- Remove the console upper cover. Refer to «CONSOLE»(ref-584184-S35696267862013110100000) .
- Remove the front console assembly. Refer to «CONSOLE»(ref-584184-S35696267862013110100000) .
- Disconnect sports mode connector (A).
- Remove the shift lever assembly mounting nuts (A). Tightening torque: 18.6 ~ 27.5 N.m (1.9 ~ 2.8 kgf.m, 13.7 ~ 20.3 lb-ft)
- Remove the shift cable mounting nut (A) and cap (B). Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
Description
- Integrated one unit for input & output speed sensor
- Differential current type (low: 7mA, high: 14mA)
- Fail-safe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
- Integrated one unit for input & output speed sensor
- Differential current type (low: 7mA, high: 14mA)
- Fail-safe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
| Item | Specification |
|---|---|
| Type | Combination of output signals from 4 terminals |
| Power supply | 12V |
| Range detection | 7-position (P, R, N, D, X, Y, Z) |
| Fail-safe | 1st, 2nd gear is prohibited. |
INHIBITOR SWITCH SPECIFICATION
Scheme 44
Scheme 45
Scheme 46
- Set room side lever and T/M side lever to "N" position.
- Remove the battery and the battery tray. Refer to «BATTERY»(ref-584190-S28990788252013110100000) .
- Remove the air cleaner assembly. Refer to «INTAKE MANIFOLD»(ref-584173-S29685122042013110100000) .
- Remove the shift cable mounting nut (B). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
- Disconnect the inhibitor switch connector (A).
- Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, fix the manual control lever and the inhibitor switch with Ø5 mm (0.1969 in.) fixing jig. And then tighten the inhibitor assembly mounting bolts.
- Remove the inhibitor assembly (A) after removing the bolts (2 ea.). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly.
