Intermediate Reduction Drive (IRD)

1. Remove underbelly panel. See «UNDERBELLY PANEL»(ref-169160-S22536658112004120100000) under REMOVAL & INSTALLATION. Place container under IRD unit. Clean area around filler/level and drain plugs.
2. Using wrench LRT-41-021, remove filler plug and discard sealing washer. (Scheme 9) Remove drain plug, discard sealing washer and allow oil to drain. Install NEW sealing washer and tighten drain plug to 35 Nm (26 lbf.ft).
3. Fill with fluid until it just runs from filler/level hole. Allow sufficient time for fluid to flow and reach a common level in unit. Install NEW sealing washer and tighten filler/level plug to 35 Nm (26 lbf.ft). Install underbelly panel. See «UNDERBELLY PANEL»(ref-169160-S22536658112004120100000) under REMOVAL & INSTALLATION.

Scheme 9

JATCO Transmission

Check JATCO transmission fluid level every 12 months or 12,000 miles, whichever comes first. Change JATCO transmission fluid every 60 months or 60,000 miles, whichever comes first.

Check Intermediate Reduction Drive (IRD) fluid level every 12 months or 12,000 miles, whichever comes first. There is no specified fluid replacement interval required unless a leak is present.

INHIBITOR SWITCH

1. Set gear selector lever to Neutral position. Loosen 2 bolts securing inhibitor switch to gearbox casing. (Scheme 10)
2. Fit alignment tool LRT-44-018 to selector lever on gearbox, rotate inhibitor switch sufficient to insert tool alignment pin through tool lever into inhibitor switch. (Scheme 10)
3. Tighten inhibitor switch bolts to 3 Nm (2.2 lbf.ft). Remove alignment tool LRT-44-018.
4. Check that the engine will start in Park and Neutral positions and is inhibited when drive positions are selected.

Scheme 10

KICKDOWN CABLE

Freelander JATCO transmission kickdown is electronically controlled. No adjustments are required.

AUTOMATIC TRANSMISSION FILTER

Note. JATCO transmission has a non-servicable oil strainer and no oil filter.
