Automatic Transaxle Control System: Specifications Kia Sedona II рестайлинг

Automatic Trans 16 illustrations ~684 words

Specification

ItemSpecification
TypeHall Effect Sensor, 2 pins (Power: 9V, Signal)
Operation condition40 ~150 (°C) (-40 ~ 302 (°F))
Sensor length43.2~ 43.4 mm (1.7008 ~ 1.7087 in.)
Air gap0.95 ~ 1.55 mm (0.0374 ~ 0.0610 in.)

ITEM SPECIFICATION

Scheme 24

Scheme 24: Removal

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-584190-S28990788252013110100000) .
  2. Remove the under cover (A). Under cover installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-584179) .
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: Use new gasket on the eyebolt. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3 ea.) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the connector (A) from the main wiring.
  9. Remove the input & output speed sensor (B) after removing the bolts (2 ea.) Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeHall Effect Sensor, 2 pins (Power: 9V, Signal)
Operation condition40 ~150 (°C) (-40 ~ 302 (°F))
Sensor length30.7 ~ 30.9 mm (1.2087 ~ 1.2165 in.)
Air gap1 ~ 0.55 mm (0.0394 ~ 0.0217 in.)

ITEM SPECIFICATION

Scheme 30

Scheme 30: Removal

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-584190-S28990788252013110100000) .
  2. Remove the under cover (A). Under cover installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-584179) .
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: Use new gasket on the eyebolt. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3 ea.) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the connector (A) from the main wiring.
  9. Remove the input & output speed sensor (B) after removing the bolts (2 ea.) Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeNegative Thermal Coefficient Type
Operation temperature40 ~ 165°C (-40 ~ 329°F)
Resistance4.68kohms ~ 43 ohms
Fail-safeOil temperature set to default value (80°C (176°F))

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATION

Scheme 36

Scheme 36: Removal

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-584190-S28990788252013110100000) .
  2. Remove the under cover (A). Under cover installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-584179) .
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: Use new gasket on the eyebolt. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Disconnect the oil temperature sensor connector (A).
  6. Remove the oil temperature sensor (A) after removing a bolt. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
