Specification

Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

Scheme 35

Scheme 35

Scheme 36

Scheme 36: Signal Waveform

Scheme 37

Scheme 37: (M/T)

Scheme 38

Scheme 38: (A/T)
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
501221.56 ~ 1.74
601400.54 ~ 0.62
801760.29 ~ 0.34

Scheme 39

Scheme 39: (M/T)

Scheme 40

Scheme 40: (A/T)
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

Scheme 41

Scheme 41: (M/T)

Scheme 42

Scheme 42: (A/T)
ItemSpecification
Coil Resistance (ohms)774 ~ 946 [20°C (68°F)]

Scheme 43

Scheme 43: Waveform

Scheme 44

Scheme 44

This example shows a typical Crankshaft Position Sensor (CKPS) and Camshaft Position Sensor (CMPS) waveform at idle. The PCM controls the injection and ignition timing by using these signals.

Generally CkPS signal is used to detect the piston's position and CMPS signal is used to detect the Top Dead Center of each cylinder.

Scheme 45

Scheme 45: (M/T)

Scheme 46

Scheme 46: (A/T)
ItemSpecification
Capacitance (pF)950 ~ 1,350
Resistance (Mohms)4.87

Scheme 47

Scheme 47: (M/T)

Scheme 48

Scheme 48: (A/T)

Scheme 49

Scheme 49: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the intake manifold (Refer to «INTAKE MANIFOLD»(/kia/soul/i-2011-2014/remont/exhaust/#intake-system-and-exhaust-system-16l) .
  3. Disconnect the injector connector (A).
  4. Remove the installation bolt (B), and then remove the sensor from the cylinder block.
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.275 ~ 0.475
W.O.T3.8 ~ 4.41.75 ~ 2.35

Scheme 50

Scheme 50

Scheme 51

Scheme 51: (M/T)

Scheme 52

Scheme 52: (A/T)
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

Scheme 53

Scheme 53

Scheme 54

Scheme 54: (M/T)

Scheme 55

Scheme 55: (A/T)
ItemSpecification
Coil Resistance (ohms)1.5 [20°C(68°F)]

Scheme 56

Scheme 56: Signal Waveform

Scheme 57

Scheme 57: (M/T)

Scheme 58

Scheme 58: (A/T)
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 [20°C(68°F)]

Scheme 59

Scheme 59: (M/T)

Scheme 60

Scheme 60: (A/T)
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C(68°F)]

Scheme 61

Scheme 61: (M/T)

Scheme 62

Scheme 62: (A/T)
ItemSpecification
Coil resistance (ohms)30.0 ~ 35.0 [20°C(68°F)]

Scheme 63

Scheme 63: (M/T)

Scheme 64

Scheme 64: (A/T)
ItemSpecification
Coil Resistance (ohms)0.5 [20°C(68°F)

Scheme 65

Scheme 65: Signal Waveform

Scheme 66

Scheme 66: (M/T)

Scheme 67

Scheme 67: (A/T)
ItemSpecification
Coil Resistance (ohms)15.5 ~ 18.5 [20°C(68°F)

Scheme 68

Scheme 68: (M/T)

Scheme 69

Scheme 69: (A/T)
