Specifications
| Item | Specification |
|---|
| Compressor | Clutchless, belt driven from engine with electronically controlled outputs |
| Make | Denso |
| Type | 7SEU17 |
| Specifications |
|---|
| Refrigerant | R134A |
| Compressor oil | JLM 12260 |
Lubricants, Fluids, Sealers and Adhesives
| Item | Specification |
|---|
| Refrigerant charge weight | 700g ± 25g |
| Compressor oil capacity | 130 ml |
| Item | Nm |
|---|
| Compressor to mounting bracket - bolt | 25 |
| Compressor mounting bracket to engine - bolt | 25 |
| Condenser core to bracket - bolt | 10 |
| Pressure cutoff switch to refrigerant pipe | 10 |
| Refrigerant pipes to compressor - bolt | 9 |
| Refrigerant pipes to condenser - nut | 10 |
| Thermostatic expansion valve to evaporator - bolt | 6 |
Scheme 1
Scheme 1: COMPONENT LOCATION
| Item Number | Description |
|---|
| 1 | Evaporator |
| 2 | Thermostatic expansion valve |
| 3 | High pressure line |
| 4 | Low pressure line |
| 5 | Air Conditioning (A/C) compressor |
| 6 | Receiver/Drier |
| 7 | Condenser |
| 8 | Refrigerant pressure sensor |
| 9 | High pressure servicing connection |
| 10 | Low pressure servicing connection |
