Automatic Transaxle Control System: Removal & Installation Kia Sedona II рестайлинг

Installation

1. Installation is the reverse of removal. CAUTION: Set room side lever and T/M side lever to "N" position.

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Remove the shift lever knob (A) by removing the two screws.
2. Disconnect the solenoid connector (A) and remove the indicator panel (B).
3. Remove the switch assembly (A) and 'P' position switch assembly.
4. Remove the solenoid (B) and solenoid lever (A).
5. Remove the lever assembly (B) by the mounting bolt (A).
6. Remove the lever (A) and tube (B) by removing the bolt (C).

Replacement

Note. In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure. Refer to TEACHING PROCEDURES .

Scheme 53

Scheme 54

1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
2. Disconnect the TCM Connector (A).
3. Remove the air cleaner assembly. Refer to «INTAKE AND EXHAUST SYSTEM»(ref-584173) .
4. After removing the installation bolts (A) and nut (B), remove the TCM (C). TCM installation bolt/nut: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
5. Installation is reverse of removal.

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-584179) .

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-584179) .

1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-584179) .

1. Installation is the reverse of removal.
