2.0L Engine - Service Information: Removal & Installation Jeep Compass I

Mechanical 6 illustrations ~148 words

REMOVAL

WARNINGRelease fuel system pressure before servicing system components. Service vehicles in well ventilated areas and avoid ignition sources. Never smoke while servicing the vehicle.

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54
  1. Remove engine cover (1).
  2. Perform fuel system pressure release procedure before attempting any repairs. Refer to «STANDARD PROCEDURE»(ref-304342-S34730499872008110700000) .
  3. Remove clean air hose (5).
  4. Remove air cleaner housing (1).
  5. Disconnect negative cable at battery (3).
  6. Disconnect fuel line at rail (3).
  7. Remove fuel injector electrical connectors (4).
  8. Remove fuel rail retaining bolts and remove fuel rail.
  9. Disconnect oil temperature sensor (1).
  10. Disconnect variable valve timing solenoid electrical connector.
  11. Disconnect intake camshaft position sensor electrical connector.
  12. Position harness out of the way.
  13. Remove throttle body support bracket (1).
  14. Disconnect electronic throttle control electrical connector.
  15. Remove wiring harness retainer from the intake manifold (2).
  16. Disconnect MAP sensor electrical connector.
  17. Disconnect vacuum lines at intake.
  18. Remove upper radiator hose retaining bracket (1).
  19. Remove intake manifold retaining bolts.
  20. Remove intake manifold.
