Engine Emission Control (4.4L): Removal & Installation Land Rover Range Rover III facelift

INSTALLATION

1. To install, reverse the removal procedure. Clean the components. Lubricate the seal with clean engine oil. Tighten the bolts to 10 Nm (7 lb.ft).

Scheme 58

1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-522601) .
2. Remove the engine cover. Refer to «ENGINE COVER - 4.4L»(ref-522605-S29289372042013011500000) .
3. Disconnect the EGR valve electrical connector.
4. Release the clips and disconnect the coolant hoses from the EGR valve cooler. Position an absorbent cloth to collect fluid spillage. Clamp the EGR coolant hoses to minimize coolant loss.
5. Remove the EGR valve. Remove the 2 bolts from the EGR cooler valve body.

1. Install the EGR valve. Clean the component mating faces. Tighten the bolts to 10 Nm (7 lb.ft).
2. Connect the coolant hoses. Secure the clips. Remove the hose clamps.
3. Connect the EGR valve electrical connector.
4. Install the engine cover. Refer to «ENGINE COVER - 4.4L»(ref-522605-S29289372042013011500000) .
5. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-522601) .
6. Check and top-up the coolant.
