ECM Problem Inspection Procedure

  1. TEST ECM GROUND CIRCUIT: Measure resistance between ECM and chassis ground using the backside of ECM harness connector as ECM side check point. If the problem is found, repair it. Specification: Below 1ohms
  2. TEST ECM CONNECTOR: Disconnect the ECM connector and visually check the ground terminals on ECM side and harness side for bent pins or poor contact pressure. If the problem is found, repair it.
  3. If problem is not found in Step 1 and 2 , the ECM could be faulty. If so, make sure there were no DTC's before swapping the ECM with a new one, and then check the vehicle again. If DTC's were found, examine this first before swapping ECM.
  4. RE-TEST THE ORIGINAL ECM: Install the original ECM (may be broken) into a known-good vehicle and check the vehicle. If the problem occurs again, replace the original ECM with a new one. If problem does not occur, this is intermittent problem (Refer to " «INTERMITTENT PROBLEM INSPECTION PROCEDURE»(ref-537296-S03186921152013032200000) " in Basic Inspection Procedure).

Inspection

  1. Connect the GDS on the Data Link Connector (DLC).
  2. Measure the output voltage of the MAPS at idle and IG ON.
ConditionOutput Voltage (V)
IG ON3.9 ~ 4.1
Idle0.8 ~ 1.6

Scheme 215

Scheme 215: Removal
Scheme 215: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the manifold absolute pressure sensor connector (A).
  3. Remove the installation bolt (B), and then remove the sensor from the intake manifold.
  1. Turn the ignition switch OFF.
  2. Disconnect the IATS connector.
  3. Measure resistance between the IATS terminals 3 and 4.
  4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S08866204022013032200000) "
  1. Turn the ignition switch OFF.
  2. Disconnect the ECTS connector.
  3. Remove the ECTS.
  4. After immersing the thermistor of the sensor into engine coolant, measure resistance between the ECTS terminals 1 and 3.
  5. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S15851124402013032200000) "

Scheme 216

Scheme 216: Removal
Scheme 216: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the engine coolant temperature sensor connector (A).
  3. Remove the sensor (B). CAUTION: Note that engine coolant may be flowed out from the water temperature control assembly when removing the sensor.
  4. Supplement the engine coolant (Refer to «REFILLING AND BLEEDING»(ref-537288-S05060284722013032200000) .
  1. Check signal waveform of CKPS and CMPS using a scan tool. Specification: Refer to " «WAVEFORM»(ref-537296-S42904232262013032200000) "

Scheme 217

Scheme 217: Removal
Scheme 217: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the crankshaft position sensor connector (A) and remove the sensor after removing the installation bolt (B).
  1. Check the signal waveform of the CMPS and CKPS using the GDS. Specification: Refer to " «WAVE FORM»(ref-537296-S10618458252013032200000) "
  1. Turn the ignition switch OFF.
  2. Disconnect the HO2S connector.
  3. Measure resistance between the HO2S terminals 2 and 5 [B1/S1]. Measure resistance between the HO2S terminals 3 and 4 [B1/S2].
  4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S05599620032013032200000) "

Scheme 218

Scheme 218: (Bank 1 / Sensor 1)
Scheme 218: (Bank 1 / Sensor 1)

Scheme 219

Scheme 219
Scheme 219
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the connector (A), and then remove the sensor (B). NOTE: Note that the SST (Part No.: 09392-2H100) is useful when removing the heated oxygen sensor.

Scheme 220

Scheme 220: (Bank 1 / Sensor 2)
Scheme 220: (Bank 1 / Sensor 2)

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the console side cover [LH] (A).
  3. Disconnect the connector (A), and then remove the sensor (B). NOTE: Note that the SST (Part No.: 09392-2H100) is useful when removing the heated oxygen sensor.
  1. Connect the GDS on the Data Link Connector (DLC).
  2. Turn the ignition switch ON.
  3. Measure the output voltage of the APS 1 and 2 at C.T and W.O.T. Specification: Refer to " «SPECIFICATION»(ref-537296-S10853677072013032200000) "

Scheme 223

Scheme 223: Removal
Scheme 223: Removal
  1. Turn the ignition switch OFF and disconnect the negative (-) battery cable.
  2. Disconnect the accelerator position sensor connector (A).
  3. Remove the installation nuts (B), and then remove the accelerator pedal module.
  1. Connect the GDS on the Data Link Connector (DLC).
  2. Measure the output voltage of the FTPS. Specification: Refer to " «SPECIFICATION»(ref-537296-S11539200012013032200000) "

Scheme 224

Scheme 224: Removal
Scheme 224: Removal

Scheme 225

Scheme 225
Scheme 225
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the rear seat (Refer to " «REAR SEAT»(ref-537223-S26496345532013032200000) " in BD group).
  3. Remove the fuel pump service cover (A).
  4. Disconnect the fuel tank pressure sensor connector (A).
  5. Remove the fuel tank pressure sensor (B) after releasing the hooks vertically.
  1. Turn the ignition switch OFF.
  2. Disconnect the injector connector.
  3. Measure resistance between the injector terminals 1 and 2.
  4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S01860113552013032200000) "

Scheme 226

Scheme 226: Removal
Scheme 226: Removal

Scheme 227

Scheme 227
Scheme 227
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Release the residual pressure in fuel line (Refer to the " «RELEASE RESIDUAL PRESSURE IN FUEL LINE»(ref-537222-S28516556792013032200000) "). CAUTION: When removing the fuel pump relay, a Diagnostic Trouble Code (DTC) may occur. Delete the code with the GDS after completion of "Release Residual Pressure in Fuel Line" work.
  3. Disconnect the injector connector (A).
  4. Disconnect the fuel feed tube quick-connector (B).
  5. Remove the installation bolt (C), and then remove the delivery pipe & injector assembly from the engine.
  6. Remove the fixing clip (A), and then separate the injector from the delivery pipe.
  1. Turn the ignition switch OFF.
  2. Disconnect the PCSV connector.
  3. Measure resistance between the PCSV terminals 1 and 2.
  4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S17624264212013032200000) "

Scheme 228

Scheme 228: Removal
Scheme 228: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the purge control solenoid valve connector (A).
  3. Disconnect the vapor hoses (B) from the purge control solenoid valve.
  4. Remove the valve (C) from the surge tank after pulling it.
  1. Turn the ignition switch OFF.
  2. Disconnect the OCV connector.
  3. Measure resistance between the OCV terminals 1 and 2.
  4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S27070614102013032200000) "
  1. Turn the ignition switch OFF.
  2. Disconnect the VIS valve connector.
  3. Measure resistance between VIS valve terminals 1 and 2. Specification: Refer to " «SPECIFICATION»(ref-537296-S08094973002013032200000) "

Scheme 229

Scheme 229: Removal
Scheme 229: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the variable intake solenoid valve connector (A).
  3. Disconnect the vacuum hoses (B) from the valve.
  4. Remove the installation nut, and then remove the valve from the intake manifold.
  1. Turn the ignition switch OFF.
  2. Disconnect the CCV connector.
  3. Measure resistance between the CCV terminal 1 and 2.
  4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S07217680812013032200000) "
  5. Disconnect the vapor hose connected with the canister from the CCV.
  6. Connect a vacuum pump to the nipple.
  7. Ground the CCV control line and apply battery voltage to the CCV power supply line.
  8. Apply vacuum and check the valve operation. Specification: Vacuum maintained

Scheme 230

Scheme 230: Removal
Scheme 230: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Lift the vehicle.
  3. Disconnect the canister close valve connector.
  4. Disconnect the ventilation hose (A) from the fuel tank air filter and canister close valve.
  5. Remove the installation bolts (B), and then remove the canister close valve.
  1. Turn ignition switch OFF.
  2. Disconnect the VCMA connector.
  3. Check that the VCMA is not stuck by foreign material.
  4. Measure resistance between motor (+) and (-) control terminals of the motor.
  5. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S07217680812013032200000) "
  6. Measure resistance between voltage supply terminal and ground terminal of the position sensor.
  7. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-537296-S07217680812013032200000) "

Scheme 231

Scheme 231: Removal
Scheme 231: Removal

Scheme 232

Scheme 232
Scheme 232
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the VCMA connector (A).
  3. Remove the VCMA (A) after removing 3 installation bolts.
