See «CAMSHAFT»(ref-159137-S20806121372003111300000) .
5. Inspect valve lifter for damage. Measure valve lifter diameter and bore diameter. Ensure oil clearance is within specification. Replace components if not within specification. See «VALVE LIFTERS»(ref-159137-S40273616772003111300000) table under ENGINE SPECIFICATIONS.

Scheme 3

Scheme 4

Inspect components for damage. Measure valve lifter diameter and bore diameter. Ensure oil clearance is within specification. Replace components if not within specification. See VALVE LIFTERS table under ENGINE SPECIFICATIONS.

1. Inspect components for damage. Check camshaft journal diameter, lobe height and journal runout. Replace camshaft if not within specification. See «CAMSHAFT»(ref-159137-S28038154422003111300000) table under ENGINE SPECIFICATIONS.
2. Install camshaft in cylinder head. Using Plastigage, check camshaft oil clearance. Tighten camshaft bearing cap bolts to specification in sequence when checking oil clearance. DO NOT rotate camshaft. See «TORQUE SPECIFICATIONS»(ref-159137-S23585106052003111300000).
3. Remove bearing caps and measure Plastigage. Replace camshaft and/or cylinder head if oil clearance is not within specification. See «CAMSHAFT»(ref-159137-S28038154422003111300000) table under ENGINE SPECIFICATIONS.
4. Check camshaft end play with camshaft bearing cap bolts tightened to specification. Replace camshaft and/or cylinder head if end play is not within specification. See «CAMSHAFT»(ref-159137-S28038154422003111300000) table under ENGINE SPECIFICATIONS.
5. Mount hexagon wrench head portion of intake camshaft in a soft jawed vise. Ensure VVT-i will not turn. Cover the port opposite of advance angle port with vinyl tape. Apply air at approximately 14 psi (1 kgf/cm 2 ) to port on advance side and ensure VVT-i turns. see scheme 25 While applying air pressure to VVT-i advance angle port, turn VVT-i by hand in direction of arrow in see scheme 25. Allow VVT-i to turn back and forth and ensure there is about 30 degrees of smooth movable range. Turn VVT-i with your hand and lock it at maximum delay angle position (opposite of direction of arrow in see scheme 25 ).
6. Install both camshafts without sub-gear installed on exhaust camshaft. Tighten camshaft bearing cap bolts to specification. Check gear backlash between camshaft gears.
7. Replace camshaft if gear backlash exceeds specification. See «CAMSHAFT»(ref-159137-S28038154422003111300000) table under ENGINE SPECIFICATIONS. Measure distance between ends of gear spring. Replace gear spring if distance between ends of gear spring is not.712-.740 in. (18.08-18.80 mm).

1. Inspect components for damage. Coat relief valve with engine oil. Ensure relief valve slides freely in bore on oil pump body. Install drive and driven rotors in oil pump body. Ensure both rotors are installed in oil pump body with identification mark (triangle mark) facing oil pump body cover.
2. Using feeler gauge, measure driven rotor-to-oil pump body clearance. Replace rotor assembly or oil pump body if clearance exceeds specification. See «OIL PUMP SPECIFICATIONS»(ref-159137-S12186545752003111300000) table.
3. Using feeler gauge, measure clearance between tip of both rotors. Replace rotor assembly if clearance exceeds specification. See «OIL PUMP SPECIFICATIONS»(ref-159137-S12186545752003111300000) table.
4. Place straightedge across oil pump body, above both rotors. Using feeler gauge, measure rotor end clearance between straightedge and rotor surface. Replace rotor assembly or oil pump body if clearance exceeds specification. See «OIL PUMP SPECIFICATIONS»(ref-159137-S12186545752003111300000) table.

OIL PUMP SPECIFICATIONS
