COMPONENT LOCATIONS

(Scheme 11)

Scheme 11

1. Raise front of vehicle.
2. Remove front console. See «CONSOLE (FRONT)»(ref-169938-S04397335742004122000000).
3. Release inner cable from selector lever. (Scheme 12)
4. Remove "C" clip securing outer cable to selector housing.
5. If fitted, release mirror fold ECU and place aside.
6. Disconnect shift interlock solenoid connector. (Scheme 13)
7. Disconnect multiplug from sport/manual switch.
8. If fitted, remove bolt and disconnect cable from key interlock mechanism.
9. Remove 6 nuts securing selector housing. (Scheme 14)
10. Remove selector housing.
11. Remove screw and remove mirror fold ECU housing.

Scheme 12

Scheme 13

Scheme 14

1. Position mirror fold ECU housing and secure with screw.
2. Fit selector housing, fit nuts and tighten to 10 Nm (7.5 ft. lbs.).
3. Connect key interlock mechanism inner cable. Locate outer cable, fit clamp and clamp bolt but do not tighten clamp bolt at this stage.
4. Connect multiplug to sport/manual switch.
5. Connect shift interlock solenoid connector.
6. Secure inner cable to selector lever.
7. Secure outer cable to selector housing with "C" clip.
8. Check key interlock cable adjustment. See «ADJUSTMENT»(ref-171730-S36976078392005021000000) .
9. Fit front console.
10. Remove stand(s) and lower vehicle.

Pull gear knob upwards to disengage locating tang from gear selector lever. (Scheme 15)

Scheme 15

1. Position gear knob to gear selector lever engaging locating tang on knob with slot in selector lever.
2. Push gear knob fully on to gear selector lever. CAUTION: Selector lever must be in 'Park' before fitting knob, failure to comply may result in damage to selector assembly.

1. Remove front console. See «CONSOLE (FRONT)»(ref-169938-S04397335742004122000000).
2. Release inner cable from selector lever. (Scheme 12)
3. Remove "C" clip securing outer cable to selector housing.
4. Raise front of vehicle. WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
5. Remove underbelly panel. See «PANEL (UNDERBELLY)»(ref-169938-S29833892222004122700000).
6. Remove cable tie and release gear selector cable from clip on body.
7. Loosen selector cable trunnion nut. (Scheme 16)
8. Release clip securing selector cable to gearbox bracket, remove selector cable and collect trunnion from selector lever.

Scheme 16

1. Position trunnion to selector lever, locate inner cable through trunnion, do not tighten nut at this stage.
2. Position selector cable to gearbox bracket and secure with clip.
3. Locate cable in selector housing and secure outer cable in clip.
4. Secure outer cable to selector housing with "C" clip
5. Secure inner cable to selector lever.
6. Fit front console.
7. Check and adjust selector cable. See «SELECTOR CABLE»(ref-169109-S33819310462004112900000) .
8. Fit underbelly panel.
9. Remove stands and lower vehicle.

1. Release selector indicator from selector lever trim panel. (Scheme 17)
2. Disconnect multiplug from selector indicator and remove indicator. (Scheme 18)

Scheme 17

Scheme 18

1. Connect multiplug to selector indicator.
2. Position selector indicator to selector lever trim panel.

1. Position gear selector lever in "Neutral" and remove gear selector knob.
2. Working from forward edge, carefully release spring clip securing gear selector indicator assembly to center console. Release 2 additional clips at the sides and slide assembly forward. See «GEAR KNOB»(ref-169938-S03194123472004122700000). (Scheme 19).
3. Disconnect multiplug from hill descent switch. (Scheme 20)
4. Disconnect multiplug from gear selector indicator module.
5. Remove gear selector indicator assembly.

Scheme 19

Scheme 20

1. Position gear selector indicator assembly to center console.
2. Connect 2 multiplugs.
3. Ensure Light Emitting Diode (LED) display module is located on pegs.
4. Fit and secure gear selector indicator assembly to center console.
5. Fit gear selector knob.

1. Release inhibitor switch harness multiplug from clip on fluid pan and disconnect multiplug. (Scheme 21)
2. Set selector lever to "N" position.
3. Remove 2 bolts securing inhibitor switch to gearbox and remove inhibitor switch.

Scheme 21

1. Clean inhibitor switch and mating face on gearbox.
2. Align the internal lugs with the mark on the inhibitor switch.
3. Position inhibitor switch, aligning the 2 lugs with the machined grooves in the selector lever shaft.
4. Fit bolts securing inhibitor switch but do not tighten at this stage.
5. Connect inhibitor switch multiplug and secure to mounting bracket with clip.
6. Adjust inhibitor switch. See «INHIBITOR SWITCH»(ref-169160-S16828389742004120100000) .
