Electronic Engine Controls (4.4L): Specifications Land Rover Range Rover III facelift

Engine Control Systems 2 illustrations

SPECIFICATIONS

ItemLand Rover Part No.
* HO2s removalSTC 50545
HO2s threadsApply suitable high temperature anti-seize compound to threads of sensor

LUBRICANTS

* Apply to area around sensor threads prior to attempting to remove sensor

ItemDescription
Engine management system
MakeDenso
TypePAG EMS - Generation 1

ENGINE MANAGEMENT SYSTEM

DescriptionNm
+ Heated oxygen sensor (HO2S)45
* RH catalytic converter to exhaust manifold bolts22
* LH catalytic converter to exhaust manifold bolts22
LH catalyst monitor sensor45
Mass Air Flow (MAF) sensor Torx screws2
Camshaft position (CMP) sensor bolt7
Throttle body bolts10
Crankshaft position (CKP) sensor Torx screw8
Knock sensor (KS) bolt20
Engine oil pressure sensor13
Engine oil temperature sensor20
Variable Camshaft Timing (VCT) oil control solenoid bolt10
Fuel temperature sensor7

TORQUE SPECIFICATIONS

+ Apply anti-seize lubricant to threads of sensor - See Lubricants

* New bolts must be installed

Scheme 29

Scheme 29: COMPONENT LOCATION (SHEET 1 OF 2)
Item NumberDescription
1Positive crankcase ventilation (PCV) valve
2Fuel rail temperature sensor
3Injectors
4Knock sensors
5Heated Exhaust Gas Oxygen (HEGO) sensor
6Universal Heated Exhaust Gas Oxygen (UHEGO) sensor
7Universal Heated Exhaust Gas Oxygen (UHEGO) sensor
8Heated Exhaust Gas Oxygen (HEGO) sensor
9Crankshaft position (CKP)
10Mass air flow (MAF)
11Spark plugs
12Ignition coils
13Electric throttle
14Camshaft position (CMP)
15Exhaust gas recirculation (EGR) valve
16Variable Valve Timing (VVT) oil control solenoid

Scheme 30

Scheme 30: COMPONENT LOCATION (SHEET 2 OF 2)
Item NumberDescription
1Generic electronic module (GEM)
2DMTL Module
3Brake light switch
4Accelerator pedal position (APP)
5Transmission control module (TCM)
6Anti-lock brake system (ABS) control module
7E-box
8Engine control module (ECM)
