Servicing - Automatic Transaxle: Adjustments Land Rover Freelander I рестайлинг

Adjust

1. Remove underbelly panel. See «UNDERBELLY PANEL»(ref-169160-S22536658112004120100000) under REMOVAL & INSTALLATION.
2. Loosen trunnion nut securing inner cable to selector lever. (Scheme 1) Move gear change lever into Park position. Move selector lever on gearbox fully clockwise to engage Park position.
3. Pull inner cable as far forward as possible, then release. This will remove any backlash from the cable. Tighten trunnion nut to 6 Nm (4 lbf.ft).
4. Fit underbelly panel. See «UNDERBELLY PANEL»(ref-169160-S22536658112004120100000) under REMOVAL & INSTALLATION.
5. Move selector lever through its working arc from Park to "2" position and back to Park. Check that all gear positions are correctly selected.
6. Check that the engine will start in Park and Neutral positions and is inhibited when drive positions are selected.

Scheme 1

1. Remove engine acoustic cover. Before adjusting cable, ensure that cable is correctly routed and located. (Scheme 2)
2. Release cable adjusting nut from abutment bracket. (Scheme 3) Hold throttle cam in fully closed position.
3. Rotate adjusting nut until all slack is taken out of inner cable and nut is in contact with rear face of abutment bracket. Ensure throttle does not open. (Scheme 4)
4. Fit throttle cable adjusting nut in abutment bracket. Operate throttle pedal and ensure that full throttle pedal movement is available. Fit engine acoustic cover.
