TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Balance Shaft Module | 29 + 90° | 22 + 90° | |
| Bell Housing | 48 | 35 | |
| Camshaft Sprocket-Bolt | 60 | 44 | |
| Camshaft Bearing Cap-Bolts | |||
| M6 Bolts | 9.5 | 85 | |
| M8 Bolts | 25 | 18 | 220 |
| Connecting Rod Cap-Bolts | 20 +90° | 15 +90° | |
| Coolant temperature Sender | 8 | 71 | |
| Crankshaft Main Bearing Cap-Bolts | 27 + 45° | 20 + 45° | |
| Crankshaft Damper-Bolt | 210 | 155 | |
| Cylinder Head-Bolts | Refer to STANDARD PROCEDURE | ||
| Cylinder Head Cover-Bolts | 10 | 90 | |
| Engine Support Bracket-Bolts | 40 | 30 | |
| Exhaust Manifold-Bolts | 34 | 25 | |
| Exhaust Manifold Heat Shield-Bolts | 9 | 80 | |
| Flex Plate to Crankshaft-Bolts | 95 | 70 | |
| Intake Manifold | 24 | 18 | |
| Ladder Frame | 26 | 19 | |
| Oil Cooler Connector Bolt | 49 | 36 | |
| Oil Filter | 14 | 10 | |
| Oil Filter Nipple | 49 | 36 | |
| Oil Jet Fastener | 12 | 105 | |
| Oil Pan-Bolts | |||
| M6 Bolts | 12 N.m | 105 | |
| M8 Bolts | 24 N.m | 18 | 0 |
| Oil Pan Drain-Plug | 40 | 30 | |
| Oil Pressure Switch | 8 | 71 | |
| PCV Valve | 5 | 40 | |
| Spark Plugs | 27 | 20 | 239 |
| Timing Chain Cover | |||
| M6 Bolts | 9 N.m | 80 | |
| M8 Bolts | 26 N.m | 230 | |
| Timing Chain Tensioner Assembly-Bolts | 12 N.m | 105 | |
| Timing Chain Guides | 12 N.m | 105 | |
Scheme 342
Scheme 343
Scheme 344
Scheme 345
Scheme 346
Scheme 347
Scheme 348
Scheme 349
Scheme 350
Scheme 351
Scheme 352
Scheme 353
Scheme 354
Scheme 355
The engine serial number (1) is located between the oil pan and the bellhousing. The serial number contains engine build date, build location, and displacement.
Example: 8CAP1339710217
| WORLD ENGINE | |||||||
|---|---|---|---|---|---|---|---|
| 8 | C | A | P1 | 339 | 7 | 1 | 0217 |
| Model Year | Engine Displacement | Engine Build Variation (with oil cooler, turbo, for MMNA) | Engine Plant | Julian Day of Year | Julian Year 2007 | Shift | Build Sequence Number |
| 2008 | A = 1.8L | P1 = GEMA North | |||||
| B = 2.0L | P2 = GEMA South | ||||||
| C = 2.4L | |||||||
Scheme 356
Scheme 357
Scheme 358
- Turn lock retainers (5) and remove fresh air inlet (2) from air cleaner housing (1).
- Disconnect intake air temperature sensor connector (4).
- Remove air inlet tube (5) from air cleaner housing (1).
- Unfasten clasps (2) on sides of air cleaner housing cover.
- Pull air cleaner cover (1) aside.
- Remove filter element (3).
- If necessary, clean the inside of the air cleaner housing (2).
Scheme 359
Scheme 360
Scheme 361
- Install new filter element.
- Place cover over air cleaner housing. Snap clasps (2) in place.
- Install air inlet tube (5).
- Connect intake air temperature sensor connector (4).
- Install fresh air inlet (2) on air cleaner housing (1) and lock retainers (5).
Scheme 362
Scheme 363
- Remove fresh air inlet (2) from air cleaner housing (1).
- Remove intake air temperature sensor electrical connector (4).
- Remove air inlet tube (5) from housing (1).
- Pull housing (1) upward to remove.
Scheme 364
Scheme 365
- Make sure the rubber grommets, for the air cleaner housing lower pins, are in place when reinstalling the air cleaner housing. The rubber grommets mount to the PDC bracket.
- Push air cleaner housing (1) down while aligning pins into the grommets.
- Connect the throttle body air inlet hose (5) to the air cleaner housing (1).
- Connect intake air temperature sensor connector (4).
- Install fresh air inlet (2) and lock retainers (5).
OIL FILTER SPECIFICATION
All engines are equipped with a high quality full-flow, disposable type oil filter. Replace oil filter with a Mopar® or the equivalent.
