Removal
- Raise front of vehicle. Remove 2 screws securing bumper valance to underbelly panel brackets. (Scheme 5) Remove 4 screws securing wheel arch liners to bumper valance, if fitted.
- Remove 2 bolts securing rear of underbelly panel. Remove 6 bolts securing underbelly panel frame. Remove underbelly panel.
Scheme 5
Installation
- Position underbelly panel. Fit bolts securing underbelly panel frame and tighten to 45 Nm (33 lbf.ft).
- Fit bolts securing rear of underbelly panel and tighten to 8 Nm (6 lbf.ft). Fit and tighten screws securing wheel arch liners to bumper valance, if fitted.
- Fit and tighten screws securing bumper valance to brackets. Remove stands and lower vehicle.
