2.4L Engine - Service Information: Removal & Installation Jeep Compass I

Mechanical 7 illustrations ~150 words

REMOVAL

WARNINGRelease fuel system pressure before servicing system components. Service vehicles in well ventilated areas and avoid ignition sources. Never smoke while servicing the vehicle.

Scheme 391

Scheme 391
Scheme 391

Scheme 392

Scheme 392
Scheme 392

Scheme 393

Scheme 393
Scheme 393

Scheme 394

Scheme 394
Scheme 394

Scheme 395

Scheme 395
Scheme 395

Scheme 396

Scheme 396
Scheme 396

Scheme 397

Scheme 397
Scheme 397
  1. Remove engine cover (1).
  2. Perform fuel system pressure release procedure before attempting any repairs. Refer to «STANDARD PROCEDURE»(ref-304342-S34730499872008110700000) .
  3. Remove air cleaner inlet (2).
  4. Remove air cleaner housing (1).
  5. Disconnect negative cable at battery (3).
  6. Disconnect fuel line at rail (3).
  7. Remove fuel injector electrical connectors (4).
  8. Remove fuel rail retaining bolts and remove fuel rail.
  9. Disconnect oil temperature sensor (1).
  10. Disconnect variable valve timing solenoid electrical connector.
  11. Disconnect intake camshaft position sensor electrical connector.
  12. Position harness out of the way.
  13. Remove throttle body support bracket (1).
  14. Disconnect electronic throttle control electrical connector.
  15. Remove wiring harness retainer from the intake manifold (2).
  16. Disconnect MAP sensor electrical connector.
  17. Disconnect vacuum lines at intake.
  18. Remove upper radiator hose retaining bracket (1).
  19. Remove intake manifold retaining bolts.
  20. Remove intake manifold.
