Automatic Transaxle Control System - A5CF2: Diagnosis Kia Forte I

Inspection

1. Check the shift cable for proper operation and for damage.
2. Check the boots for damage.
3. Check the boots for wear, abrasion, sticking, restricted movement or damage.
4. Check for the weak or damaged spring.

Scheme 211

1. Set the room side lever and the manual lever (A) to "N" position.
2. Push the shift cable (B) lightly to "F" direction ( (Scheme 211)) to eliminate the free play.
3. Tighten the adjusting nut (C). Tightening torque: 10~14Nm (1.0~1.4kgf.m, 7.2~10.1lb-ft)
4. Check that this part operates surely at each range of the manual lever corresponding to each position of the room lever.

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

1. After placing the manual lever in N position, install the shift cable to the transaxle. (refer to «AUTOMATIC TRANSAXLE SYSTEM - A5CF2»(ref-362226) )
2. Install the retainer (A) and nuts (B). Tightening torque: 12~15Nm (1.2~1.5kgf.m, 8.7~10.8lb-ft) NOTE: In case, install the crash pad and cowl cross bar. (For Coupe, refer to «CRASH PAD»(ref-362224-S30236245892010060400000) and «COWL CROSS BAR»(ref-362224-S19093883002010060400000) . For Sedan, refer to «CRASH PAD»(ref-362245-S13817783762010060400000) and «COWL CROSS BAR»(ref-362245-S25505231752010060400000) .)
3. Install the shift lever assembly (A). Tightening torque: 9~14Nm (0.9~1.4kgf.m, 6.5~10.1lb-ft)
4. Connect the interlock switch connector (A).
5. Install the shift cable assembly (B) by installing the clamp (A).
6. Install the center console. (For Coupe, refer to «CONSOLE»(ref-362224-S29666035482010060400000) . For Sedan, refer to «CONSOLE»(ref-362245-S31568523972010060400000) .)
7. Install the shift lever knob (A).
