Engine Control System - 2.0L: Specifications Kia Soul I рестайлинг

Testing & Diagnostics 32 illustrations ~120 words

Specification

Throttle angle (°)Output voltage (V) [Vref = 5.0V]
TPS1TPS2
00.54.5
100.964.05
201.413.59
301.873.14
402.322.68
502.782.23
603.231.77
703.691.32
804.140.86
904.60.41
984.650.35
C.T (0)0.54.5
W.O.T (86)4.410.59

Scheme 158

Scheme 158
Scheme 158
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

Scheme 159

Scheme 159
Scheme 159

Scheme 160

Scheme 160: (M/T)
Scheme 160: (M/T)

Scheme 161

Scheme 161: (A/T)
Scheme 161: (A/T)
Temperature [°C(°F)]Resistance (kohms)
40(-40)40.93 ~ 48.35
20(-4)13.89 ~ 16.03
0(32)5.38 ~ 6.09
10(50)3.48 ~ 3.90
20(68)2.31 ~ 2.57
40(104)1.08 ~ 1.21
50(122)0.76 ~ 0.85
60(140)0.54 ~ 0.62
80(176)0.29 ~ 0.34

Scheme 162

Scheme 162: (M/T)
Scheme 162: (M/T)

Scheme 163

Scheme 163: (A/T)
Scheme 163: (A/T)
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

Scheme 164

Scheme 164: (M/T)
Scheme 164: (M/T)

Scheme 165

Scheme 165: (A/T)
Scheme 165: (A/T)
ItemSpecification
Coil Resistance(ohms)774 ~ 946 [20°C (68°F)]

Scheme 166

Scheme 166: Waveform
Scheme 166: Waveform

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168: (M/T)
Scheme 168: (M/T)

Scheme 169

Scheme 169: (A/T)
Scheme 169: (A/T)
ItemSpecification
Capacitance (pF)850 ~ 1, 150

Scheme 170

Scheme 170: (M/T)
Scheme 170: (M/T)

Scheme 171

Scheme 171: (A/T)
Scheme 171: (A/T)

Scheme 172

Scheme 172: Removal
Scheme 172: Removal

Scheme 173

Scheme 173
Scheme 173
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the knock sensor connector (A).
  3. Remove the intake manifold (Refer to «REMOVAL AND INSTALLATION»(/kia/soul/i-2011-2014/remont/exhaust/#intake-system-and-exhaust-system-20l) .
  4. Remove the installation bolt (A), and then remove the sensor from the cylinder block.
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.275 ~ 0.475
W.O.T3.85 ~ 4.351.75 ~ 2.35

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175: (M/T)
Scheme 175: (M/T)

Scheme 176

Scheme 176: (A/T)
Scheme 176: (A/T)
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178: (M/T)
Scheme 178: (M/T)

Scheme 179

Scheme 179: (A/T)
Scheme 179: (A/T)
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C(68°F)]

Scheme 180

Scheme 180: (M/T)
Scheme 180: (M/T)

Scheme 181

Scheme 181: (A/T)
Scheme 181: (A/T)
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 [20°C(68°F)]

Scheme 182

Scheme 182: (M/T)
Scheme 182: (M/T)

Scheme 183

Scheme 183: (A/T)
Scheme 183: (A/T)
ItemSpecification
Coil Resistance (ohms)9, 4 ~ 10, 4 [20°C(68°F)]

Scheme 184

Scheme 184: (M/T)
Scheme 184: (M/T)

Scheme 185

Scheme 185: (A/T)
Scheme 185: (A/T)
ItemSpecification
Coil resistance (ohms)30.0 ~ 35.0 [20°C(68°F)]

Scheme 186

Scheme 186: (M/T)
Scheme 186: (M/T)

Scheme 187

Scheme 187: (A/T)
Scheme 187: (A/T)
ItemSpecification
Coil Resistance (ohms)15.5 ~ 18.5 [20°C(68°F)]

Scheme 188

Scheme 188: (M/T)
Scheme 188: (M/T)

Scheme 189

Scheme 189: (A/T)
Scheme 189: (A/T)
